Optoma TH1060 User Manual
Hide thumbs
Also See for TH1060:
- User manual (57 pages) ,
- Quick start card (2 pages) ,
- Specifications (2 pages)
Table of Contents
Advertisement
Table of Contents ................................................................................... 1
Usage Notice .......................................................................................... 3
Safety Information .........................................................................................3
Precautions....................................................................................................4
Eye Safety Warnings .....................................................................................6
Introduction............................................................................................. 7
Package Overview.........................................................................................7
Product Overview ..........................................................................................8
Main Unit ................................................................................................................ 8
Connection Ports ................................................................................................... 9
Remote Control .................................................................................................... 10
Installation ............................................................................................ 11
Connecting the Projector .............................................................................11
Connect to Notebook ........................................................................................... 11
Connect to Video Sources ................................................................................... 12
Powering On/Off the Projector .....................................................................13
Powering On the Projector ................................................................................... 13
Powering Off the Projector ................................................................................... 14
Warning Indicator ................................................................................................. 14
Adjusting the Projected Image.....................................................................15
Adjusting the Projector's Height ........................................................................... 15
Adjusting Projection Image Size .......................................................................... 16
User Controls ....................................................................................... 17
Remote Control ...........................................................................................17
On-screen Display Menus ...........................................................................19
How to operate .................................................................................................... 19
Menu Tree ...................................................................................................20
Image ................................................................................................................... 21
Image | Advanced ................................................................................................ 23
Display ................................................................................................................. 24
System ................................................................................................................. 26
System | Lamp Settings ....................................................................................... 28
System | Startup Image ....................................................................................... 29
System | Network ................................................................................................. 30
Setup .................................................................................................................... 34
Appendicess ......................................................................................... 38
Troubleshooting ...........................................................................................38
Image ................................................................................................................... 38
Other .................................................................................................................... 39
Downloaded From projector-manual.com Optoma Manuals
Table of contents
Advertisement
Table of Contents
Related Manuals for Optoma TH1060
Summary of Contents for Optoma TH1060
-
Page 1: Table Of Contents
Display ......................... 24 System ......................... 26 System | Lamp Settings ..................28 System | Startup Image ..................29 System | Network ....................30 Setup ........................34 Appendicess ..................38 Troubleshooting ...................38 Image ........................38 Other ........................39 Downloaded From projector-manual.com Optoma Manuals... - Page 2 Compatibility Modes ..................45 RS232 Commands and Protocol Function List..........46 RS232 Pin Assignments (projector side) ............. 46 RS232 Protocol Function List ................47 Ceiling Mount Installation ................53 Optoma Global Offices ................54 Regulation & Safety Notices ................56 Downloaded From projector-manual.com Optoma Manuals...
-
Page 3: Usage Notice
Do not attempt to service the unit yourself. Opening or removing covers may expose you to dangerous voltages or other hazards. Please call Optoma before you send the unit for repair. 7. Do not let objects or liquids enter the projector. They may touch dangerous voltage points and short out parts that could result in fire or electric shock. -
Page 4: Precautions
To replace Please contact your local reseller or service the lamp, follow the center to change the lamp as soon as procedures listed under possible. "Replacing the Lamp" section on page 42. Downloaded From projector-manual.com Optoma Manuals... - Page 5 5 - 35°C Relative Humidity is 5 - 35°C, 80% (Max.), non-condensing - In areas susceptible to excessive dust and dirt. - Near any appliance generating a strong magnetic field. - In direct sunlight. Downloaded From projector-manual.com Optoma Manuals...
-
Page 6: Eye Safety Warnings
When projector is used in a classroom, adequately supervise students when they are asked to point out something on the screen. ▀■ In order to minimize the lamp power, use room blinds to reduce ambient light levels. Downloaded From projector-manual.com Optoma Manuals... -
Page 7: Introduction
Introduction Package Overview Unpack and inspect the box contents to ensure all parts listed below are in the box. If something is missing, please contact Optoma customer service. Projector with lens cap Power Cord 1.8m 15 pin D-sub VGA Cable... -
Page 8: Product Overview
Introduction Product Overview Main Unit 1. Tilt-Adjustment Button 2. Tilt-Adjustment Feet 3. Lens Cap 4. LED Indicators 5. Power Button 6. Function Keys 7. Zoom 8. Focus 9. IR Receiver 10. Lens 11. Connection Ports Downloaded From projector-manual.com Optoma Manuals... -
Page 9: Connection Ports
8. HDMI 1 9. HDMI 2 10. 12V OUT 11. Kensington Microsaver Lock Port 12. Speaker 13. IR Receiver 14. AUDIO IN (L and R) 15. AUDIO IN 16. RS232 17. AUDIO OUT 18. LAN Downloaded From projector-manual.com Optoma Manuals... -
Page 10: Remote Control
18. Down 19. R 20. p / Page Up 21. Re-Sync/Right Key 22. Volume +/- 23. q / Page Down 24. ZOOM/3 25. AV mute/6 26. Video/9 27. Freeze/5 DVI-D function is 28. VGA/8 model dependent. Downloaded From projector-manual.com Optoma Manuals... -
Page 11: Installation
VGA / SCART / YPbPr may have different AUDIO OUT AUDIO IN L-AUDIO IN-R accessories. RS-232 E62405SP 1..............Audio Cable (Optional Accessory) 2....................VGA Input Cable 3............DVI/HDMI Cable (Optional Accessory) 4..............HDMI Cable (Optional Accessory) 5....................Power Cord 6...............RS232 Cable (Optional Accessory) Downloaded From projector-manual.com Optoma Manuals... -
Page 12: Connect To Video Sources
12V OUT is a programmable trigger. S−Video Output 1......RCA Component Cable for YPbPr (Optional Accessory) 2..........Composite Video Cable (Optional Accessory) 3........SCART RGB/S-Video Adapter (Optional Accessory) 4..............HDMI Cable (Optional Accessory) 5....................Power Cord 6............. S-Video Cable (Optional Accessory) Downloaded From projector-manual.com Optoma Manuals... -
Page 13: Powering On/Off The Projector
5. If more than one input device is connected, press the "Source" button sequentially to switch between devices. For direct source selection, see page 18. 12V OUT is a programmable trigger. Downloaded From projector-manual.com Optoma Manuals... -
Page 14: Powering Off The Projector
If the problem persists, you should contact symptoms. See page your local dealer or our service center. See pages 40. 54 for more information. Downloaded From projector-manual.com Optoma Manuals... -
Page 15: Adjusting The Projected Image
Position the To lower the image: projector so that it is perpendicular Press the height-adjuster button and gently push down the to the screen. projector. For personal safety, please secure the cables properly. Downloaded From projector-manual.com Optoma Manuals... -
Page 16: Adjusting Projection Image Size
21.94 26.33 0.35 1.16 230.00 5.09 2.86 16.71 9.40 8.10 9.72 26.56 31.87 0.43 1.41 280.00 6.20 3.49 20.34 11.44 9.86 11.83 32.34 38.80 0.52 1.72 300.00 6.64 3.74 21.79 12.26 10.56 34.65 0.56 1.84 Downloaded From projector-manual.com Optoma Manuals... -
Page 17: User Controls
Press "Source" to choose RGB, Source Component, S-Video, Composite Video, and HDMI source. Left Use directional select keys to select Directional items or make adjustments to your selec- Select Key tion. Enter Confirm your item selection. Downloaded From projector-manual.com Optoma Manuals... -
Page 18: Using The Remote Control
Press "AV Mute" to mute the built-in AV Mute/6 speaker. Press "S-Video" to choose S-video S-Video/7 source. Press "VGA" to choose source from VGA VGA/8 connector. Press "Video" to choose Composite Video/9 Video source. Downloaded From projector-manual.com Optoma Manuals... -
Page 19: On-Screen Display Menus
"Menu" to confirm, and the screen will return to the main menu. To exit, press "Menu" again. The OSD menu will close and the projector will automatically save the new settings. Main Menu Setting Sub Menu Downloaded From projector-manual.com Optoma Manuals... -
Page 20: Menu Tree
User Controls Menu Tree Downloaded From projector-manual.com Optoma Manuals... -
Page 21: Image
The contrast controls the degree of difference between the lightest and darkest parts of the picture. Adjusting the contrast changes the amount of black and white in the image. Press the t to decrease the contrast. Press the u to increase the contrast. Downloaded From projector-manual.com Optoma Manuals... - Page 22 Press the u to increase the amount of red in the image. Sharpness Adjust the sharpness of the image. Press the t to decrease the sharpness. Press the u to increase the sharpness. Advanced Use this option to enter the Advanced menu see page 23. Downloaded From projector-manual.com Optoma Manuals...
-
Page 23: Image | Advanced
Blue for brightness (Gain) and contrast (Bias). Color Space: Select an appropriate color matrix type from RGB or YCbCr. RGB Channel: Select this menu to adjust the RGB Bias and Gain levels for each primary (RGB) color. Downloaded From projector-manual.com Optoma Manuals... -
Page 24: Display
DVD and HDTV film source) that support anamorphic wide is enhanced for 16x9 Display in a wide 2.35:1 image. In this case, there are no black bars. Lamp power and vertical resolution are fully utilized. Downloaded From projector-manual.com Optoma Manuals... - Page 25 Press the t or u to adjust image distortion vertically and make a squarer image. Closed Captioning Select the screen to display closed captioning. Off-the supplied default setting. CC1 I CC2-closed captioning type select. Downloaded From projector-manual.com Optoma Manuals...
-
Page 26: System
User Controls System Menu Location Choose the menu location on the display screen. Lamp Settings Choose this menu to adjust your desired lamp setting. Projection Front-Projection This is the default selection. The image is projected straight on the screen. Rear-Desktop When selected, the image will appear reversed. Rear-Desktop and Rear-Ceiling are to be Front-Ceiling used with a translucent screen. When selected, the image will turn upside down. Rear-Ceiling When selected, the image will appear reversed in upside down position. Background Color Use this feature to display a "Dark Blue", "Gray", or "Black" screen when no signal is available. Startup Image Select the screen to display during startup. Downloaded From projector-manual.com Optoma Manuals... - Page 27 Select a two digit projector ID from 0 through 99. RS232 Allows RS232 control of an individual projector. Network Allows LAN via web browser (Internet Explore) to control of projector. See pages 30 for more information. Downloaded From projector-manual.com Optoma Manuals...
-
Page 28: System | Lamp Settings
30 hours before reaching end of its life. Brightness Mode Choose "Bright" to increase the lamp brightness. Choose "STD" to return to normal mode. Lamp Reset Reset the lamp life hour after replacing the lamp. Downloaded From projector-manual.com Optoma Manuals... -
Page 29: System | Startup Image
HDMI 720p/1080p 3. Select OK. Screen capture in progress will display. VGA 1920X1080@60Hz When finished, Screen capture Succeeded will display. YPbPr 720p/1080p The captured screen is saved as User in the Image menu. Downloaded From projector-manual.com Optoma Manuals... -
Page 30: System | Network
User Controls System | Network For simplicity and ease of operation, the Optoma projector provides diverse networking and remote management features. The Network function of the projector through a network, such as re- motely manage: Power On/Off, Brightness and Contrast settings. Also, projector status information, such as: Video-Source, Sound-Mute, etc. - Page 31 On the PC (Laptop), select Start -> Control Panel -> Network Connections. Right click on your Local Area Connection and select Properties. In the Properties window, select the General tab, and select Internet Protocol (TCP/IP). Click Properties. Downloaded From projector-manual.com Optoma Manuals...
- Page 32 10. Press Apply (Enter) to confirm settings. 11. Open a web browser. 12. In the Address bar, input the IP address: 10.10.10.10. 13. Press Apply. The projector is setup for remote management. The Network function displays as follows. Downloaded From projector-manual.com Optoma Manuals...
- Page 33 Assigned To DHCP (Enabled) (N/A) IP Address Network Configuration Subnet Mask Default Gateway DNS Server Enabled (N/A) User Password New Password Confirm Enabled (N/A) Admin Password New Password Confirm For more information, please visit http://www.crestron. Downloaded From projector-manual.com Optoma Manuals...
-
Page 34: Setup
Enable the input filter. Press t or u into the next menu as below and then use p or q to select. Press "Select (Enter)" to finalize the selection. The projector will not search inputs that are de-selected. Downloaded From projector-manual.com Optoma Manuals... -
Page 35: High Altitude
O ff: Status messages appear as normal on screen during operation. Auto Power Off Set the time interval (in minutes) to power off the system if there is no input signal detected. Signal VGA Source Video Source HDMI Source Downloaded From projector-manual.com Optoma Manuals... - Page 36 Black Level (for HDMI): Allows user to adjust the Black Level for HDMI signals. Signal Power On Off: Projector can only be turned on by pressing the "Power" button. On: Projector turns on automatically when an active signal is detected. Downloaded From projector-manual.com Optoma Manuals...
-
Page 37: Appendicess
Security menu is allowed: Reset Return the adjustments and settings to factory default values. Current: Return the current menu's settings to factory default. All: Return the settings for all menus to factory default values. Downloaded From projector-manual.com Optoma Manuals... -
Page 38: Troubleshooting
If the image is still stretched, you will also need to adjust the aspect ratio by referring to the following: Please setup the display format as 16:9 (wide) aspect ratio type on your DVD player. Downloaded From projector-manual.com Optoma Manuals... -
Page 39: Other
If this happens, the projector will not turn on until the lamp module has been replaced. To replace the lamp, follow the procedures in the "Replacing the Lamp" section on page 48. Downloaded From projector-manual.com Optoma Manuals... -
Page 40: Projector Led Status Indicator
0.5 sec off Error (Lamp fail) 0.5 sec on Flashing Flashing 0.5 sec off Error (Fan fail) 0.5 sec off 0.5 sec on 0.5 sec on Flashing 0.5 sec off Error (Over Temp) 0.5 sec on Downloaded From projector-manual.com Optoma Manuals... -
Page 41: Remote Control
Make sure there are no any obstructions between the remote control and the projector. Move to within 7 m (23 ft) of the projector. Make sure batteries are inserted correctly. Replace batteries if they are exhausted. Downloaded From projector-manual.com Optoma Manuals... -
Page 42: Replacing The Lamp
Warning: Lamp compartment is hot! Allow it to cool down before changing lamp! Warning: To reduce the risk of personal injury, do not drop the lamp module or touch the lamp bulb. The bulb may shatter and cause injury if it is dropped. Downloaded From projector-manual.com Optoma Manuals... - Page 43 Appendices Downloaded From projector-manual.com Optoma Manuals...
- Page 44 9. Turn on the projector and do "Lamp Reset" after the lamp module is replaced. Lamp Reset: (i)Press "Menu" -> (ii)Select "System" -> (iii)Select "Lamp Settings" ->(iv)Select "Lamp Reset" -> (v)Select "Yes". Downloaded From projector-manual.com Optoma Manuals...
-
Page 45: Compatibility Modes
45.0 60.0 1080i 33.8 60.0 HDTV 1080i 28.1 50.0 1080p 67.5 60.0 1080p 56.3 50.0 Downloaded From projector-manual.com Optoma Manuals... -
Page 46: Rs232 Commands And Protocol Function List
Appendices RS232 Commands and Protocol Function List RS232 Pin Assignments (projector side) Pin no. Name I/O (From Projector Side) RS232 RS232 Downloaded From projector-manual.com Optoma Manuals... -
Page 47: Rs232 Protocol Function List
Remote Mouse Right Remote Mouse Down Mouse Left Click Mouse Right Click Up/Page + n=10 Left/Source n=11 Enter (for projection MENU) n=12 Right/Re-SYNC n=13 Down/Page - n=14 Keystone + n=15 Keystone - n=16 Volume - n=17 Downloaded From projector-manual.com Optoma Manuals... - Page 48 Red Gain (2a) -50~+50 ~XX24 n Green Gain -50~+50 ~XX25 n (2a) Blue Gain (2a) -50~+50 ~XX26 n Red Bias (2a) -50~+50 ~XX27 n Green Bias (2a) -50~+50 ~XX28 n Blue Bias (2a) -50~+50 ~XX29 n Downloaded From projector-manual.com Optoma Manuals...
- Page 49 ~XX71 2 Projection (1) Front-Ceiling ~XX71 3 Rear-Ceiling ~XX71 4 Dark Blue ~XX104 1 Background Color Grey ~XX104 3 Black ~XX104 2 Default ~XX82 1 Image Startup Image User ~XX82 2 Image Capture ~XX83 n Downloaded From projector-manual.com Optoma Manuals...
- Page 50 ~XX70 16 SETUP Russian ~XX70 17 Hungarian ~XX70 18 Czechoslovak ~XX70 19 Arabic ~XX70 20 Thai ~XX70 21 Turkish ~XX70 22 Exit Input Filter (1) Exit ~XX100 0 ~XX100 2 Source Lock (1) ~XX100 1 Downloaded From projector-manual.com Optoma Manuals...
- Page 51 Lamp Fail Thermal Switch Error Fan Lock Over Temperature Lamp Hours Running Out Function RS232 command Response Information display ~XX150 1 Okabbbbccdddde a = Power State b = Lamp Hour bbbb c = Input Source None Downloaded From projector-manual.com Optoma Manuals...
- Page 52 ~XX125 1 Contrast ~XX126 1 Aspect Ratio ~XX127 1 16:9 Native Color Temperature ~XX128 1 Warm Medium Cold Projection Mode ~XX129 1 Front-Desktop Rear-Desktop Front-Ceiling Rear-Ceiling Model Name ~XX151 1 EH1060 RS232 Version No ~XX152 1 Downloaded From projector-manual.com Optoma Manuals...
-
Page 53: Ceiling Mount Installation
It depends on the plate thickness. 2. Be sure to keep at least 10cm gap between the ceiling and the bottom of the projector. 3. Avoid installing the projector near a heat source. Downloaded From projector-manual.com Optoma Manuals... -
Page 54: Optoma Global Offices
D40549 Düsseldorf, Fax : +49 (0) 211 506 66799 Germany Service : info@optoma.de Optoma Scandinavia AS Lerpeveien 25 Tel : +4732988990 3040 Drammen FAX : +4732988999 Norway Service : info@optoma.no PO.BOX 9515 3038 Drammen Norway Downloaded From projector-manual.com Optoma Manuals... - Page 55 Fax: +852-2370-1222 www.optoma.com.hk China 上海市长宁区凯旋路1205号5楼 电话：+86-21-62947376 邮编: 200052 传真：+86-21-62947375 www.optoma.com.cn Japan 東京都足立区綾瀬 3-25-18 サポートセンター: 0120-46-5040 株式会社オーエスエム E-Mail: info@osscreen.com http://www.os-worldwide.com/ Korea WOOMI TECH.CO.,LTD. 4F, Minu Bldg.33-14, Nonhyun-Dong, Tel : +82+2+34430004 Kangnam-Ku, seoul, 135-815, Fax: +82+2+34430005 KOREA Downloaded From projector-manual.com Optoma Manuals...
-
Page 56: Regulation & Safety Notices
FCC regulations. Caution Changes or modifications not expressly approved by the manufacturer could void the user’s authority, which is granted by the Federal Communications Commission, to operate this projector. Downloaded From projector-manual.com Optoma Manuals... -
Page 57: Operation Conditions
R & TTE Directive 1999/5/EC (if product has RF function) Disposal instructions Do not throw this electronic device into the trash when discarding. To minimize pollution and ensure utmost protection of the global environment, please recycle it. Downloaded From projector-manual.com Optoma Manuals...
