Hardware Overview Front Panel Power LED Indicates the unit is powered on. The Run LED will flash when performing a self- test/booting up and light solid green if the self-test or bootup fails. The Alarm LED will light solid red if the self-test or Alarm bootup fails.
Rear Panel Line Ports Connect to your original telephone line on the wall jack with RJ-11 cable. LAN Port Connect to your Ethernet enabled computers using Ethernet cabling. Connects to your broadband modem using an Ethernet WAN Port cable. Reset This is used to reset the unit to the factory default settings.
Page 4
Modem and Computer If your computer connects directly to a DSL or Cable modem and does not connect to a router, follow the steps below to install your DVG-6004S. For any other configuration, please refer to the user manual located on the CD-ROM.
Page 5
Connecting the DVG-6004S directly to a Modem and Computer (continued) e. Attach one end of the Ethernet Cable provided in this package to the LAN or Ethernet Port on the Cable/DSL Modem. Attach the other end of the provided Ethernet Cable to the WAN Port of the DVG-6004S.
PPPoE Configuration Some Internet Service providers use PPPoE as their method of connecting clients. If you have a PPPoE connection, you must follow the steps below to complete the configuration of your hardware. If you are unsure of your connection type or do not know your username and password, please check with your Internet Service Provider.
Page 7
Once the unit reboots you will see the message. Check to see if the status LED light goes from blinking green to solid green on the front panel of the DVG-6004S. The information found on the Device Information page is necessary for VoIP service...
