OWI 701 Specifications

701i/202
4" 2-WAY
70 VOLTS & 8 OHMS
OWI Incorporated
®
17141 Kingsview Avenue, Carson, CA 90746 USA
Tel: 310.515.1900
Toll Free: 800.638.1694
Fax: 310.515.1606
Web: www.owi-inc.com
E-mail: info@owi-inc.com
GENERAL SPECIFICATIONS
MODEL NUMBER:
DESCRIPTION:
ENCLOSURE:
OUTDOOR RATED:
SELECTABLE SWITCH
70V TRANSFORMER TAP:
SENSITIVITY (1W/1M):
POWER HANDLING:
FREQUENCY RESPONSE:
CROSSOVER:
DISPERSION:
WOOFER SIZE:
WOOFER MATERIAL:
TWEETER(S):
TWEETER SIZE:
TWEETER MATERIAL:
GRILL MATERIAL:
DIMENSIONS :
(HxWxD)
WEIGHT:
"U" MOUNT BRACKET:
COLOR(S):
ARCHITECTS AND ENGINEERS
SPECIFICATIONS / TECHNICAL DATA
701i / 202
4" 2-Way
Aluminum Diecast
Yes
70Volts & 8 Ohms Combination
2.5, 5, 10, 15 Watts
88 dB
80 Watts Max.
40 Watts Nom.
90 Hz - 20 kHz
6 kHz
140°
4"
Paper Coated/Rubber Surround
1 ea.
.5" (13mm) Dome
PEI
Aluminum
7" x 4.5" x 4"
5.2 lbs.
Included
Black or White
