User Manual Microwave MODEL: WCM660B/W 1. READ these instructions carefully before installing and operating the oven. Keep them for further reference. 2. Record in the space below the “SERIAL NO.” found on the nameplate on your oven and retain this information for future reference.
Before You Call For Service Customer Service Troubleshooting Limited Warranty PRODUCT REGISTRATION Thank you for purchasing our Westinghouse product. This Model number easy-to-use manual will guide you in getting the best use of your microwave oven. Serial number Remember to record the model and serial numbers.
SAFETY INFORMATION DANGER WARNING CAUTION DANGER - Immediate hazards WARNING - Hazards or unsafe CAUTION - Hazards or unsafe which WILL result in severe practices which COULD result in practices which COULD result in personal injury or death severe personal injury or death minor personal injury PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO...
SAFETY INFORMATION IMPORTANT SAFETY INSTRUCTIONS WARNING When using electrical appliances, basic safety precautions should be followed, including the following WARNING: To reduce the risk of burns, electric shock, fire, and injury to persons or exposure to excessive microwave energy: 1. Read all instructions before using the appliance. 2.
SAFETY INFORMATION 12. The contents of feeding bottles and baby food jars should be stirred or shaken and the temperature should be checked before serving in order to avoid burns. 13. Cooking utensils may become hot because of heat transferred from the heated food.
NOTE: Neither Westinghouse nor the dealer can accept any liability for damage to the oven or personal injury resulting from failure to observe the electrical connection procedures.
SAFETY INFORMATION UTENSIL GUIDE FOR THE MICROWAVE This section lists which utensils can be used in the microwave, which have limited use, and which should not be used in the microwave at all. CAN USE CAN NOT USE LIMITED USE •...
SAFETY INFORMATION CAN USE CAN NOT USE LIMITED USE • Wax paper: To • Aluminium tray: May • Straw, wicker, and wood: For short- prevent spattering. cause arcing. Avoid • Thermometers: aluminium foil this may term heating, such as Only those labelled cause arcing.
SET UP & USE SPECIFICATIONS • Power Consumption: 120V~60Hz, 850W • MWO Power: 600W • Operation Frequency: 2450MHz • Outside Dimensions (H x W x D): 10 5/16” x 17 13/16” x 13 5/8” • Oven Cavity Dimensions (H x W x D): 7 13/16” x 12 3/8” x 11 9/16” •...
SET UP & USE PARTS & FEATURES Glass Tray Wave Guide Control Panel Door Safety Turntable Roller Lock System NOTE: Do not remove the mica plate covering the wave guide in the oven cavity. CONTROL PANEL • Power selector: Use this dial to choose a cooking power level.
SET UP & USE OPERATION INSTRUCTIONS STARTING A COOKING SESSION Always follow recommendation from the food package and use the cooking guide table for guidance only. To start cooking: 1. Place food in microwave oven on the turntable and close the door. 2.
SET UP & USE COOKING TECHNIQUES ARRANGEMENT Arrange unevenly shaped foods, such as chicken pieces or chops, with the thicker, meatier parts toward the outside of the turntable where they receive more microwave energy. To prevent overcooking, place delicate areas, such as asparagus tips, toward the center of the turntable. SHIELDING Shield food with narrow strips of aluminium foil to prevent overcooking.
CLEANING AND CARE 8. It is occasionally necessary to remove the glass tray for cleaning. Wash the tray in warm sudsy water or in a dishwasher. 9. The roller ring and oven floor should be cleaned regularly to avoid excessive noise. Simply wipe the bottom surface of the oven with mild detergent.
TROUBLESHOOTING & WARRANTY TROUBLESHOOTING Troubleshoot your problem by using the chart below. If the microwave oven still does not work properly, contact W Appliance Co. customer service center or the nearest authorized service center. Customers must never troubleshoot internal components. Microwaves hold dangerous voltage (5000V) even after power is removed.
TROUBLESHOOTING & WARRANTY LIMITED WARRANTY Westinghouse brand is used under license. 13. Transportation and shipping costs. 14. Labor after the initial 12 months. Any repair, replacement, or warranty service, 15. Food loss for loss due to product and all questions about this product should...
Page 16
, WESTINGHOUSE, and INNOVATION YOU CAN BE SURE OF are trademarks of Westinghouse Electric Corporation. Used under license by W Appliance Company LLC. All Rights Reserved. 020414 Page 16...
