Summary of Contents for Boss Audio Systems 632UAB
-
Page 2: Table Of Contents
CONTENTS Precautions..............................1 ..........................1 Lithium Battery Cell Warnings Use Caution s ............................1 Installation ..............................2 Installation Procedures .......................... 2 Installation Opening..........................2 Wiring Connections..........................3 Uninstall the Main Unit ........................... 3 Control Panel Button Locations ........................4 Operation ..............................4 Power / SRC ............................ -
Page 3: Precautions
PRECAUTIONS Lithium Battery Cell Warnings Cell leakage may cause damage to the remote control. Do not throw cells into as this may cause an explosion. Keep battery cells out of reach of children. Use cautions Some MP3/WMA files may not be playable. Be sure to lower the volume before switching off the unit or the ignition key. -
Page 4: Installation
INSTALLATION Installation Procedures First complete the electrical connections and then check for correctness. Installation Opening This unit can be installed in any dashboard Having an opening as shown below. 2.05 inch 7.20 inch Insert mounting collar into the dashboard and bend the mounting tabs out with a screwdriver. Make sure that lock lever is flush with the mounting collar( not projecting outward). -
Page 5: Wiring Connections
INSTALLATION(CONT.) - Only use speakers with 4 ohms impedance. - Do not attach the control panel to the chassis before wiring is complete. - The maximum current of the auto antenna is 200mA. Wiring Connections WIRING DIAGRAM Radio Antenna White:Front Left PRE-AMP Output Red: Front Right PRE-AMP Output Red: Rear Right PRE-AMP Output White: Rear Left PRE-AMP Output... -
Page 6: Control Panel Button Locations
CONTROL PANEL BUTTON LOCATIONS /SRC 2 INT 5 -10 MUTE REMOVE PANEL RESET OPERATION 1.POWER/SRC to turn off the unit. RADIO, USB, CARD , BT, AUX IN,modes (if there are USB and SD card inside the unit). radio , BT and Aux. When the user inserts a USB flash drive or SD Card, their respective logos will illuminate on the display. -
Page 7: Play/Pause, Intro, Repeat, Random, Tracks Playback
OPERATION >|| During USB or SD card mode, press the ‘1/ ’ button to pause or resume music playback. Press the ‘2/INT’ button to play the first 10 seconds of each track, press again to stop the introduction scan, and play the current track. Press the ‘3/RPT’... -
Page 8: Change Bands (Band)
OPERATION In the USB or SD card mode: Briefly press the button to play the the next or previou track. Press and hold the button to fast forward or fast backward. 13.BND/AMS In radio mode,short press the BND/AMS button repeatedly to select the one of the radio band : FM 1, FM 2,FM 3, AM1,AM2 in a cycle sequence. -
Page 9: Reset System (Reset)
To begin pairing, enable BT mode on your mobile phone. 2. When the phone the car audio system, the BOSS 632UAB name will be displayed. 3. Choose the BOSS 632UAB from the device list to pair and connect with the car audio system. Upon the BT logo will stop 4. -
Page 10: Remote Control
REMOTE CONTROL Button Names and Locations Power button BAND or button >|| or 1 button + 10 or 6 button INT (intro) or 2 button MUTE or DEL button - 10 or 5 button RPT (repeat) or 3 button AMS (automatic music search) or 9 button LOUD (loudness) or 8 button CLK (clock) or button... -
Page 11: Remove Insulating Sheet
REMOTE CONTROL Remove Insulating Sheet The remote control comes with an insulating sheet attached to the underside of the remote control, as illustrated on the right. The remote control will not work until the insulating sheet is removed. Replace Lithium Battery Cell When the lithium cell battery becomes weak, replace it as illustrated on the right. -
Page 12: Troubleshooting
TROUBLESHOOTING A lot of static in broadcast Connect the battery cable to the terminal that is always live. -
Page 13: Specifications
SPECIFICATIONS General Power supply Requirement : DC 12V Maximum power output : 50W X 4CH Speaker impedance : 4 - 8 Ohm Unit Dimensions(WxHxD) : 7.0 X 2.0 X 3.8 inch Weight : 1.54 Lb (0.7 kg) Fuse : 15 A RADIO Frequency Range USA / EUROPE: 87.5 MHz - 107.9 MHz / 87.5 MHz - 108.0MHz...
