Summary of Contents for Optoma Optoma TW1692

Page 1: Table Of Contents
Installation ... 13 Connecting the Projector ...13 Connect to Computer / Notebook ...13 Connect to Video Sources ...14 Powering On / Off the Projector ...15 Powering On the Projector ...15 Powering Off the Projector ...16 Warning Indicator...16 Adjusting the Projected Image ...17 Adjusting the Projector’s Height ...17...
Page 2: Usage Notice
B. Do not use this projector near water or moisture. To reduce the risk of fire or electric shock, do not expose the projector to rain or moisture. C. Do not install near any heat sources, such as radiators, heaters, stoves or other apparatus (including amplifiers) that produce heat.
Page 3 Please call Optoma to be referred to an authorized service center near you. 8. Do not let objects or liquids enter the projector as they may touch dangerous voltage points or short-out parts that could result in a fire or electric shock.
Page 4: Precautions
Usage Notice Precautions ▀■ Warning - Do not look into the projector’s lens when the lamp is ▀■ Warning - To reduce the risk of fire or electric shock, do not ▀■ Warning - Please do not open or disassemble the projector as this ▀■...
Page 5 Turn off the product before cleaning. Use a soft cloth moistened with a mild detergent to clean the display housing. Disconnect the power plug from the AC outlet if the product is not being used for a long period of time. Don’t Do not block the ventilation slots and openings on the unit.
Page 6: Eye Safety Warnings
Usage Notice Eye Safety Warnings ▀■ Avoid staring directly into the projector’s beam of light at all times. ▀■ Minimize standing facing into the beam. Keep your back to the beam as much as possible. ▀■ Using a stick or laser pointer is recommended to avoid the need for the presenter to enter the beam.
Page 7: Introduction
Product Features This product is a single chip 0.55” XGA series and 0.65” WXGA series DLP projector. Outstanding features include: ® Texas Instruments Single chip DLP Computer Compatibility: Apple Macintosh, iMac, and VESA Standards: UXGA, SXGA+, SXGA, WXGA, WUXGA, XGA, SVGA, VGA Video Compatibility: ■...
Page 8: Package Overview
Introduction Package Overview This projector comes with all the items shown below. Check to make sure your unit is complete. Contact your dealer immediately if anything is missing. Projector with lens cover Composite cable (RCA) Due to the difference in...
Page 9: Product Overview
Product Overview Main Unit 1. Control Panel 2. Zoom 3. Focus 4. Lens 5. Front IR Receiver 6. Lens Cover 7. Elevator foot Introduction 8. Ventilation 9. Power Socket 10. Connection Ports 11. Kensington™ Lock English...
Page 10: Control Panel
Introduction Control Panel 1. Power 3. Power LED 4. Lamp LED 5. Temp LED 6. AV-Mute English ◄/Source (Left arrow) 7. Enter ▲/Keystone+ (Up arrow) ►/Re-Sync (Right arrow) ▼/Keystone - (Down arrow) 11. Menu...
Page 11: Rear View
Introduction Rear View AC IN 1. AC IN (Power) 2. USB Connector 3. Audio Input Connector 4. S-Video Input Connector 5. Video Input Connector 6. VGA/SCART Input Connector 7. HDMI Connector 8. Kensington™ Lock Port 9. Ventilation Opening English...
Page 12: Remote Control
Introduction Remote Control 1. Button LED 2. Power On/Off 3. Laser Button 4. Page Up 5. Mouse Right Click 6. Four Directional Select Keys 7. Re-Sync 8. Page Down 9. Volume +/- 10. Menu 11. Zoom 12. AV mute 13. Video Source 14.
Page 13: Installation
Connecting the Projector Connect to Computer / Notebook Due to the difference in applications for each country, some regions may have different accessories. 1. Power Cord 2. USB Cable 3. Audio-in (mini jack) 4. S-Video Cable 5. Video Cable 6. VGA Cable 7.
Page 14: Connect To Video Sources
Installation Connect to Video Sources Due to the difference in applications for each country, some regions 1. Power Cord may have different 2. Component Cable (optional) accessories. 3. RGB to Component Adapter (optional) 4. Stereo system cable (optional) 5. RCA Video Cable 6.
Page 15: Powering On / Off The Projector
Turn on the keys on the computer keyboard to switch the display output to projector first the projector. (Check the user manual of the PC to determine the and then appropriate Fn key combination to change display output.) select the signal sources.
Page 16: Powering Off The Projector
Installation Powering Off the Projector 1. Press POWER to turn off the projector lamp, a message displays on the projector’s screen. 2. Press POWER again to confirm, otherwise the message disappears after 15 seconds. 3. The cooling fans continue to operate for about 10 seconds for cooling cycle.
Page 17: Adjusting The Projected Image
• Position the projector so that it is perpendicular to the screen. • Ensure the cables are in a safe location. You could trip over them. 1. To raise the level of the projector, lift the projector [A] and press the height-adjuster button [B]. The height adjuster drops down [C].
Page 18: Adjusting The Zoom / Focus
[B]. 2. Use the Image-focus control (on the projector only) to sharpen the projected image [A]. 3. Use the keystone buttons to correct image distortion. They can be found on the remote control and on the projector’s control panel. English...
Page 19: User Controls
Control Panel Using the Control Panel Refer to the “Power On/Off the Projector” Power section on page 15. Press Menu to launch the on-screen display Menu (OSD) menu. To exit OSD, Press Menu again. ▲/Keystone+ •Adjust the image Keystone positively.
Page 20: Remote Control
Keystone +/- Volume +/- English Refer to the “Power On/Off the Projector” section on page 15. Aim the remote at the viewing screen, press and hold this button to activate the laser pointer. Use ▲▼◄► to select items or make adjustments to your selection.
Page 21: Menu 21
Using the Remote Control Brightness Menu Zoom HDMI Freeze AV Mute S-Video HDMI Video User Controls Adjust the brightness of the image. Press Menu to launch the on-screen display (OSD) menu. To exit OSD, Press Menu again. Press +/- to zoom in of an image. Press HDMI to choose HDMI source.
Page 22: On-Screen Display Menus
User Controls On-screen Display Menus The Projector has multilingual On-screen Display menus that allow you to make image adjustments and change a variety of settings. The projector will automatically detect the source. How to operate 1. To open the OSD menu, press Menu on the Remote Control or Projector Keypad.
Page 23: Menu Tree
User Controls Menu Tree English...
Page 24: Image
User Controls Image Display Mode There are many factory presets optimized for various types of images. Presentation: Good color and brightness from PC input. Bright: Maximum brightness from PC input. Movie: For home theater. sRGB: Standardised accurate color. User1: User’s own settings. User2: User’s own settings.
Page 25: Color Setting
Image Saturation Adjusts a video image from black and white to full color saturation. Press ◄ to decrease the amount of saturation in the image. Press ► to increase the amount of saturation in the image. Tint Adjusts the color balance of red and green. Press ◄...
Page 26 User Controls Image | Color Setting Gain Set RGB Gain to adjust the Brightness of the follow in Colors: Red—increase or decrease the gain value for red. Green—increase or decrease the gain value for green. Blue—increase or decrease the gain value for blue. Bias Set RGB Bias to adjust the Contrast of the follow in Colors: Red—increase or decrease the bias value for red.
Page 27: Brilliant Color
Image | Advanced Brilliant Color This adjustable item utilizes a new color-processing algorithm and system level enhancements to enable higher brightness while providing true, more vibrant colors in picture. The range is from 0 to 10. If you prefer a stronger enhanced image, adjust toward the maximum setting. For a smoother, more natural image, adjust toward the minimum setting.
Page 28 Use this option to enable / disable input sources. Press ◄ or ► into the next menu as below and then use ▲ or ▼ to select. Press Enter to finalize If all sources the selection. The projector will not search inputs that are de-selected. are deselected, the projector cannot display any images.
Page 29: Display
HDTV and DVD enhanced for Wide screen TV. 16:9 II (XGA series)/16:10 (WXGA series): The non-standard wide-screen display format of the projector. Part of the original image will be cut if the image aspect ratio is less than 1.67:1.
Page 30: Keystone
Press ► to move the image up on the projected screen. Press ◄ to move the image down on the projected screen. V Keystone Press ◄ or ► to compensate for vertical image distortion when the projector is positioned at an angle to the screen. English...
Page 31: Setup
Select projection method: Front Desktop The factory default setting. Rear Desktop When you select this function, the projector reverses the image so you can project behind a translucent screen. Front Ceiling When you select this function, the projector turns the image upside down for ceiling-mounted projection.
Page 32 Signal Enter the Signal menu. Set projector signal properties. See page 34 for more information. Security Enter the Security menu. Access the projector’s security features. See page 35 for more information. Mute Toggle the audio on or off. Off—the speaker volume is turned on.
Page 33 Setup | Language Language Choose the multilingual OSD menu. Press ENTER ( menu and then use the Left (◄) or Right (►) key to select your preferred language. User Controls ) into the sub English...
Page 34 User Controls Setup | Signal Frequency Change the display data frequency to match the frequency of your computer’s graphics card. If you experience a vertical flickering bar, use this function to make an adjustment. Phase Phase synchronizes the signal timing of the display with the graphic card. If you experience an unstable or flickering image, use this function to correct it.
Page 35: Security Timer
Security Timer and times to allow power on and access to the security menu. or Security If the projector is in use and the Security Timer is active, the following Setting are screen displays 60 seconds before the password is required.
Page 36: Change Password
User Controls Setup | Security Change Password If the incorrect Use this submenu to change the security password for the projector. password is 1. Select Change Password from the Security submenu. The Confirm entered three Change Password dialog box displays.
Page 37: Security Setting
Setup | Security Security Setting Enable or disable the security password. Enabled—the current password is required to power on the projector and access the Security menu. Disabled—no password is required for any function. When security is enabled, the following screen displays at startup and...
Page 38: Logo Capture
User—customized screen capture using the Logo Capture function. Logo Capture Capture a displayed screen to use as the startup screen. 1. Display the desired screen on the projector. 2. Select Logo Capture from the Advanced menu. A confirmation screen displays.
Page 39: Options
Options Source Lock Lock the current source as the only available source, even if the cable is unplugged. On—only the current source is recognized as an input source. Off—all sources selected in Image | Advanced | Input Source are recognized as an input source. High Altitude Adjust the fan speed to reflect the environment.
Page 40: Keypad Lock
User Controls Options Keypad Lock Lock the buttons on the projector top panel. On—a warning message displays to confirm keypad lock. Off—projector keypad functions as normal. Background Color Select the desired background color for the projected image when no source is detected.
Page 41: Direct Power On
Off— the projector must be powered on as normal. Auto Power Off Set the Auto Power Off interval. The projector powers off the lamp after 30 minutes of no signal by default. The following warning is displayed 60 seconds before power off.
Page 42: Lamp Hour
User Controls Options | Lamp Setting Lamp Hour Displays the number of hours the lamp has been active. This item is for display only. Lamp Reminder Enable or disable the lamp life span reminder. On—a warning message displays when remaining lamp life is less than 30 hours.
Page 43 Options | Lamp Setting Lamp Reset After replacing the lamp, reset the lamp counter to accurately reflect the new lamp’s life span. 1. Select Lamp Reset. A confirmation screen displays. 2. Select Yes to reset the lamp counter to zero. User Controls English...
Page 44: Appendices
Appendices Troubleshooting If you experience a problem with your projector, please refer to the following information. If a problem persists, please contact your local reseller or service center. Image Problems No image appears on-screen Ensure all the cables and power connections are correctly and securely connected as described in the Installation section.
Page 45: Image Is Unstable Or Flickering
Image is out of focus Make sure the lens cap is removed. Adjusts the Focus Ring on the projector lens. Make sure the projection screen is between the required distances from the projector. See pages 17-18 for more information. Appendices IBM/Lenovo � [Fn]+[F7]...
Page 46: Intermission Problems
16:9 format in OSD. If you play 4:3 format DVD title, please change the format as 4:3 in projector OSD. If the image is still stretched, you will also need to adjust the aspect ratio...
Page 47: Projector Status Indication
Projector Status Indication Error Code Message Thermal break status error Fan1 error (Power Fan) Fan2 error (Lamp Fan) Fan3 error (Blower Fan) Lamp door sensor detect high DMD error Color wheel error Appendices Power LED/ Lamp LED/ Flashes Flashes English...
Page 48: Remote Control Problems
Check the operating angle for the remote control is approximately ±15°. Make sure there are no obstructions between the remote control and the projector. Move to within 7m (23 ft) of the projector. Make sure the batteries are inserted correctly. Replace weak batteries in the remote control.
Page 49: Replacing The Lamp
Avoid touching the glass surface of the new lamp, doing so may shorten its operation life. Warning: Be sure to turn off and unplug the projector at least an hour before replacing the lamp. Failure to do so could result in a severe burn.
Page 50: Cleaning The Projector
Warning: Be sure to turn off and unplug the projector at least an hour before cleaning. Failure to do so could result in a severe burn. Use only a dampened cloth when cleaning. Do not allow water to enter the ventilation openings on the projector.
Page 51: Compatibility Modes
Compatibility Modes Computer Compatibility Signal Resolution NTSC PAL/SECAM VESA 640 x 350 640 x 400 720 x 350 720 x 400 720 x 576 640 x 480 SVGA 800 x 600 832 x 624 1024 x 576 1024 x 768 1152 x 864 1152 x 870 HD720...
Page 52 Appendices Apple Mac Compatibility Resolution 800x600 800x600 800x600 800x600 1024x768 1024x768 1024x768 1024x768 1280x720 1280x720 1280x720 1280x768 1280x768 1280x768 1280x800 1280x1024 1280x1024 1680x1050 1920x1200 English Macbook Pro Macbook (Intel) Analog Analog Power Mac Power Mac Analog Analog...
Page 53: Ceiling Installation
Ceiling Installation To prevent damage to your projector please use the recommended mounting package for installation. To ensure compliance, only use a UL Listed ceiling mount and Damage to the screws that meet the following specifications: projector as a result of...
Page 54: Optoma Global Offices
Appendices Optoma Global Offices For service or support please contact your local office. 715 Sycamore Drive Milpitas, CA 95035, USA Tel : 408-383-3700 www.optomausa.com Canada 5630 Kennedy Road, Mississauga, ON, L4Z 2A9, Canada Tel : 905-361-2582 www.optoma.ca Europe 42 Caxton Way, The Watford Business Park Watford, Hertfordshire, WD18 8QZ, UK Tel : +44 (0) 1923 691 800 www.optoma.eu...
Page 55 Scandinavia Grev Wedels Plass 2 3015 Drammen, Norway Tel : +47 32 26 89 90 Service : info@optoma.no Latin America 715 Sycamore Drive Milpitas, CA 95035, USA Tel : 408-383-3700 www.optoma.com.br Korea WOOMI TECH.CO.,LTD 4F,Minu Bldg.3.tw3-14, Kangnam-Ku, seoul,135-815, KOREA Tel : +82+2+34430004 Japan 東京都足立区綾瀬3-25-18 株式会社オーエスエム...
Page 56: Regulation & Safety Notices
Appendices Regulation & Safety notices This appendix lists the general notices of your projector. FCC notice This device has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
Page 57: Operation Conditions
Operation conditions This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. Notice: Canadian users This Class B digital apparatus complies with Canadian ICES-003.
