• D/A CONVERTER (MAIN UNIT: IC1)
LINE
NAME
TRXS Antenna switching (TX/RX)
BAND N/C (RF UNIT: CP502)
POCV TX output power setting
FANV Cooling fan rotation speed control
ID1V Idling current control (Pre-driver)
ID2V Idling current control (driver 1/2)
ID3V Idling current control (driver 2/2)
ID4V Idling current control (Final AMP 1/2)
ID5V Idling currrent control (Final AMP 2/2)
UNSB N/C
DRVC Drive gain control
ICCV APC current adjustment
• D/A CONVERTER (MAIN UNIT: IC2)
LINE
NAME
REFV Reference fequency adjustment
VCT4 RX 1st IF AMP tunig voltage
VCT5 RX 1st IF AMP tunig voltage
AJLC ALC control
DESCRIPTION
TX, over input=5V, other conditions:0V
-
0 (TX low)–5V (TX high)
0 (Stop) –5V (max. speed)
In proportional Voltage vs Current (IPD)
In proportional Voltage vs Current (IDL)
In proportional Voltage vs Current (IDL)
In proportional Voltage vs Current (IDL)
In proportional Voltage vs Current (IDL)
–
–
ALC line control
DESCRIPTION
3 - 7
