Page 4
Index ..........91 Oki contact details ........94...
Page 5
NOTES, CAUTIONS AND WARNINGS NOTE A note appears in this manual like this. A note provides additional information to supplement the main text which may help you to use and understand the product. CAUTION! A caution appears in this manual like this. A caution provides additional information which, if ignored, may result in equipment malfunction or damage.
Then, the paper moves back down for printing. This feature has to be enabled. Paper Park Your printer’s paper park feature allows you to print a single sheet (cut-sheet) page without removing continuous feed paper from the printer. For more information, see “Paper Park” in “Using your Printer”.
Page 7
“Top of Form (TOF) and Forms Tear-Off” in “Using your Printer”. Turning the Platen Knob Always turn the printer off before turning the platen knob! If you turn the platen knob when the printer is on, the Top of Form will misalign. NOTE INTRODUCTION > 7...
Page 8
Controlling Access to the Printer > You can control access to the printer by changing the setting for the Operator Panel Function in the Menu from Full Operation (the factory default) to Limited Operation. > When Limited Operation is selected, the PRINT QUALITY and CHARACTER PITCH keys don’t work.
“Using your Printer”. PRINTER DRIVERS The Oki driver for your printer is provided on the CD included with the printer. You can either load the Oki driver or select one of the compatible drivers listed below in your software application.
WinVer is the Windows versions, and CodePage is the selected option. To find out more about Code pages, see Help on the Oki CD Browser. After files have finished copying, click [Finish]. Switch your printer ON. USING A COMPATIBLE DRIVER The drivers below are listed by decreasing compatibility with your printer.
Using an inferior cable can cause printing problems and special cables are needed for longer runs than five metres The operation of a printer is not assured if a USB compatible device is connected concurrently with other USB compatible machines.
Page 12
If the printer had formerly been used as a parallel or serial device and there is no output from the printer once a USB cable has been connected, check to see that the correct port has been selected.
USING YOUR PRINTER COMPONENTS: REAR FEED (CONTINUOUS FORMS) The serial number of your printer is on a label fixed to the back of the printer. Sheet Guide Paper Lever ON-OFF Switch Platen Knob COMPONENTS: TOP FEED (SINGLE SHEETS) Paper Guides...
The first line prints at the red line of the plastic paper shield (1) on the printhead. If you turn the platen knob when the printer is not at Top of Form, the TOF will misalign. Always feed the paper to TOF before turning the platen knob.
To use the TEAR key: Make sure paper is loaded and wait 2 seconds. Press TEAR (3). If the paper moves up , Forms Tear-Off is OFF . If the paper moves down , Forms Tear-Off is ON . USING YOUR PRINTER > 15...
Do not use the platen knob to change the Top of Form. If you turn the platen knob when the printer is not at Top of Form, the TOF will misalign. Always feed the paper to TOF before turning the platen knob.
Page 17
(When you begin pressing the Micro Feed key, the printhead will move to the right). Press SEL | MENU (1) to save the setting and place the printer back on line. To reset the Top of Form to the factory default, see the next page.
Do not use the platen knob to change the Top of Form. If you turn the platen knob when the printer is not at Top of Form, the TOF will misalign. Always feed the paper to TOF before turning the platen knob! To move the Top of Form position lower for one page only: Press SEL to deselect the printer.
POTENTIAL ISSUES WITH SOFTWARE PACKAGES If Forms Tear-Off is set to ON and the software package you are using “pauses” for a long enough interval while sending data to the printer, Forms Tear-Off may be activated. No data is lost, but this causes uneven print registration due to the paper movement.
If you don’t wish to engage the Forms Tear-Off feature, you can advance: rear-feed continuous forms loaded on the built-in tractor bottom-feed continuous forms loaded on the optional push tractor up to the tear-off position manually by pressing TEAR (5). Form Tear-Off Form Tear-Off USING YOUR PRINTER > 20 1 Sec...
Never park labels. Paper park allows you to switch to single-sheet printing without removing continuous feed paper from the printer. When you wish to print single sheets, simply press PARK (6) to retract the continuous form paper from the paper path, then lift the sheet guide, load the sheet and send the print job.
Adjust the paper guides (1) for the size of paper you are using, then place a sheet of paper in the sheet guide. SINGLE SHEETS TO CONTINUOUS FORMS Press FF/LOAD to remove the single-sheet paper. Lower the sheet guide into the continuous-forms position. USING YOUR PRINTER > 22...
Page 23
Swing the wire feed guide over onto the pull-up roller. Move the paper lever to the appropriate position. Rear feed: Bottom feed: If necessary, load continuous-form paper. Press FF/LOAD. USING YOUR PRINTER > 23...
To adjust the gap, open the access cover and move the coloured lever (1) to the recommended setting from the table. Setting When the head gap is set to 2, 3, 4 or 5, the printer automatically slows down for better print quality with multipart forms. CAUTION!
Lowest quality, highest speed (570 cps) Gothic typeface only Near Letter Quality (NLQ): Highest quality, slowest speed (95 cps) Courier or Gothic Front panel settings for print quality and character pitch are normally overridden by software commands. NOTE USING YOUR PRINTER > 25...
To select Proportional, press the CHARACTER PITCH key until both the cpi value and PROP lights are illuminated. To select non-proportional, press the CHARACTER PITCH key until the light for the cpi value you wish to use is illuminated. NOTE USING YOUR PRINTER > 26...
PITCH key (5). Pressing SHIFT and RESET reinitialises the printer, but does not affect any menu settings and does not reset the printer to the factory defaults. For information on resetting the printer to the factory defaults, see “Resetting the Menu to the Factory Defaults” later in this chapter.
MENU MODE In Menu Mode, use the front panel keys to change the defaults for the printer parameters. The changes made in the Menu Mode are automatically saved when you exit the Menu Mode and are retained, even when the printer is turned off.
Hold down the SHIFT key while pressing SEL. RESETTING THE MENU TO THE FACTORY DEFAULTS Turn the printer off. Press SEL and LF while turning the printer ON. PRINTING THE MENU SETTINGS Make sure paper is loaded in the printer.
Press and hold SHIFT, then press SEL to exit the Menu Mode and save your settings. If you turn off the printer without first exiting the Menu Mode, the changes you have made will be lost. MENU SETTINGS For a complete explanation of each menu item, see “Explanations of Menu Items”...
Page 31
Group Item Symbol Sets Character Set Language Set Zero Character Code Page Rear Feed Line Spacing Form Tear-Off Skip Over Perforation Page Width (wide model) Page Length Bottom Feed Line Spacing Form Tear-Off Skip Over Perforation Page Width (wide model) Page Length Settings Set I, Set II [Epson and IBM mode]...
Page 32
Group Item Top Feed Line Spacing Form Tear-Off* Bottom Margin Page Width (wide model) Page Length Wait Time Page Length Control * With RollPaper Stand fitted Set-Up Graphics 7 or 8 Bit Graphics* Receive Buffer Size Paper Out Override Print Registration 1 Print Registration 2 7 or 8 Bits Data Word* Operator Panel Function...
Page 33
Group Item Parallel I/F I-Prime Pin 18 Auto Feed XT* Bi-Direction Note: *When Epson emulation selected. Serial I/F* Parity Serial Data 7/8 bits Protocol Diagnostic Test Busy Line Baud Rate DSR Signal DTR Signal Busy Time * When Serial I/F installed. CSF Bin 1** Line Spacing Bottom Margin...
Change this setting to 7 if your system uses 7-bit data word lengths. Auto CR, Default =No IBM emulation only. If you want the printer to automatically add a carriage return when a Line Feed is received at the end of a line, change the setting to Yes.
Page 35
Change this setting if you wish to disable bi-directional transmission (PnP) in Nibble mode. Bottom Margin, Default = Valid Change to Invalid if you want the printer to ignore the bottom margin setting. Setting the Bottom Margin to Invalid can cause loss of data and damage the printhead by allowing printing without paper.
Page 36
CSF Type, Default = Wide To avoid paper jams, change this setting to Narrow if you are using the optional Cut Sheet Feeder on the wide model ML5521 printer. Diagnostic Test, Default = No Appears only when the optional Serial Interface is installed. Select YES to perform a diagnostic test of the serial interface.
Page 37
DTR Signal, Default = Ready On Power Up Appears only when the optional Serial Interface is installed. Change to Ready On Select if the DTR signal is required when the printer is selected (leave as Ready On Power Up if the DTR signal is required when the printer is turned ON).
Page 38
ON the printer. Page Length, Default = 11-2/3" or 1/2" Selects the length of the paper you are using. This enables the printer to keep track of the initial printing position (TOF) on each page. Page Length Control, Default = by Actual Page Length If you wish to use the Paper End sensor to detect the actual paper end, use Actual Page Length setting.
Page 39
Choose the character width in characters per inch (cpi). Power Save Time, Default = 5 min. Sets the interval the printer waits for more data before it goes into the power save mode. Power Saving must be set to Enable (the factory default) for this to be effective.
Page 40
Reset Inhibit, Default = No Select Yes if you wish the printer to ignore the reset command sent by software. This prevents your software from changing the settings you make through the front panel controls or through printer commands.
Page 41
Change to Double for double width and height printing. Skip Over Perforation, Default = No Change to Yes if you want the printer to go to the next page when it comes within 1" (25 mm) of the bottom of the page. Keep it set to No if your software has its own page formatting controls.
REPLACING THE RIBBON CARTRIDGE Important! Make sure you have the correct replacement ribbon for your printer. The wrong ribbon will not print when installed in your printer. Look for the printer model number on the ribbon package. Ribbon Cartridge Handling Leave unused ribbon cartridges in their packages until needed.
Page 43
Turn the take-up knob (1) in the direction of the arrow to take up any ribbon slack. Close the access cover and turn the printer back on. If ribbon should contact the eyes: Flush eyes with large quantities of water for 15 minutes, keeping eyelids open with fingers.
Loading Rear Feed Paper from the Back of the Printer These instructions assume you have ready access to the back of the printer. If you do not, go to “Loading Rear Feed Paper from the Front of the Printer.” Make sure the paper lever is forward (position marked “REAR”).
Page 45
Open the access cover (1). Grasp the sheet guide. Lift it slightly, then slide it back. Pivot the sheet guide forward and gently rest it against the roller assembly. Careful! If you push the sheet guide too hard against the roller assembly, it may dislodge it.
Page 46
From the back of the printer, locate the tractors (1). Open the lock levers (1) and move the right tractor ( as viewed from the back of the printer ) to the reference mark (2) matching the width of the paper you are loading. Then close...
Page 47
Place continuous forms paper on the first two pins of either tractor. Important! You must keep the number of paper holes engaged on either pin the same. If you don’t the paper will skew and jam. Close the right tractor cover. Adjust the left tractor until the holes in the paper are centred on the pins then lock the lever and close the left tractor cover.
Page 48
Lower the sheet guide and slide it towards the front of the printer until the marks align. Place the wire guide in the sheet guide on the pull-up roller assembly. Press FF/LOAD. The factory default setting for the Top of Form (where the printing should begin) is 1"...
Page 49
Loading Rear Feed Paper from the Front of the Printer These instructions assume that you do not have ready access to the back of the printer. If you do, go back to “Loading Rear Feed Paper from the Rear of the Printer” earlier in this chapter.
Page 50
Grasp the tabs and lift off the sheet guide. Pull up on the lock levers to release them. The movement of the left tractor (as viewed from the front of the printer) is restricted to ensure that the paper covers the paper out sensor.
Page 51
Open the tractor covers and place continuous forms paper on the first two pins of either tractor, then close the left tractor cover. You must keep the number of paper holes engaged on either pin the same. If you don’t the paper will skew and jam. Adjust the position of the right tractor to centre the holes in the paper on the pins.
Page 52
Reinstall the sheet feeder. MAINTENANCE > 52...
Page 53
Place the wire guide (1) in the sheet guide on the pull-up roller assembly. Press FF/LOAD. The factory default setting for the Top of Form (where the printing should begin) is 1" down from the top of the page. To change the setting, see “Top of Form (TOF)”...
If you have continuous form paper in the path, press PARK to remove it before loading single sheets. Make sure the printer is on and deselected (SEL light off). Move the paper lever (1) to the centre position (marked “TOP”).
REAR FEED JAMS Turn the printer OFF. Use the platen knob to back the paper all the way out of the printer. Make sure the printer is turned OFF before you open the access cover. NOTES CAUTION! MAINTENANCE > 55...
Page 56
Lift the sheet guide (1) and reload paper. Make sure you lock the tractor covers. Lower the sheet guide, then install the pull-up roller assembly and close the access cover. Turn the printer ON and press FF/LOAD. MAINTENANCE > 56...
Fragments of Paper in the Paper Path Turn off the printer. Use the platen knob to back the paper all the way out of the printer. Make sure the printer is turned OFF before you open the access cover. CAUTION! MAINTENANCE > 57...
Page 58
Open the access cover (1) and remove the pull-up roller assembly (2). Then grasp the tabs (3) on the sheet guide (4) and lift it off the printer. Remove any torn pieces of paper. Fold some continuous-form paper over three times to make a page four sheets thick.
Page 59
Load standard paper, close and lock the tractor covers. Install the sheet guide, then install the pull-up roller assembly and close the access cover. Turn the printer on and press FF/LOAD. MAINTENANCE > 59...
SINGLE SHEET PAPER JAMS Turn off the printer. Use the platen knob to back the paper out. Open the access cover (1) and remove the pull-up roller assembly (2). Remove any torn pieces from around the carriage. Reinstall the pull-up roller assembly and close the access cover.
Turn off the printer. Use the platen knob to back the paper out of the printer. Make sure the printer is turned off before you open the access cover. Open the access cover (1) and remove the pull-up roller assembly (2).
Page 62
Reinstall the pull-up roller assembly and close the access cover. MAINTENANCE > 62...
Does the paper being used meet the specifications for this product? Is the paper properly installed? Is the ribbon properly installed? Is an Oki ribbon being used? Is the printhead gap correctly set? Are the correct printer drivers being used for the printer? >...
Page 64
Nothing happens when I turn ON the printer. Solution Check the power cord connection to the outlet and to the printer. If you are using a power strip, make sure it is turned ON, and that the fuse hasn’t blown or that the circuit breaker hasn’t tripped.
Page 65
This may be caused by excessive printhead travel from the centering position. Enter the Menu and set the Centring Position to MODE 1. See “Using Your Printer, Menu Mode.” For the wide carriage printer, if MODE 1 doesn't work, try setting the Centering Position to MODE 2. Problem I've installed a new ribbon and the printing is smeared and streaked.
Page 66
Problem The ALARM light is flashing. Solution Try turning the printer OFF and then back ON again. If the light still blinks, call for service. Problem The ALARM light is ON and the Character Pitch 10 light is flashing.
Page 67
(Limited Function). If the printer is part of a customized system or if it is used by a number of people, the system manager may have used this option to make sure the printer is always set properly.
Item descriptions and part numbers are provided in this section. Consult the dealer where you purchased your printer. Locate an Authorised Oki Reseller by visiting your local Oki web site. Links to all countries are provided on: Item...
Page 69
Push Tractor, Bottom-Mount (2) Roll Paper Stand (3) Cut Sheet Feeder (4) Single Bin Dual Bin Serial Interface RS232C (5) PARTS AND ACCESSORIES > 69 Part number Part number ML5520 ML5521 09002365 09002369 09002366 09002370 09002332 09000691 09000695 09000692 09000696...
PRINTER CONTROL CODES This section lists the most commonly used printer control codes. You will find a comprehensive listing of the control codes (English only) on your Printer CD. To access it: Place the CD in your CD-ROM drive and wait for it to AutoPlay.
Page 71
Overscore ON Overscore OFF Paper Out Sensor OFF Paper Out Sensor ON Print Quality, Select HSD Print Suppress Mode ON ML5520 ML5521 Print Suppress Mode Off Proportional Spacing ON Proportional Spacing OFF Reset: Clear Print Buffer Software I-Prime Stop Printing...
OKI MICROLINE STANDARD COMMANDS Oki Command Backspace Carriage Return Character Pitch: Select 10 cpi Select 12 cpi Select 15 cpi Select 17.1 cpi Select 20 cpi Character Sets: Standard Block Graphic Line Graphic Publisher Slashed Zero Unslashed Zero Double Height ON...
Page 75
Oki Command Paper Out Sensor OFF Paper Out Sensor ON Print Quality: Select HSD Select NLQ Courier Select NLQ Gothic Select Utility Print Speed: Set to Full Set to Half Print Suppress ON Print Suppress OFF Proportional Printing: Reset: Clear Print Buffer...
200 million characters average in 10 cpi utility mode at 25% duty and 35% page density 20,000 hours at 25% duty cycle and 35% page density 15 minutes IBM Proprinter III Epson FX Oki MICROLINE Standard Speed* 570 cps 507 cps 380 cps 95 cps...
Page 77
Item Resident Fonts Near Letter Quality Utility High Speed Draft Super Speed Draft Bar Codes Paper Thickness: Tractor Feed Rear Feed: Bottom Feed*: *requires optional push or pull tractor. Specification Courier, Gothic Gothic Gothic Gothic Code 39 UPC A, UPC E EAN 8, EAN 13 Interleaved 2 of 5 Code 128...
Top only 14 to 24 lb. US Bond (52.6 to 90 g/m ML5520: 7.2" to 8.5" (183 to 216 mm) ML5521: 7.2" to 14.3" (183 to 363.2 mm) Rear, Bottom* 12 to 24 lb. US Bond (45 to 90 g/m ML5520: 3"...
Page 79
Humidity Operating: Storage: Electrical Requirements Physical Specifications ML5520 Size (WxDxH*): Weight: ML5521 Size (WxDxH*): Weight: Specification 41 to 95°F (5 to 36°C) 14 to 122°F (-10 to 50°C) 20 to 80% RH 5 to 95% RH 230 ac, (+15%, -14 %) 50 or 60 Hz (±2%)
SETTING UP YOUR PRINTER LOCATION Place your printer on a firm, solid surface. Allow enough space around the printer to easily access the platen knob and the various paper feed paths. Make sure a suitable grounded power outlet is available nearby.
Page 81
Remove any packing tape, then grasp the tabs (1) at either end of the access cover and pivot it towards the front of the printer as far as it will go. Remove the printhead shipping restraint. Remove the shipping restraint from the pull-up roller assembly (1).
Page 82
Use the tabs (1) to lift and remove the sheet guide, then remove the shipping restraint. Reinstall the sheet guide: insert the clips on either side of the separator into the notches marked with a triangle, then press down to secure the separator in place. SETTING UP YOUR PRINTER > 82...
INSTALLING THE RIBBON CARTRIDGE Make sure you have the correct replacement ribbon for your printer. The wrong ribbon will not print when installed in your printer. RIBBON CARTRIDGE HANDLING Leave unused ribbon cartridges in their packages until needed. Careful; the ribbon ink may cause permanent stains.
Page 84
Do not remove the ribbon shield (1) from the ribbon! Turn the take-up knob (1) in the direction of the molded-in arrow to take up any ribbon slack. Close the access cover and turn the printer ON. CAUTION! SETTING UP YOUR PRINTER > 84...
POWER CONNECTION Make sure both the printer and the computer are switched OFF. Plug the power cord into the back of the printer, then into a grounded outlet. Turn on the printer. SETTING UP YOUR PRINTER > 85...
Make sure the printer and computer are both turned OFF. Attach a suitable bi-directional cable to the parallel connector on the back of the printer. Then attach and secure the cable to your computer. Turn the printer and computer back ON.
Attach a suitable USB cable to the printer. Then attach the cable to your computer. Turn the computer and printer back on. LOADING PAPER For instructions on loading paper, see “Loading Paper” in the chapter on “Maintenance”. TESTING THE PRINTER...
Page 88
Make sure paper is loaded. Turn the printer OFF. Press and hold the LF key while turning the printer back ON. The printer will print a page of font samples and the test ends. SETTING UP YOUR PRINTER > 88...
Page 89
Wide carriage Model ML5521: If you are using 8.5 inch paper to run the tests, make sure the paper width selection in the printer menu is set to 8.5 inches. Otherwise, printing on the platen may damage the printer. See the chapter on “Menu Mode”...
Page 90
Hexadecimal Dump Mode When the printer is placed in the Hexadecimal Dump Mode, all data received, including text and printer commands, is printed in both hexadecimal and ASCII formats. For example, the following line of BASIC code LPRINT CHR$ (27);”0”;CHR$ (30);”THIS IS AN EXAMPLE OF A HEXADECIMAL DUMP.”...
Computer Connections...86 Electrical Requirements...79 Emulations ...27 Mode ...37 Envelopes...78 Environmental Requirements...79 Font Sample Test ...88 Fonts Embedded Printer Commands ..65 Resident...77 Selecting...39 Forms Tear-Off ...37 Top of Form ...19 Graphics Printing ... 32 GROUP, Menu Mode...28 Height, Double Height Printing ...41 Hexadecimal Dump Mode...90...
Page 92
Near Letter Quality ...77 Operator Panel Function...67 Page Length Rear Feed ...31 Top Feed ...32 Page Width Bottom Feed...31 Rear Feed ...31 Setting in the Printer Menu ...32 Top Feed ...32 Paper Static ...67 Thickness...77 Widths ...32 Paper Jams ...66 Paper Lever...66 Paper Out ...66...
Page 93
Temperature Specifications...79 Testing the Printer ...87 Thickness, Paper...77 Time Out... 32 Top Feed...78 Bottom Margin ...32 Line Spacing ...32 Top of Form...34 Forms Tear-Off... 7 Paper Shield... 7 Typefaces Selecting...39 Uni-directional printing, graphics ...32 Unpacking ...80 USB, Specification 1.1 Compliant...86 Utility Front Panel Light...77...
