Page 1: Installation Instructions
INSTALLATION INSTRUCTIONS CASCADE UNIT FOR WALL HUNG GAS-FIRED CONDENSING BOILER GB162-65/80/100 UK/IE... - Page 2 PRODUCT OVERVIEW Product overview 7214 6000-001.1TD Fig. 1 Overview of cascade frame Supports Connecting frame Main gas pipe Flow and return header Gas connection kit TL-inline Mounting bracket Boiler connection set TL-inline Boiler connection set TR-back-to-back Boiler assembly connection kit Gas connection kit TR-back-to-back Flange Low loss header...
-
Page 3: Table Of Contents
CONTENTS CONTENTS Key to symbols ......4 Explanation of symbols ....4 General points . -
Page 4: Key To Symbols
KEY TO SYMBOLS KEY TO SYMBOLS EXPLANATION OF SYMBOLS WARNINGS Warnings in this document are framed and identified by a warning triangle which is printed on a grey background. Electrical hazards are identified by a lightning symbol surrounded by a warning triangle. -
Page 5: General Points
GENERAL POINTS GENERAL POINTS The installation instructions for cascade systems with GB162 appliances are provided to enable correct and easy installation. The modular cascade frame consists of a number of supports with connecting frames which are screwed together during installation. -
Page 6: Items Supplied With Unit
Boiler • Fig. 3 Items supplied with pump group Siphon • Worcester supplies cascade systems in TL and TR Installation instructions. • configurations: TL: INLINE INSTALLATION All boiler assemblies are in a line enabling an easy-to- monitor installation in a narrow room. - Page 7 ITEMS SUPPLIED WITH UNIT BEND SETS WITH LOW LOSS HEADER The GB162 cascade system can be installed in various configurations ( fig. 4). By using the bend set the low loss header can be installed at an angle to the boilers.
-
