Basic Operating Instructions

Digital Camera

DMC-FX75
Model No.
Before use, please read these instructions completely.
Please also refer to the
Operating Instructions (PDF
format) contained on the
CD-ROM (supplied).
You can learn about advanced operation
methods and check the Troubleshooting.
GN
VQT2V63

Advertisement

Table of Contents
loading

Related Manuals for Panasonic DMC-FX75

Summary of Contents for Panasonic DMC-FX75

  • Page 1: Basic Operating Instructions

    Basic Operating Instructions Digital Camera DMC-FX75 Model No. Before use, please read these instructions completely. Please also refer to the Operating Instructions (PDF format) contained on the CD-ROM (supplied). You can learn about advanced operation methods and check the Troubleshooting.

  • Page 2: Information For Your Safety

    Dear Customer, We would like to take this opportunity to thank you for purchasing this Panasonic Digital Camera. Please read these Operating Instructions carefully and keep them handy for future reference. Please note that the actual controls and components, menu items, etc. of your Digital Camera may look somewhat different from those shown in the illustrations in these Operating Instructions.
  • Page 3 ∫ About the battery pack CAUTION Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer’s instructions. • Do not heat or expose to flame. •...
  • Page 4 ∫ Cautions for Use • Do not use any other AV cables except the supplied one. • Always use a genuine Panasonic HDMI mini cable (RP-CDHM15, RP-CDHM30; optional). Part numbers: RP-CDHM15 (1.5 m), RP-CDHM30 (3.0 m) • Do not use any other USB connection cables except the supplied one.
  • Page 5 -If you see this symbol- Information on Disposal in other Countries outside the European Union This symbol is only valid in the European Union. If you wish to discard this product, please contact your local authorities or dealer and ask for the correct method of disposal.

  • Page 6: Table Of Contents

    Contents Information for Your Safety ................2 Standard Accessories ................... 7 Names of the Components ................8 How to Use the Touch Panel ..............10 Charging the Battery ................... 12 About the Built-in Memory/the Card ............14 Inserting and Removing the Card (optional)/the Battery ......15 Setting Date/Time (Clock Set)..............

  • Page 7: Standard Accessories

    Standard Accessories Check that all the accessories are supplied before using the camera. Product numbers correct as of June 2010. These may be subject to change. Battery Pack (Indicated as battery pack or battery in the text) Charge the battery before use. Battery Charger (Indicated as battery charger or DMW-BCF10E...

  • Page 8: Names Of The Components

    Names of the Components Flash Lens Self-timer indicator AF assist lamp Hand strap eyelet • Be sure to attach the hand strap   when using the camera to ensure that you will not drop it. Touch panel/LCD monitor [REC]/[PLAYBACK] selector switch [MODE] button [MENU] button VQT2V63 (ENG)
  • Page 9 When using an AC adaptor, ensure that the Panasonic DC coupler (DMW-DCC4; optional) and AC adaptor (DMW-AC5G; optional) are used. • Always use a genuine Panasonic AC adaptor (DMW-AC5G; optional). • When using an AC adaptor, use the AC cable supplied with the AC adaptor.

  • Page 10: How To Use The Touch Panel

    How to Use the Touch Panel This touch panel is a type that detects pressure. Operation or settings are performed by directly touching the icons displayed on the LCD monitor (touch panel) or by moving while touching the touch panel (dragging) using your fingers or the supplied stylus pen. Touch the screen Drag To touch and release the touch panel.
  • Page 11 Note • The touch panel does not operate when the LCD monitor is turned off. • If you use a commercially available liquid crystal protection sheet, please follow the instructions that accompany the sheet. (Some liquid crystal protection sheets may impair visibility or operability.) •...

  • Page 12: Charging The Battery

    The camera has a function for distinguishing batteries which can be used safely. The dedicated battery (DMW-BCF10E) supports this function. The only batteries suitable for use with this unit are genuine Panasonic products and batteries manufactured by other companies and certified by Panasonic.

  • Page 13: Charging Time

    Normal Picture Mode • Temperature: 23 oC/Humidity: 50%RH when LCD monitor is on. • Using a Panasonic SD Memory Card (32 MB). • Using the supplied battery. • Starting recording 30 seconds after the camera is turned on. (When the Optical Image Stabilizer function is set to [AUTO].)

  • Page 14: About The Built-In Memory/The Card

    (4 GB to 32 GB) • Check that the PC and other equipment are compatible when using the SDXC Memory Cards. SDXC Memory Card http://panasonic.net/avc/sdcard/information/ (48 GB, 64 GB) SDXC.html • Only cards bearing the SDHC logo (indicating that the card conforms to SD video standards) may be used as 4 GB to 32 GB cards.

  • Page 15: Inserting And Removing The Card (Optional)/The Battery

    Inserting and Removing the Card (optional)/the Battery • Check that this unit is turned off. • We recommend using a Panasonic card. Slide the release lever in the direction of the arrow and open the card/battery door. • Always use genuine Panasonic batteries (DMW-BCF10E).

  • Page 16: Setting Date/Time (Clock Set)

    Setting Date/Time (Clock Set) • The clock is not set when the camera is shipped. Turn the camera on. Touch [CLOCK SET]. Touch the items you wish to set (Year/Month/Day/Hours/Minutes), and set using [3]/[4]. • Touch [CANCEL] to cancel the date and time settings without setting a date and time.

  • Page 17: Setting The Menu

    Setting the Menu This section describes how to select the [REC] Mode menu settings, and the same setting can be used for the [MOTION PICTURE] Mode menu, [PLAYBACK] Mode menu and [SETUP] menu as well. Example: Setting [AF MODE] from [ ] to [ ] in the Normal Picture Mode Ø...

  • Page 18: Selecting The [Rec] Mode

    Mode switching Selecting the [REC] Mode Turn the camera on. A [REC]/[PLAYBACK] selector switch B [MODE] button Slide the [REC]/[PLAYBACK] selector switch to [!], and then press [MODE]. Touch the mode. ∫ List of [REC] Modes [INTELLIGENT AUTO] ¦ The subjects are recorded using settings automatically selected by the camera. [NORMAL PICTURE] The subjects are recorded using your own settings.

  • Page 19: Taking Pictures Using The Automatic Function Ñ : Intelligent Auto Mode)

    ñ [REC] Mode: Taking Pictures Using the Automatic Function : Intelligent Auto Mode) ñ The camera will set the most appropriate settings to match the subject and the recording conditions so we recommend this mode for beginners or those who want to leave the settings to the camera and take pictures easily.

  • Page 20: Scene Detection

    Scene Detection When the camera identifies the optimum scene, the icon of the scene concerned is displayed in blue for 2 seconds, after which its colour changes to the usual red. > [i-PORTRAIT] ¦ [i-SCENERY] [i-MACRO] • [i-NIGHT PORTRAIT] Only when [ ] is selected [i-NIGHT SCENERY] [i-SUNSET]...

  • Page 21: Recording Motion Pictures

    ñ· ¿ [REC] Mode: Recording Motion Pictures This can record high definition motion pictures compatible with the AVCHD format or motion pictures recorded in Motion JPEG. Audio will be recorded in monaural. Slide the [REC]/[PLAYBACK] selector switch to [!], and then press [MODE].

  • Page 22: Playing Back Pictures ([Normal Play])

    ¸ [PLAYBACK] Mode: Playing Back Pictures ([NORMAL PLAY]) Slide the [REC]/[PLAYBACK] selector switch A to [(]. Forward or rewind the image by dragging the screen horizontally. • After selecting the motion picture, touch ] to start playback. ¸ [PLAYBACK] Mode: Deleting Pictures Once deleted, pictures cannot be recovered.

  • Page 23: Reading The Operating Instructions (Pdf Format)

    Reading the Operating Instructions (PDF format) • You have practised the basic operations introduced in these operating instructions and want to progress to advanced operations. • You want to check the Troubleshooting. In these kinds of situations refer to Operating Instructions (PDF format) contained on the CD-ROM (supplied).
  • Page 24 OS from the following Web Site. http://get.adobe.com/reader/otherversions ∫ To uninstall the Operating Instructions (PDF format) Delete the PDF file from the “Program Files\Panasonic\Lumix\” folder. • When the contents in the Program Files folder cannot be displayed, click the [Show the contents of this folder] to display them.

  • Page 25: Specifications

    Specifications Digital Camera: Information for your safety Power Source: DC 5.1 V Power Consumption: 1.2 W (When recording) 0.6 W (When playing back) Camera effective pixels: 14,100,000 pixels Image sensor: 1/2.33q CCD, total pixel number 14,500,000 pixels, Primary colour filter Lens: Optical 5kzoom, fl4.3 mm to 21.5 mm (35 mm film camera equivalent: 24 mm to 120 mm)/F2.2 to F5.9...
  • Page 26 Burst recording Burst speed: Approx. 1.8 pictures/second Number of recordable pictures: Max. 5 pictures (Standard), max. 3 pictures (Fine). Hi-speed burst Burst speed: Approx. 10 pictures/second (Speed priority) Approx. 6 pictures/second (Image priority) [3M (4:3), 2.5M (3:2), 2M (16:9) or 2.5M (1:1) is selected as the picture size.] Number of recordable...
  • Page 27 Approx. 165 g (with card and battery) Approx. 144 g (excluding card and battery) Operating 0 oC to 40 oC temperature: Operating humidity: 10%RH to 80%RH Battery Charger (Panasonic DE-A60A): Information for your safety Input: 110 V to 240 V 50/60 Hz, 0.2 A Output: 4.2 V...
  • Page 28 HDMI Licensing LLC in the United States and other countries. • HDAVI Control™ is a trademark of Panasonic Corporation. • QuickTime and the QuickTime logo are trademarks or registered trademarks of Apple Inc., used under license therefrom.
