Omega FoodPro Instruction Manual

Premier food processor
Hide thumbs

Advertisement

Quick Links

FoodPro
™
PReMIeR FOOD PROCeSSOR
INSTRUCTION MANUAL

Advertisement

loading

Summary of Contents for Omega FoodPro

  • Page 1 FoodPro ™ PReMIeR FOOD PROCeSSOR INSTRUCTION MANUAL...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Introduction Food Processor Safety ... 4 electrical Requirements ... 4 Important Safeguards ... 5 Cleaning ... 6 Features and Operations Food Processor Features ... 7-9 Mulitpurpose Blade and Dough Blade Assembly ...10 Mulitpurpose Blade and Dough Blade Disassembly ...11 Mulitpurpose Blade and Dough Blade Use ...12...

  • Page 4: Food Processor Safety

    Volts: 120 V.A.C. only. Hertz: 60 Hz NOTe: This Food Processor has a polarized plug (one blade is wider than the other). To reduce the risk of electrical shock, this plug will fit in a polarized outlet only one way.

  • Page 5: Important Safeguards

    10. Keep hands and utensils away from moving blades or discs while processing food to reduce the risk of severe injury to persons or damage to the Food Processor. A scraper may be used but must be used only when the Food Processor is not running. 11. Blades are sharp. Handle carefully.

  • Page 6: Cleaning

    Handle blades carefully. Failure to do so can result in cuts. First Cleaning Before using your Omega Food Pro for the first time, wash all removable parts. Cleaning the Food Processor 1. Make sure the Food Pro is unplugged. 2. Wipe the motor base and cord with a warm, sudsy cloth, and wipe clean with a damp cloth.

  • Page 7: Food Processor Features

    FOOD PROCESSOR FEATURES This food processor includes the following items: Large 11-Cup Work Bowl • Large Chopping/Mixing • Stainless Steel Blade Work Bowl Cover with • wide Feed Chute Stainless Steel Dough Blade • Compact 4-Cup Mini Chopper • Compact Chopping/Mixing •...
  • Page 8 FOOD PROCESSOR FEATURES 1. Large 11-Cup Work Bowl Durable polycarbonate bowl large enough for most jobs. 2. Work Bowl Cover with Wide Feed Chute Handles large items with minimal preparation. 3. Large Chopping/Mixing Stainless Steel Blade Multi-use blade for quick mincing, chopping, mixing, and emulsifications.
  • Page 9 FOOD PROCESSOR FEATURES 7. 2mm/4mm Stainless Steel Slicing Disk The two-sided disc will produce two different size slices depending on the side used. 4 mm Side = 1/8-inch Slices (approx.) 2 mm Side = 1/16-inch Slices (approx.) 8. 2mm/4mm Stainless Steel...
  • Page 10 ASSEMBLY – LARGE BLADE OR DOUGH BLADE 1. Place the large work bowl onto the motor housing with the main handle to the left of the power panel. This aligns the bowl to properly engage the safety interlock. Turn the main handle to the right until it “clicks”...
  • Page 11 DISASSEMBLY – LARGE BLADE OR DOUGH BLADE 1. Rotate the Cover to the left until the “tab” is unseated. 2. Remove the Blade by pulling upward. (If the blade is held in place by ingredients, it may be removed with the Work Bowl) 3.
  • Page 12 USING – LARGE BLADE OR DOUGH BLADE Maximum Liquid Level This line is visible on the work bowl. Use as an indication of the maximum amount of liquid that can be used in the Food Pro. Power Pad The Food Pro will not operate until the Large Work Bowl and the Work Bowl Cover are both properly installed.
  • Page 13 ASSEMBLY–SLICING OR SHREDDING DISK 1. Place the large work bowl onto the motor housing with the main handle to the left of the power panel. This aligns the bowl to properly engage the safety interlock turn the main handle to the right until it clicks”...
  • Page 14 DISASSEMBLY – SLICING OR SHREDDING DISK 1. Rotate the Cover to the left until the “tab” is unseated. 2. Remove the Disk and Adapter by pulling upward. 3. Remove the Disk from the Adapter by rotating the disk and/or adapter. 4.
  • Page 15 USING – SLICING OR SHREDDING DISK POWER PAD The Food Pro will not operate until the Large Work Bowl and the Work Bowl Cover are both properly installed. Once installed, the indicator light will remain lit if the unit has power. On –...
  • Page 16 ASSEMBLY-MINI CHOPPER 1. Place the large work bowl onto the motor housing with the main handle to the left of the power panel. This aligns the bowl to properly engage the safety interlock. Turn the main handle to the right until it “clicks” or “locks” into place.
  • Page 17 DISASSEMBLY-MINI CHOPPER 1. Rotate the Cover to the left until the “tab” is unseated. 2. Remove the Mini Blade by pulling upward. (If the blade is held in place by ingredients, it may be removed with the Mini Chopper Bowl) 3.
  • Page 18 Power Pad The Food Pro will not operate until the Large Work Bowl and the Work Bowl Cover are both properly installed. Once installed, the indicator light will remain lit if the unit has power. On – Once pressed, the Food Pro will run continuously.

  • Page 19: Food Processing Tips

    FOOD PROCESSING TIPS Hard cheese (example: Parmesan, Romano) If the cheese cannot be pierced with the tip of a sharp knife, it is too hard to process. Do not use your Food Pro for processing. If the cheese can be pierced with the tip of a sharp knife, it is okay to continue.

  • Page 20: Helpful Hints

    1. Never process any food that is so hard or firmly frozen that it cannot be pierced with the tip of a sharp knife Hard food can cause damage to the blade or motor. If a piece of hard food, such as carrot, becomes wedged or stuck on the blade, stop the processor and remove the blade.
  • Page 21 This will help keep the counter clean. This warranty extends to the purchaser and any succeeding owner for Food Processors operated in the United States and District of Columbia. Omega Food Processor Warranty HELPFUL HINTS 14. To remove the contents of the work...
  • Page 22 This warranty is limited to repair or replacements of original parts, which, in the opinion of Omega Products, Inc. are defective in workmanship or material. Should such a defect be discovered within five (5) years from date of purchase, Omega Products, Inc. will, upon receipt of machine, shipped prepaid, repair such defect and return the unit prepaid.
  • Page 23 Registration and Guarantee Record Omega Food Pro Serial Number ___________________________________________________ Name __________________________________________________________ Address _________________________________________________________ City __________________ State ____________________ Zip Code ________ Phone __________________________________________________________ Purchased From __________________________________________________ City __________________ State _____________________________________ Date of Purchase _________________________________________________ IMPORTANT To protect your purchase, fill out and mail...
  • Page 24 Omega Food Pro 11- Cup Direct Drive Food Processor with 4-Cup Mini Chopper INSTRUCTION MANUAL Omega Products, Inc. 6291 Lyters Lane Harrisburg, PA 17111 717-561-1105 717-561-1298 fax 800-633-3401 www.omegajuicers.com omega@omegajuicers.com...
