19.5" LCD Monitor
Service
Service
Service
Description
Table of Contents.........................................................1
Revision List................................................................2
Important Safety Notice...............................................3
1.Monitor Specification.................................................4
2.LCD Monitor Description.......................................5
3.Operation Instruction...............................................6
3.1.General Instructions.................................................6
3.2.Control Button......................................................6
3.3.OSD Setting...........................................................8
4.Input/Output Specification......................................16
4.1.Input Signal Connector.........................................16
4.2.Factory Preset Display Modes..............................17
4.3.Panel Specification............................................18
5.Block Diagram........................................................20
5.1.Main Board.....................................................20
ANY PERSON ATTEMPTING TO SERVICE THIS CHASSIS MUST FAMILIARIZE HIMSELF WITH THE CHASSIS
AND BE AWARE OF THE NECESSARY SAFETY PRECAUTIONS TO BE USED WHEN SERVICING
ELECTRONIC EQUIPMENT CONTAINING HIGH VOLTAGES.
CAUTION: USE A SEPARATE ISOLATION TRANSFOMER FOR THIS UNIT WHEN SERVICING
R FOR TH
UNIT WHEN S

Table of Contents

Page
Description
5.2.Power Board.............................................21
6.Schematic.......................................................22
6.1.Main Board....................................................22
6.2.Power Board..................................................27
6.3.Key Board......................................................30
7.PCB Layout.....................................................31
7.1.Main Board....................................................31
7.2.Power Board..................................................34
7.3.Key Board...................................................36
8.Maintainability.................................................37
8.2.Trouble Shooting..........................................38
10.Monitor Exploded View.................................44
11.BOM List...................................................45
SAFETY NOTICE
AOC E2060Swda
Horizontal Frequency
30-83 KHz
Page

Advertisement

Table of Contents
loading

Summary of Contents for AOC E2060SWDA

  • Page 1: Table Of Contents

    19.5" LCD Monitor AOC E2060Swda Service Service Service Horizontal Frequency 30-83 KHz Table of Contents Description Page Description Page Table of Contents..……......……..1 5.2.Power Board……………..……………...…..21 6.Schematic……………........22 Revision List.…........…………..2 6.1.Main Board………...........22 Important Safety Notice.……......……..3 6.2.Power Board...…….........27 1.Monitor Specification......………..4 6.3.Key Board...……..........30 2.LCD Monitor Description……………………………..5 7.PCB Layout..…………........31...
  • Page 2: Revision List

    Revision List Version Release Date Revision History TPV Model Name Nov.-30-2012 Initial release T9CMUF7BBGACDNE...
  • Page 3: Important Safety Notice

    Important Safety Notice Proper service and repair is important to the safe, reliable operation of all AOC Company Equipment. The service procedures recommended by AOC and described in this service manual are effective methods of performing service operations. Some of these service operations require the use of tools specially designed for the purpose. The special tools should be used when and as recommended.
  • Page 4: Monitor Specification

    1. Monitor Specifications...
  • Page 5: Lcd Monitor Description

    2. LCD Monitor Description The LCD monitor will contain a main board, a power board, a key board which house the flat panel control logic, brightness control logic and DDC. The power part will provide AC to DC Inverter voltage to drive the backlight of panel and the main board chips each voltage.
  • Page 6: Operation Instruction

    This monitor only has one external control function button; press the Power/Auto Configuration button to turn the monitor on or off. If you need to adjust other functions, please visit the official AOC website (www.aoc.com)to download and install AOC’s exclusive i-Menu application software, and then perform related function adjustments to get the screen you require.
  • Page 7 USB (Optional) Power DVI (Optional) Analog (DB-15 VGA cable) Line in (Optional) To protect equipment, always turn off the PC and LCD monitor before connecting. 1. Connect the power cable to the AC port on the back of the monitor. 2.
  • Page 8: Osd Setting

    3.3 OSD Setting Basic and simple instruction on the control keys. 1) Press the MENU-button to activate the OSD window. 2) Press < or > to navigate through the functions. Once the desired function is highlighted, press the MENU-button to activate it . press< or >to navigate through the sub-menu functions. Once the desired function is highlighted, press MENU-button to activate it.
  • Page 9 Luminance 1 Press (Menu) to display menu. 2 Press < or > to select (Luminance), and press to enter. 3 Press < or > to select submenu, and press to enter. 4 Press < or > to adjust. 5 Press to exit.
  • Page 10 Image Setup 1 Press (Menu) to display menu. 2 Press < or > to select (Image Setup), and press to enter. 3 Press < or > to select submenu, and press to enter. 4 Press < or > to adjust. 5 Press to exit.
  • Page 11 Color Setup 1 Press (Menu) to display menu. 2 Press < or > to select (Color Setup), and press to enter. 3 Press < or > to select submenu, and press to enter. 4 Press < or > to adjust. 5 Press to exit.
  • Page 12 Picture Boost 1 Press (Menu) to display menu. 2 Press < or > to select (Picture Boost), and press to enter. 3 Press < or > to select submenu, and press to enter. 4 Press < or > to adjust. 5 Press to exit.
  • Page 13 OSD Setup 1 Press (Menu) to display menu. 2 Press < or > to select (OSD Setup), and press to enter. 3 Press < or > to select submenu, and press to enter. 4 Press < or > to adjust. 5 Press to exit.
  • Page 14 Extra 1 Press (Menu) to display menu. 2 Press < or > to select (Extra), and press to enter. 3 Press < or > to select submenu, and press to enter. 4 Press < or > to adjust. 5 Press to exit.
  • Page 15 Exit 1 Press (Menu) to display menu. 2 Press < or > to select (Exit), and press to enter. 3 Press < or > to select submenu, and press to enter. 4 Press < or > to adjust. 5 Press to exit.
  • Page 16: Input/Output Specification

    4. Input/Output Specification 4.1 Input Signal Connector Pin Assignments...
  • Page 17: Factory Preset Display Modes

    4.2 Factory Preset Display Modes...
  • Page 18: Panel Specification

    4.3 Panel Specification 4.3.1 General Features M195FGE-L20 is a 19.5” TFT Liquid Crystal Display module with WLED Backlight unit and 30 pins 2ch-LVDS interface. This module supports 1600 x 900 HD+ mode and can display up to 16.7M colors. The converter module for Backlight is not built in.
  • Page 19 Back Light Unit Ta = 25 ± 2.º C 4.3.4 Optical Characteristics...
  • Page 20: Block Diagram

    VLCD 04.SCALER 06.POWER T P V ( Top Victory Electronics Co . , Ltd. ) OEM MODEL Size AOC E960SWDA/SDA 絬 隔 瓜 絪 腹 G5270-M01-000-0040-7-120710 TPV MODEL DUAL Key Component COVER & REVISE HISTORY PCB NAME 715G5270M010000040 称 爹...
  • Page 21: Power Board

    5.2 Power Board 715G4497P05000001C AC input Bridge Rectifier Transformer EMI filter Rectifier diodes and Filter Start Resistor (R908,R935) Feedback PWM Control Circuit Power Switch (U901) (Q901) Photo coupler Regulator (U902) (U903) L801 D801 14.5V MOSFET (Q801) (CN804) ON/OFF PWM Control PF7024 (U801) Audio...
  • Page 22: Schematic

    0.1UF 16V AZC398-04S AZC398-04S T P V ( Top Victory Electronics Co . , Ltd. ) OEM MODEL Size AOC E960SWDA/SDA 絬 隔 瓜 絪 腹 G5270-M01-000-0040-7-120710 TPV MODEL DUAL Key Component D-SUB I/O PCB NAME 715G5270M010000040 称 爹 <称爹>...
  • Page 23 NC/22K 1/16W 5% R154 DVI_HPD 5 NC/LMBT3904LT1G T P V ( Top Victory Electronics Co . , Ltd. ) OEM MODEL Size AOC E960SWDA/SDA 絬 隔 瓜 絪 腹 G5270-M01-000-0040-7-120710 TPV MODEL DUAL Key Component PCB NAME 715G5270M010000040 称 爹 <称爹> Date...
  • Page 24 NC/100R 1/16W 5% R471 NC/CONN NC/CONN T P V ( Top Victory Electronics Co . , Ltd. ) OEM MODEL Size AOC E960SWDA/SDA 絬 隔 瓜 絪 腹 G5270-M01-000-0040-7-120710 TPV MODEL DUAL 715G5270M010000040 Key Component 5.0.SCALER PCB NAME 称 爹 <称爹>...
  • Page 25 RXOC- C432 C433 RXEC+ RXOC+ T P V ( Top Victory Electronics Co . , Ltd. ) OEM MODEL AOC E960SWDA/SDA Size 絬 隔 瓜 絪 腹 G5270-M01-000-0040-7-120710 TPV MODEL DUAL Key Component LVDS PANEL I/O PCB NAME 715G5270M010000040 <称爹>...
  • Page 26 0.1UF 16V 0.1UF 16V <Variant Name> T P V ( Top Victory Electronics Co . , Ltd. ) OEM MODEL Size AOC E960SWDA/SDA 絬 隔 瓜 絪 腹 G5270-M01-000-0040-7-120710 TPV MODEL DUAL Key Component POWER PCB NAME 715G5270M010000040 称 爹...
  • Page 27: Power Board

    6.2 Power Board 715G4497P05000001C R929 100 OHM 1/4W BD901 FB803 C916 2.2N 630V F801 R930 100 OHM 1/4W 0R05 1/4W +14.5V JUMP R903 100 OHM 1/4W C928 2.2N 630V R904 ZD901 250OHM2W MTZJ T-72 22B D901 C918 2KBP08M-70 NC/SR5150 330UF/25V R905 D902 470OHM +-5% 1/8W...
  • Page 28 D801A SR3100-MK18 FB802 D801 L801 CN803 +14.5V C801 47UH BEAD Q801 330uF 25V R804 C814 100N 50V 10 OHM 1/8W C810 R801 APM8005KCTRG 0.47UF 50V R815 R819 R820 R822 C809 160K 1/8W ON/OFF R814 4.7uF100V 10K 1/8W C802 C811 R805 0.47UF 50V R821 CN804...
  • Page 29 +5V1 +5V1 R602 C604 470UF M 16V 10K 1/10W 5% FB602 R603 10K 1/10W 5% C609 1U 25V 120 OHM 10K 1/10W 5% C618 470pF 50V U601 FB601 R609 SE/BTL LOUTP CN601 120 OHM CN602 VOLUME R604 10K 1/10W 5% C601 0.47uF 16V LINN LOUTN...
  • Page 30: Key Board

    6.3 Key Board 715G5357K03000001M BLUE CN001 SGND SGND LBADC1 R005 2KOHM 1/10W LBADC2 DC_POWERON R003 100R 1/10W 5% LED_1# LED_2# R001 100R 1/10W 5% R002 1K 1/10W 5% R004 2KOHM 1/10W CONN SGND AUTO(2.0K) 1.118V LBADC1 ( 100 ohm ) 0.083V DOWN (2K)
  • Page 31: Pcb Layout

    7. PCB Layout 7.1 Main Board 715G5270M01000004I...
  • Page 34: Power Board

    7.2 Power Board 715G4497P05000001C...
  • Page 36: Key Board

    7.3 Key Board 715G5357K03000001M...
  • Page 37: Maintainability

    8. Maintainability 8.1 Equipments and Tools Requirement Voltmeter. Oscilloscope. Pattern Generator. DDC Tool with an IBM Compatible Computer. Alignment Tool. LCD Color Analyzer. Service Manual. User Manual.
  • Page 38: Trouble Shooting

    8.2 Trouble Shooting No Power No power Check power cable is Re-plug the power cable tightened? Check Power “On/Off” Turn on the Power “On/Off” switch is “On”? Check the LED Check the AC power indicate is OK? Replace the converter board Replace main board and check connections Replace key board and check connections...
  • Page 39 2. No Video (Power LED Blue) No Video (Power LED Blue) Press the power Replace the main board button is OK? Replace the converter The end board Replace the main The end board and connection Replace the LVDS/FFC Check the LVDS/FFC cable or panel cable or panel Replace the key board...
  • Page 40 3. DIM DIM (image overlap, focus or flicker) Reset in factory mode The end Set to the optimal The end frequency, select the recommended frequency Readjust the phase and pixel The end clock in the user mode Pull out signal cable and Check the signal cable check “Self Test Feature and the PC...
  • Page 41 4. Color is not optimal Color is not optimal Color shift Miss color Reset the factory mode Replace the signal cable In the user mode, set the” color settings” until customer satisfy The end Pull out the signal cable and check the screen color display is normal? Replace the signal cable or PC Replace the main board...
  • Page 42: White-Balance, Luminance Adjustment

    9. White- Balance, Luminance Adjustment Approximately 30 minutes should be allowed for warm up before proceeding white balance adjustment. How to setting MEM channel you can reference to chroma 7120 user guide or simpl use “SC” key and “NEXT” Key to modify xyY value and use “ID”...
  • Page 43 A. Adjust Warm (6500K) color-temperature 1. Switch the chroma-7120 to RGB-Mode (with press “MODE” button) 2. Switch the MEM.channel to Channel 3 (with up or down arrow on chroma 7120) 3. The LCD-indicator on chroma 7120 will show x = 313 ±20, y = 329 ±20 4.
  • Page 44: Monitor Exploded View

    10. Monitor Exploded View...
  • Page 45: Bom List

    11. BOM List Note: The parts information listed below are for reference only, and are subject to change without notice. Please go http://cs.tpv.com.cn/hello1.asp for the latest information. T9CMUF7BBGACDNE Location Part No. Description Remark 040G 58162435A MANUAL P/N LABEL 052G 2191 A PAPER TAPE HDCP-SMT 070GHDCP500HDC...
  • Page 46 Q45G990161940500BX PROTECT BAG M05203 Q52G100204500A00HB AL FOIL M05202 Q52G100204500A00HB AL FOIL M05201 Q52G100204500A00HB AL FOIL Q52G1801MNT170AFJY INSULATING SHEET H40G000261553A TCO'05 EPA LABEL 756GHCCB0BV0030001 MAIN BOARD-CBPCCUFA1H1 SMTCC-U402 100GAMMA006W11 MCU ASSY-056G2233501 CN404 033G3802 6B Y WAFER CN701 033G3802 9B Y CONN 2.0 9P CN410 033G801930F CH JS FFC CONN 1.0mm 30P R/A 34mm 6.3mm...
  • Page 47 709G4497 HM001 CONSUMPTIVE ASS'Y H40G 45762429A LABEL T901 S80GL22T3V6 X'FMR 490UH 7% 4UH EER28 -- Q55G 100625 TIN STICK_LOW ARGENTUM C430 067G 3051013PB EC 105C 100uF M 16V 5*11mm JH CD263 C705 067G 3051013PB EC 105C 100uF M 16V 5*11mm JH CD263 C702 067G 3051013PB EC 105C 100uF M 16V 5*11mm JH CD263...
  • Page 48 R608 061G0805000 JF RST CHIPR 0 OHM +-5% 1/8W FENGHUA R818 061G0805000 JF RST CHIPR 0 OHM +-5% 1/8W FENGHUA R804 061G0805100 JF RST CHIPR 10 OHM +-5% 1/8W FENGHUA R928 061G08051001FF RST CHIPR 1KOHM +-1% 1/8W FENGHUA R827 061G08051008FT RST 0805 1R 1% 1/8W R824 061G08051008FT...
  • Page 49 R908 061G1206103 JT RST CHIPR 10KOHM +-5% 1/4W TZAI YUAN R602 061G1206103 JT RST CHIPR 10KOHM +-5% 1/4W TZAI YUAN R913 061G1206109 JT RST CHIPR 1 OHM +-5% 1/4W TZAI YUAN R923 061G1206221 JT RST CHIPR 220 OHM +-5% 1/4W TZAI YUAN R812 061G1206308 JT RST 1206 0.3R 5% 1/4W...
  • Page 50 C804 065G080547432K CAP CHIP 0805 0.47UF K 50V X7R C917 065G120622272K CAP 1206 2.2NF 10% 500V X7R C928 065G120622272K CAP 1206 2.2NF 10% 500V X7R C916 065G120622272K CAP 1206 2.2NF 10% 500V X7R C929 065G120622272K CAP 1206 2.2NF 10% 500V X7R FB604 071G 56K121 M CHIP BEAD 120OHM 6A MGLB2012-120T-LF...
  • Page 51 U903 056G 563355 Shunt Regu TL431G-A-TA TO-92 42V 150mA J812 095G 90 23 JUMP WIRE - - R904 061G152M47152T SY RST MOF 470R 5% 2W FUTABA D903 093G 6026T52T CTIFIER DIODE FR107 FB801 071G 55 29 FERRITE BEAD J903 095G 90 23 JUMP WIRE - - J905 095G 90 23...
  • Page 52 U701 056G 563527BHF LDO BL1117-33CX 1A 3.3V SOT-223 U103 056G 662 52 ESD PROTECT AZC398-04S.R7G SOT23-6 U104 056G 662 52 ESD PROTECT AZC398-04S.R7G SOT23-6 U106 056G 662 52 ESD PROTECT AZC398-04S.R7G SOT23-6 U101 056G 662 52 ESD PROTECT AZC398-04S.R7G SOT23-6 U107 056G 662 52 ESD PROTECT AZC398-04S.R7G SOT23-6...
  • Page 53 R423 061G0402102 JY RST CHIPR 1KOHM +-5% 1/16W YAGEO R421 061G0402102 JY RST CHIPR 1KOHM +-5% 1/16W YAGEO R131 061G0402102 JY RST CHIPR 1KOHM +-5% 1/16W YAGEO R716 061G0402103 JF RST CHIPR 10KOHM +-5% 1/16W FENGHUA R703 061G0402103 JF RST CHIPR 10KOHM +-5% 1/16W FENGHUA R401 061G0402103 JF RST CHIPR 10KOHM +-5% 1/16W FENGHUA...
  • Page 54 R723 061G0402472 JY RST CHIPR 4.7KOHM +-5% 1/16W YAGEO R133 061G0402472 JY RST CHIPR 4.7KOHM +-5% 1/16W YAGEO R701 061G0402472 JY RST CHIPR 4.7KOHM +-5% 1/16W YAGEO R121 061G0402750 JY RST CHIPR 75OHM +-5% 1/16W YAGEO R113 061G0402750 JY RST CHIPR 75OHM +-5% 1/16W YAGEO R107 061G0402750 JY RST CHIPR 75OHM +-5% 1/16W YAGEO...
  • Page 55 C102 065G040247312K CAP 0402 47NF 10% 16V X7R C101 065G040250931C CAP 0402 5PF 0.25pF 50V NP0 C106 065G040250931C CAP 0402 5PF 0.25pF 50V NP0 C110 065G040250931C CAP 0402 5PF 0.25pF 50V NP0 C412 065G040256031J CAP CHIP 0402 56pF 50V NP0 +/-5% C413 065G040256031J CAP CHIP 0402 56pF 50V NP0 +/-5%...
