Samsung 5500 Quick Start Manual

Attach the TV to Connect video
the Stand devices
Step Step
1
Warning: Screens can be damaged
from direct pressure when handled
incorrectly. We recommend lifting the
TV by the edges, as shown.
Step 1 Attach the TV to the Stand
1A
REQUIRED TOOLS: a Phillips head screwdriver and a soft, flat surface larger than the TV
(such as the box).
1C
1E
1 2

QUICK START

GUIDE
BN68-05034A-04
Power on and
Using the Smart
start the initial
Touch Control
setup
Step Step
2 3
Lay the TV on a soft surface, screen side down.
Use the packing material to protect the screen.
Fit the stand and mount together, making sure
the notch on the mount aligns with the stand.
Holding the stand parallel to the screen, slide
the stand into the notches on the back of the
TV.
3
Welcome to your new Smart TV!
The following instructions cover assembling, connecting, and setting up your new TV. Make
sure you have the accessories listed below.
Included in this box
Remote Control
Smart Touch Control
4
Batteries (AAA x 2)
Also included: User manual, regulatory guide, 3D Active Glasses,
ferrite core
1B
Base
1D
1F
Stand Parts and Cables
Stand Mount Power cord
IR extender Cable manager
Find the stand base and screws in the box and
set aside.
x 8
Screws
Insert 4 screws and secure the stand to the
mount.
51 inch models: x4 (M4 X L12)
60 inches and above models:
x4 (M4 X L10)
Insert 4 screws and secure the stand to the TV.
x4 (M4 X L12)
