Page 3 VÄLKOMMEN! We trust that you will enjoy many years of safe driving in your Volvo, an cle if you may be affected by alcohol, medication or any impairment that automobile designed with your safety and comfort in mind. To help get could hinder your ability to drive.
Page 4: Table Of Contents
CONTENTS INTRODUCTION SAFETY Contacting Volvo On-board digital owner's manual General safety information Volvo On Call Roadside Assistance Navigating in the digital owner's manual Occupant safety Additional information about your vehicle Glass Reporting safety defects Volvo and the environment Technician certification...
Page 5 INSTRUMENTS AND CONTROLS Lower child seat attachment points Instruments and controls Voice control Top tether anchors Trip computer Using voice commands Integrated booster cushion* Displaying trip computer information Voice control for cell phones Displaying trip statistics Voice control for radio and media Raising the integrated booster cushion* ®...
Page 6 CLIMATE Passenger compartment lighting Easy access to and from the driver seat Climate control system Home safe lighting Rear seats Perceived temperature Approach lighting Adjusting the second row head restraints Climate system sensors Messages in the instrument panel Air quality Folding the rear seat backrests* and center display Driver profiles...
Page 7 LOADING AND STORAGE LOCKS AND ALARM Air distribution table Cargo space Locks and remote keys Ski hatch* Immobilizer Loading Changing the remote key's battery Remote key Passenger compartment storage spaces Using the glove compartment Remote key's range Tunnel console Red Key* Grocery bag holder Detachable key blade Load anchoring eyelets...
Page 8 DRIVER SUPPORT Start and lock system type designations Driver support systems Switching between Cruise Control and Adaptive Cruise Control* Adjustable steering force* Distance Alert* Electronic Stability Control (ESC) Using Distance Alert* Electronic Stability Control (ESC) sport mode Distance Alert* limitations Electronic Stability Control (ESC) Adaptive Cruise Control (ACC)* symbols and messages...
Page 9 Setting a Pilot Assist-1 time interval City Safety limitations Run-off Mitigation* symbols and messages Deactivating/resuming Pilot Assist-1 City Safety symbols and messages Park Assist* Automatic braking with Pilot Assist-1 Rear Collision Warning (RCW) Activating/deactivating Park Assist Pilot Assist-1 limitations Blind Spot Information (BLIS)* Park Assist limitations Pilot Assist-2* Blind Spot Information (BLIS)* On/Off...
Page 10 STARTING AND DRIVING INFOTAINMENT Starting and driving Driving with a trailer The infotainment system Brakes Detachable trailer hitch Apps (applications) Brake functions Trailer Stability Assist (TSA) Sound settings Auto-hold brake function Ignition modes Radio Brake assist system Battery drain Radio settings Braking effect after a collision Starting the engine RBDS radio...
Page 11 WHEELS AND TIRES Handling text messages Tethering (Wi-Fi sharing) Tires Phone settings Deleting Wi-Fi networks Tire sidewall designations Text message settings Wi-Fi technology and security Wheel (rim) designations ® Vehicle modem settings Tire terminology Connecting a Bluetooth device Infotainment system license information Tire direction of rotation Connecting a device via the AUX/USB socket...
Page 12 MAINTENANCE AND SERVICING SPECIFICATIONS Volvo's service program Hoisting the vehicle Label information System updates Opening and closing the hood Dimensions Remote updates Engine compartment overview Weights Vehicle status Engine oil Air conditioning refrigerant Booking service and repairs Checking and refilling engine oil...
Page 13 INDEX Index...
Page 15 INTRODUCTION...
Page 16: Introduction
Use the following contact information if you Your new Volvo comes with a four year ON would like to get in touch with Volvo in the Uni- CALL roadside assistance. Volvo Cars' website and support site provide ted States or Canada.
Page 17: Volvo And The Environment
See a trained and qualified Volvo service • technician as soon as possible for inspection On-board digital owner's manual (p. 51) Volvo was the first in the world to introduce into if the check engine (malfunction indicator) production a three-way catalytic converter with a •...
Page 18: Owner's Manual And The Environment
FSC (Forest Stewardship • City Safety™ (p. 306) ® help make driving and traveling in a Volvo safer. Council ) certified forests and other responsible • Driving lane assistance (p. 330) sources.
Page 19: Sensus
Sensus Sensus provides an intelligent interface and Internet-connected service with an intuitive navi- Sensus is the core of your personal Volvo experi- gation structure that offers access to relevant ence and provides information, entertainment information when it is needed, with minimal dis- and features that make owning your vehicle eas- tractions.
Page 20 INTRODUCTION Information when it's needed, where it's needed Information is presented in different displays depending on how it should be prioritized (generic illustration) Head-up-display* ately, such as traffic warnings, speed information Center display and navigation. Road sign information and incom- ing phone calls are also displayed here.
Page 21 INTRODUCTION • Many of the vehicle's main functions are con- Head-up display (HUD)* (p. 116) trolled from the center display, a touchscreen that • Instrument panel (p. 126) reacts to taps or other gestures. The number of • Voice control (p. 119) physical buttons is thereby minimized.
Page 22: Owner's Manual In Mobile Devices
This QR code will take you directly to the app or you can search for "Volvo manual" in the App Store or Google Play. The mobile app is available at the App Store and Google...
Page 23: Options, Accessories And The On- Board Diagnostic (Obdii) Socket
In some cases it may formed only by a trained and qualified Volvo be difficult or impossible to comply with WARNING service technician. these requirements. Modifications to the...
Page 24: Finding Owner's Information
Volvo service technician before ter display, as a mobile app and on Volvo's sup- Volvo Cars takes no responsibility for the con- installing any accessory in or on your vehicle.
Page 25 (or a new owner's manual supplement) Related information Navigation between the various articles in the can be ordered through a Volvo retailer. • Owner's manual in mobile devices (p. 20) owner's manual is designed to provide easy •...
Page 26: Driver Distraction
Your new Volvo is, or someone unfamiliar with your vehicle. programmed presets to make radio use can be, equipped with many feature-rich enter- •...
Page 27: Volvo Structural Parts Statement
Due to the above, Volvo Car USA does not sup- port the use of aftermarket, alternative or any- thing other than original Volvo parts for collision repair.
Page 28: Crash Event Data
Whether or not the driver and passenger them to diagnose and rectify any faults that have safety belts were buckled/fastened; occurred in the vehicle and to enable Volvo to ful- • fill legal and other regulatory requirements. Infor- How far (if at all) the driver was depressing mation thus registered in the vehicle is registered the accelerator and/or brake pedal;...
Page 29: Volvo Id
3. Register a personal email address and then (p. 436) follow the instructions that will be sent auto- • matically to this address. Connecting to the Internet (p. 434) These services vary and may be subject to change. Consult your Volvo retailer.
Page 30: Center Display Overview
INTRODUCTION Center display overview Many of the vehicle's functions are controlled from the center display. Three of the center display's basic views. Swipe to the right/left to access the Function/App view (generic illustration)
Page 31 INTRODUCTION Function view: vehicle functions can be acti- The extra sub-view: the most recently used vated/deactivated by tapping. Certain func- apps/vehicle functions that do not belong in tions are called "trigger functions", which any of the other sub-views are listed here. Camera open settings windows, e.g., Tap the sub-view to expand it.
Page 32: Changing Center Display Settings
INTRODUCTION Changing center display settings which can increase readability in strong ambient lighting. The center display activates automatically when the driver's door is opened. Settings can be These alternatives are always available and do made for e.g., sounds, background and themes. not shift automatically according to changes in ambient lighting.
Page 33: Using The Center Display Keyboard
INTRODUCTION Using the center display keyboard A keyboard can be used on the center display to enter characters and search for e.g., destina- tions using the navigation system, adding con- tacts in phone book, etc. It is also possible to use handwriting on the screen.
Page 34 INTRODUCTION Keyboard function buttons (the appearance may vary depending on language settings, context, etc.) Field for possible search hits. The word word to select it. The keyboard may not sup- The characters that can be entered are lan- changes as new letters are added. Scroll in port all language selections, in which case guage-dependent (see point 7).
Page 35 INTRODUCTION Several buttons (depending on the context below). Tap to display a list of possible lan- 3. Select and one or more of the languages in for which the keyboard is being used) will be guages and tap a language to use it. the list.
Page 36 INTRODUCTION Special characters Entering characters 1. Enter a handwritten character (1) using a fin- gertip or by holding e.g., a pen near the screen. > Several character suggestions will appear (3). The most likely character will be at the top of the list. CAUTION Do not touch the screen with sharp objects because this could cause scratches.
Page 37 INTRODUCTION Erasing/changing handwritten characters New lines Erase a character by swiping over the handwriting area Create a new line by drawing above the characters as shown in the illustration Characters can be erased/changed in several Related information ways: • Using the center display (p. 45) •...
Page 38: Function View Buttons
INTRODUCTION Function view buttons Different types of buttons on-screen function buttons. From the Home view, swipe from left to right on the screen to There are three different types of vehicle function The Function view, which is one of the center come to the Function view.
Page 39 INTRODUCTION The yellow triangle indicates that the function is not working correctly Related information • Center display overview (p. 28) • Navigating in the center display's views (p. 38) • Categories in Settings view (p. 110)
Page 40: Navigating In The Center Display's Views
INTRODUCTION Navigating in the center display's sub-view contains the most recently used app/ NOTE views vehicle function that is not related to the other • In Home view's standard mode (reached three sub-views. For example, if the most recently There are 5 different basic views in the center by pressing the Home button briefly), an used app/vehicle function is a music app, the display: Home view, Top view, Climate view, App...
Page 41 INTRODUCTION Expanding/minimizing a sub-view The Media sub-view shown minimized (left) and expanded (right) • To expand a sub-view, tap the screen any- where in the sub-view to access the respec-...
Page 42 INTRODUCTION tive app's basic functions. When a sub-view is expanded, the Home view's fourth sub- view will temporarily not be displayed. • To minimize a sub-view, tap anywhere on the screen. Opening/closing a sub-view in full-screen mode Navigation The extra sub-view and the sub-view can be opened in full-screen mode to show addi- tional information and possible settings.
Page 43 INTRODUCTION App view ignition is being started/switched off or when a When applicable, swipe downward to scroll in the message is displayed on the screen. list of apps (depending on the number of apps currently running). Going to Top view from an app To move an app, press and hold it.
Page 44 INTRODUCTION Swipe the screen from left to right to access Function view from Home view. From Function view, you can activate/deactivate various vehicle Drive Modes Speed limit functions such as adaptation Park Assist When applicable, swipe upward to scroll in the list of functions (depending on the number of func- tions).
Page 45: Symbols In The Center Display Status Bar
INTRODUCTION • Symbols in the center display status Warning symbols in the instrument panel Symbol Meaning (p. 134) Remote diagnostics active. • The following table provides an overview of the Messages in the instrument panel and center symbols used in the center display's status bar. display (p.
Page 46: Changing Settings In Different Types Of Apps
Basic apps A number of apps are standard and are part of FM Radio Volvo Sensus, such as To change settings in a basic app: Phone 1. Open the app, for example , either on the home screen or full-screen from App view.
Page 47: Using The Center Display
INTRODUCTION Using the center display The screen reacts differently depending on CAUTION whether the user taps, drags or swipes on the Many of the vehicle's functions can be con- Do not touch the screen with sharp objects screen. This makes it possible to move between trolled and settings can be made from the because this could cause scratches.
Page 48 INTRODUCTION Procedure Gesture Result Drag Moves between screen views, scrolls in a list, text or a view. Press and hold to drag apps or objects in a list. Swipe Moves between screen views, scrolls in a list, text or a view Stretch Zooms in.
Page 49 INTRODUCTION Turning off and reactivating the center Moving apps and vehicle function 2. Reactivate by pressing the Home button display briefly. buttons > The view that was displayed when the Apps and function buttons can be moved and screen was turned off will be displayed organized in their respective views.
Page 50 INTRODUCTION Digital controls are available for many of the vehi- cle's functions. For example, to set the tempera- ture: • Drag the control to the desired temperature • − to raise or lower the temperature incrementally, or • Tap the desired temperature on the control Related information •...
Page 51: Using The Owner's Manual
There are several displays in the vehicle that mation and how to contact Volvo if help is show messages generated by various systems required. and functions in the vehicle. The appearance of...
Page 52 INTRODUCTION Risk of damage to the vehicle White ISO symbols and white text/image on a Arrows containing letters are used to indi- black background. These decals provide general cate movement. information. If there are no illustrations associated with a step-by-step list, the steps in the procedure are NOTE indicated by ordinary numbers.
Page 53: On-Board Digital Owner's Manual
INTRODUCTION On-board digital owner's manual Continues on next page Symbols and their descriptions This symbol can be found at the lower right When printed owner's information refers to digi- Takes you to the owner's corner to indicate that the current topic continues tal owner's information, this is the on-board infor- information start page.
Page 54 INTRODUCTION Navigating in the digital owner's Symbols and their descriptions Symbols and their descriptions manual Exterior/interior views of Leads to short instructional The digital on-board owner's manual is the vehicle in which certain videos for various vehicle accessed from the center display. The contents areas/components are functions.
Page 55 INTRODUCTION Searching using categories Saving/deleting favorites 1. Tap Exterior Interior followed by The articles in the owner's Save an article as a favorite by tapping the star > Exterior/interior views will be displayed manual are structured in main ) at the upper right when an article is open. with hotspots, which lead to relevant arti- and sub-categories.
Page 56: Glass
Volvo at peak operating con- Related information Laminated glass symbol • dition.
Page 57 SAFETY...
Page 58: General Safety Information
Our concern for safety dates back to 1927 when sensors in the vehicle that react and trigger the first Volvo rolled off the production line. Related information safety systems such as Roll Stability Control, air- Three-point seat belts (a Volvo invention), safety •...
Page 59: Reporting Safety Defects
Related information tation, Washington D.C. 20590. should immediately inform Transport Canada in • Recall information (p. 58) addition to notifying Volvo Cars of Canada Corp. • Reporting safety defects (p. 57)
Page 60: Recall Information
Transport Canada can be contacted at: 1-800-333-0510 The seat belt should always be worn during On our website, select the tab YOUR VOLVO and pregnancy. However, it is crucial that it be worn Teletypewriter (TTY): 613 990-4500 the heading RECALL INFORMATION will be dis- correctly.
Page 61: Whiplash Protection System
Function must be inspected by a trained and quali- In the event of certain rear-end collisions, the fied Volvo service technician, even if the hinges and brackets of the front seat backrests seats appear to be undamaged. Certain components in the WHIPS system may are designed to change position slightly to allow need to be replaced.
Page 62: Pedestrian Protection System (Pps)
In certain types of frontal impacts with a pedes- • In order to help PPS to function properly, trian, sensors in the front bumper will react and the use of Volvo original windshield wiper trigger PPS. arms/parts is recommended. •...
Page 63: Seat Belts
Volvo service technician only. seat determined by age, weight and height. sion. Some or all of the pretensioners will be •...
Page 64: Buckling And Unbuckling Seat Belts
SAFETY Buckling and unbuckling seat belts The electric pretensioner positions the occupant 2. Insert the latch plate into the receptacle. The in the seat to help reduce the risk of striking the seat belt retractor is normally "unlocked" and Seat belts should be used by all occupants in interior of the passenger compartment and you can move freely, provided that the shoul- the vehicle when it is in motion.
Page 65 SAFETY 3. The height of the seat belts in the front seats 4. Tighten the lap section of the seat belt by can be adjusted. The height of the shoulder pulling the diagonal section upward toward section of the seat belt must be correctly the shoulder.
Page 66: Door And Seat Belt Reminders
SAFETY Door and seat belt reminders Unbuckling the seat belt Seat belt reminder To remove the seat belt, press the red section on The door and seat belt reminders are intended the seat belt receptacle. Before exiting the vehi- to alert all occupants of the vehicle that their cle, check that the seat belt retracts fully after seat belts should be buckled before the vehicle being unbuckled.
Page 67: Airbag System
If necessary seek medical attentIon. while you are driving, have the vehicle cle is in motion. The reminders will disappear inspected by a trained and qualified Volvo when the seat belt has been buckled again service technician as soon as possible.
Page 68: Driver/Passenger Side Airbags
SAFETY Driver/passenger side airbags The location of the front airbags is indicated by WARNING SRS AIRBAG embossed on the steering wheel The front airbags supplement the three-point • The airbags in the vehicle are designed to pad and above the glove compartment, and by seat belts.
Page 69 SRS system, please contact a trained and severe, but severe enough to present a • The amount of damage to the bodywork qualified Volvo service technician or Volvo cus- clear injury risk, the airbags are triggered does not reliably indicate if the airbags tomer support: at partial capacity.
Page 70 Never try to open the airbag cover on the steering wheel or the passenger's side Airbag decals dashboard. This should only be done by a Passenger's side airbag decal trained and qualified Volvo service techni- cian. WARNING • Failure to follow these instructions can •...
Page 71: Occupant Weight Sensor
Occupant Weight Sensor should • be inspected by a trained and qualified Volvo a front passenger takes his/her weight off of service technician as soon as possible. the seat for a period of time, Occupant Weight Sensor (OWS) indicator light •...
Page 72 Volvo at: out by an a trained and qualified Volvo collision anytime the system senses that a per- service technician. son of adult size is sitting properly in the front In the USA •...
Page 73 SAFETY Related information WARNING WARNING • Airbag system (p. 65) • • No objects that add to the total weight on Keep the following points in mind with the seat should be placed on the front respect to the OWS system. Failure to passenger's seat.
Page 74: Side Impact Airbags
Volvo service technician. severity, angle, speed and point of impact. • In order for the SIPS airbag to provide its...
Page 75: Inflatable Curtains
IC system. This should be and the occupant of the outboard rear seating reduced. done only by a trained and qualified Volvo positions in certain side impact collisions. service technician. If the vehicle has been involved in a collision, the •...
Page 76: Starting Or Moving A Vehicle In Safety Mode
It must be trans- ported on a flatbed tow truck to a trained and qualified Volvo service technician for inspec- 2. Turn the start knob to STOP and release it. tion/repairs. 3. Try to start the vehicle.
Page 77: Child Safety
A specially designed and tested booster cushion LATCH attachments, which make it more conven- erly restrained. A child restraint system can help and backrest can be obtained from your Volvo ient to install child seats. protect a child in a vehicle. Here's what to look retailer.
Page 78 Volvo's recommendations • Why does Volvo believe that no child should sit in Volvo strongly recommends that everyone in the front seat of a car? It's quite simple really. A the vehicle be properly restrained.
Page 79: Child Restraints
SAFETY Child restraints Suitable child restraints should always be used when children travel in the vehicle. Child restraint systems Convertible seat Booster cushion WARNING WARNING A child seat should never be used in the front Always refer to the child restraint manufactur- passenger seat of any vehicle with a front er's instructions for detailed information on Infant seat...
Page 80: Infant Seats
A small child's head represents a consid- erable part of its total weight and its neck Do not use child safety seats or child booster is still very weak. Volvo recommends that cushions/backrests in the front passenger's children up to age 4 travel, properly seat.
Page 81 SAFETY WARNING A child seat should never be used in the front passenger seat of any vehicle with a front passenger airbag – not even if the "Passen- ger airbag off" symbol near the rear-view mir- ror is illuminated (on vehicles equipped with Occupant Weight Sensor).
Page 82: Convertible Seats
SAFETY Convertible seats NOTE WARNING Suitable child restraints should always be used The locking retractor will automatically It should not be possible to move the child when children (depending on their age/size) are restraint (child seat) more than 1 in. (2.5 cm) release when the seat belt is unbuckled and seated in the vehicle.
Page 83 4. Pull the shoulder section of the seat belt out still very weak. Volvo recommends that children up to age 4 travel, properly as far as possible to activate the belt's auto- restrained, facing rearward.
Page 84 SAFETY Related information NOTE WARNING • ISOFIX/LATCH lower anchors (p. 84) The locking retractor will automatically It should not be possible to move the child • Top tether anchors (p. 86) restraint (child seat) more than 1 in. (2.5 cm) release when the seat belt is unbuckled and in any direction along the seat belt path.
Page 85: Booster Cushions
SAFETY Booster cushions Related information 3. Fasten the seat belt by inserting the latch • plate into the buckle (lock) until a distinct ISOFIX/LATCH lower anchors (p. 84) Securing a booster cushion click is audible. • Top tether anchors (p. 86) •...
Page 86: Isofix/Latch Lower Anchors
4. Firmly tension the lower child seat straps according to the manufacturer's instructions. WARNING Volvo's ISOFIX/LATCH anchors conform to FMVSS/CMVSS standards. Always refer to the child restraint system's manual for weight and size ratings. Fasten the attachment correctly to the ISOFIX/LATCH...
Page 87: Instruments And Controls
SAFETY • Lower child seat attachment points Occupant weight sensor (p. 69) The vehicle is equipped with lower attachment points for child seats in the rear seat. The lower attachment points are intended for use with rear-facing child restraints. Always follow the child restraint manufacturer's installation instructions when attaching a child restraint to these attachment points.
Page 88: Top Tether Anchors
– Related information Firmly tension all straps. • Child safety (p. 75) Your Volvo is equipped with child restraint top Refer also to the child seat manufacturer's • tether anchorages for all three seating positions Child restraints (p. 77) instructions for information on securing the child in the rear seat.
Page 89: Integrated Booster Cushion
SAFETY Integrated booster cushion* WARNING Volvo's optional integrated booster cushions are DEATH or SERIOUS INJURY can located in the rear seat's outer positions and are occur designed to raise the child higher so that the • Follow all instructions on this shoulder strap crosses over the child's collar- bone, not over the neck.
Page 90: Raising The Integrated Booster Cushion
SAFETY • Raising the integrated booster Canadian models The integrated two-stage booster cushion is cushion* set in the correct position according to the Stage 1 Stage 2 child's height and weight The integrated booster cushions in the rear • Weight 22 –...
Page 91 SAFETY Upper position (assuming the booster cushion is already in the lower position): Press the booster cushion rearward to lock it Lift the front edge of the booster cushion in position. and press it rearward toward the backrest to lock it in position. Press the button to release the booster cushion.
Page 92 This work should be performed by a trained and qualified Volvo service technician only. NOTE The integrated booster cushion cannot be moved directly from the upper position to the lower one.
Page 93 This work should be folded down. performed by a trained and qualified Volvo service technician only. * Option/accessory, for more information, see Introduction.
Page 95 INSTRUMENTS AND CONTROLS...
Page 96 INSTRUMENTS AND CONTROLS Instruments and controls Display/function/control Display/function/control This overview shows the location of the primary Steering wheel adjustment Ceiling console display displays, and controls/buttons/switches. Horn Manual rearview mirror auto-dim (certain markets only) Left-side steering wheel keypad Hood open Display lighting, trunk unlock, trunk open/close* Display/function/control Parking lights, daytime running lights, low...
Page 97: Top Tether Anchors 86 Trip Computer
INSTRUMENTS AND CONTROLS Trip computer Display/function/control The trip computer registers and calculates infor- Parking brake mation such as distance driven, fuel consump- tion and average speed. This information is dis- Auto-hold brakes played in the instrument panel. To help promote fuel efficient driving, the trip computer provides readings for current and aver- age fuel consumption.
Page 98: Integrated Booster Cushion* 87 Displaying Trip Computer Information
INSTRUMENTS AND CONTROLS Displaying trip computer Distance to empty information This function shows the approximate distance that can be driven on the fuel remaining in the The trip computer registers and calculates infor- tank. mation such as distance driven, fuel consump- tion and average speed.
Page 99: Raising The Integrated Booster Cushion* 88 Displaying Trip Statistics
Changing these units of measure will also sents a driving distance of • Tourist (alternative speedometer). change the ones used in the Volvo navigation 1 mile, 10 miles or 100 miles Select or deselect an alternative using the system*. depending on the current scale; bars are added center button (4).
Page 100: Homelink
INSTRUMENTS AND CONTROLS ® HomeLink Wireless Control tion can be found on the Internet at, www.homelink.com/www.youtube.com/ System* HomeLinkGentex or by phoning the hotline at 1– ® HomeLink can be used to open garage doors, 800–355–3515. gates, etc. WARNING • ® If you use HomeLink to open a garage door or gate, be sure no one is near the...
Page 101: Programming The Homelink ® Wire
INSTRUMENTS AND CONTROLS ® Related information Programming the HomeLink 3. Press and hold the button on the original • remote control that is to be programmed on ® Wireless Control System* Programming the HomeLink Wireless Con- ® ® HomeLink and observe the HomeLink trol System* (p.
Page 102 INSTRUMENTS AND CONTROLS ® 4. Press the programmed HomeLink Gate Operator/Canadian Programming button and check the indicator light. Canadian radio-frequency laws require transmit- ter signals to “time-out” (or quit) after several Indicator light glows steadily green: pro- seconds of transmission – which may not be long gramming has been completed.
Page 103 INSTRUMENTS AND CONTROLS indicator light will glow steadily or flash when the 2. Release both buttons. rules. Changes or modifications not expressly button has been pressed. Activation will now approved by the party are prohibited. ® > HomeLink is now in the training (or occur for the trained device (i.e., garage door learning) mode and can be programmed opener, gate operator, security system, entry door...
Page 104: Adjusting The Power Door Mirrors
INSTRUMENTS AND CONTROLS Adjusting the power door mirrors Storing the position* Automatically tilting the door mirrors The mirror positions are stored in the key mem- when parking The control on the driver's door is used to adjust ory* when the vehicle has been locked with the the position of the door mirrors.
Page 105: Moonroof
INSTRUMENTS AND CONTROLS Moonroof* Settings 1. Tap The level of sensitivity is set from the center dis- in Top view. play: The moonroof controls are located in the ceiling 2. Tap My Car Mirrors. console near the rearview mirror. Settings 1.
Page 106: Operating The Moonroof
INSTRUMENTS AND CONTROLS Operating the moonroof* Wind blocker WARNING When opened automatically, the sun shade and • During manual closing, if the moonroof is moonroof open completely. obstructed, immediately open it again. • In the tilt (ventilation) position, the rear edge of Never open or close the moonroof if it is obstructed in any way.
Page 107: Automatic Operation
INSTRUMENTS AND CONTROLS Manual close Perform this procedure in reverse order to close CAUTION the moonroof. • Remove ice and snow before opening the Auto close Tilt (ventilation) position moonroof. The moonroof can be operated when the ignition • Do not operate the moonroof if it is fro- is in mode I or II.
Page 108: Power Windows
INSTRUMENTS AND CONTROLS Power windows Sun shade Related information • The moonroof has a sun shade that can be Moonroof* (p. 103) All power windows can be operated using the opened and closed manually. The sun shade • control panel in the driver's door. The control Locking/unlocking from outside the vehicle opens automatically along with the moonroof.
Page 109: Operating The Power Windows
INSTRUMENTS AND CONTROLS Operating the power windows Resetting been running, the power windows can be oper- ated for several minutes after the ignition has If the battery has been disconnected, the auto been switched off, or until a door has been WARNING open function must be reset so that it will work opened.
Page 110: Rearview Mirror
INSTRUMENTS AND CONTROLS Rearview mirror Using sun shades NOTE The interior rearview mirror has an auto-dim Both rear doors have integrated sun shades. When the level of sensitivity is changed, this function that helps reduce glare from following change will not be noticeable immediately but There is a sun shade integrated into the rear par- vehicle's headlights.
Page 111: Settings View
INSTRUMENTS AND CONTROLS Settings view Rear window NOTE The center display's Settings view is used to The sun shade cannot be operated at low make many of the vehicle's function settings and temperatures in the passenger compartment. to display vehicle-related information. Opening Settings view Related information •...
Page 112: Categories In Settings View
INSTRUMENTS AND CONTROLS Categories in Settings view Changing a setting Type of Description Settings view consists of a number of main cate- setting gories and sub-categories that contain settings Multi- Select a level for a particular set- and information for many of the vehicle's fea- selection ting by pressing the desired part tures and functions.
Page 113 Vehicle Wi-Fi Hotspot Global Settings view (p. 109) Personal • Changing system settings in Settings view Vehicle Modem Internet Global (p. 112) Route Personal Volvo On Call – Traffic Personal Volvo Service Networks Global Guidance Personal Climate System Personal Climate...
Page 114: Changing System Settings In Settings View
INSTRUMENTS AND CONTROLS Changing system settings in Viewing the VIN (Vehicle Identification 3. Select one of the following measurement Settings view standards: Number) • 1. Pull down the center display's Top view and System Settings view's main category contains Metric : kilometers, liters and degrees Cel- Settings general settings and information, such as lan-...
Page 115: Changing Settings In Apps
Third party apps view. Third party apps have to be downloaded e.g., 2. Tap System Global Reset. Volvo ID . Settings for these apps are made in > A pop-up menu will appear. the apps themselves, not in Top view.
Page 116: Resetting User Data When The Vehicle Changes Owners
> The selected settings will be reset. When the vehicle changes owners, it is essential to reset all user data and system settings to their Related information factory defaults, including Volvo On Call. • Settings view (p. 109) • Related information Resetting user data when the vehicle •...
Page 117: Clock
INSTRUMENTS AND CONTROLS Clock Settings Automatic time Automatic Time Changing measurement standard in the center The function is also available, The clock is displayed in the instrument panel display: which adjusts the time zone automatically, and in the center display. Automatic depending on the vehicle's location.
Page 118: Head-Up Display (Hud)
INSTRUMENTS AND CONTROLS Head-up display (HUD)* NOTE The head-up display provides information such If the City Safety is activated, the information as speed, cruise control functions, navigation, in the HUD will be replaced by a City Safety- traffic sign information, incoming phone calls, related graphic.
Page 119 • Head-Up Display 3. Select/deselect the use of polarizing sunglasses • the use of an aftermarket or non-Volvo This selection can be stored as a personal set- replacement windshield ting in a driver profile. • not sitting in the center of the driver's...
Page 120 If the windshield has to be replaced, contact a Rotate counterclockwise trained and qualified Volvo service technician or authorized workshop. The correct type of replace- Rotate clockwise ment windshield must be used for a head-up dis- Confirm play.
Page 121: Voice Control
Bluetooth-connected cell phone, cli- Press the button on the right- mate system and the Volvo navigation system*. In certain cases, text messages are also provided side steering wheel keypad to in the instrument panel. Voice control offers convenience and enables the...
Page 122: Voice Control For Cell Phones
INSTRUMENTS AND CONTROLS Voice control for cell phones Voice command examples sequence of numbers, e.g., twenty-two twenty-two (22 22) and "double" or "triple" Press , say "Call"-"[First-name]"-"[Last- Voice commands can be used to control many can also be used, e.g., double zero (00) or tri- ®...
Page 123: Voice Control For Radio And Media
INSTRUMENTS AND CONTROLS • Voice control for radio and media Related information " ": starts playback from a USB flash • drive. Voice control (p. 119) The following voice commands can be used for • • iPod the radio or an external media player. "...
Page 124: Climate System Voice Commands
INSTRUMENTS AND CONTROLS • • Climate system voice commands Air condition on Air condition off Turn on seat ventilation Turn off seat " "/" ": " "/" ventilation activates/deactivates the air conditioning. ": activates/deactivates seat ven- Voice commands can be used to control the cli- tilation*.
Page 125: Navigation System Voice Commands
INSTRUMENTS AND CONTROLS • Navigation system voice commands Go to [Zip code] Related information " ": Enter a zip code as a • destination, e.g., "Go to 07405." Voice control (p. 119) Many of the navigation system's functions can • •...
Page 126: Voice Control Settings
Related information system. If this happens, please • Voice control (p. 119) have your vehicle checked by a • Using voice commands (p. 119) trained and qualified Volvo service • technician as soon as possible. Navigation system voice commands (p. 123)
Page 127 INSTRUMENTS AND CONTROLS Symbol Explanation Symbol Explanation Symbol Explanation Left/right turn signals Automatic/active high beams Not in use Both turn signal indicators will flash when the hazard warning The symbol will be blue when the flashers are being used. automatic high beams are on. The Stability system parking lights will also be on.
Page 128: Instrument Panel
Canadian models read, do not drive the vehicle. Contact a Door/hood/trunk/fuel filler door trained and qualified Volvo service techni- cian. reminder If a door or the hood/trunk/fuel filler door are not closed properly, the information or warning sym- bol will illuminate and a graphic will be displayed in instrument panel.
Page 129 INSTRUMENTS AND CONTROLS • 12" Instrument panel 8" instrument panel Media player • Navigation system map • Cell phone • Voice control Right side • Tachometer (depending on current driving mode) • Fuel gauge • Gear indicator • Current driving mode (Comfort, Off Road, Eco, Dynamic and Individual) •...
Page 130 INSTRUMENTS AND CONTROLS To reactivate it, do one of the following: Center The system language can be changed under • Messages (and in certain cases also graph- Settings System Choose system • Press the brake pedal ics) language. This change affects the language •...
Page 131: Instrument Panel Licenses
INSTRUMENTS AND CONTROLS Instrument panel licenses ANY EXPRESS OR IMPLIED WARRANTIES, the documentation and/or other materials INCLUDING, BUT NOT LIMITED TO, THE provided with the distribution. BSD 4-clause "Original" or "Old" IMPLIED WARRANTIES OF MERCHANTABILITY 3. Neither the name of the organisation nor the License AND FITNESS FOR A PARTICULAR PURPOSE names of its contributors may be used to...
Page 132 INSTRUMENTS AND CONTROLS BSD 2-clause “Simplified” license OR TORT (INCLUDING NEGLIGENCE OR distribution) o You can use this software for Copyright ©) <YEAR>, <OWNER> All rights OTHERWISE) ARISING IN ANY WAY OUT OF whatever you want, in parts or full form, THE USE OF THIS SOFTWARE, EVEN IF without having to pay us.
Page 133 INSTRUMENTS AND CONTROLS must contact us to verify this. The FreeType documentation. The copyright notices of the Discusses bugs, as well as engine internals, project is copyright (C) 1996-1999 by David unaltered, original files must be preserved in design issues, specific licenses, porting, etc. Turner, Robert Wilhelm, and Werner all copies of source files.
Page 134 INSTRUMENTS AND CONTROLS COPYRIGHT NOTICE, DISCLAIMER, and Tom Lane The PNG Reference Library is supplied "AS IS". The Contributing Authors and Group 42, Inc. LICENSE: Glenn Randers-Pehrson disclaim all warranties, expressed or implied, If you modify libpng you may insert additional Willem van Schaik including, without limitation, the warranties of notices immediately following this sentence.
Page 135 INSTRUMENTS AND CONTROLS A "png_get_copyright" function is available, for LIMITED TO THE WARRANTIES OF misrepresented as being the original convenient use in "about" boxes and the like: MERCHANTABILITY, FITNESS FOR A software. PARTICULAR PURPOSE AND 3. This notice may not be removed or altered printf("%s",png_get_copyright(NULL));...
Page 136: Warning Symbols In The Instrument Panel
Silicon Graphics, Inc. activated or that a serious fault qualified Volvo service technician Related information has occurred that may affect the as soon as possible.
Page 137: Compass
DO NOT DRIVE. Have the vehicle towed driving, stop the vehicle, the to a trained and qualified Volvo service engine oil level is too low. Stop the technician and have the brake system engine immediately and check the inspected.
Page 138: Calibrating The Compass
INSTRUMENTS AND CONTROLS Calibrating the compass Related information • Calibrating the compass (p. 136) North America is divided into 15 magnetic zones • and the compass will need to be calibrated if the Ignition modes (p. 380) vehicle is driven from one zone to another. To calibrate the compass: 1.
Page 139: Lighting Panel And Controls
INSTRUMENTS AND CONTROLS Lighting panel and controls 8. Repeat the calibration procedure if neces- Lighting Result sary. The lighting ring on the left-side steering wheel ring posi- lever can be used to activate the vehicle's exte- tion Related information rior lighting. •...
Page 140 NOTE Lighting Result Instrument lighting ring posi- Volvo recommends the use of Daytime Run- tion ning Lights in the United States. The use of these lights is mandatory in Canada. With the ignition in mode II or if the engine is running: •...
Page 141: Parking Lights
NOTE lights will illuminate instead of the front parking lights. Volvo recommends the use of Daytime Run- ning Lights in the United States. The use of With the lighting ring in this position, the parking these lights is mandatory in Canada.
Page 142: Low Beam Headlights
INSTRUMENTS AND CONTROLS Low beam headlights Related information With the lighting ring in the position • Daytime Running Lights (DRL) (p. 139) The low beam headlights can be activated in and the ignition in mode II or if the engine is •...
Page 143: High And Low Beam Headlights
INSTRUMENTS AND CONTROLS High and low beam headlights Continuous high beams When released, the ring will automatically return Continuous high beams are available if the light- to the position. If the ignition is in mode II or when the engine is started, the low beams are activated automati- ing ring is turned to .
Page 144: Active Bending Lights
• When oncoming vehicles have dim front • The use of aftermarket or non-Volvo lighting glass can have an adverse effect on the • If there are pedestrians on or near the automatic high beam function.
Page 145: Front Fog Lights
INSTRUMENTS AND CONTROLS Front fog lights* Corner illumination NOTE The front fog lights include corner illumination, This function is only active in twilight or dark which temporarily provides extra light to the front conditions, and only when the vehicle is in left or right of the vehicle (depending on which motion.
Page 146: Rear Fog Lights (Certain Models Only)
INSTRUMENTS AND CONTROLS • Rear fog lights (certain models only) Brake lights the ignition is in mode II or if the engine is running and the lighting ring is in the The brake lights illuminate automatically when The rear fog lights are considerably brighter the brakes are applied.
Page 147: Hazard Warning Flashers
INSTRUMENTS AND CONTROLS Hazard warning flashers Using turn signals NOTE The hazard warning flashers should be used to The turn signals are controlled using the left • This automatic flashing sequence can be indicate that the vehicle has become a traffic steering wheel lever.
Page 148: Passenger Compartment Lighting
INSTRUMENTS AND CONTROLS Passenger compartment lighting Rear interior lighting Courtesy lighting (AUTO) switch The passenger compartment lighting is con- Rear reading lights Passenger's side reading light trolled using the buttons in the ceiling above the The rear interior lighting/reading lights are front and rear seats.
Page 149 INSTRUMENTS AND CONTROLS Ground lighting Change the color of the light The ground lighting comes on or goes off when a 1. In the center display's Top view, select door is opened or closed. Settings My Car Lights Interior Mood Lighting.
Page 150: Home Safe Lighting
INSTRUMENTS AND CONTROLS Home safe lighting Approach lighting Lighting in the front tunnel console cup holders The home safe lighting function illuminates the Approach lighting (the parking lights, outer door This lighting is switched on or off when the vehi- area in front of the vehicle in dark conditions.
Page 151: Messages In The Instrument Panel
INSTRUMENTS AND CONTROLS Messages in the instrument panel Message Action and center display Stop safely Stop and switch off the Information and warning messages are dis- engine. There is a risk of played in the instrument panel and center dis- serious damage to the vehi- play.
Page 152: Handling Messages In The Instrument Panel And Center Display
Messages' form can vary and they may be dis- played with graphics, symbols or buttons for e.g., Part of the message is context-dependent. confirming a message or accepting a request. Contact a Volvo retailer or a trained and qualified Volvo service technician. Pop-up messages Center display Messages are sometimes displayed in pop-up windows.
Page 153 INSTRUMENTS AND CONTROLS For messages without buttons: Handling new messages For messages with buttons: – Close the message by pressing (2) or let the message time-out after a short period. – Tap the button to carry out the action or let the message time-out after a short period.
Page 154: Handling Messages Stored From The Instrument Panel And Center Display
INSTRUMENTS AND CONTROLS Handling messages stored from the Reading saved messages Booking service: instrument panel and center display Reading a saved message immediately: – With the message in expanded form, tap Request appoint. Call to make – Tap the button to the right of the message Messages saved from the instrument Car message stored in Car status Appointment...
Page 155 INSTRUMENTS AND CONTROLS Instrument panel App menu Messages saved from the center Messages saved in Top view are erased automat- display ically when the engine is switched off. The App (application) menu in the instrument panel provides quick access to commonly used Related information functions in certain apps.
Page 156: Using The Instrument Panel App Menu
INSTRUMENTS AND CONTROLS Using the instrument panel App Opening/closing the App menu Functions menu – Press the App menu (1). Trip com- Select a trip odometer, make The App (application) menu in the instrument The App menu cannot be opened if there are puter instrument panel display set- panel is controlled using the right-side steering...
Page 157: Using The Windshield Wipers
INSTRUMENTS AND CONTROLS Using the windshield wipers Activating/deactivating the rain Continuous wipers sensor Move the lever upward for the wipers to Before using the wipers, ice and snow should operate at normal speed. be removed from the windshield. Be sure the The rain sensor monitors the amount of water on wiper blades are not frozen in place.
Page 158: Windshield And Headlight Washers
INSTRUMENTS AND CONTROLS Windshield and headlight washers Activating/deactivating the memory Activate the rain sensor by pressing the function button. The wipers will make one sweep. Use the windshield/headlight washers to help The rain sensor's memory function can be set to improve visibility.
Page 159: Steering Wheel
INSTRUMENTS AND CONTROLS Steering wheel A text message and the symbol will be dis- CAUTION played in the instrument panel to remind the The steering wheel has controls for the horn, • Use ample washer fluid when washing driver to fill the washer fluid reservoir. certain optional driver support systems, menus/ the windshield.
Page 160 INSTRUMENTS AND CONTROLS • Horn Using the instrument panel App menu (p. 154) • Phone (p. 417) Steering wheel keypads and paddles* Driver support system controls The horn is located in the steering wheel hub. Paddles for manually shifting gears* Related information •...
Page 161: Adjusting The Steering Wheel
INSTRUMENTS AND CONTROLS Adjusting the steering wheel Seats WARNING The steering wheel can be adjusted to various The front seats can be adjusted electronically* or Never adjust the steering wheel while driving. positions. manually. The rear seats are adjusted primarily manually.
Page 162: Manually Operated Front Seats
INSTRUMENTS AND CONTROLS Manually operated front seats Power front seats* WARNING The front seats can be adjusted in a number of The power front seats offer a number of adjust- • Do not adjust the seat while driving. The ways to help provide the most comfortable seat- ment possibilities to help maximize comfort and seat should be adjusted so that the brake ing position.
Page 163: Adjusting Power Front Seats
INSTRUMENTS AND CONTROLS Adjusting the passenger's seat from Adjusting power front seats* Related information • the driver's seat* Power front seats* (p. 160) The power front seat(s) can be adjusted to many • positions to help improve comfort and ergonom- Using the controls on the side of the driver's Using the power seat memory function* ics.
Page 164: Using The Power Seat Memory Function
INSTRUMENTS AND CONTROLS Using the power seat memory 2. Press and release the M button. The indica- function* tor light in the button will illuminate. The memory function can be used to store the 3. Press button 1 or 2 within 3 seconds to settings (positions) of the power front seats*, store the current position of the seat/ door mirrors and the head-up display*.
Page 165: Multifunctional Front Seats
INSTRUMENTS AND CONTROLS Multifunctional front seats* Front door closed center of the display. If both seats are adjusted, – Press and hold one of the buttons (1 or 2) the settings for the driver seat are shown on the In addition to the adjustment settings offered by upper half of the screen and the ones made for until the seat, door mirrors and head-up dis- the power seat controls, the multifunction control...
Page 166: Adjusting Function Settings In The Multifunctional Front Seats
INSTRUMENTS AND CONTROLS Adjusting function settings in the 3. Select massage settings by tapping the cen- multifunctional front seats* ter display or by moving the cursor up/down using the multifunction control's upper/lower The multifunction controls on the side of the seat buttons.
Page 167 INSTRUMENTS AND CONTROLS Adjusting front seat lumbar support* Restarting the massage function Lumbar support can be adjusted up/down/front/ rear. Massage restart button in the center display The massage function switches off automatically after 20 minutes and must be restarted manually for continued use.
Page 168 INSTRUMENTS AND CONTROLS Lumbar Related information 2. Select in the seat settings view. • Multifunctional front seats* (p. 163) • Tap the button up/down to move lumbar support up/down. • Tap the front button to make lumbar sup- port firmer. •...
Page 169 INSTRUMENTS AND CONTROLS Easy access to and from the driver Rear seats 2. Activate/deactivate the function by select- seat Easy Ingress & Egress ing/deselecting the The rear seat has three seating positions and the box. Easy Ingress & Egress backrests can be folded down separately. function can be used to make getting into and out of the driver's Related information...
Page 170 INSTRUMENTS AND CONTROLS Adjusting the second row head Electrically folding down the rear seat’s WARNING restraints outboard head restraints* The center rear seat head restraint should only be in its lowest position when this seat is The center head restraint in the second row of NOT occupied.
Page 171 INSTRUMENTS AND CONTROLS Folding the rear seat backrests* Via settings WARNING The ignition has to be in at least mode II. The rear seat backrests are divided into two sec- • When one or more sections of the back- tions that can be folded down together or sepa- 1.
Page 172 INSTRUMENTS AND CONTROLS Driver profiles Folding a section of the backrest 3. Return the head restraint to the upright posi- tion. Many of the vehicle's settings can be adapted to Folding down the driver's personal preferences and saved in Related information one or more driver profiles.
Page 173 INSTRUMENTS AND CONTROLS Selecting a driver profile Global settings Confirm 4. Tap Global settings and parameters remain the same > The new driver profile has now been The most recently selected driver profile will be regardless of which driver profile is currently selected and the system will load the set- used automatically the next time the vehicle is active.
Page 174 INSTRUMENTS AND CONTROLS Editing a driver profile Back Close Settings 3. Save the changes by tapping 1. Tap in the center display's Top view. > The name has now been changed. The driver profiles can be edited to e.g., change their names or lock a profile.
Page 175 INSTRUMENTS AND CONTROLS Linking a remote key to a driver Related information 4. Open Top view in the center display and tap profile • Settings System Driver Profile Driver profiles (p. 170) Edit Profile. • A remote key can be linked to a driver profile, Editing a driver profile (p.
Page 176: Importing/Exporting A Driver Profile From/To A Usb Flash Drive
INSTRUMENTS AND CONTROLS Importing/exporting a driver profile Import Profile From USB Export Related information 4. Select from/to a USB flash drive • Profile To USB Driver profiles (p. 170) The personal settings stored in a driver profile NOTE can be imported or exported to another vehicle using a USB flash drive.
Page 177: Climate
CLIMATE...
Page 178: Climate Control System
CLIMATE Climate control system Perceived temperature 4-zone climate system* The vehicle is equipped with Electronic Climate The climate system regulates passenger com- Control (ECC) that cools, heats, dehumidifies partment temperature based on the perceived and filters the air in the passenger compartment. temperature, not on the actual one.
Page 179: Climate System Sensors
All floor mats (including the trunk) can be easily removed for cleaning. Only use cleaning agents and car care products recommended by Volvo. Clean regularly and fol- low the instructions included with the product. Air filtering systems Humidity sensor: in the rearview mirror con- In addition to the passenger compartment filter, sole.
Page 180: Clean Zone Interior Package (Czip)
CLIMATE Clean Zone Interior Package NOTE (CZIP)* Please be aware that the Clean Zone function The Clean Zone Interior Package includes a does not indicate that the air quality in the number of features that help further reduce aller- passenger is good, only that the conditions genic substances in the passenger compart- for good air quality have been met.
Page 181: Interior Air Quality System (Iaqs)
(p. 178) contaminants are detected, the air intake closes replaced more often. Consult your Volvo retailer. • Turning recirculation on and off (p. 187) and the air inside the passenger compartment is Related information recirculated, i.e., no outside air enters the vehicle.
Page 182: Automatic Climate Control
CLIMATE Automatic climate control Climate system controls Related information • Climate system controls in the center display The Auto feature automatically controls a num- Climate system functions are controlled using (p. 181) ber of climate system functions. buttons on the center console, the center dis- play and the climate system panel on the rear side of the tunnel console*.
Page 183 CLIMATE • Climate system controls in the Climate view Defrosting windows and mirrors (p. 188) center display • Tap the center button on the climate bar to Climate system voice commands (p. 122) access Climate view, which is divided into the fol- All climate system functions can be controlled * and Main climate...
Page 184 CLIMATE Main climate settings Air distribution controls. In addition to the climate bar's functions, other Blower control for the front seats (also for primary climate system functions can also be the rear seat on models with a 2-zone cli- Main climate controlled from the tab.
Page 185: Rear Climate System Controls On The Tunnel Console
CLIMATE Rear climate system controls on the Setting the blower speed Related information • tunnel console* Climate system controls (p. 180) The blower can be set to five different automatic • speeds plus . In models with the 4- The rear seat climate system functions are con- Defrosting windows and mirrors (p.
Page 186 CLIMATE Setting blower speed for the front Setting the rear seat blower speed* From the rear seat seats From the front seat Blower controls on the climate panel on the rear side of the tunnel console Blower control buttons in Climate view Blower control buttons in the Rear climate tab in Cli- –...
Page 187: Setting The Temperature
CLIMATE Related information Setting the temperature • Climate system controls in the center display The temperature can be set separately for the (p. 181) left and right sides of the passenger compart- • Rear climate system controls on the tunnel ment.
Page 188 CLIMATE Setting the rear seat temperature* Synchronizing the temperature From the front seat Temperature control Synchronization button on the driver's side temperature 4. Set the temperature by: control Temperature buttons in the Rear climate group in Cli- • dragging the control to the desired tem- 1.
Page 189: Turning Recirculation On And Off
CLIMATE • Turning recirculation on and off From the rear seat Rear climate system controls on the tunnel console* (p. 183) Recirculation can be used to shut out exhaust • fumes, smoke, etc., from the passenger com- Perceived temperature (p. 176) partment.
Page 190: Defrosting Windows And Mirrors
CLIMATE Defrosting windows and mirrors Activating/deactivating the recirculation Models without a heated windshield. timer The max. defroster, heated windshield* and – Press button (1). With the timer activated, recirculation will switch heated rear window/door mirror functions are > Max. defroster is activated (button indica- off automatically after 20 minutes.
Page 191 CLIMATE From the center display's Climate view Activating/deactivating windshield heating* NOTE Activate/deactivate max. defroster • Triangular areas at the far sides of the windshield are not heated electrically and will take slightly longer to defrost/de-ice. • The heated windshield may affect the performance/range of e.g., transponders used to automatically pay highway tolls or other communication equipment.
Page 192: Turning Steering Wheel Heating* On And Off
CLIMATE • Turning steering wheel heating* on Automatically activating/deactivating Turning steering wheel heating* on and off and off the defrosting function when the engine (p. 190) is started The steering wheel can be heated electrically for The rear window/door mirror/windshield heating* added comfort in cold weather.
Page 193: Air Conditioning
CLIMATE Air conditioning 2. Tap the steering wheel heating button NOTE repeatedly to select one of four levels: The air conditioning cools and dehumidifies the • For the air conditioning to function opti- High Middle air in the passenger compartment. mally, close the side windows >...
Page 194: Turning Seat Heating* On And Off
CLIMATE Turning seat heating* on and off 2. Tap the seat heating button repeatedly to From the rear seat High Middle select one of four levels: With the 2-zone climate system The seats can be heated for added comfort in cold weather.
Page 195: Turning Front Seat Ventilation* On And Off
CLIMATE Turning front seat ventilation* on The automatic function starts heating the seats and off when the ambient temperature is sufficiently cold. Settings Seat ventilation can be used e.g., to help remove 1. Tap in the center display's Top dampness from the seat occupant's clothing. view.
Page 196: Air Distribution
CLIMATE Air distribution Activating/deactivating front seat NOTE ventilation The incoming air is distributed through a number Seat ventilation cannot be started if the tem- of different vents in the passenger compartment. perature in the passenger compartment is too low. Air distribution overview For use over extended periods, the setting is recommended.
Page 197: Opening/Closing/Directing Air Vents
CLIMATE Opening/closing/directing air vents Rear seat air vents Some of the passenger compartment air vents can be open/closed/directed individually. Direct the dashboard and door pillar outer air vents toward the side windows to defrost. Direct the vents into the passenger compartment to help maintain a comfortable temperature in warm weather.
Page 198: Adjusting Air Distribution
CLIMATE Adjusting air distribution Directing air flow Related information • Air distribution (p. 194) Air distribution can be adjusted manually. • Opening/closing/directing air vents (p. 195) • Air distribution table (p. 197) • Climate system controls in the center display (p.
Page 199: Air Distribution Table
CLIMATE Air distribution table Air distribution can be adjusted manually. Air distribution If all air distribution buttons are deselected in manual mode, the climate system will revert to automatic mode. Main air flow from the defroster vents, some flow from the other vents. To remove ice and condensation (with moderate blower speed).
Page 200 CLIMATE Air distribution Main air flow from the defroster and dashboard vents, some flow from the other For best comfort in hot and dry weather. vents. Main air flow from the defroster and floor vents, some flow from the other vents. For best comfort and defrosting in cold or humid con- ditions.
Page 201 LOADING AND STORAGE...
Page 202: Cargo Space
LOADING AND STORAGE Cargo space Loading Ski hatch* The vehicle has flexible cargo capacity that The hatch in the center section of the rear seat The load carrying capacity of your vehicle is makes it possible to load and secure large backrest can be opened without folding the determined by factors such as the number of objects.
Page 203 Roof loads • this level could impede the function of If the rear seat backrests are folded Load carriers are available as Volvo accessories. the Inflatable Curtain. down, cargo must be secured to prevent Observe the following points when in use:...
Page 204: Passenger Compartment Storage Spaces
LOADING AND STORAGE • Passenger compartment storage Secure the cargo correctly with appropriate spaces tie-down equipment. • Check periodically that the load carriers and The following is an overview of the passenger load are properly secured. compartment and its storage spaces. •...
Page 205: Using The Glove Compartment
LOADING AND STORAGE Using the glove compartment Locking/unlocking the glove side of the front seat backrest, and 12-volt socket on the rear side of the tunnel console compartment The glove compartment provides storage space Related information for small items. • Tunnel console (p.
Page 206: Tunnel Console
LOADING AND STORAGE Tunnel console The tunnel console, located between the front seats, contains a 12-volt electrical socket, cup holders and storage spaces, etc. To lock the glove compartment: Cooling activated Insert the key into the lock. Cooling deactivated Turn the key 90 degrees clockwise. Activate/deactivate cooling by moving the –...
Page 207: Grocery Bag Holder
LOADING AND STORAGE Grocery bag holder Load anchoring eyelets NOTE The grocery bag holders (hooks) help keep The eyelets in the trunk can be folded out to One of the alarm sensors, which is sensitive shopping bags in place. secure objects with straps, a net, etc. to metallic objects, is located under the tunnel console cup holders.
Page 208: Sun Visors
LOADING AND STORAGE Sun visors Related information • Loading (p. 200) There are vanity mirrors with card holders on the • upper sides of the sun visors. Grocery bag holder (p. 205) Lighted vanity mirror and card holder The vanity mirror lighting comes on when the mir- ror is opened.
Page 209: Electrical Sockets
LOADING AND STORAGE Electrical sockets 2. Disconnect the device by pulling its plug, not WARNING its cord. There are two 12-volt sockets in the tunnel con- • Be sure to place any devices connected sole, a 120-volt socket on the rear side of the Pull up the cover over the socket when it is not in to the socket safely so that they do not tunnel console, and one 12-volt socket in the...
Page 210 Put the vehicle's ignition in at least mode I. The socket is not active. The socket has been active but has been deactivated. Start the engine and/or charge the start battery. If a problem persists, have the socket checked by a trained and qualified Volvo service technician.
Page 211 LOADING AND STORAGE 12-volt socket in the tunnel console Fold down the cover to access the socket. Max. WARNING current provided is 10 A (120 W). Always keep the sockets covered when not in use. NOTE The 12-volt socket in the trunk provides elec- CAUTION trical current even when the ignition is Max.
Page 213 LOCKS AND ALARM...
Page 214: Locks And Remote Keys
The vehicle can be locked and unlocked in vari- The immobilizer is a start inhibitor that helps pre- ous ways and there are several types of remote vent unauthorized persons from starting the Additional keys can be ordered from a Volvo keys that can be used. engine. retailer.
Page 215: Changing The Remote Key's Battery
Hold the remote key with the front side attempts to unlock or lock the vehicle (with the Volvo symbol) toward you and move The cover will loosen and can be the button on lower edge of the key near the removed from the key.
Page 216 LOCKS AND ALARM Use e.g., a screwdriver to turn the battery Insert a new battery with the positive (+) The battery's positive (+) side is up. Pry cover counterclockwise so that the markers side up. Put the battery cover back in place out the battery as shown in the illustration.
Page 217 Volvo workshop fulfill the above criteria. Old batteries should be disposed of properly at a recycling center or at your Volvo retailer. Put the rear cover in position and press down until it clicks into place.
Page 218: Remote Key
LOCKS AND ALARM Remote key Each of the remote keys provided with the vehicle This key functions in the same way as a standard can be linked to a driver profile containing unique remote key but does not have a detachable key The remote key is used to lock/unlock the vehi- personal settings that will be applied when that blade and its battery cannot be replaced;...
Page 219 If a remote key is lost, the others should be taken with the vehicle to a Volvo retailer. As an anti- Panic alarm: Press to attract attention dur- theft measure, the code of the lost remote key ing emergency situations.
Page 220: Remote Key's Range
LOCKS AND ALARM • Remote key's range Changing the remote key's battery (p. 213) For keyless entry into the vehicle, the remote key must be within approximately 5 feet (1.5 meters) • Driver profiles (p. 170) In order to function correctly, the remote key of the sides of the vehicle or approximately 3 feet must be within a certain distance of the vehicle.
Page 221: Red Key*
One or more Red Keys can be ordered from a Related information See the article "Speed limiter" for additional Volvo retailer after the vehicle has been pur- • Remote key (p. 216) information. chased. A total of 11 keys can be programmed •...
Page 222: Detachable Key Blade
• City Safety™ (p. 306) door, etc. • Driver Alert Control (DAC) (p. 328) A Volvo retailer can provide you with the key • Road Sign Information (RSI)* (p. 326) blade's unique code. Using the detachable key blade The remote key's detachable key blade can be used to: •...
Page 223: Locking/Unlocking From Outside The Vehicle
LOCKS AND ALARM Locking/unlocking from outside the door is opened from inside the vehicle using a vehicle door handle. See also the article "Locking/ unlocking from inside the vehicle" for additional The buttons on the remote key can be used to information.
Page 224: Automatic Relocking
NOTE Remote door unlock Only one of a door handle's lock/unlock sur- The vehicle can be unlocked using the Volvo On faces should be pressed at a time. If both Call app. Outer indentation for locking, the pressure sensitive sur-...
Page 225: Locking/Unlocking From Inside The Vehicle
LOCKS AND ALARM Locking/unlocking from inside the Unlocking To unlock a rear door: vehicle • Press the button to unlock all doors and – To open one of the rear doors individually, The lock buttons on either of the front doors can the trunk.
Page 226: Antenna Locations For The Start And
LOCKS AND ALARM Antenna locations for the start and Locking and unlocking confirmation WARNING lock system The turn signals can be used to indicate that the People with implanted pacemakers should not vehicle has been locked/unlocked with the The vehicle is equipped with a keyless start and allow the pacemaker to come closer than remote key.
Page 227 LOCKS AND ALARM Interior confirmation Indicators in the interior lock buttons In all doors Lock buttons in the front doors Lock and alarm indicator light on the dashboard Rear door lock button and indicator light A long flash indicates the vehicle is locked. While Indicator light in the respective door on: that door Front door lock button and indicator light the vehicle is locked, the indicator will flash...
Page 228: Locking/Unlocking The Trunk
LOCKS AND ALARM Locking/unlocking the trunk Related information 1. Press the button on the remote key • Locking/unlocking from outside the vehicle briefly. The trunk can be locked, unlocked and opened (p. 221) in several ways. > The trunk will unlock but will remain •...
Page 229 LOCKS AND ALARM Keyless unlocking* Unlocking the trunk from inside the 2. Lift to open the trunk completely. vehicle CAUTION • When pressing the rubberized pressure plate, only light pressure is necessary to release the trunk's electronic locking mechanism. • When opening the trunk, pull it up using the handle.
Page 230: Power Trunk Release
LOCKS AND ALARM Power trunk release* Locking with the remote key WARNING – Press the button on the remote key. The optional power trunk function can be used • Keep vehicle doors and trunk locked and to open/close the trunk lid automatically. >...
Page 231 LOCKS AND ALARM The power trunk release can be activated by: To close and lock the trunk • – Pressing and holding the button on the Press the button on the lower edge of lighting panel until the trunk lid begins to the trunk lid.
Page 232 LOCKS AND ALARM Programming the trunk lid's maximum Preloaded springs NOTE opening angle If the trunk lid has been opened and closed The trunk lid's maximum opening angle can be continuously too long, the automatic function programmed, for example, if the trunk has to be will be deactivated to avoid overloading the opened in a garage with a low ceiling.
Page 233: Foot Movement Trunk Operation
LOCKS AND ALARM Foot movement trunk operation* Opening/closing CAUTION – With the remote key within range, move your The foot movement sensor* simplifies opening or One of the remote keys must be in your pos- foot slowly forward in a kicking motion below closing the trunk if your hands are full.
Page 234: Private (Valet) Locking
• If private locking is activated and the vehi- diffuser* cle is unlocked using Volvo On Call or the To open/close the trunk lid, make the kicking Volvo On Call mobile app, it will be auto- motion from the side of the rear bumper.
Page 235: Locking/Unlocking With The Detacha Ble Key Blade
LOCKS AND ALARM Locking/unlocking with the Deactivating private locking 2. Enter the code to be used to unlock the detachable key blade trunk after it has been locked and tap 1. This function can be deactivated from the Confirm center display's Function view or under Set- The detachable key blade can be used to e.g., tings in Top view: >...
Page 236 LOCKS AND ALARM Lock the door in the same way, but turn the key NOTE in step 3 counterclockwise. If the child safety locks are activated for the Turning off the alarm rear doors and the mechanical locking mech- anism has also been activated with the key blade, it will not be possible to open these doors from the inside or the outside.
Page 237: Automatically Arming/Disarming The
The alarm can be disarmed by: locked. insurance policy on the vehicle. Contact a trained • Unlock the vehicle by pressing the remote Related information and qualified Volvo service technician. key's unlock button • Alarm (p. 235) • Pressing the pressure-sensitive area on the •...
Page 238: Deactivating The Alarm Without A
LOCKS AND ALARM Deactivating the alarm without a Alarm signals the ignition has been put in mode I (turn the functioning remote key start knob to START and release it): the The following occurs if the alarm has been trig- alarm has been triggered gered: If the remote key is not functioning properly, the...
Page 239: Child Safety Locks
LOCKS AND ALARM Child safety locks 2. Press the button on the driver's door control Symbol Message Explanation panel. Child safety locks help prevent children from Rear child The rear-door Rear child lock Activated > will be dis- inadvertently opening one of the rear doors from lockActivated child safety played in the instrument panel and the...
Page 240: Start And Lock System Type Designations
USA–FCC ID: LTQVO3134 This device complies with Part 15 of the FCC Volvo Standard Key FCC ID: YGOHUF8423 Rules. Operation is subject to the following two conditions: Volvo Tag ID FCC ID: YGOHUF8432 (1) This device may not cause harmful interfer-...
Page 241 LOCKS AND ALARM Any changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. Canada–IC:3659A-VO3134 This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) This device may not cause harmful interfer- ence, and (2) this device must accept any inter- ference received, including interference that may...
Page 243 DRIVER SUPPORT...
Page 244: Driver Support Systems
DRIVER SUPPORT • Driver support systems Adjustable steering force* Driver Alert Control (DAC) (p. 328) • The vehicle is equipped with a number of driver Driving lane assistance (p. 330) Steering force increases with the speed of the support systems that help provide the driver with •...
Page 245: Electronic Stability Control (Esc)
Traction control This function is designed to help reduce wheel spin by transferring power from a drive wheel that This function is included if the vehicle is equipped with a Volvo original trailer hitch. * Option/accessory, for more information, see Introduction.
Page 246: Electronic Stability Control (Esc)
DRIVER SUPPORT Electronic Stability Control (ESC) When Sport mode is activated, this sport mode symbol will illuminate in the instrument panel. It will remain on until the driver ESC is always activated and cannot be switched deactivates the function. ETC will also off.
Page 247 DRIVER SUPPORT Electronic Stability Control (ESC) symbols and messages Symbol Message Description Steady glow for 2 seconds The system is performing a self-diagnostic test. when the engine is started. Flashing symbol. ESC is actively functioning to help counteract wheel spin and/or a skid. Sport mode has been activated.
Page 248 • Stop the vehicle in a safe place, turn off the engine and restart it. • If the message is still displayed when the engine has restarted, drive to an authorized Volvo workshop to have the system inspected. WARNING The stability system is intended to help improve driving safety.
Page 249: Speed Limiter (Sl)
Roll stability control (RSC) Speed limiter (SL)* Set maximum speed indicator Volvo's Roll Stability Control (RSC) is a stability The Speed Limiter (SL) is a feature that helps The vehicle's current speed system designed to help minimize the risk of a...
Page 250: Starting And Activating The Speed
DRIVER SUPPORT Starting and activating the Speed Related information Activating SL (putting it in active mode • Limiter (SL)* and setting a maximum speed) Starting and activating the Speed Limiter (SL)* (p. 248) The engine must be running before SL can be The Speed Limiter (SL) is a feature that has to •...
Page 251: Changing A Speed Limiter (Sl Maximum Speed
DRIVER SUPPORT Changing a Speed Limiter (SL)* Automatic Speed Limiter (ASL)* Limitations maximum speed When driving down steep hills, the Speed The Automatic Speed Limiter (ASL) helps the Limiter's braking effect may not be adequate and driver adapt the vehicle's maximum speed to the the set maximum speed may be exceeded.
Page 252 DRIVER SUPPORT • Is SL or ASL active? Starting and activating the Speed Limiter Road sign Explanation (SL)* (p. 248) Symbols in the instrument panel indicate which symbol's color function is active: • Deactivating/reactivating the Speed Limiter* Green/yellow ASL is active (p.
Page 253: Activating/Deactivating The Automatic Speed Limiter (Asl)
DRIVER SUPPORT Activating/deactivating the Changing tolerance for the Deactivating ASL Automatic Speed Limiter (ASL)* Automatic Speed Limiter – Speed Sign Assist Tap the button in the center display's Function view. Automatic Speed Limiter can be set to different The function Automatic Speed Limiter (ASL) is a >...
Page 254: Deactivating/Reactivating The Speed
DRIVER SUPPORT Deactivating/reactivating the Speed (80 km/h) in the center of the speedometer Limiter* (4). > The vehicle will then use the selected tol- The Speed Limiter (SL) can be temporarily deac- erance +5 mph (+5 km/h) until the vehi- tivated and put in standby mode.
Page 255 DRIVER SUPPORT Turning the Speed Limiter* off Reactivating SL from standby mode Related information • To reactivate SL after it has temporarily been put Speed limiter (SL)* (p. 247) The Speed Limiter (SL) can be turned off. in standby mode: •...
Page 256: Cruise Control (Cc)
DRIVER SUPPORT Cruise Control (CC) Starting and activating Cruise The vehicle's current speed Control Cruise Control (CC) is designed to assist the The set speed driver by maintaining a set speed. It is primarily Cruise Control (CC) must be selected and acti- intended for use on long straight roads in steady vated before it can regulate the vehicle's speed.
Page 257: Changing Cruise Control Speed
DRIVER SUPPORT Changing Cruise Control speed become the set speed assuming that the accel- NOTE erator pedal is still depressed when the button is Before CC can be activated, the vehicle's Changing a set speed pressed. speed must be at least 20 mph (30 km/h). A temporary increase in speed, such as when This is also the lowest speed that can be set.
Page 258: Deactivating/Resuming Cruise
DRIVER SUPPORT Deactivating/resuming Cruise Reactivating CC from standby mode Standby mode due to action by the driver Control (CC) CC is temporarily deactivated and put in standby To reactivate CC after it has temporarily been put mode if: in standby mode: Cruise Control (CC) can be temporarily deacti- vated and put in standby mode.
Page 259 DRIVER SUPPORT Turning Cruise Control off between CC and ACC – see the article "Switch- – Press the button (2). ing between Cruise Control and Adaptive Cruise Cruise Control (CC) can be deactivated (turned > The set speed marker (4) and symbols will Control".
Page 260: And Adaptive Cruise Control
DRIVER SUPPORT Switching between Cruise Control 3. Press the 3. Press the button on the left-side steer- button on the left-side steer- and Adaptive Cruise Control* ing wheel keypad. ing wheel keypad. In models equipped with the optional ACC, the >...
Page 261: Distance Alert
DRIVER SUPPORT Distance Alert* Related information Head-up-display* • Distance Alert* limitations (p. 260) Distance Alert is a function that alerts the driver • if the time interval to the vehicle ahead is too Using Distance Alert* (p. 260) short. • Head-up display (HUD)* (p.
Page 262: Using Distance Alert
Control is activated. • Maintenance of radar sensor components may only be performed by a trained and NOTE qualified Volvo technician. • • The greater the vehicles' speed, the Strong sunlight, reflections from the road greater the distance between them for a...
Page 263: Adaptive Cruise Control (Acc)
DRIVER SUPPORT Adaptive Cruise Control (ACC)* vehicle set by the driver. If the radar sensor does WARNING not detect a vehicle ahead, ACC will instead ACC is an optional system designed to assist • Poor weather or winding roads can affect maintain the speed set by the driver.
Page 264 Volvo technician. Puts ACC in active mode and stores the cur- rent speed or puts ACC in standby mode Overview Reduces the set speed...
Page 265 DRIVER SUPPORT Collision warning Instrument panel WARNING Adaptive Cruise Control only warns of vehicles detected by the radar sensor. In some cases there may be no warning or the warning may be delayed. The driver should always apply the brakes when necessary. Head-up-display* Speed indicators Audible/visual warning signals...
Page 266: Starting And Activating Adaptive
DRIVER SUPPORT Starting and activating Adaptive Related information Activating ACC (putting it in active • Cruise Control (ACC)* mode and setting a speed) Starting and activating Adaptive Cruise Control (ACC)* (p. 264) Before ACC can be put in active mode: ACC must first be put in active mode before it •...
Page 267: Deactivating/Resuming Adaptive Cruise Control (Acc)
DRIVER SUPPORT Deactivating/resuming Adaptive The time interval to the vehi- WARNING Cruise Control (ACC) cle ahead will only be shown When ACC is in standby mode, the driver has when two vehicles are dis- ACC can be put temporarily in standby mode to control the vehicle's speed and distance to played.
Page 268 DRIVER SUPPORT • ESC Sport Mode Related information Automatic standby mode the stability system's • activated ACC interacts with other systems, such as Adaptive Cruise Control (ACC)* (p. 261) Electronic Stability Control. If any of these other • • Off Road drive mode is selected Starting and activating Adaptive Cruise systems are not functioning properly, ACC will...
Page 269: Changing Adaptive Cruise Control
DRIVER SUPPORT Changing Adaptive Cruise Control Setting an Adaptive Cruise Control If speed is increased by pressing the accelerator (ACC) speed time interval pedal before the button is pressed, the vehi- cle's speed when the button is pressed will ACC makes it possible to set various speeds. ACC makes it possible to set various time inter- become the set speed assuming that the accel- vals to the vehicle ahead.
Page 270: Passing Assistance With Adaptive
DRIVER SUPPORT Passing Assistance with Adaptive Changing a time interval time interval to the vehicle ahead does not Cruise Control or Pilot Assist-2 allow an increase in speed. • The higher the speed, the greater the dis- ACC or Pilot Assist can assist the driver when tance to the vehicle ahead for a given time passing other vehicles.
Page 271: Changing Target Vehicles And Auto Matic Braking With Adaptive Cruise
DRIVER SUPPORT Changing target vehicles and Using passing assistance Passing assistance in these situations can be automatic braking with Adaptive deactivated by putting ACC or Pilot Assist in To activate passing assistance: Cruise Control (ACC) standby mode. • Your vehicle (ACC or Pilot Assist) must be At certain speeds, Adaptive Cruise Control can following another vehicle (the target vehicle).
Page 272: Control (Acc
DRIVER SUPPORT • the gear selector is moved to the P, N or R The driver will then have to reactivate ACC in – WARNING one of the following ways: positions If ACC changes targets from a moving vehicle • •...
Page 273: Adaptive Cruise Control (Acc Troubleshooting
A text message can be erased by briefly pressing the O button on the right-side steering wheel keypad. If the message recurs, contact a trained and authorized Volvo service technician or retailer. Related information • Adaptive Cruise Control (ACC)* (p. 261)
Page 274: Tations
DRIVER SUPPORT Adaptive Cruise Control (ACC) - limitations Adaptive Cruise Control (ACC) functionality may be limited in certain situations. Steep roads and/or heavy loads Adaptive Cruise Control is primarily intended for use on relatively level roads. The function may not be able to maintain the correct time interval to the vehicle ahead when driving down steep hills.
Page 275: Adaptive Cruise Control (Acc) Sym
DRIVER SUPPORT Adaptive Cruise Control (ACC) This illustration shows that ACC is set at a symbols and messages speed of 68 mph (110/km/h) and that there is no vehicle ahead to follow. A number of ACC symbols and/or messages may appear in the instrument panel or the head- up display*.
Page 276 DRIVER SUPPORT Symbol Message Explanation Adaptive cruise The system is not functioning properly. Contact a trained and qualified Volvo Service tech- nician. Service required Windscreen sensor Sensor blocked, see Clean the windshield in front of the camera/radar sensor. Owner's manual...
Page 277 DRIVER SUPPORT Pilot Assist* Pilot Assist-1* Pilot Assist helps the driver keep the vehicle The Pilot Assist feature helps keep the vehicle in between a traffic lane's side marker lines as well its current traffic lane by providing steering as helping to maintain a set time interval (dis- assistance and maintaining an even speed and a tance) to a vehicle ahead.
Page 278 • Pilot Assist must only be used where Volvo service technician. there are clearly visible traffic lane side • Pilot Assist regulates your vehicle's marker lines on both sides of the current speed using the accelerator pedal and traffic lane.
Page 279: Collision Warning
DRIVER SUPPORT Pilot Assist overview Collision warning Function symbols Controls Symbols for the time interval and the vehicle ahead Instrument panel Warning light Pilot Assist can exert brake force that is equiva- Function buttons and symbols lent to approximately 40% of the vehicle's total Activates Pilot Assist when the vehicle is braking capacity.
Page 280 DRIVER SUPPORT Starting and activating Pilot Head-up-display* WARNING Assist-1* Pilot Assist only provides warnings for vehi- Pilot Assist has to be started and then activated cles that its radar sensor and camera have before it can provide steering assistance and detected.
Page 281 DRIVER SUPPORT • bad weather conditions (rain, snow, fog, Prerequisites WARNING slush, poor visibility, backlighting, etc). The prerequisites for activating Pilot Assist are: Pilot Assist is not a collision avoidance sys- The driver should also be aware that Pilot • The vehicle ahead must be within a reasona- tem.
Page 282: Setting A Pilot Assist-1 Time Interval
DRIVER SUPPORT Setting a Pilot Assist-1 time interval Related information • Pilot Assist* (p. 275) Different time intervals to the vehicle ahead can • be selected and are shown in the instrument Pilot Assist-1* (p. 275) panel as 1–5 horizontal bars. •...
Page 283: Deactivating/Resuming Pilot Assist-1
DRIVER SUPPORT Deactivating/resuming Pilot Standby mode due to driver action WARNING Assist-1 If a turn signal is used or if the accelerator pedal • Only use a time interval that is suitable in is pressed, Pilot Assist will temporarily go into Pilot Assist can be temporarily deactivated, put current traffic conditions.
Page 284 DRIVER SUPPORT • Reactivating Pilot Assist from standby Automatic standby mode Distance Alert* (p. 259) mode Pilot Assist interacts with other systems, such as Electronic Stability Control. If any of these other systems are not functioning properly, Pilot Assist will automatically be deactivated. WARNING If this happens, the driver will be alerted by an audible signal and a message in the instru-...
Page 285: Automatic Braking With Pilot Assist-1
DRIVER SUPPORT Automatic braking with Pilot Related information Deactivation of the auto-hold brake function Assist-1 • In certain situations, auto-hold will be deactivated Pilot Assist* (p. 275) when the vehicle is at a standstill and Pilot Assist • The auto-hold brakes function as follows with Pilot Assist-1* (p.
Page 286: Pilot Assist-1 Limitations
DRIVER SUPPORT • Pilot Assist-1 limitations bad weather conditions (rain, snow, fog, WARNING slush, poor visibility, backlighting, etc). Pilot Assist functionality may be limited in certain Pilot Assist is not a collision avoidance sys- The driver should also be aware that Pilot situations.
Page 287 DRIVER SUPPORT Pilot Assist-2* Additional information camera and radar sensor mounted in the upper, • Off Road center section of the windshield. It helps maintain drive mode cannot be The Pilot Assist feature helps keep the vehicle in the set time interval by automatically adjusting selected if Pilot Assist is activated.
Page 288 Volvo service technician. maintain the speed set by the driver. This will also road conditions. •...
Page 289 DRIVER SUPPORT Pilot Assist overview Collision warning Function symbol Controls Distance and target vehicle symbol Steering assistance symbol Instrument panel Audible/visual warning signals Audible warning signal Function buttons and symbols (generic illustration) Increase set speed or resume Pilot Assist set Visual warning signal speed and distance (time interval) to the vehicle ahead...
Page 290: Starting And Activating Pilot Assist-2
DRIVER SUPPORT Starting and activating Pilot Assist-2 WARNING NOTE Pilot Assist has to be started and then activated Pilot Assist only provides warnings for vehi- Strong sunlight, reflections, extreme light con- before it can provide steering assistance and cles that its radar sensor and camera have trasts, the use of sunglasses, or if the driver is regulate speed and the distance to the vehicle detected.
Page 291 DRIVER SUPPORT Prerequisites And Pilot Assist will only regulate the time inter- WARNING val to the vehicle ahead when a vehicle symbol The prerequisites for activating Pilot Assist are: Pilot Assist is not a collision avoidance sys- (1) is displayed above the steering wheel. •...
Page 292: Changing Pilot Assist-2 Speed
DRIVER SUPPORT • Changing Pilot Assist-2 speed the lane is at the top of a hill, on an Assist will go into standby mode and must be uneven road surface or over a bump. reactivated by pressing Different speeds can be set for Pilot Assist. •...
Page 293: Setting A Pilot Assist-2 Time Interval
DRIVER SUPPORT • Setting a Pilot Assist-2 time interval become the set speed assuming that the accel- Pilot Assist-2 limitations (p. 295) erator pedal is still depressed when the button is • Pilot Assist-2 symbols and messages Different time intervals to the vehicle ahead can pressed.
Page 294: Deactivating/Resuming Pilot Assist
DRIVER SUPPORT Deactivating/resuming Pilot Assist WARNING Pilot Assist can be temporarily deactivated, put • Only use a time interval that is suitable in in standby mode and then reactivated. current traffic conditions. • A short time interval gives the driver lim- ited reaction time if an unexpected situa- tion occurs in traffic.
Page 295 DRIVER SUPPORT • In standby mode, the driver will have to regulate systems are not functioning properly, Pilot Assist The camera lens/radar sensor is covered by the vehicle's speed and the distance to the vehi- will automatically be deactivated. e.g., wet snow or if heavy rain interferes with cle ahead.
Page 296: Changing Target Vehicles And Auto
DRIVER SUPPORT • Changing target vehicles and Changing Pilot Assist-2 speed (p. 290) WARNING automatic braking with Pilot • Setting a Pilot Assist-2 time interval (p. 291) If Pilot Assist changes targets from a moving Assist-2 • vehicle to a stationary one at speeds above Changing target vehicles and automatic At certain speeds, Pilot Assist can change target 20 mph (30 km/h), the system will not react...
Page 297: Pilot Assist-2 Limitations
DRIVER SUPPORT • Pilot Assist-2 limitations the gear selector is moved to the P, N or R The driver will then have to reactivate Pilot – Assist in one of the following ways: positions Pilot Assist functionality may be limited in certain •...
Page 298 DRIVER SUPPORT • bad weather conditions (rain, snow, fog, Additional information WARNING slush, poor visibility, backlighting, etc). • Off Road drive mode cannot be Pilot Assist is not a collision avoidance sys- The driver should also be aware that Pilot selected if Pilot Assist is activated.
Page 299: Pilot Assist-2 Symbols And Messages
DRIVER SUPPORT Pilot Assist-2 symbols and messages A number of Pilot Assist symbols and/or mes- sages may appear in the instrument panel or the head-up display*. Several examples are provided here. In this illustration, Pilot Assist is set at 65 mph In this illustration, Pilot Assist is set at 65 mph (110 km/h) and there is a target vehicle ahead (110 km/h) and there is a target vehicle ahead...
Page 300: Driver Support System Radar Sensor
DRIVER SUPPORT • Driver support system radar sensor Distance Alert* (p. 259) • The radar sensor is used by a number of driver Adaptive Cruise Control (ACC)* (p. 261) support systems to e.g., help detect other vehi- • Pilot Assist* (p. 275) cles.
Page 301: Radar Sensor Limitations
No action. The driver should be extra alert in conditions of this view. type. There is dirt between the inside of the windshield and the camera/radar sensor. Have the area of the windshield cleaned by a trained and quali- fied Volvo service technician.
Page 302 DRIVER SUPPORT Vehicle's speed The radar sensor's capacity to detect vehicles ahead is impeded: • if the speed of the vehicle ahead differs greatly from your vehicle's speed. Limited field of vision The radar sensor has a limited field of vision. In some situations it may detect a vehicle later than expected or not detect other vehicles at all.
Page 303 • • When replacing windshield wipers, use City Safety limitations (p. 314) CAUTION the same type or ones approved by Volvo. • City Safety limitations (p. 314) • Service and maintenance on City Safety After the windshield has been replaced, the •...
Page 304: Radar Sensor - Type Approval
DRIVER SUPPORT Radar sensor - type approval Driver support system camera Related information • Camera limitations (p. 303) The camera is used by a number of driver sup- • USA & Canada: port systems to e.g., detect a driving lane's side Adaptive Cruise Control (ACC)* (p.
Page 305: Camera Limitations
DRIVER SUPPORT Camera limitations WARNING Obstructions The camera used by several of the driver support Never place any objects, decals, electronic toll systems has certain limitations, which also affect devices, window tinting films etc., on the wind- the systems using it. shield in front of or around the camera/radar sensor.
Page 306 Before the windshield is replaced, con- may only be carried out by a trained and temporarily turned off for approx. 15 minutes tact a Volvo retailer to ensure that the qualified Volvo service technician. after the engine has been started to protect their correct windshield is ordered and instal- •...
Page 307 DRIVER SUPPORT free of dirt, ice, snow, etc. and should be washed regularly with a suitable car washing detergent. NOTE Dirt, ice and/or snow covering the camera and radar sensors reduce functionality and may disable the vehicle's camera-/radar- based systems. This can also result in certain functions being reduced or disabled, or they may respond incorrectly.
Page 308: City Safety
DRIVER SUPPORT City Safety™ Normally, the occupants of the vehicle will not be WARNING aware of City Safety except when the system City Safety™ is a support system designed to • City Safety™ is a supplemental aid to the intervenes when a collision is imminent. help alert the driver to pedestrians, cyclists, large driver.
Page 309 This function increases pressure on the brake City Safety maintenance may only be carried steps in the following order: pedal if the driver does not apply enough pres- out by a trained and qualified Volvo service sure to the pedal. 1. Collision warning technician.
Page 310: City Safety Warning Level Settings
DRIVER SUPPORT City Safety warning level settings If City Safety has prevented a collision, the vehi- WARNING cle will be kept at a standstill until the driver City Safety is always activated but the function's • No automatic system can be guaranteed takes action.
Page 311: Detecting Obstructions With City Safety
DRIVER SUPPORT Detecting obstructions with City and Whiplash Protection System will be shoulders, legs, the upper and lower parts of the Safety activated. body and a cyclist's normal pattern of movement. • City Safety can detect vehicles, cyclists, large If major parts of the cyclist's body are not Related information animals and pedestrians.
Page 312 DRIVER SUPPORT Pedestrians Large animals body and the person must be at least 32 in. (80 cm) tall. • City Safety can also help detect pedestrians in dark conditions if they are in the path of the vehicle's headlights. WARNING City Safety is designed to be a supplementary driving aid.
Page 313: City Safety In Crossing Traffic
DRIVER SUPPORT City Safety in crossing traffic WARNING WARNING City Safety can help the driver when turning in • City Safety is designed to be a supplementary City Safety is a supplementary driving aid the path of an oncoming vehicle in an intersec- driving aid.
Page 314: City Safety When Evasive Action Is Not Possible
DRIVER SUPPORT City Safety when evasive action is City Safety™ troubleshooting However, if City Safety determines that an eva- not possible sive steering maneuver is not possible due to a Messages pertaining to any possible problems lack of space in the adjacent traffic lanes, the City Safety can help the driver by automatically with City Safety will be displayed in the instru- function will attempt to assist the driver by auto-...
Page 315 The following table shows some of the situations When replacing windshield wipers, use CAUTION that can cause the message to be displayed and the same type or ones approved by Volvo. • Service and maintenance on City Safety suggested actions.
Page 316: City Safety Limitations
DRIVER SUPPORT City Safety limitations Related information Do not mount or in any way attach anything on • the windshield that could obstruct the camera/ Radar sensor limitations (p. 299) City Safety™ may have limited or reduced func- radar sensor. •...
Page 317 43 mph (70 km/h) and less effective at lower speeds. Camera and radar sensor components should only be serviced or replaced by a trained and qualified Volvo service technician. WARNING Action by the driver • Warnings for stationary or slow-moving...
Page 318 DRIVER SUPPORT • Do not place, attach or mount any objects on the inside or outside of the windshield near or over the sensor. This could affect the camera-based functions. • Objects, snow, ice or dirt in the camera's field of vision may result in certain func- tions being reduced or disabled, or they may respond incorrectly.
Page 319: City Safety Symbols And Messages
Automatic intervention City Safety The system is not functioning properly. Contact a trained and authorized Volvo service technician. Reduced functionality Service required A text message can be erased by briefly pressing the O button on the right-side steering wheel keypad.
Page 320: Rear Collision Warning (Rcw)
DRIVER SUPPORT • Rear Collision Warning (RCW) Seat belts (p. 61) NOTE • Rear Collision Warning with braking at City Safety warning level settings (p. 308) • Due to local traffic regulations in certain standstill (RCW) function can help the driver markets, RCW will not activate the rear avoid rear-end collisions.
Page 321: Blind Spot Information (Blis)
DRIVER SUPPORT Blind Spot Information (BLIS)* Overview Blind Spot Information is a system designed to alert the driver to the presence of other vehicles moving in the same direction as your vehicle on roads with several lanes. Blind Spot Information is a driving aid intended •...
Page 322: Blind Spot Information (Blis)* On/Off
DRIVER SUPPORT Blind Spot Information (BLIS)* If BLIS is deactivated when the engine is WARNING On/Off switched off, it will remain off the next time the • Blind Spot Information does not function engine is started and the indicator lights in the The Blind Spot Information function can be acti- in sharp curves.
Page 323: Blind Spot Information (Blis)* Limitations
Dirt, ice and snow on the sensors may repainting the rear bumper should only be reduce functionality and prevent the system When does Cross Traffic Alert function done by a trained and qualified Volvo service from providing warnings. technician. •...
Page 324: Activating/Deactivating Cross Traffic
DRIVER SUPPORT • Activating/deactivating Cross Traffic Related information An audible signal indicates that CTA has Alert (CTA)* • detected something that is approaching from Cross Traffic Alert (CTA)* (p. 321) the side. The signal will come from either the • Cross Traffic Alert (CTA) can be activated/deac- Blind Spot Information (BLIS)* On/Off left or right infotainment system speakers,...
Page 325 Repairs to the BLIS/CTA systems and/or reduce the system's function or make it repainting the rear bumper should only be impossible to detect other vehicles or done by a trained and qualified Volvo service objects. technician. The vehicle is pulled far into a parking space •...
Page 326 DRIVER SUPPORT • Blind Spot Information (BLIS)* with Cross Traffic Alert (CTA)* symbols and messages (p. 325) • Blind Spot Information (BLIS)* limitations (p. 321) * Option/accessory, for more information, see Introduction.
Page 327: Blind Spot Information (Blis)* With
Message Explanation Blind spot sensor The system is not functioning properly. Contact a trained and qualified Volvo service technician Service required Blind spot system off BLIS and CTA have been deactivated because a trailer has been connected to teh vehicle's electrical system.
Page 328: Road Sign Information (Rsi)* Operation
DRIVER SUPPORT Road Sign Information (RSI)* Road Sign Information (RSI)* NOTE operation RSI is a feature that helps the driver see road If the vehicle is equipped with the Sensus signs showing the posted speed limit. Navigation system, speed-related information Speed limit information is provided by this system in the following instances:...
Page 329 DRIVER SUPPORT Activating/deactivating RSI 4. Select the limit at which the speed warning is If the Sensus navigation system to be given by pressing the up/down arrows. in your vehicle is being used, RSI can be activated/deacti- the driver can be alerted if the vated in the center display's Please be aware that the set warning limit vehicle is exceeding a detected...
Page 330: Road Sign Information (Rsi)* Limitations
DRIVER SUPPORT Driver Alert Control (DAC) Road Sign Information (RSI)* Related information limitations • Road Sign Information (RSI)* (p. 326) DAC is intended to alert the driver if his/her driv- • ing becomes erratic due to e.g., distraction or The RSI function may be limited in certain situa- Road Sign Information (RSI)* operation fatigue.
Page 331: Using Driver Alert Control (Dac)
DRIVER SUPPORT Using Driver Alert Control (DAC) WARNING DAC settings are made in the center display's • DAC is not intended to extend the dura- menu system. tion of driving. Always plan breaks at reg- ular intervals to help remain alert. Activating/deactivating Driver Alert •...
Page 332: Driver Alert Control Limitations
DRIVER SUPPORT Driver Alert Control limitations Driving lane assistance Driver Alert Control (DAC) may in certain situa- Lane Assistance functions are designed to tions have limited or reduced functionality. help reduce the risk of accidents in situations where the vehicle unintentionally leaves its lane In certain situations, DAC may provide warnings on highways or other major roads.
Page 333 DRIVER SUPPORT will sound and the following message will be dis- NOTE played: If the turn signal is used, Lane Keeping Aid • Lane Keeping Aid Standby until – will not provide an alert or steering assis- steering applied tance. If the driver still does not begin to steer the vehi- cle, LKA will go into standby mode.
Page 334: Activating/Deactivating Lane
DRIVER SUPPORT Activating/deactivating Lane Limitations Lane Keeping Aid Warning 3. Under Keeping Aid (LKA) Feedback , select: In certain demanding driving situations, the driv- ing lane assistance functions may not be able to • LKA can be activated/deactivated. Sound : an audible warning signal will be assist the driver.
Page 335 DRIVER SUPPORT Driving lane assistance symbols LKA are monitoring the driving lane's marker Steering/warning indicator and messages line(s). Not available A number of symbols and messages relating to Lane Keeping Aid (LKA) may appear in the instrument panel. Symbols in the instrument panel The driving lane assistance systems use a symbol in the instrument panel in different...
Page 336 The following table lists several LKA-related symbols and messages. Symbol Message Explanation Driver support system The system is not functioning properly. Contact a trained and qualified Volvo service techni- cian. Reduced functionality Service required Windscreen sensor The camera's functionality is limited.
Page 337 DRIVER SUPPORT Run-off Mitigation Run-off Mitigation with steering assistance Run-off Mitigation with steering assistance only and braking Run-off Mitigation is designed to assist the driver by helping return the vehicle to its traffic lane if it is about to go off the road. Run-off Mitigation is active at speeds between on roads with 40–87 mph (65–140 km/h)
Page 338 DRIVER SUPPORT The setting selected when the engine was WARNING switched off will be used the next time the • Run-off Mitigation is only intended to engine is started. assist the driver and does not function in all driving, weather, traffic or road condi- Limitations tions.
Page 339: Messages Run-Off Mitigation
Run-off Mitigation This message indicates that Run-off Mitigation has been activated. Automatic intervention Driver support system The system is not functioning properly. Contact a trained and qualified Volvo service techni- cian. Reduced functionality Service required Windscreen sensor The camera's functionality is limited.
Page 340: Park Assist
The highlighted sector shows which of the sen- a supplementary aid when parking the vehicle. ing is used. If a non-Volvo trailer hitch is being sors has detected the object. The closer the It is not, however, intended to replace the driv-...
Page 341: Activating/Deactivating Park Assist
DRIVER SUPPORT Activating/deactivating Park Assist Side park assist Front park assist The Park Assist system can be turned on or off. On/Off Park Assist's front and side sensors are activated automatically when the engine is started. The rear sensors activate if the vehicle rolls rearward in N or if R is selected.
Page 342: Park Assist Limitations
DRIVER SUPPORT Park Assist limitations Cleaning the sensors NOTE The Park Assist system has certain limitations. • The system will not detect high objects, such as a loading dock, etc. NOTE • Certain materials or fabrics may not be A trailer hitch whose wiring is integrated with detected by the sensors.
Page 343: Park Assist Symbols And Messages
Message Explanation Park Assist System The system is not functioning properly. Contact a trained and qualified Volvo service technician. Unavailable Service required Park Assist System One or more of the system's sensors are blocked. Check and clean the sensors as soon as possible.
Page 344: Park Assist Camera (Pac)
DRIVER SUPPORT Park Assist Camera (PAC)* CTA: Cross Traffic Alert* On/Off selected camera will be displayed at the top of the view. The Park Assist Camera system is designed to Zoom: Zoom in/out provide the driver with a view of the area around Panorama (360°) view the vehicle in the form of a camera image and NOTE...
Page 345 DRIVER SUPPORT Backing up Front camera NOTE The front camera will only reactivate automati- Auto Camera Reverse Activation cally if Settings My Car has been selected in Park Assist. Side camera Location of the rear Park Assist Camera (generic illus- Location of the front Park Assist Camera (generic illus- tration) tration)
Page 346: Park Assist Camera (Pac)* Trajectory
DRIVER SUPPORT Park Assist Camera (PAC)* These lines also indicate the outermost limits that Models with the 360° panorama camera trajectory lines and fields any object (door mirrors, corners of the body, a system and Park Assist sensors* trailer hitch, etc.) extends out from the vehicle, The Park Assist Camera system uses trajectory even when it turns.
Page 347 DRIVER SUPPORT Front and rear sensor fields Trajectory lines for a trailer hitch (towbar) Side sensors If the vehicle is also equipped with the optional The side fields will only be shown in orange. Park Assist system, this information will be dis- Side field color Distance to the object played on the screen as colored field showing...
Page 348 DRIVER SUPPORT Starting the Park Assist Camera Activating/deactivating automatic start 2. Tap My Car Park Assist. (PAC)* of PAC Rear View Instead of 360° 3. Select to set PAC can be started automatically when reverse PAC starts automatically when the gear selector the rear view as default.
Page 349: Park Assist Camera* (Pac) Limitations
DRIVER SUPPORT • Park Assist Camera* (PAC) 360° view the trunk is open With selected, objects/obstacles may limitations not be detected at the edges of the individual Ambient lighting cameras' fields of vision. The Park Assist Camera system has certain limi- The camera images are adjusted automatically to tations that the driver should be aware of.
Page 350: Park Assist Pilot (Pap)
DRIVER SUPPORT Park Assist Pilot (PAP)* Types of parking Perpendicular parking Park Assist Pilot (PAP) helps the driver drive into Parallel parking parallel or perpendicular parking spaces and leave parallel parking spaces. Park Assist Pilot provides assistance when park- ing by measuring the parking space and turning the steering wheel to guide the vehicle into the space.
Page 351: Using Park Assist Pilot (Pap)
DRIVER SUPPORT Using Park Assist Pilot (PAP)* WARNING NOTE Park Assist Pilot (PAP) gives the driver instruc- • PAP does not function in all situations If a trailer hitch is configured in the vehicle's tions during the parking procedure. The function and is only intended to assist the driver electrical system, PAP will take the trailer can also assist when leaving a parking space.
Page 352 DRIVER SUPPORT Park In 1: Searching and measuring 2: Backing into the parking space 1. Tap the button in the center display's Function view. If necessary, slow down to: • a speed below 20 mph (30 km/h) for parallel parking •...
Page 353 DRIVER SUPPORT When the vehicle is backing up, PAP will steer it 3: Adjusting the vehicle's position adjusted by driving slightly forward and backing into the parking space. Do as follows: 1. Put the gear selector in D, wait until the 1.
Page 354: Park Assist Pilot (Pap)* Limitations
Changing to a different approved tire size cle's exhaust, etc.) emitting ultrasound may affect PAP's parameters. Consult a using approximately the same frequen- trained and qualified Volvo service technician. cies as PAP. * Option/accessory, for more information, see Introduction.
Page 355 DRIVER SUPPORT • Maintenance Heavy rain or snow may inhibit PAP's capacity to correctly measure a parking space. • Do not use PAP when using snow chains and/or a temporary spare tire. • Do not use PAP if there are any objects pro- truding from the vehicle.
Page 356: Park Assist Pilot (Pap)* Symbols And
Message Explanation Park Assist System The system is not functioning properly. Contact a trained and qualified Volvo service technician. Unavailable Service required Park Assist System One or more of the system's sensors are blocked. Check and clean the sensors as soon as possible.
Page 357 STARTING AND DRIVING...
Page 358: Starting And Driving
STARTING AND DRIVING Starting and driving Brakes Anti-lock Braking System ABS The ABS system helps to improve vehicle control The vehicle is equipped with features that sup- The brake system is a hydraulic system consist- (stopping and steering) during severe braking plement its basic functions, such as shifting ing of two separate brake circuits.
Page 359 STARTING AND DRIVING Brake pad inspection Instrument panel symbols WARNING On vehicles equipped with a jack*, the condition Symbol Explanation • Use the jack intended for the vehicle of the brake pads can be checked by raising the when changing a tire. For any other job, Check the brake fluid level.
Page 360: Brake Functions
NOT DRIVE. Have the vehicle towed to a matic brake assist functions. These systems help When the vehicle is no longer moving forward, trained and qualified Volvo service technician the driver by e.g., keeping the vehicle stationary Auto-hold applies the brakes automatically, either and have the brake system inspected.
Page 361: Brake Assist System
STARTING AND DRIVING Brake assist system Braking effect after a collision When Auto-hold is off, Hill Start Assist (HSA) will be activated to help prevent the vehicle from roll- In certain types of collisions, the vehicle's brakes The Brake Assist System (BAS) increases brak- ing backwards when starting up a hill.
Page 362: Emergency Brake Lights
STARTING AND DRIVING Emergency brake lights Hill Descent Control (HDC) Activating HDC This function can be activated in different ways, The emergency brake lights activate in the event HDC is a type of low-speed automatic engine depending on how the vehicle is equipped. of hard braking/rapid deceleration at most nor- brake and makes it possible to increase or mal driving speeds or if the ABS system is acti-...
Page 363: Hill Start Assist
STARTING AND DRIVING Hill Start Assist Parking brake From the center display's Function view Models without the drive mode Hill Start Assist (HSA) helps prevent the vehicle The electric parking brake helps to keep the Hill control have a button for from rolling backwards when starting up a hill.
Page 364: Using The Parking Brake
STARTING AND DRIVING Using the parking brake ted. If it is applied while the vehicle is moving, the Symbol in the instrument panel normal brakes are used on all four wheels. The The electric parking brake helps to keep the Symbol Explanation brakes will only be applied on the rear wheels...
Page 365 STARTING AND DRIVING Releasing the parking brake 1. Keep the electric parking brake control NOTE pushed in. • For safety reasons, the parking brake is 2. While pressing the accelerator pedal to pull only released automatically if the engine away, release the parking brake control only is running and the driver is wearing a seat after the vehicle begins to move.
Page 366: Parking Brake Malfunctions
It is always worthwhile to have your vehicle Symbol Explanation parking brake after several attempts, consult a checked by a trained and qualified Volvo service If the symbol flashes, a parking trained and authorized Volvo service technician technician before driving long distances. Your brake fault has been detected.
Page 367: Driving Economically
STARTING AND DRIVING • Driving economically in countries where it may be difficult to Remove snow tires when threat of snow or obtain the correct fuel. ice has ended. Better driving economy can be obtained by • • Consider your destination. If you will be driv- thinking ahead, avoiding rapid starts and stops Note that roof racks, ski racks, etc, increase ing through an area where snow or ice are...
Page 368: Driving Through Standing Water
STARTING AND DRIVING Driving through standing water the steering wheel has to be turned more CAUTION than might seem appropriate for the curva- The vehicle should be driven with extreme cau- • Engine damage will occur if water is ture of a bend. This ensures good stability tion if it is necessary to drive through standing drawn into the air cleaner.
Page 369: Overheating The Engine And Transmission
STARTING AND DRIVING • Overheating the engine and Related information The air conditioning may be switched off • transmission temporarily. Towing recommendations (p. 370) • In demanding driving conditions, such as when After a prolonged period of driving, do not transporting heavy loads, driving in mountainous turn off the engine immediately after stop- areas or in very hot weather there is a risk of...
Page 370: Winter Driving
• Volvo recommends the use of snow tires on side of the front and rear bumpers. There are The following advice is worth noting: all four wheels for winter driving.
Page 371 STARTING AND DRIVING CAUTION In certain conditions, the towing eyelet may be used to pull the vehicle onto a flatbed tow truck. • The vehicle's position and ground clear- ance determine if it can be pulled up onto a flatbed tow truck using the towing eye- let.
Page 372: Towing Recommendations
STARTING AND DRIVING Towing recommendations CAUTION WARNING Always check with state and local authorities • General towing precautions: When the vehicle is being towed, the igni- before attempting to tow another vehicle tion should be in mode II (in mode I, all of •...
Page 373 STARTING AND DRIVING Tow trucks To do so: WARNING Settings 1. Tap in the center display's Top PROPOSITION 65 WARNING! CAUTION view. Battery posts, terminals, and related accesso- In certain conditions, the towing eyelet 2. Tap ries contain lead and lead compounds, chemi- My Car Suspension may be used to pull the vehicle onto a...
Page 374: Fuel
If this occurs, please return NOTE your vehicle to a trained and qualified Volvo service technician for service. Volvo does not recommend the use of exter- nal fuel injector cleaning systems.
Page 375: Octane Rating
TOP TIER Detergent Gasoline Many fuels contain benzene as a solvent. Unburned benzene has been strongly linked to Volvo endorses the use of “TOP TIER Detergent certain forms of cancer. If you live in an area Gasoline” where available to help maintain engine where you must fill your own gas tank, take pre- performance and reliability.
Page 376: Opening/Closing The Fuel Filler Door
3. Avoid overfilling the fuel tank. Do not press the vehicle to a trained and qualified Volvo the handle on the filler nozzle after it has service technician for correction.
Page 377: Emission Controls
STARTING AND DRIVING Emission controls or location or removing components, and/or CAUTION repeated use of leaded fuel. Avoid spilling gasoline during refueling. In Three-way catalytic converter addition to causing damage to the environ- • Keep your engine properly tuned. Certain NOTE ment, gasolines containing alcohol can cause engine malfunctions, particularly involving the...
Page 378: Jump Starting
• All Volvo models are equipped with energy- • Do not connect the trailer's brake system Related information absorbing shock-mounted bumpers. Trailer directly to the vehicle's brake system.
Page 379 An adapter is required if the vehicle's trailer hitch more than 15%. has a 13-pin connector and the trailer has 7 pins. Use an adapter cable approved by Volvo. Make sure the cable does not drag on the ground. Self-leveling suspension*...
Page 380: Detachable Trailer Hitch
3. Align the hole in the ball holder with the one • in the hitch assembly. Detachable trailer hitch (p. 378) Volvo recommends the use of Volvo trailer • hitches that are specially designed for the vehi- Trailer Stability Assist (TSA) (p. 379) 4.
Page 381: Trailer Stability Assist (Tsa)
STARTING AND DRIVING Trailer Stability Assist (TSA) Stowing the ball holder How TSA works Once swaying has begun, it can be very difficult Trailer Stability Assist is a system designed to to stop, which makes it difficult to control the help stabilize a vehicle that is towing a trailer vehicle and trailer.
Page 382: Ignition Modes
STARTING AND DRIVING Ignition modes Related information Mode Functions available • Detachable trailer hitch (p. 378) The vehicle's ignition can be put in various • The odometer, clock and tem- • modes (levels) to make different functions availa- Driving with a trailer (p. 376) perature gauge are illuminated ble.
Page 383: Battery Drain
STARTING AND DRIVING Battery drain NOTE Mode Functions available Your vehicle's electrical functions drain the bat- To access ignition modes I or II without star- • The headlights illuminate tery to varying extents. ting the engine, the brake pedal must not be •...
Page 384: Starting The Engine
3. Turn the start knob toward START and impeded. release it to start the engine. • Volvo's floor mats are specially manufac- > The starter motor will crank until the tured for your car. They must be firmly secured in the clips on the floor so that...
Page 385 STARTING AND DRIVING back-up reader in the tunnel console (see the WARNING CAUTION illustration) and try again to start the engine. • • Always remove the remote key from the When starting in cold weather, the auto- passenger compartment when leaving the matic transmission may shift up at slightly NOTE vehicle and ensure that the ignition in...
Page 386: Turning The Engine Off
STARTING AND DRIVING Turning the engine off Drive modes* Selecting a drive mode The engine can be turned off using the start Selecting a drive mode affects the vehicle's driv- knob on the tunnel console. ing characteristics to help make driving more enjoyable or easier in certain types of situations.
Page 387 STARTING AND DRIVING • Not possible to select due to limitations INDIVIDUAL • This setting allows you to adapt a driving mode to Not possible to select due to high your personal preferences. speed Select one of the other driving modes as a basis Available drive modes and change the settings to provide the driving COMFORT...
Page 388: Eco Drive Mode
STARTING AND DRIVING ECO drive mode Comfort Dynamic Selecting ECO mode 3. Select: When the engine is switched off, ECO mode is The Eco drive mode is a function designed to The following settings can be modified: deactivated and must be reactivated each time give the driver the opportunity to drive more eco- •...
Page 389 STARTING AND DRIVING • With the drive mode control* This feature is primarily intended to be used in The vehicle's speed is between approxi- driving situations where the vehicle can roll freely, mately 40 and 87 mph(65 and 140 km/h) such as down gentle hills or when a decrease in Always observe posted speed limits speed is expected, such as when approaching an...
Page 390 STARTING AND DRIVING • ECO gauge in the instrument panel Deactivating and turning off Eco Coast A low reading in the green area indicates economical driving. In certain situations, it may be advisable to switch • off the Eco Coast function, such as: A higher reading indicates higher fuel con- •...
Page 391: Start/Stop
STARTING AND DRIVING Start/Stop Using the Start/Stop function approx. 3 seconds. See also the article "Condi- tions for Start/Stop." Start/Stop is a function that temporarily switches Start/Stop is a function that temporarily switches off the engine when the vehicle is not moving, off the engine when the vehicle is not moving, Auto-start for instance in heavy traffic or at a traffic light, to...
Page 392 STARTING AND DRIVING Symbols in the instrument panel Related information Symbol Explanation • Conditions for Start/Stop (p. 391) 12" instrument panel White symbol: the function is avail- • • READY Start/Stop (p. 389) will be displayed in the tachometer able. when Start/Stop is available.
Page 393: Conditions For Start/Stop
STARTING AND DRIVING • • Conditions for Start/Stop the road's incline is very steep. condensation forms on the inside of the win- dows. • Certain conditions must be met for the Start/ the hood is opened. • Stop feature to function. If a condition is not met, the climate system cannot keep the desired •...
Page 394: Automatic Transmission
STARTING AND DRIVING Automatic transmission Related information WARNING • Gear selector positions (p. 394) The automatic transmission has 8 forward gears Do not open the hood if the engine has auto- • and shifts up or down based on the level of Gear shift indicator (p.
Page 395: Shiftlock
STARTING AND DRIVING Shiftlock Automatic shiftlock from the P or D positions into N so that the vehi- cle can be moved. To do so: The automatic transmission's shiftlock feature From Park – P helps prevent inadvertently moving the gear In order to move the gear selector from the P Lift away the rubber mat on the bottom of selector between different positions.
Page 396: Gear Shift Indicator
STARTING AND DRIVING Gear shift indicator Gear selector positions The ignition must be in mode II and the brake pedal must be depressed before the gear selec- The gear shift indicator in the instrument panel The automatic transmission has 8 forward gears tor can be moved from P.
Page 397: Steering Wheel Paddles
STARTING AND DRIVING Steering wheel paddles* Drive – D For smooth shifting and engine performance, the D is the normal driving position and gear shifting transmission will shift down automatically if the In addition to the manual gearshift function using vehicle's speed becomes too low for the selected is fully automatic.
Page 398 STARTING AND DRIVING Manually shifting gears The number of the current gear will no longer be In shift mode M, the paddles are automatically displayed. activated. The paddles will remain active if engine braking is currently being used. Related information •...
Page 399: Low Speed Control (Lsc)
All Wheel Drive (AWD) NOTE Low Speed Control (LSC) helps make off-road Your Volvo can be equipped with All Wheel The function is deactivated when driving at driving easier on slippery surfaces when towing Drive, which means that power is distributed higher speeds and must be reactivated at a trailer on grass, etc.
Page 400: Suspension And Leveling Control
STARTING AND DRIVING Suspension and leveling control* Transport When transporting the vehicle on a ferry, train or Self-leveling and the active chassis functions are a tow truck, it may only be secured (lashed) controlled automatically. around the tires, not using any other chassis Self-leveling control components.
Page 401 INFOTAINMENT...
Page 402: The Infotainment System
INFOTAINMENT The infotainment system Apps (applications) Related information • Media player (p. 424) The infotainment system consists of a radio, Apps (applications) are programs used to con- • media player and has the capacity to communi- trol some of the vehicle's features and functions. Radio (p.
Page 403: Sound Settings
INFOTAINMENT Sound settings Some apps are only available if the vehicle is ceiling liner react to engine noise and the info- connected to the Internet. tainment system produces signals (white noise) The infotainment system is precalibrated for opti- to counteract this. mal sound reproduction but these settings can –...
Page 404: Radio
INFOTAINMENT • Radio Radio settings Radio (p. 402) • Your vehicle's radio offers AM and FM with HD The following information lists the settings that HD Radio™reception (p. 404) Radio ™ Technology and SiriusXM ® can be made for the various wavebands. Satellite radio*.
Page 405: Rbds Radio
INFOTAINMENT RBDS radio Changing and searching for radio Favorites stations If a favorite station from a list is currently availa- RBDS radio ble, the radio will automatically tune to that sta- The radio automatically compiles a list of the RBDS (Radio Data Broadcast System) enables tion.
Page 406 INFOTAINMENT HD Radio™reception Library Changing wavebands 1. Tap HD Radio is a brand name registered by the 2. Tap iBiquity digital corporation . They are the devel- > The search view with a keyboard will open. oper of a broadcasting technology called IBOC 3.
Page 407 INFOTAINMENT How HD Radio ™ Technology The IBOC system is referred to as a "hybrid" be displayed immediately. Album art is synched since it is both analogue and digital. During with the artist that you are currently listening to. broadcasting works hybrid operation, receivers still continue to HD Radio works similarly to conventional radio iTunes tagging...
Page 408: Switching Hd Radio On And Off
INFOTAINMENT Switching HD Radio on and off HD Radio sub-channels Related information • HD Radio™reception (p. 404) The factory setting for HD Radio is off. In many cases, a main HD Radio station (FM • wavebands only) will also have sub-channels HD Radio sub-channels (p.
Page 409: Hd Radio Limitations
INFOTAINMENT HD Radio limitations Selecting sub-channels NOTE To listen to a station's sub-channel(s), tap the There may be a noticeable difference in Limitations station on the screen or press the forward/back sound quality when a change from analogue • Main channel vs. sub-channels (FM only): arrow keys on the right-side steering wheel key- to digital or digital to analogue occurs, such The main channel is the only channel that...
Page 410: Siriusxm ® Satellite Radio
INFOTAINMENT ® SiriusXM Satellite radio* function and display the channel list included in your subscription. ® The SiriusXM Satellite system broadcasts from of a number of high elevation satellites in geo- Related information synchronous orbit. • ® Using SiriusXM Satellite radio radio* (p.
Page 411: Using Siriusxm ® Satellite Radio Radio
INFOTAINMENT ® Using SiriusXM Satellite radio EPG (Electronic Program Guide) Search radio* Tap the magnifying glass to display a screen On the center display's Home screen, tap where you can enter text using the center dis- for information about e.g., when a program is ®...
Page 412: Siriusxm ® Satellite Radio* Settings
INFOTAINMENT ® iTunes tagging SiriusXM Satellite radio* settings JUMP From the Home screen, tap to activate the SiriusXM function. When traffic/weather information is From the center display's Top view, tap There are numerous settings that can be made available from the selected city, the radio will Settings iTunes Tagging .
Page 413: Siriusxm Travel Link
INFOTAINMENT SiriusXM Travel Link* Game Alerts Skipped categories Tap to display a list of sports. Tap to display a list of categories. Tap a category SiriusXM Travel Link is a feature offered by to skip (hide) it. It will not be displayed in the list ®...
Page 414 INFOTAINMENT • Subscription Status 3. Tap Navigating in the center display's views NOTE (p. 38) > To subscribe, call the phone number listed If the Close button is used to return to • on the screen. SiriusXM Travel Link - Weather (p. 413) SiriusXM Travel Link home screen, the follow- •...
Page 415: Siriusxm Travel Link - Weather
INFOTAINMENT SiriusXM Travel Link - Weather Local 5 days Tap to see weather information for the coming 5 Information from the closest weather station will This SiriusXM Travel Link service provides days. be displayed and the following alternatives are weather-related information near the vehicle, at a available: local ski resort, etc.
Page 416: Siriusxm Travel Link - Alerts
INFOTAINMENT SiriusXM Travel Link - Alerts Areas Call If a phone number is available in an alert, a Areas button will be displayed. Tap this button for addi- to display a list of areas/locations in This SiriusXM Travel Link service provides alerts tional information.
Page 417: Siriusxm Travel Link - Fuel
INFOTAINMENT SiriusXM Travel Link - Fuel appear on the screen. Enter the text of your line (unless another grade/type of fuel has been Search Select fuel type choice and tap for detailed information if selected in ) or of stations This SiriusXM Travel Link service provides infor- available.
Page 418: Siriusxm Travel Link - Sports
INFOTAINMENT SiriusXM Travel Link - Sports Nearest 4. Tap one of the divisions to display: arrange the list according to Recommended Done . Tap to return to the pre- • This SiriusXM Travel Link service provides infor- In progress : play-by-play information vious screen.
Page 419: Phone
INFOTAINMENT • Phone Overview Text message settings (p. 423) A Bluetooth-enabled cell phone can be paired and connected to the vehicle's integrated hands- free system. The infotainment system offers hands-free func- tionality for remote-controlling a number of a cell phone's features. The phone's integrated controls can also be used, even when it is connected to the vehicle.
Page 420: Pairing A Cell Phone
INFOTAINMENT Pairing a cell phone There are two ways of pairing a Bluetooth device 5. For the phone selected, accept or cancel the to the infotainment system: alternatives for the phone book (list of con- ® A Bluetooth -enabled cell phone or other device tacts), text messages, etc.
Page 421: Connecting/Disconnecting A Cell Phone
Communication www.volvocars.com for a list of compatible 2. In the center display, open Phone view and Bluetooth. phones or contact your Volvo retailer. Change phone > A list of available Bluetooth devices (ones Related information > A list of available Bluetooth devices (ones that have already been paired to the info- •...
Page 422: Handling Phone Calls
INFOTAINMENT Handling phone calls Remove device 4. Tap 2. Initiate a call from: recently made calls, the and confirm. phone book (list of contacts) or enter a num- > The phone or other device is no longer Calls can be made to one or more parties. ber.
Page 423: Handling Text Messages
INFOTAINMENT • Handling text messages Incoming calls Using the center display (p. 45) • Information about incoming calls is displayed in Using the center display keyboard (p. 31) Text messages can be received and sent from a the instrument panel and the center display. Han- connected cell phone.
Page 424: Phone Settings
INFOTAINMENT Phone settings • To reply to a message: tap the name of The following settings can be made for a paired the contact who sent the message and and connected cell phone. Answer then tap • Create To create a new message: tap Cell phones +.
Page 425: Text Message Settings
Messages and choose among the following Consult your Volvo retailer or go to settings: support.volvocars.com for any questions regar- If there are two USB sockets, the one with a ding a device's compatibility with the vehicle's •...
Page 426: Media Player
INFOTAINMENT • Media player Apps (applications) (p. 400) • The media player can play audio from a CD*, CD (media) player* (p. 427) from external media devices connected to the • Playing media through the AUX/USB sock- USB/AUX sockets or it can stream audio from ets (p.
Page 427: Apple Carplay
(including its position) is transferred to your Apple CarPlay helps make it possible to listen to • Please be aware that Volvo has no con- iPhone. In relation to Volvo Cars, you are music, make phone calls, get directions to a...
Page 428: Apple Carplay Settings
INFOTAINMENT Apple CarPlay settings From a previously connected iPhone 3. Deselect the Apple device's box that will no longer start Apple CarPlay when it is con- 1. Connect the iPhone to the USB socket in This article explains settings for a cell phone nected.
Page 429: Cd (Media) Player
INFOTAINMENT Playing media CD (media) player* 2. Tap Sound System Volumes and select the following settings: The CD (media) player can play commercially The media player can controlled from the right- purchased discs as well as ones that you have side steering wheel keypad, the center display or •...
Page 430 INFOTAINMENT Controlling and changing media Bluetooth-connected device 1. Insert a CD. 1. Connect the device. The media player can be con- trolled using voice commands, 2. Open the app in the center display's App 2. Activate Bluetooth in the device. the right-side steering wheel view.
Page 431: Media Searches
INFOTAINMENT Media searches Primary Audio Default Language Subtitle Play/pause: tap the track's image, press the Primary Subtitle Default Language symbol on the keypad or press the button under Searches can be made for information such as the center display. ® artists, composers, song titles, albums, video, Play DivX audio books, playlists and podcasts (digital...
Page 432: Playing Media Through The Aux/Usb Sockets
INFOTAINMENT Playing media through the Streaming media through a Search 3. Tap AUX/USB sockets Bluetooth connection > The infotainment system will search ® through all connected devices and any An external media device, such as an iPod or an The media player is equipped with Bluetooth results will be displayed by category.
Page 433: Media Sound Settings
INFOTAINMENT Media sound settings Gracenote System volumes for media Open the center display's Top view and tap Sound settings for the media player can be per- Gracenote identifies artists, albums, tracks and Settings Sound System Volumes: sonalized. any associated images that can be displayed during playback.
Page 434: Video
INFOTAINMENT • Video Media player technical data None : no results will be shown. The media player can play video from USB-con- The following tables list compatible file formats Updating Gracenote nected devices. and other technical specifications for the media Gracenote's contents are updated continuously.
Page 435 INFOTAINMENT File extension .divx, .avi Format File extension Max. number Max. file size 4 GB .avi Tracks in a playlist 1,000 AVI (DivX) .avi, .divx Audio codec MP3, AC3 Subfolders No limit .asf, .wmv Subtitles XSUB USB socket • Type A socket Special func- Multiple subtitles, multiple .mkv...
Page 436: Internet Connected Vehicle
System updates (p. 470) The vehicle can connect to the Internet using The cell phone and the network service provider • Volvo ID (p. 27) Bluetooth, Wi-Fi, a cell phone connected by a must support Internet sharing (tethering) and the •...
Page 437 > The vehicle will connect to the network. When the vehicle is connected using the modem, (p. 419) Volvo On Call services will use the connection. Please be aware that certain cell phones disable • Connecting a device via the AUX/USB tethering when the connection to the vehicle has 1.
Page 438: Bluetooth Settings
INFOTAINMENT Bluetooth settings Downloading, updating and operated in conjunction with any other antenna uninstalling apps or transmitter. The following settings apply to a Bluetooth-con- nected cell phone or other device. When the vehicle is connected to the Internet, Canada apps can be added (downloaded), kept up-to- Bluetooth This device complies with Industry Canada date or deleted.
Page 439: Internet Connection Troubleshooting
INFOTAINMENT Internet connection troubleshooting Install Uninstalling an app 3. Select to start downloading the app. It will remain in the list and a new download An app being used must be closed before it can The following are factors that may affect the can be initiated if necessary.
Page 440: Tethering (Wi-Fi Sharing)
INFOTAINMENT Tethering (Wi-Fi sharing) Related information Connected devices to see a list of con- • nected devices. Internet connected vehicle (p. 434) When the vehicle is connected to the Internet, • this connection can be shared (tethered) with Connecting to the Internet (p. 434) Related information other devices •...
Page 441: Deleting Wi-Fi Networks
INFOTAINMENT Deleting Wi-Fi networks Wi-Fi technology and security Vehicle modem settings Networks that are not used can be deleted. The following are types of networks can be con- The vehicle is equipped with a modem that can nect to. be used to connect the vehicle to the Internet. It Settings 1.
Page 442: Infotainment System License Information
INFOTAINMENT Infotainment system license Change PIN Dirac Live technology has been used in the : enter max. 4 digits. information development and tuning of the sound in order to Disable ensure a world-class sound experience. Dirac The following license information pertains to Vol- : Allow access to the SIM card without Live and the D-symbol are registered trademarks vo's agreements with certain manufacturers/...
Page 443 INFOTAINMENT ® Gracenote agree not to assign, copy, transfer or transmit the or implied, regarding the accuracy of any Grace- Gracenote Software or any Gracenote Data to note Data from in the Gracenote Servers. Grace- any third party. YOU AGREE NOT TO USE OR note reserves the right to delete data from the EXPLOIT GRACENOTE DATA, THE GRACE- Gracenote Servers or to change data categories...
Page 444 INFOTAINMENT 1993), The Regents of the University of SUBSTITUTE GOODS OR SERVICES; LOSS OF oss.sgi.com/projects/FreeB/ shall be included in California. All or some portions are derived from USE, DATA, OR PROFITS; OR BUSINESS all copies or substantial portions of the Software. material licensed to the University of California by INTERRUPTION) HOWEVER CAUSED AND ON THE SOFTWARE IS PROVIDED "AS IS",...
Page 445 INFOTAINMENT You have the right of acquisition, modification, of conditions and the following disclaimer in "Data Files") or Unicode software and any and distribution of the source code of the GPL/ the documentation and/or other materials associated documentation (the "Software") to LGPL software.
Page 446: Terms, Conditions And Confidentiality
Except as contained in this notice, the name of a Terms & Conditions for Services copyright holder shall not be used in advertising Volvo offers the best possible services to make or otherwise to promote the sale, use or other owning and operating a Volvo safe, convenient, dealings in these Data Files or Software without comfortable and enjoyable.
Page 447 WHEELS AND TIRES...
Page 448: Tires
(radial) and CAUTION preferably from the same manufacturer, on all four wheels. Otherwise there is a risk of altering Some Volvo models are equipped with an the car's roadholding and handling characteris- Ultra High Performance tire and wheel com- tics.
Page 449 WARNING ble cracks or discoloration should be replaced • • The wheel and tire sizes for your Volvo If the tires are rotated, they should only immediately. are specified to meet stringent stability be moved from front to rear or vice versa.
Page 450: Tire Sidewall Designations
WHEELS AND TIRES Tire sidewall designations NOTE NOTE The following information can be found on a Please be aware that the following tire desig- The tire's load index and speed rating may tire's sidewall. nation is an example only and that this par- not appear on the sidewall because they are ticular tire may not be available on your vehi- not required by law.
Page 451: Wheel (Rim) Designations
42.5 Offset in mm (distance from the center The wheel and tire sizes for your Volvo top speed. of the wheel to the wheel's contact sur- are specified to meet stringent stability and handling requirements.
Page 452: Tire Terminology
• Recommended tire inflation pressure: rying capability. inflation pressure, established by Volvo, • Extra load: A class of P-metric or Metric which is based on the type of tires that are tires designed to carry a heavier maximum mounted on a vehicle at the factory.
Page 453: Tire Direction Of Rotation
• Contact a trained and qualified Volvo service Related information technician if you are unsure about the tread • Tire direction of rotation (p. 451) depth.
Page 454: Loading Specifications
Safety Standards (FMVSS/CMVSS) label, and rating. Use only tires with the correct load 3. Subtract the combined weight of the driver the vehicle's tire information placard: carrying capacity. Consult your Volvo and passengers from XXX kg or XXX lbs. retailer for information. Curb weight 4.
Page 455: Uniform Tire Quality Grading
WARNING MENTS IN ADDITION TO THESE GRADES. Snow chains can be used on your Volvo with the The traction grade assigned to this tire is Quality grades can be found, where applica- following restrictions:...
Page 456: Checking Tire Inflation Pressure
WHEELS AND TIRES Checking tire inflation pressure temperature drop causes a corresponding drop CAUTION of 1 psi (7 kPa) in inflation pressure. Check your Correct tire inflation pressure helps improve driv- • Snow chains should not be used on tire pressures frequently and adjust them to the ing stability, save fuel and increase the service wheels larger than 18".
Page 457 WHEELS AND TIRES of the factory-mounted tires on your vehicle, as 2. Add air to reach the recommended air pres- NOTE well as load limits and inflation pressure. sure. • If you overfill the tire, release air by push- 3. Replace the valve cap. ing on the metal stem in the center of the NOTE valve.
Page 458: Changing Tires
Be sure the jack is on a firm, level, non- the factory-installed tires, contact an authorized slippery surface. Volvo retailer to update the vehicle's software. • Never allow any part of your body to be This may also be necessary when changing from extended under a vehicle supported by a summer to winter tires, or vice versa.
Page 459: Spare Tire
• In the event of damage to this tire, a new the center display's Top view. cargo compartment. A retaining bolt holds the one can be purchased from your Volvo spare tire and foam block containing tools in retailer. place.
Page 460: Wheel Bolts
Checking tire inflation pressure (p. 454) lbs. (140 Nm). Over-tightening could damage the threads. Only use wheels/rims that have been tested and approved by Volvo and are included in Volvo's product range. Use a torque wrench to check that the wheel bolts are tightened correctly.
Page 461: Removing A Wheel
WHEELS AND TIRES Removing a wheel WARNING NOTE Wheel changes should always be carried out • The jack must correctly engage the jack The jack provided with your vehicle is correctly. attachment. intended to be used only in temporary situa- •...
Page 462: Installing A Wheel
WHEELS AND TIRES Installing a wheel 7. When hoisting the vehicle, it is essential that the jack (or garage lift arms) are positioned It is important to install wheels properly. correctly on the underside of the vehicle. 1. Clean the contact surfaces on the wheel and There are two jack attachment points on hub.
Page 463: Tire Pressure Monitoring System (Tpms)
WHEELS AND TIRES Tire Pressure Monitoring System the inflation pressure recommended by the vehi- CAUTION (TPMS) cle manufacturer on the vehicle placard or tire • After inflating the tires, always reinstall inflation pressure label. (If your vehicle has tires TPMS provides a warning if inflation pressure in the valve cap to help avoid damage to the of a different size than the size indicated on the one or more tires is too low.
Page 464: Checking Tire Inflation Pressure
WHEELS AND TIRES Checking tire inflation pressure When the system detects a malfunction, the tell- After changing wheels, always calibrate the sys- tale will flash for approximately one minute and tem to avoid false warnings. The Tire Pressure Monitoring System (TPMS) then remain continuously illuminated.
Page 465: Reinflating Tires Equipped With The Tire Pressure Monitoring System (Tpms)
System, see the article "Calibrating the Tire the TPMS symbol in the instrument panel Pressure Monitoring System". ) remains illuminated after flashing for 1 minute: the system is not functioning correctly. Have it checked by a trained and qualified Volvo service technician.
Page 466: Calibrating The Tire Pressure
WHEELS AND TIRES Calibrating the Tire Pressure 4. In some cases, it may be necessary to drive CAUTION Monitoring System (TPMS) the vehicle for several minutes at a speed of • After inflating the tires, always reinstall at least 20 mph (30 km/h) to erase the In order for the Tire Pressure Monitoring System the valve cap to help avoid damage to the TPMS telltale warning and the text message.
Page 467 WHEELS AND TIRES 6. Tap the calibration button. NOTE 7. Tap after the tire pressure in all four tires Always remember to calibrate the Tire Pres- has been checked and adjusted. sure Monitoring System when the wheels have been changed or the tire inflation pres- 8.
Page 469 MAINTENANCE AND SERVICING...
Page 470: Volvo's Service Program
• therefore must be performed by a qualified tech- Parts and Accessories Limited Warranty and services necessary for the proper nician. To keep your Volvo in top condition, spec- • Corrosion Protection Limited Warranty function of your vehicle and includes ify time-tested and proven Genuine Volvo Parts •...
Page 471 OBD II to • inspection? Wipe driver information displays with a soft reach readiness. Your Volvo retailer can pro- cloth. Your vehicle can fail OBD II emission inspection vide you with more information on planning a for any of the following reasons.
Page 472: System Updates
MAINTENANCE AND SERVICING System updates Related information NOTE • Climate system service (p. 475) Updates are available for infotainment-related Downloading data may affect other system services and Internet connections. If system soft- features that share the Internet connection. A ware updates are available, they can be to be download can be cancelled at any time or the downloaded all at once or separately.
Page 473: Remote Updates
MAINTENANCE AND SERVICING Remote updates Vehicle status Keep in mind that a download can be cancelled but an installation that has already begun cannot With the vehicle connected to the Internet, The vehicle's general status can be displayed in be interrupted. updates for a number of the vehicle's systems the center display along with the possibility to can be downloaded from the center display.
Page 474: Booking Service And Repairs
If you would like to register a different email the number of hours the engine has run This feature makes it convenient to book a work- address, open the Volvo ID app in the center dis- since the last service shop appointment directly from your vehicle.
Page 475 Sending vehicle-related information nection. Information about the vehicle can be sent at any > Volvo will send a booking invitation to your time using its Internet connection. email address with a link to your preferred Using this function does not send a workshop workshop's On-Line Service Scheduler.
Page 476: Wi-Fi Connection To A Workshop
App view. Each time the vehicle slows down to a sufficiently Appointments 2. Tap low speed, it begins searching for a Wi-Fi net- work. If an authorized Volvo network (at a retailer Appointments Workshop 3. Under , tap or workshop) is found, a message will be dis-...
Page 477: Climate System Service
The type of connection (manual or automatic) by unwanted requests to connect (e.g., if the done by a trained and qualified Volvo service can be changed in the center display's Settings vehicle is often parked near a workshop with an technician.
Page 478: Start Battery
If contact The start battery should only be replaced by a occurs, flush the affected area immedi- trained and qualified Volvo service technician. ately with water. Obtain medical help immediately if eyes are affected. The vehicle has an alternating current generator.
Page 479 MAINTENANCE AND SERVICING CAUTION NOTE • • The infotainment system's energy-saving The service life of the start battery is feature may not function correctly or at shortened if it becomes discharged all, and/or a message may be displayed if repeatedly. a battery charger or jumper cables are •...
Page 480: Support Battery
Cold start capacity (Cold • When replacing the start battery, a new bat- Cranking Amperes - tery with the same specifications and dimen- CCA) (A) sions must be used. The battery should only be replaced by a trained and qualified Volvo service technician.
Page 481 The support battery does not normally required more service than the start battery. If questions To help ensure auto-start, the start battery arise, consult a Volvo retailer or trained and quali- should be charged first. At a temperature of fied Volvo service technician.
Page 482: Hybrid Battery
Keep batteries away from children. NOTE A used battery should be disposed of in an environmentally responsible manner. Consult Batteries contain corrosive your Volvo retailer or take the battery to a acid. recycling station. Related information • Start battery (p. 476)
Page 483: Fuses
WARNING trained and qualified Volvo service technician. Never use metal objects or fuses with higher Location of the fuseboxes amperage than those stated on the following pages.
Page 484: Fuses In The Engine Compartment
MAINTENANCE AND SERVICING Fuses in the engine compartment The fuses in the engine compartment help pro- tect electrical components such as engine and brake functions.
Page 485 MAINTENANCE AND SERVICING Positions There is a fuse removal tool on the inside of the fuse box cover. There are also positions in the There is a decal on the inside of the cover with a fuse box for several extra fuses. list of fuses.
Page 486 Fuses 31–34, 38–45 and 71–78 are called side "MCase" and should only be replaced by a – – trained and qualified Volvo service technician. Feed when ignition is switched Heated windshield*, driver side Shunt on to: engine control module, Function...
Page 487 MAINTENANCE AND SERVICING Function Function – – – – – – – – – – – – Engine control module; actuator; – – Turbocharger valve – – Solenoids; Valves; Engine cool- ing system thermostat Starter motor Shunt Vacuum regulators; Valve Starter motor Spoiler shutter control module;...
Page 488: Fuses In The Passenger Compartment
MAINTENANCE AND SERVICING Fuses in the passenger tect electrical components such as the 120-volt There is a fuse removal tool on the inside of the compartment socket, displays and door modules. fuse box covers. There are also positions in the fuse box for several extra fuses.
Page 489 MAINTENANCE AND SERVICING...
Page 490 Head-up display* are called "Micro". • Fuses 2, 22, 37–38 and 54 are called – – Courtesy lighting "MCase" and should only be replaced by a trained and qualified Volvo service technician. – – – – Function – – Ceiling console display (seat belt reminder, front passenger side air- –...
Page 491 MAINTENANCE AND SERVICING Function Function – – – – Fuel pump control module Circuit breaker for fuses 53 and 58 – – Certain markets only. Related information – – • Fuses (p. 481) Driver side front seat heating* • Replacing fuses (p. 481) •...
Page 492: Fuses In The Trunk
MAINTENANCE AND SERVICING Fuses in the trunk The fuses in the trunk help protect electrical components such as power seats*, airbags and seat belt tensioners. * Option/accessory, for more information, see Introduction.
Page 493 MAINTENANCE AND SERVICING There is a fuse removal tool on the inside of the fuse box cover. There are also positions in the fuse box for several extra fuses.
Page 494 Fuses 1–12, 18–20 and 37 are called "MCase" and should only be replaced by a – – – – trained and qualified Volvo service technician. Foot movement detection module Blind Spot Information (BLIS)* Function for opening the power trunk –...
Page 495: Replacing Bulbs
• Condensation may form temporarily on face is flush with the surface of the clip. Consult your Volvo retailer if you are uncertain the inside of the lenses of exterior lights about the type of headlights in your vehicle. such as headlights, fog lights, or taillights.
Page 496 Brake light (LED) Fog light with corner illumination (LED)* Taillight (LED) Backup light High-mounted brake light (LED) Not available in all markets. Must be replaced by a trained and qualified Volvo service technician. * Option/accessory, for more information, see Introduction.
Page 497: Removing The Rectangular Headlight
MAINTENANCE AND SERVICING Removing the rectangular headlight Related information Related information • cover • Bulb specifications (p. 500) Replacing bulbs (p. 493) • Most of the bulbs in the headlight housing can Removing the rectangular headlight cover be accessed when the rectangular cover has (p.
Page 498: Replacing High Beam Headlight Bulbs
MAINTENANCE AND SERVICING Replacing low beam headlight bulbs Replacing High Beam headlight 2. Remove the connector from the bulb. bulbs 3. Remove the bulb by pressing it slightly On models with halogen headlights, the low On models with halogen headlights, the High upward and then pulling it out.
Page 499: Replacing Parking Light Bulbs
MAINTENANCE AND SERVICING Replacing parking light bulbs 3. Carefully pry the plastic sleeve by the con- 7. Put the rubber cover back into position. nector's locking lug to release it. On models with halogen headlights, the front Related information parking light bulb can be replaced by the owner. 4.
Page 500: Replacing Front Turn Signal Bulbs
MAINTENANCE AND SERVICING • Replacing front turn signal bulbs Replacing rear fog lights Bulb specifications (p. 500) On models with halogen headlights, the front The rear fog light bulb is are located behind the turn signal bulb can be replaced by the owner. panel on the inside of the trunk lid, on the driv- er's side of the vehicle.
Page 501 MAINTENANCE AND SERVICING NOTE When putting the plastic cover over the hinges back in place: • The pin in the clip must be fully pressed in before the clip is put back on the plas- tic cover. • When the plastic cover is put back in place, the pin must be pressed in until its end is flush with the surface of the clip.
Page 502: Bulb Specifications
MAINTENANCE AND SERVICING Bulb specifications The following specifications apply to models equipped with halogen headlights . If other bulbs need to be replaced, contact a trained and qualified Volvo service technician. Function Type Low beam High Beam Front turn signal...
Page 503: Hoisting The Vehicle
MAINTENANCE AND SERVICING Hoisting the vehicle When the vehicle is hoisted, the jack or garage lift must be positioned correctly under the vehi- cle. For vehicles equipped with leveling control*, if it is also equipped with the optional pneumatic sus- pension, this must be deactivated before the vehicle is hoisted.
Page 504 MAINTENANCE AND SERVICING Location of the jack attachment points (triangles)/lifting points (red areas) NOTE WARNING • Ensure that the jack is positioned so that The jack provided with your vehicle is the vehicle cannot slide off it. intended to be used only in temporary situa- •...
Page 505: Opening And Closing The Hood
For additional information about this symbol, see also the article "Door and seat belt reminders." NOTE If the warning symbol remains on or if the audible signal is given even if the hood is completely closed and locked, consult a trained and qualified Volvo service technician.
Page 506: Engine Compartment Overview
MAINTENANCE AND SERVICING Engine compartment overview WARNING The engine compartment overview shows some • The cooling fan (located at the front of maintenance points. the engine compartment, behind the radi- ator) may start or continue to operate (for up to 6 minutes) after the engine has been switched off.
Page 507: Engine Oil
(p. 510) • Oil that is lower than the specified quality can damage the engine. • Volvo does not recommend the use of oil additives. • Always add oil of the same type and vis- cosity as already used. •...
Page 508: Checking And Refilling Engine Oil
If the oil level sensor indicates that the level is displayed, have the vehicle checked by a trained and qualified Volvo service techni- too low, using the correct oil, top up with the cian. The oil level may be too high.
Page 509: Windshield Wipers In The Service Position
MAINTENANCE AND SERVICING Windshield wipers in the service The service position can be activated in two ways Via Function view position from the center display: The windshield wiper blades must be in the verti- Via Function view cal (service) position for replacement, washing or to lift them away from the windshield when e.g., removing ice or snow.
Page 510: Replacing Wiper Blades
MAINTENANCE AND SERVICING Replacing wiper blades Related information • Replacing wiper blades (p. 508) The wiper blades should be replaced regularly • for best effect. Using the windshield wipers (p. 155) The windshield wiper blades must be in the verti- cal (service) position for replacement, washing or to lift them away from the windshield when e.g., removing ice or snow.
Page 511: Refilling Coolant
MAINTENANCE AND SERVICING Refilling coolant Coolant helps keep the gasoline engine at the proper operating temperature. The heat transfer- red from the engine to the coolant can be used to warm the passenger compartment. When refilling coolant, follow the instructions on the package and use the recommended amount of coolant.
Page 512: Refilling The Windshield Washer Fluid Reservoir
Coolant specifications and volumes with windshield washer solvent containing anti- (p. 528) freeze. Use Volvo Original Washer Fluid or the equivalent with a recommended pH value between 6 and 8 in a 1:1 solution. When there is approx. 1 qt (1 liter) of washer...
Page 513: Cleaning The Exterior
MAINTENANCE AND SERVICING • Cleaning the exterior Dry the car with a clean chamois and CAUTION remember to clean the drain holes in the The vehicle should be washed at regular inter- • During high pressure washing, the spray doors and rocker panels. vals since dirt, dust, insects and tar spots mouthpiece must never be closer to the •...
Page 514: Exterior Components
This con- stitutes a fire risk. Exterior components Volvo recommends the use of special cleaning products, available at your Volvo retailer, for cleaning colored plastic, rubber, or ornamental components such as chromed strips on the exte-...
Page 515: Cleaning The Interior
• Take extra care when removing stains Volvo also offers a special leather softener that such as ink or lipstick since the coloring should be applied after the cleaner and protec- Related information can spread.
Page 516 Type 1 (ink, wine, coffee, milk, sweat or blood) For best protection in winter, Volvo recommends the use of Volvo rubber floor mats. Consult your – Use a soft cloth or sponge. Wipe the wheel Volvo retailer.
Page 517: Cleaning The Center Display
Do not spray any liquid or corrosive • chemicals directly on the screen. Do not Volvo's floor mats are specially manufac- tured for your car. They must be firmly use window cleaning liquid, cleaning secured in the clips on the floor so that...
Page 518: Corrosion Protection
The corrosion protection does not normally Paint repairs require special equipment and skill. require maintenance but keeping the vehicle Contact your Volvo retailer for any extensive dam- clean helps prevent the onset of corrosion. The age. use of strong alkaline or acidic cleaning fluids...
Page 519: Touching Up Paint Damage
MAINTENANCE AND SERVICING Touching up paint damage Related information NOTE • Paint damage (p. 516) Stone chips or other minor paint damage can be When touching up the vehicle, it should be • repaired by the vehicle's owner. Cleaning the exterior (p. 511) clean and dry.
Page 520: Polishing And Waxing
MAINTENANCE AND SERVICING Polishing and waxing CAUTION Normally, polishing is not required during the Volvo does not recommend the use of long- first year after delivery, however, waxing may be life or durable paint protection coatings, some beneficial. of which may claim to prevent pitting, fading, •...
Page 521 SPECIFICATIONS...
Page 522: Label Information
SPECIFICATIONS Label information The labels in your vehicle provide information such as the chassis number, paint code, tire inflation pressure, etc.
Page 523 SPECIFICATIONS Location of labels...
Page 524 Vehicle Emission Control Information. (A) try of Transport (CMVSS) standards US models, (B) Canadian models. Your Volvo (Canada). Your Volvo is designed to meet all is designed to meet all applicable emission applicable safety standards, as evidenced by standards, as evidenced by the certification the certification label on the driver's side B- label on the underside of the hood.
Page 525: Dimensions
SPECIFICATIONS Dimensions The following table lists your vehicle's most important dimensions.
Page 526 SPECIFICATIONS Dimension Dimension (mm) (mm) Ground clearance (curb 5.6 (142) Width incl. door mirrors 79.5 (2019) (folded out) weight + 2 people) Width incl. door mirrors 74.6 (1895) Wheelbase 115.8 (2941) (folded in) Length 195.4 (4963) Varies slightly depending on tire size, chassis options, etc. Load length, floor, seat- 69.9 (1978) 18"...
Page 527: Weights
SPECIFICATIONS Weights The following table lists important weight data for your vehicle. Category Canada Gross vehicle weight 4-cyl. AWD 5,200 lbs 2,360 kg 4-cyl. FWD 4,980 lbs 2,260 kg Capacity weight 4-cyl. 950 lbs 4,30 kg Permissible axle weights, front 4-cyl.
Page 528 SPECIFICATIONS Category Canada Max. trailer weights Without brakes: 1,650 lbs Without brakes: 750 kg With brakes (AWD): 2,000 lbs With brakes (AWD): 900 kg With brakes (AWD Towing Pack): 3,500 lbs With brakes (AWD Towing Pack): 1,580 kg With brakes (FWD): 2,000 lbs With brakes (FWD): 900 kg Max.
Page 529: Air Conditioning Refrigerant
A/C decal marked according to SAE J2842. Topping up or replacing brake fluid should only Related information be done by a trained and qualified Volvo service • technician. Climate system service (p. 475) Specification: Volvo Original Standard DOT 4 or...
Page 530: Coolant Specifications And Volumes
Coolant specifications and volumes Coolant volumes and specifications. Specification: Coolant with corrosion inhibitor mixed with water (50/50 mix), see packaging. Consult a Volvo retailer if you are uncertain. Different types of coolant should not be mixed to help avoid health risks.
Page 531: Engine Specifications
SPECIFICATIONS Engine specifications Not all engines listed here are available in all markets. The following table provides technical data for the respective engines. Engine specifications for Special Edition vehicles may vary. Specification T6 AWD Engine designation B4204T27 Output (kW/rps) 235/95 Output (hp/rpm) 316/5700 Torque (Nm/rps)
Page 532 SPECIFICATIONS Related information • Engine oil specifications and volume (p. 531) • Coolant specifications and volumes (p. 528)
Page 533: Engine Oil Specifications And Volume
• Opening/closing the fuel filler door (p. 374) Viscosity chart Extreme engine operation Volvo oil VCC RBS0-2AE/SAE 0W20 is recom- Refer to the warranty and Service Records infor- mended for extreme driving conditions. mation booklet for information on oil change Oil volume intervals and oil type requirements.
Page 534: Tire Inflation Pressure Table
Temporary spare tire 60 (420) 60 (420) T125/80 R18 Vehicles built with a standard chassis must be modified with a front suspension limiter. Please check your vehicle's specification at a Volvo retailer. Related information • Checking tire inflation pressure (p. 454)
Page 535: Transmission Fluid Specification And Volume
SPECIFICATIONS Transmission fluid specification and volume Under normal driving conditions the transmission fluid does not need to be changed during its service life. However, it may be necessary under adverse driving conditions. Transmission: TG-81SC Specification: Transmission fluid AW-1...
Page 537 INDEX INDEX Alarm shifting with steering wheel paddles automatically arming/disarming shiftlock override A/C (air conditioning) Deactivating Axle weight Accessory installation warning 21, 24 All Wheel Drive Active high beams Ambient temperature sensor Active yaw control Antennas passive entry system Adaptive brake lights Battery Anti-freeze Adaptive cruise control...
Page 538 INDEX Brakes CD player Child safety locks auto-hold Cell phone Child seats Brake system hands-free lower attachment points Brake pad inspection Pairing City safety 306, 314 fluid Cell phone voice control City Safety general information 356, 358, 359 Center display crossing traffic Bulbs changing settings...
Page 539 INDEX rear controls 180, 183 Driving in cold weather recirculation Driving through water refrigerant Daytime running lights 137, 139 service Defroster setting the temperature rear window and mirrors voice commands Detachable key blade 220, 233 Clock Eco (driving function) Digital owner's manual 51, 52 Cold weather driving Eco coast...
Page 540 INDEX Engine compartment Front seats Gross vehicle weight (GVW) fuses heated multifunctional 163, 164 Engine compartment overview power 160, 161, 162, 167 Engine oil Front seats, manual adjustment checking 505, 506 Hand brake (parking brake) 361, 362, 364 Fuel Engine specifications Hazard warning flashers Travel Link service Environment...
Page 541 401, 431 battery type approval video voice control remote 173, 216 Inspection readiness Key blade 220, 233 ID, Volvo Instrument lighting Keys Ignition modes Instrument overview Immobilizer (start inhibitor) Intellisafe Indicator lights Interior Air Quality System Infant seats Interior lighting...
Page 542 INDEX Locks and alarm MP3 files Overheating, engine Low beam bulb, replacing Multifunctional front seats 163, 164 Owner's information mobile applications Low beams 140, 141 MY CAR 109, 110 Owner's manual Low Speed Control Ownership, changing Oxygen sensors, heated Navigation system voice commands Maintenance hoisting the vehicle...
Page 543 INDEX Phone Radio Remote key 216, 219, 224 receiving calls RBDS immobilizer text messages 421, 423 settings linking to a driver profile ® range SiriusXM Satellite radio 408, 409, 410 Pilot Assist 268, 275, 278, 280, 281, replacing the battery 283, 284, 285, 288, 291, 292, 294, 295 Radio functions restricted (red) key...
Page 544 INDEX ® Seat belt Starting the vehicle SiriusXM Satellite radio reminder after a crash (crash mode) 73, 74 traffic information 408, 409, 410 Seat belts Start inhibitor (immobilizer) Ski hatch Automatic locking retractor/Emergency center backrest Steering wheel locking retractor adjusting Snow chains buckling heated...
Page 545 INDEX Tethering Towing a trailer 376, 379 Trunk wi-fi sharing trailer hitch locking/unlocking (private locking) operating with the foot movement sen- Three-way catalytic converter Towing eyelet Tire inflation pressure Towing the vehicle power release Tire Pressure Monitoring System 461, 463 Traction control Turn signals calibrating...
Page 546 Wi-Fi 438, 439 Volvo and the environment Windows Volvo ID laminated glass Volvo maintenance power 106, 107 Volvo On Call Roadside Assistance sun shade Volvo programs Windshield rain sensor washers wipers/washers Windshield washer fluid reservoir Warning flashers, hazard Windshield wiper blades...

This manual is also suitable for:

Xc90

Volvo S 90 Owner's Manual

Introduction

Instruments and Controls

Loading and Storage Locks and Alarm

Driver Support

Starting and Driving

Quick Links

Troubleshooting

Related Manuals for Volvo S 90

Summary of Contents for Volvo S 90
