OPERATOR'S HANDBOOK
Utility Vehicle Model Brutus HD and HD
• Never use the vehicle without instructions. Read vehicle labels (decals),
Owner's Manual and this Handbook.
• Always fasten seat belt before operating or riding in the vehicle.
• Keep hands and feet inside the vehicle.
• Polaris recommends using proper protective equipment such as helmets
and eyewear when required.
• Never use vehicle without Occupant Protective Structure (OPS).
• Do not modify or remove OPS. Replace OPS if damaged.
• Keep away from drop-offs, steep slopes and unstable surfaces.
• Always carry bucket or attachment as low as possible. Slow down when
turning. Do not make sharp turns. Look in the direction of travel. Never
attempt jumps or other stunts with the vehicle.
• Load, unload and turn on flat, level ground. Keep load level when raising lift
arm.
• Travel at appropriate vehicle speeds for the type of terrain, visibility,
operating conditions and your operating experience.
• Carry a rider only in a passenger seat.
• Keep bystanders away from the work area.
• Secure load in cargo box.
• Do not exceed vehicle load capacities.
• No riders in cargo box.
• Never modify the vehicle or add non-approved attachments.
• Keep PTO shields and all guards in place (if equipped). Keep away from
moving parts.
• Before leaving the operator seat:
Park on flat level ground.
Lower attachment arm.
Put attachment flat on ground.
Move gear selector lever to Park.
Disengage the PTO (if equipped) and make sure all rotating components
are completely stopped.
Stop the engine and remove the key.
9925252
This Handbook is for the
WARNING
AVOID INJURY OR DEATH
1
PTO

Advertisement

loading

Summary of Contents for Polaris BRUTUS HD

  • Page 1 • Always fasten seat belt before operating or riding in the vehicle. • Keep hands and feet inside the vehicle. • Polaris recommends using proper protective equipment such as helmets and eyewear when required. • Never use vehicle without Occupant Protective Structure (OPS).
  • Page 2 Learn about the Utility Vehicle from this Handbook, Owner’s Manual and safety labels (decals). See Owner’s Manual for full detailed illustrations. Replace damaged or missing labels (decals) as shown in the Owner’s Manual. Ask the dealer about equipment for each application. Refer to the Owner’s Manual and dealer regarding attachments for Vehicle Load Capacity.
  • Page 3 INSTRUMENT PANEL AND OPERATOR CONTROLS 13 14 NA5901B REF. FUNCTION REF. FUNCTION Instrument Panel (See Page 4) 11. Cup Holder (3) Key Switch 12. Fan Speed Switch (Optional) Gear Selector Lever 13. AC / Defrost Switch (Optional) A. - Move up for Low Gear 14.
  • Page 4 INSTRUMENT PANEL AND OPERATOR CONTROLS (CONT’D) P-97832A REF. FUNCTION REF. FUNCTION Speedometer (KM/H or MPH) Hourmeter, Trip Meter, Odometer, Tachometer, Battery Voltage, Engine Coolant Temperature Indicator Engine Coolant Temperature, (Red Light) Service Interval, Check Engine Hydraulic Fluid Temperature Indicator Not used for this model (Red Light) Not used for this model (Orange Light) Drive Mode Indicator...
  • Page 5 INSTRUMENT PANEL AND OPERATOR CONTROLS (CONT’D) Hydraulic Controls Raise attachment arm. Lower attachment arm. Float position: - Joystick pushed fully forward (Item 3) - Attachment will follow ground as vehicle moves backward. - Move joystick backward (Item 2) to deactivate float. Tilt attachment forward.
  • Page 6: Daily Inspection

    DAILY INSPECTION WARNING Use the Occupant Protective Structure (OPS), which was designed for the Utility Vehicle. Non-approved OPS structure modifications can cause loss of operator protection and result in serious injury or death. Always fasten seat belt when operating. • Check seat belts and replace if damaged. •...
  • Page 7 STARTING AND DRIVING THE UTILITY VEHICLE HIGH START NEUTRAL NA5286 PARK NA5178 NA5285 Be sure load (if any) is secured. Turn the key to ON position and wait for the glow plug light to turn Connect the seat belt. Adjust so OFF, turn the key to START that the belt fits snug around the position (for improved cold...
  • Page 8: Leaving The Vehicle

    LEAVING THE VEHICLE NA5901 NA5920 Lower the attachment arm and Move the gear selector lever to put the attachment flat on the Park. Disengage the PTO ground. system (if equipped). Stop the engine and remove the key. WARNING Always park vehicle on flat level ground.
  • Page 9 AUXILIARY HYDRAULIC CONTROL Auxiliary Operation: Press switch (Item 1) to the left to activate the female coupler. Press switch (Item 1) to the right to activate the male coupler. Relieving Hydraulic Pressure: With engine stopped (key switch ON) and attachment flat on ground, move auxiliary hydraulic switch (Item 1) to the right and NA5909...
  • Page 10 WARNING • Do Not exceed maximum Cargo Box Load. • Do Not drive vehicle with Cargo Box raised. • Make sure loads in Cargo Box are secured. • Slow down when turning. Do Not make sharp turns. RAISING AND LOWERING THE CARGO BOX Cargo Box - With Lift Assist: Ensure cargo is positioned evenly and toward the front of...
  • Page 11 DRIVING UP AND DOWN SLOPES WARNING AVOID INJURY OR DEATH • Keep heavy end of vehicle uphill. • Do not drive across slopes. • Go directly up or down a slope. • Look in the direction of travel. With Loaded Attachment AND Cargo Box Empty Going Down Slopes Going Up Slopes NA5270...
  • Page 12: Loading And Transporting The Vehicle

    DRIVING UP AND DOWN SLOPES (CONT’D) WARNING • Do Not make sharp turns. • Do Not exceed Vehicle Load Capacity. • Keep bystanders away. • Do not leave vehicle with engine running, attachment arm up or gear selector not in PARK. LOADING AND TRANSPORTING THE VEHICLE When loading a vehicle with an attachment, drive forward onto transport vehicle.
  • Page 13 9925252...
  • Page 14 Póngase en contacto con su distribuidor para obtener más información o para solicitar versiones traducidas. Ce livret est disponible en anglais et dans de nombreuses autres langues. Veuillez consulter votre concessionnaire pour plus d'informations sur les versions traduites. Printed in U.S.A. © 2013 Polaris Sales Inc. 9925252...
