IKEA GRÄNSLÖS Manual

Hide thumbs Also See for GRÄNSLÖS:
Table of Contents

Advertisement

Quick Links

See also: Owner's Manual , User Manual
AU
GRÄNSLÖS

Advertisement

Table of Contents
loading

Related Manuals for IKEA GRÄNSLÖS

Summary of Contents for IKEA GRÄNSLÖS

  • Page 1 GRÄNSLÖS...
  • Page 3 ENGLISH...

  • Page 4: Table Of Contents

    Before first use Technical information Daily use ENVIRONMENTAL CONCERNS Microwave mode IKEA GUARANTEE Clock functions Subject to change without notice. Safety information Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible if an incorrect installation and use causes injuries and damages.

  • Page 5: General Safety

    ENGLISH Children under 3 years of age should be kept away from the • appliance unless continuously supervised. General Safety Only a qualified person must install this appliance and • replace the cable. Internally the appliance becomes hot when in operation. Do •...

  • Page 6: Conditions Of Use

    ENGLISH The appliance is intended for heating food and beverages. • Drying of food or clothing and heating of warming pads, slippers, sponges, damp cloth and similar may lead to risk of injury, ignition or fire. If smoke is emitted, switch off or unplug the appliance and •...
  • Page 7 ENGLISH • Make sure that the appliance is installed the appliance from the mains at all poles. below and adjacent safe structures. The isolation device must have a contact • The sides of the appliance must stay opening width of minimum 3 mm. adjacent to appliances or to units with the same height.
  • Page 8 ENGLISH – be careful when you remove or Glassware use install the accessories. Handling your glassware without an • Discoloration of the enamel has no effect appropriate degree of care could result in on the performance of the appliance. It is breakage, chipping, cracking or severe not a defect in the sense of the warranty scratching:...

  • Page 9: Installation

    ENGLISH Plastic parts are marked with Disposal international abbreviations such as PE, Warning! Risk of injury or PS, etc. Dispose of the packaging suffocation. material in the containers provided for this purpose at your local waste • Disconnect the appliance from the mains management facility.

  • Page 10: Product Description

    ENGLISH Product description General overview Control panel Knob for the oven functions Electronic programmer Knob for the temperature / microwave power Grill Microwave generator Lamp Rating plate Shelf support, removable Shelf positions • Microwave bottom glass plate x 1 Accessories To support microwave mode.

  • Page 11: Daily Use

    ENGLISH smoke. This is normal. Make sure that the 4. Press to confirm. This is necessary airflow in the room is sufficient. only when you set the time for the first time. Later the new time will be saved Using the Mechanical child lock automatically after 5 seconds.
  • Page 12 ENGLISH Oven function Application Microwave grill- The Microwave grilling starts as normal grilling function. When you add the microwave function, it combines the microwave and the grilling function at different time periods and power levels (refer to the power setting ta- ble).

  • Page 13: Microwave Mode

    ENGLISH Microwave mode • Do not use cookware made of porcelain, Microwave ceramic or earthenware with unglazed General: bottoms or small holes, e.g. on handles . Caution! Do not let the Moisture going into the holes can cause appliance operate when there is the cookware to crack when it is heated.
  • Page 14 ENGLISH Suitable cookware and materials Cookware / Material Microwave Grilling Defrosting Heating Cooking Ovenproof glass and porcelain with no metal components, e.g. Pyrex, heat-proof glass Non-ovenproof glass and porcelain Grill shelf, glass and glass ceramic made of ovenproof / frost-proof ma- terial e.g.
  • Page 15 ENGLISH Tips for the microwave Result Remedy You cannot find details for the amount Find details for similar type of food. Increase or of food prepared. shorten the length of the cooking time according to the following rule: double the amount - almost double the time, half the amount - half the time.
  • Page 16 ENGLISH power setting changes in 100 Watt The display shows a default temperature. steps. 2. Change the temperature. 3. Press and then turn the knob for the 3. Press . Refer to "Setting the temperature / microwave power right Microwave function" and start from step or left to change the Duration settings.

  • Page 17: Clock Functions

    ENGLISH Power setting • 100 Watt Defrosting meat, fish, bread Defrosting cheese, cream, butter Defrosting fruit and cakes (gateaux) Raising yeast dough Heating up cold dishes and drinks Clock functions Clock functions table Clock function Application TIME OF DAY To set, change or check the time of day. Refer to "Set- ting the time".

  • Page 18: Using The Accessories

    ENGLISH After 90% of the set time, an acoustic If you press when you set the signal sounds. hours for DURATION , the 4. When the set time ends, an acoustic signal sounds for two minutes. "00:00" appliance goes to setting of the flash in the display.

  • Page 19: Additional Functions

    ENGLISH Additional functions Using the Child Lock The Automatic switch-off does not work with the functions: The Child Lock prevents an accidental Duration, End. operation of the appliance. 1. Ensure the knob for the oven functions is Residual heat indicator in the off position.
  • Page 20 ENGLISH Cooking meat and fish Cooking times • Use a deep pan for very fatty food to Cooking times depend on the type of food, prevent the oven from stains that can be its consistency, and volume. permanent. Initially, monitor the performance when you •...
  • Page 21 ENGLISH Food Power Quantity Time (min) Standing Comments (Watts) time (min) Fresh vegeta- 500 g 12 - 16 Add approx. 50 ml wa- ter, cook covered, stir bles halfway through. Frozen vege- 500 g 14 - 18 Add approx. 50 ml wa- ter, cook covered, stir tables halfway through.

  • Page 22: Care And Cleaning

    ENGLISH Food Power Quantity (g) Time (min) Standing Comments (Watts) time (min) Mixed minced 10 - 15 10 - 15 Turn halfway meat through, remove defrosted parts. Chicken 1000 25 - 30 10 - 20 Turn halfway through, cover de- frosted parts with aluminium foil.

  • Page 23: Troubleshooting

    ENGLISH Cleaning the door gasket Replacing the lamp • Regularly do a check of the door gasket. Put a cloth on the bottom of the interior of The door gasket is around the frame of the appliance. It prevents damage to the the oven cavity.
  • Page 24 ENGLISH Problem Possible cause Remedy The oven does not heat up. The necessary settings are Make sure that the settings not set. are correct. The oven does not heat up. The automatic switch-off is Refer to "Automatic switch- activated. off". The oven does not heat up.

  • Page 25: Technical Information

    IKEA GUARANTEE How long is the IKEA guarantee valid? 84006270757 or at Cebas Pty Ltd, ABN 15 009 156 003 (Both Trading as IKEA) unless This guarantee is valid for five (5) years the appliance is named LAGAN in which from the original date of purchase of Your case two (2) years of guarantee apply.
  • Page 26 Contact - IKEA Customer Service at non-excludable statutory warranties in www.IKEA.com.au Australia. What will IKEA do to correct the problem? For Western Australian and South Australian customers please contact: IKEA appointed service provider will exam- ine the product and decide, at its sole dis- Cebas Pty Ltd cretion, if it is covered under this guarantee.
  • Page 27 • Transportation damages. If a customer transports the product to their home or To make a claim under the guarantee other address, IKEA is not liable for any contact IKEA after sales customer service damage that may occur during transport.
  • Page 28 ENGLISH center at the above address, the IKEA Please describe the problem that catalogue or refer to www.ikea.com.au for you are facing with the your local store customer service phone appliance in detail along number, online email and opening times.
  • Page 29 ENGLISH...
  • Page 30 ENGLISH...
  • Page 31 ENGLISH...
  • Page 32 21552 © Inter IKEA Systems B.V. 2015 AA-1755543-2...
