22 TECHNICAL DATA
Screw, rear brake disc
Screws, throttle grip
Nut, foot brake lever stop
Nut, rear sprocket screw
Nut, rim lock
Remaining nuts, chassis
Remaining screws, chassis
Screw of rear brake caliper
Screw, bottom triple clamp
Screw, chain sliding piece
Screw, engine brace on cylinder head
Screw, engine brace on frame
Screw, fork stub
Screw, front brake caliper
Screw, fuel tank
Screw, handlebar clamp
Screw, side stand attachment
Screw, subframe
Screw, top steering stem
Screw, top triple clamp
Engine bracket screw
Nut, fuel tank attachment
Remaining nuts, chassis
Remaining screws, chassis
Screw, battery compartment
Screw, cross bar
Screw, foot brake lever
Screw, footrest bracket
Screw, handlebar support
Screw, upper subframe
Screw, bottom shock absorber
Screw, top shock absorber
Nut, swingarm pivot
Nut, rear wheel spindle
Screw, front wheel spindle
Screw, top steering head
M6
M6
M8
M8
M8
M8
M8
M8
M8
M8
M8
M8
M8
M8
M8
M8
M8
M8
M8
M8
M10
M10
M10
M10
M10
M10
M10
M10
M10
M10
M12
M12
M14x1.5
M20x1.5
M20x1.5
M20x1.5
14 Nm (10.3 lbf ft)
3 Nm (2.2 lbf ft)
20 Nm (14.8 lbf ft)
35 Nm (25.8 lbf ft)
10 Nm (7.4 lbf ft)
25 Nm (18.4 lbf ft)
25 Nm (18.4 lbf ft)
25 Nm (18.4 lbf ft)
18 Nm (13.3 lbf ft)
15 Nm (11.1 lbf ft)
33 Nm (24.3 lbf ft)
25 Nm (18.4 lbf ft)
15 Nm (11.1 lbf ft)
25 Nm (18.4 lbf ft)
15 Nm (11.1 lbf ft)
20 Nm (14.8 lbf ft)
25 Nm (18.4 lbf ft)
30 Nm (22.1 lbf ft)
17 Nm (12.5 lbf ft)
22 Nm (16.2 lbf ft)
60 Nm (44.3 lbf ft)
10 Nm (7.4 lbf ft)
45 Nm (33.2 lbf ft)
45 Nm (33.2 lbf ft)
45 Nm (33.2 lbf ft)
45 Nm (33.2 lbf ft)
30 Nm (22.1 lbf ft)
45 Nm (33.2 lbf ft)
40 Nm (29.5 lbf ft)
45 Nm (33.2 lbf ft)
80 Nm (59 lbf ft)
80 Nm (59 lbf ft)
75 Nm (55.3 lbf ft)
80 Nm (59 lbf ft)
35 Nm (25.8 lbf ft)
12 Nm (8.9 lbf ft)
100
Loctite ® 243™
–
–
Loctite ® 2701™
–
–
–
Loctite ® 243™
–
–
–
Loctite ® 243™
–
Loctite ® 243™
Loctite ® 243™
–
Loctite ® 2701™
Loctite 243™
®
Loctite ® 243™
–
–
–
–
–
–
–
Loctite ® 243™
Loctite ® 243™
Loctite ® 243™
Loctite ® 243™
Loctite ® 2701™
Loctite ® 2701™
–
–
–
–
