- Page 1 For your safety, always comply with all warnings and safety instructions contained in this manual to prevent personal injury or property damage. To view the full line of Dimplex products, please visit www.dimplex.com 7209350100R07...
-
Page 2: Table Of Contents
CAUTION: Procedures and techniques which, if not carefully followed, will result in damage to the equipment. W ARNING: Procedures and techniques which, if not carefully followed, will expose the user to the risk of fire, serious injury, or death. www.dimplex.com... -
Page 3: Welcome & Congratulations
Welcome & Congratulations Thank you and congratulations for purchasing an electric fireplace from Dimplex. Please use our convenient online registration page to record your model and serial numbers for future reference at www.dimplex.com/register Model Number MODE L MOD. Plate S E R IAL No. -
Page 4: Important Instructions
① Read all instructions before dropped or damaged in any man- using the Convex In-Stud fire- ner, contact Dimplex Technical place. Service at 1-888-346-7539. ② The heater is hot when in use. ⑦ Do not use outdoors. -
Page 5: Save These Instructions
IMPORTANT INSTRUCTIONS any manner. ⑰ Do not burn wood or other materials in the fireplace. ⑬ All electrical heaters have hot and arcing or sparking parts ⑱ Do not strike the glass front. inside. Do not use in areas where ⑲... - Page 6 Consult the dealer or an experienced radio/TV technician for help. Operation is subject to the following two conditions: (1) this device may not cause interference and (2) this device must accept any interference, including interference that may cause undesired operation of the device. www.dimplex.com...
-
Page 7: Fireplace Installation
Fireplace Installation rating of the circuit breaker. WARNING: Ensure the power cord is not installed so that it is WARNING: The Convex In pinched or against a sharp edge Stud fireplace is wall mount- and ensure that the power cord is able and can be built in a wall stored or secured to avoid tripping space 16"... - Page 8 Other available combinations 4. The second mounting point are A-G, C-G, A-F, A-E, A-D should be picked such that it and D-G. is farthest (to the left or right) 5. Mark the second mounting relative to the first one among www.dimplex.com...
- Page 9 Fireplace Installation screw location; ensure that it threads for mounting the fire- is level with the first with the place. help of the provided bubble 7. With the glass assembly tak- level and the fireplace itself. en off, mount the firebox onto Screw the threaded drywall the two mounting screws.
- Page 10 1. Leave the frame uninstalled surements for the wall opening. from the fireplace chassis un- Dimplex North America will not til step 13. be responsible for inaccuracies 2. Prepare a wall opening fol-...
- Page 11 Fireplace Installation installation does not obscure the 4. Remove the outer jacket and air intake slots on top of unit in strip the individual conductor any manner. from the end. Keep a minimum of a 4" (102 5. Loosen the screw securing mm) clearance from top of the junction box cover and unit to any surface or mate-...
-
Page 12: Bathroom Installation
This unit must be installed away from showers, tubs, etc. Never locate fireplace where it may fall into a bathtub or other water containers. Keep towels www.dimplex.com... - Page 13 Fireplace Installation Figure 8 Figure 9 Top Bracket wood screws here Bottom Bracket WIRING INTEGRAL ON-OFF R/C 3-POSITION SWITCH THERMOSTAT HEAT SWITCH CUTOUT FLICKER BLOWER MOTOR MOTOR GROUND LOWER LIGHTS ELEMENTS...
-
Page 14: Operation
For additional heat, turn upward until you hear the The position is for operating click again and the heater will turn the unit with the provided remote control. www.dimplex.com... -
Page 15: Remote Control
CAUTION: If you need to continuously reset the heater, Battery Replacement (Figure 11) disconnect power and call To replace the battery: Dimplex customer service at 1. Slide battery cover open on 1-888-DIMPLEX the remote control. (1-888-346-7539). Figure 11... -
Page 16: Maintenance
3. Hold on to the glass assembly they are close to the end of their with both hands then lift the rated life. Group replacement will whole assembly straight up to www.dimplex.com... -
Page 17: Glass Cleaning
Maintenance Figure 12 Figure 13 Light Glass Block assembly Lift to remove remove (Figure 11). 4. Remove the two screws with a damp cloth. The glass securing the light block as should be completely dried with shown in Figure 13, then re- a lint free cloth to prevent water move the light block. -
Page 18: Warranty
Limited warranty service requires a proof products is with the purchaser, and in the of purchase of the product. event of a defect the purchaser assumes What Dimplex will do in the event of a the entire cost of all necessary servicing defect? or repair. - Page 19 Warranty uct or part without charge. If Dimplex OR ITS DIRECTORS, OFFICERS, OR is unable to repair or replace such AGENTS HAVE BEEN ADVISED OF product or part, or if repair or replace- THE POSSIBILITY OF SUCH LOSSES, ment is not commercially practicable or...
-
Page 20: Replacement Parts
Replacement Parts Front Glass - VCX1525 ....... 5901170100RP VCX1525-WH ......5901170200RP Flicker Motor .
