Audio-Technica ENGINEERED SOUND AT915QMRX/C User Manual

Audio-technica microphone user manual.
AT91 5QMRx/C
Cardioid
Description
While a modern condenser microphone is
not unduly sensitive to the environment, tempera-
The AT915QMRx/C is a wide-range
ture extremes can be harmful. Exposure to high
condenser microphone with a cardioid polar
Miniature
pattern. It is designed for quality sound reinforce-
temperature can result in gradual and permanent
reduction of the output level. Avoid leaving the
ment, professional recording, television, and
Condenser
other demanding sound pickup applications. The
microphone in the open sun or in areas where
temperatures exceed 110 F (43 C) for long
small-diameter alternating gooseneck design
Adjustable-
periods of time. Extremely high humidity should
permits highly flexible positioning while maintain-
ing a smooth, well-contoured appearance. Its
also be avoided.
length
adjustable-length design allows for the ultimate
Gooseneck
in positioning flexibility.
Architects and Engineers Specifications
The microphone features an XLRM-type
Quick-mount
connector insert at its base, allowing it to be
The microphone shall be a fixed-charge
plugged directly into an XLRF-type panel jack or
condenser with a cardioid polar pattern and a
Microphone
microphone cable. The integral power module
frequency response of 40 Hz to 20,000 Hz. It shall
can be powered from any external 9V to 52V DC
be capable of accepting optional interchangeable
phantom power supply. A recessed switch in the
elements for additional polar patterns. It shall
power module permits choice of flat response or
operate from an external 9V to 52V DC phantom
low-frequency roll-off to help control undesired
power source. Nominal open-circuit output voltage
ambient noise.
shall be 7.0 mV at 1 kHz, 1 Pascal. Output shall
Four additional interchangeable elements
be low impedance balanced (200 ohms).
are available to permit selection of angle of
The microphone shall have a self-contained
acceptance from 90 to 360 .
power module with an XLRM-type connector insert
Audio-Technica design engineers have utilized
at the base for direct connection to a mating
the newest low-mass diaphragm technology in the
XLRF-type panel jack or cable connector. The power
quest for superior performance. The permanent
module shall include a switch for low-frequency
charge is now on the fixed back plate, rather than
roll-off. A locking ring/isolator shall be supplied.
the moving element. With A-T fixed-charge "back
The microphone shall be a small-diameter
plate" construction, a gold-vaporized diaphragm
alternating gooseneck design, with an overall
just 2 microns thick (about .000079") can be used.
length adjustable from 15.83" (402.0 mm) to 18.39"
This considerably reduces moving mass, thus
(467.0 mm). Head diameter shall be 0.48" (12.2 mm).
improving frequency response and transient
The microphone weight shall be 4.2 oz (120 grams).
response while reducing distortion.
Finish shall be low-reflectance black.
The microphone is enclosed in a rugged
The Audio-Technica AT915QMRx /C is
housing with a low-reflectance black finish.
specified.
Installation and Operation
Frequency Response (Typical)
Output is low impedance balanced. The output
connector mates with XLRF-type cable connectors.
The balanced signal appears across Pins 2 and
3, while the ground (shield) connection is Pin 1.
10 dB
Output is phased so that positive acoustic pressure
produces positive voltage at Pin 2, in accordance
with industry convention.
50
100
200
500
1k
2k
5k
10k
20k
The microphone can be secured to a podium
Frequency in Hertz
or desktop with the included locking ring /isolator.
12" or more on axis (flat)
LEGEND
Rubber-insulated feet attenuate noise, shock and
Roll-off
vibration transmitted through the mounting surface.
A nylon compression bushing utilizes two set
screws to hold the microphone securely in place.
A template is provided on the back of this sheet
to aid in installation of the locking ring/isolator.
The provided foam windscreen simply slips
over the head of the microphone, effectively
reducing wind noise or "popping" when used
extra close.
The small-diameter gooseneck is easy to
manipulate for proper positioning. Heavily lubri-
cated, it operates smoothly and quietly. Should
the unit become noisy with prolonged use, apply
a light machine oil directly on the gooseneck area
affected.
