Page 2
Before you begin the wireless setup process, please choose the installation method. 1) To setup your printer using drivers from the web continue to page 2 To setup your printer using the included User Software CD continue to page 32 Wireless Setup Manual Page 1 ...
Page 3
To download the Color imageCLASS LBP7110Cw driver and Network Setup Tool Before the wireless setup can begin the LBP7110Cw Driver/Network Setup Tool must be downloaded, follow the steps below to download the Driver/Network Setup Tool from the Canon USA website. 1) To download the imageCLASS LBP7110Cw printer driver, go to usa.canon.com/support. 2) Select the [Consumer & Home Office] tab, and then select [Service & Support]. Wireless Setup Manual Page 2 ...
Page 4
3) Enter LBP7110 into the search box, and then select it from the list that appears. 4) Click [GO]. Wireless Setup Manual Page 3 ...
Page 5
5) Click [Drivers & Software], and then select [Drivers]. If your operating system is not automatically detected, select the operating system you are using from the Operating System drop‐down list. Wireless Setup Manual Page 4 ...
Page 6
6) Select the most recent driver, according to date and then click [I Agree – Begin Download]. 7) Save the driver to your desktop so you can easily access the driver. Wireless Setup Manual Page 5 ...
Page 7
To install the Color imageCLASS LBP7110Cw driver and setup your LBP7110Cw Wirelessly To setup the LBP7110Cw wirelessly, you must install the printer driver first. 1) Double‐click the newly downloaded LBP7110Cw Driver on your desktop. 2) Open the LBP7110Cw Driver folder. Wireless Setup Manual Page 6 ...
Page 9
4) When the Print Driver Setup Wizard launches, click [Next]. 5) Click [Yes to accept the terms of the License Agreement. Wireless Setup Manual Page 8 ...
Page 10
6) Select the [Install with USB Connection] radio button, and then click [Next]. 7) Click [Yes]. Wireless Setup Manual Page 9 ...
Page 11
8) When the screen below appears, make sure that the printer is ON and the USB cable is connected to the computer and printer. 9) If you see this message, follow the on screen instructions, then click [Retry]. *If the message reappears, try a different USB port on the computer. Wireless Setup Manual Page 10 ...
Page 12
10) When the message below appears, the driver installation is complete. Click [Exit]. Wireless Setup Manual Page 11 ...
Page 13
Follow the procedure below to set up your printer wirelessly. 1) Double‐click the LBP7110Cw Driver on your desktop. 2) Open the [Network_Setting_Tool] folder. 3) Depending on your OS you will either see a 32‐bit or 64‐bit folder. Open the appropriate folder for your operating system, and then double‐click the [Canon MF/LBP Network Setup Tool] icon. 4) If the User Account Control dialog box appears, click [YES] or [CONTINUE]. Wireless Setup Manual Page 12 ...
Page 14
5) Select the [Wireless LAN Connection] radio button, and then click [NEXT]. 6) Select the [Yes, I want to configure network settings] radio button, and then click [Next]. Wireless Setup Manual Page 13 ...
Page 15
7) Select the [Easy Setup] radio button, and then click [Next]. Wireless Setup Manual Page 14 ...
Page 16
8) Check to see if your wireless router has a WPS button, and select the appropriate radio button, as shown in the screen below. If you are not sure which connection method to use, click [Useful Tips] first or select My wireless LAN access point does not have a WPS button or I cannot find the button. Wireless Setup Manual Page 15 ...
Page 17
WPS Router Instructions 1) If your router has a WPS button, select [My wireless LAN access point has a WPS button], and then click [Next]. If your router does not have a WPS button, follow the instructions on “Non‐WPS Supporting Router Instructions,” on p. 19. Wireless Setup Manual Page 16 ...
Page 18
2) Follow the instructions on the screen, as shown below, and then click [Next]. Wireless Setup Manual Page 17 ...
Page 19
3) When the Wi‐Fi indicator turns solid blue, the printer is connected wirelessly. Click [Next]. 4) Click [Exit]. 5) To complete the wireless setup process, proceed to “Completing the Wireless Set Up,” on p. 24. Wireless Setup Manual Page 18 ...
Page 20
Non‐WPS Supporting Router 1) If your router does not have a WPS button, select [My wireless LAN access point does not have a WPS button or I cannot find the button], and then click [Next]. Wireless Setup Manual Page 19 ...
Page 21
2) Follow the instructions on the screen, as shown below, and then click [Next]. The screen below appears while searching for your wireless network. Wireless Setup Manual Page 20 ...
Page 22
If the message shown below appears, read the message, and then click [OK]. Make sure that the USB cable is connected to your computer and to the LBP7110Cw, and make sure that the printer is turned ON. Click [Next]. 3) When a list of wireless networks appears, select your wireless network, and then click [Next]. 4) If your computer is already connected to the same wireless network as the printer, you do not have to enter your network key. If your computer is not connected to the same wireless network as the printer, enter the Network Key in the blank field, and then click [Next]. Wireless Setup Manual Page 21 ...
Page 23
While the screen below appears, the Wi‐Fi indicator on your printer blinks blue. When the printer is connected to the network, the Wi‐Fi indicator turns solid blue. 5) Disconnect the USB cable from your printer, and then click [Next]. Wireless Setup Manual Page 22 ...
Page 24
6) Click [Exit] to exit the Network Setup Tool. Wireless Setup Manual Page 23 ...
Page 25
Completing the Wireless Set Up 1) Re‐open the LBP7110Cw Driver folder on your desktop. 2) Open the Driver folder. Wireless Setup Manual Page 24 ...
Page 26
3) Double‐click the [Setup] icon. 4) When the print driver Setup Wizard launches, click [Next]. Wireless Setup Manual Page 25 ...
Page 27
5) Click [YES] to accept the terms of the License Agreement. 6) Select the [Search for Network Printers to Install] radio button, and then click [Next]. Wireless Setup Manual Page 26 ...
Page 28
7) Make sure that [Add Printers] is selected, and click [Next]. Your computer searches for the LBP7110Cw printer. Wireless Setup Manual Page 27 ...
Page 29
8) Select the LBP7110Cw printer from the Printer List, and then click [Add]. Wireless Setup Manual Page 28 ...
Page 30
9) Once the printer appears in the Printer List for Driver Installation, click [Next]. Wireless Setup Manual Page 29 ...
Page 31
10) Click [Start] to install the driver. 11) Click [Yes] to continue. Wireless Setup Manual Page 30 ...
Page 32
12) Please wait until the driver installs. 13) Select [Restart My Computer Now], and then click [Restart]. If you need further assistance in setting up your printer, please contact us at 1‐800‐OK CANON (800‐652‐2666). Wireless Setup Manual Page 31 ...
Page 33
To install the Color imageCLASS LBP7110Cw driver with the included User Software CD First, you must choose your installation method: WPS ROUTER, If your router has a button that looks like this: Continue to page 33 (Preferred Method) Non‐WPS Router Wireless Setup Manual Page 32 ...
Page 34
WPS Router Instructions 1) Insert User Software CD that was included in the box. 2) Click Easy Installation. 3) You will see the below screen, click Start Wireless Setup Manual Page 33 ...
Page 35
4) Click [Yes to accept the terms of the License Agreement. 5) Select the [Wireless LAN Connection] radio button, and then click [NEXT]. Wireless Setup Manual Page 34 ...
Page 36
6) Select the [Yes, I want to configure network settings] radio button, and then click [Next]. 7) Select the [Easy Setup] radio button, and then click [Next]. Wireless Setup Manual Page 35 ...
Page 37
8) Select [My wireless LAN access point has a WPS button], and then click [Next]. If your router does not have a WPS button, follow the instructions on “Non‐WPS Supporting Router Instructions” on page 46. Wireless Setup Manual Page 36 ...
Page 38
9) Follow the instructions on the screen, as shown below, and then click [Next]. 10) When the Wi‐Fi indicator turns solid blue, the printer is connected wirelessly. Click [Next]. Wireless Setup Manual Page 37 ...
Page 39
11) Click [Next] to begin wireless driver installation. 12) When the Print Driver Setup Wizard launches, click [Next]. Wireless Setup Manual Page 38 ...
Page 40
13) Select the [Search for Network Printers to Install] radio button, and then click [Next]. Your computer searches for the LBP7110Cw printer. Wireless Setup Manual Page 39 ...
Page 41
14) Select the LBP7110Cw printer from the Printer List, and then click [Add]. If you do not see the printer in the Printer List, be sure your computer is connected to the same wireless router as the printer. To verify which access point the printer is connected to, press the “Go” button on the printer for 5 seconds to print out the User Data List. Once they are connected to the same wireless router, click [Search Again]. Wireless Setup Manual Page 40 ...
Page 42
15) Once the printer appears in the Printer List for Driver Installation, click [Next]. Wireless Setup Manual Page 41 ...
Page 43
16) Click [Start] to install the driver. 17) Click [Yes] to continue. Wireless Setup Manual Page 42 ...
Page 44
18) Please wait until the driver installs. 19) Select [Install] to install the e‐manual. Wireless Setup Manual Page 43 ...
Page 46
22) Click [Next] to continue. 23) Make sure Restart Computer Now is selected, click [Restart]. Congratulations! You can now print wirelessly to your LBP7110Cw. If you need further assistance in setting up your printer, please contact us at 1‐800‐OK CANON (800‐652‐2666). Wireless Setup Manual Page 45 ...
Page 47
Non‐WPS Router Instructions To setup the LBP7110Cw wirelessly with a Non‐WPS Router, you must install the printer driver first. 1) Insert User Software CD that was included in the box. 2) Click Easy Installation. 3) You will see the below screen, click Start Wireless Setup Manual Page 46 ...
Page 48
4) Click [Yes to accept the terms of the License Agreement. 5) Select the [USB Connection] radio button, and then click [NEXT]. Wireless Setup Manual Page 47 ...
Page 49
6) Click [Next] to begin driver installation. 7) When the Print Driver Setup Wizard launches, click [Next]. Wireless Setup Manual Page 48 ...
Page 50
8) Select the [Install with USB Connection] radio button, and then click [Next]. 9) Click [Yes]. Wireless Setup Manual Page 49 ...
Page 51
10) You will see the below message, please wait while the driver is installed. 11) If the screen below appears, make sure that the printer is ON and the USB cable is connected to the computer and printer. Wireless Setup Manual Page 50 ...
Page 52
12) If you see this message, follow the on screen instructions, then, click [Retry]. *If the message reappears, try a different USB port on the computer. 13) Select [Install] to install the e‐manual. 14) Please wait while manuals install. Wireless Setup Manual Page 51 ...
Page 54
17) Click [Exit] and then eject the CD. Follow the procedure below to set up your printer wirelessly. 18) Insert User Software CD. 19) Click Easy Installation. Wireless Setup Manual Page 53 ...
Page 55
20) You will see the below screen, click Start 21) Click [Yes to accept the terms of the License Agreement. Wireless Setup Manual Page 54 ...
Page 56
22) Select the [Wireless LAN Connection] radio button, and then click [NEXT]. 23) Select the [Yes, I want to configure network settings] radio button, and then click [Next]. Wireless Setup Manual Page 55 ...
Page 57
24) Select the [Easy Setup] radio button, and then click [Next]. Wireless Setup Manual Page 56 ...
Page 58
25) Check to see if your wireless router has a WPS button, and select the appropriate radio button, as shown in the screen below. Select [My wireless LAN access point does not have a WPS button or I cannot find the button.] if: *You are not sure which connection method to use (Or refer to Useful Tips) * Your router does not have a WPS button Then click [Next] *If your router has a WPS button continue to page 33 Wireless Setup Manual Page 57 ...
Page 59
26) Follow the instructions on the screen, as shown below, and then click [Next]. The screen below appears while searching for your wireless network. Wireless Setup Manual Page 58 ...
Page 60
If the message shown below appears, read the message, and then click [OK]. Make sure that the USB cable is connected to your computer and to the LBP7110Cw, and make sure that the printer is turned ON. Click [Next]. 27) When a list of wireless networks appears, select your wireless network, and then click [Next]. Wireless Setup Manual Page 59 ...
Page 61
28) If your computer is already connected to the same wireless network as the printer, you do not have to enter your network key. If your computer is not connected to the same wireless network as the printer, enter the Network Key in the blank field, and then click [Next]. While the screen below appears, the Wi‐Fi indicator on your printer blinks blue. When the printer is connected to the network, the Wi‐Fi indicator turns solid blue. 29) Disconnect the USB cable from your printer, and then click [Next]. Wireless Setup Manual Page 60 ...
Page 62
30) Click [Next] to begin wireless driver installation 31) When the Print Driver Setup Wizard launches, click [Next]. Wireless Setup Manual Page 61 ...
Page 63
32) Select the [Search for Network Printers to Install] radio button, and then click [Next]. 33) Make sure that [Add Printers] is selected, and click [Next]. Your computer searches for the LBP7110Cw printer. Wireless Setup Manual Page 62 ...
Page 64
34) Select the LBP7110Cw printer from the Printer List, and then click [Add]. Wireless Setup Manual Page 63 ...
Page 65
35) Once the printer appears in the Printer List for Driver Installation, click [Next]. Wireless Setup Manual Page 64 ...
Page 66
36) Click [Start] to install the driver. 37) Click [Yes] to continue. Wireless Setup Manual Page 65 ...
Page 67
38) Please wait until the driver installs. 39) Select [Install] to install the e‐manual. 40) Please wait while manuals install. Wireless Setup Manual Page 66 ...
Page 69
43) Make sure Restart Computer Now is selected, click [Restart] Congratulations! You can now print wirelessly to your LBP7110Cw. You may see two options appear when printing from an application. If you want to print wirelessly choose the one labeled LBP7110Cw. To print via USB connection (USB Cable must be connected to computer and printer) choose Canon LBP7100C/7110C. If you need further assistance in setting up your printer, please contact us at 1‐800‐OK CANON (800‐652‐2666). Wireless Setup Manual Page 68 ...
