Cartridges

Figure 16 Example of LTO
Cartridge Insertion into a
Magazine
LTO cartridge
cartridge barcode location
Scalar i2000 User's Guide
Cartridges are stored in magazines within the library, as shown in
figure 16.
Each cartridge has an operator-attached, machine-readable barcode label
on it for identification purposes. The library can dynamically support
barcode labels with 1 to 14 characters plus a one-character or two-
character media identifier, depending on drive type (LTO or DLT). The
library currently supports Code 39 (3 of 9) type barcode labels. For more
information about tape cartridges, see
additional specification information, see
page 403. For details about the use of drives and cartridges, see
Media Support and Rules
magazine barcode
LTO magazine
Tape Drives
Barcode Requirements
on page 97.
Chapter 3 Description
Cartridges
on page 94. For
on
Mixed
91
