Summary of Contents for Koss KS3112
-
Page 2: Safety
SAFETY LASER: CLASS 1 Type: Dual semiconductor laser GaAIAs Wavelength: 650nm and 780nm LASER PRODUCT Output Power: Beam Divergence: 60 degree INVISIBLE LASER RADIATION WHEN OPEN OR INTERLOCK FAILED OR DEFEATED. WARNINGS: DO NOT STARE INTO BEAM. Avoid direct exposure to laser beam. To prevent direct exposure to laser beam, do not try to open the enclosure. -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS CAUTION: RETAIN THIS BOOKLET FOR FUTURE REFERENCE. This set has been designed and manufactured to assure personal safety. Improper use can result in electric shock or fire hazard. The safeguards incorporated in this unit will protect you if you observe the following procedures for installation, use and servicing. -
Page 4: Table Of Contents
CONTENT Safety ____________________________________________________________________ 1 Important Safety Instructions __________________________________________________ 2 Contents & Package ________________________________________________________ 3 Installation ________________________________________________________________ 4 Remote Control ____________________________________________________________ 5 Front Panel ________________________________________________________________ 6 Rear Panel ________________________________________________________________ 6 Connections _______________________________________________________________ 7 Basic Operation ____________________________________________________________ 9 Playing DVD/CD Disc _______________________________________________________ 12 Example shows how to Create Program and Delete the last Selection for DVD __________ 15 Example shows how to Create Program and Delete the last Selection for CD ___________ 16 Playing MP3 / WMA / JPEG Disc ______________________________________________ 18... -
Page 5: Installation
Player Zones For the purpose of distribution of DVD Discs, the world has been separated into 6 zones. The zone your unit is intended for is indicated on the Zone Label. This should be the same as the label on discs available in your region. If you have any difficulties in playing a disc, make sure that the disc is for the same zone as your player. -
Page 6: Remote Control
REMOTE CONTROL 1. Power On / Standby switches the player between Standby and On 2. “P SCAN” key activates or deactivates Progressive Scan mode 3. “INFO” key enters and exits Active Navigation mode 4. “CLEAR” key - exits menus and Active Navigation mode - deletes the last selection in program mode 5. -
Page 7: Front Panel
FRONT PANEL 1. Power on/off 2. LED Indicator Standby Mode - RED Light OFF Mode - No Light 3. Disc loading tray 4. Opens/closes disc loading tray 5. Stops playing 6. Pauses Playing 7. Starts playing 8. Infra-Red receiver window 9. -
Page 8: Connections
CONNECTIONS Video Connections The way in which you connect your DVD player and the kinds of cabling you choose can make a noticeable difference in picture and sound quality. Before you select one of the options, please make sure that your other equipment (e.g. - Page 9 Audio Connections Before you select one of the options, please make sure that your other equipment (e.g. TV, receiver) has the required input/output channel. Use either options of below: For better sound quality, use RCA AUDIO CABLE Connecting 5.1 CH Receiver Do not connect the L-R Audio sockets to the TV, in case the L-R connections are made, you need to set the TV volume control to zero.
-
Page 10: Basic Operation
BASIC OPERATION To access the setup menu the unit must be in STOP mode.Use Active Navigation keys to make selections and then press OK to confirm. 1. Play Press OK to list the content of disc (No menu available without disc loaded.) 2. - Page 11 3.3 Rated Titles (continue) If alternative scenes with lower rating are included, Parental Level 7 Parental Level 5 Parental Level 5 Parental Level 7 the player plays the highest rated scene that the parental setting allows. For example, consider a disc Playback Path Parental Level 5 which is generally suitable for most audiences, and is...
- Page 12 4.2 PAL/NTSC Press OK to select PAL or NTSC output to match your TV or other video equipment. 4.3 Progressive Scan Press OK to turn on or off Progressive Scan video output. Warning message will follow, press OK to confirm. Refer to page 7 for connection details. 5.
-
Page 13: Playing Dvd/Cd Disc
PLAYING DVD/CD/VCD DISC 1. Press to open the disc tray. 2. Load disc on the tray with label side facing upward. 3. Press to close the tray. During Playback Pause / Freeze Press to temporarily hold the playback. Press repeat- edly to switch between Pause and Freeze. - Page 14 Numeric keys (0-9) Press to input track number for direct track selection. Zoom Press to zoom in (2x, 3x, 4x and 5x) pictures during disc playback. Info Banner Time Search 00:33:10 Input with numeric keys the time you want to play from.
- Page 15 Repeat A-B allows a passage to be repeated continu- ously. Press OK at the start of the required passage (A), then press OK again at the end of required passage (B). The passage will then be repeated continuously between point A and B. on Remote Control) Index Menu Press OK to enter Index menu.
-
Page 16: Example Shows How To Create Program And Delete The Last Selection For Dvd
Example shows how to create program and delete the last selection for DVD Use Active Navigation keys to make selections Step 1: Select Title “1” Step 2: Press to add Title “1” Step 3: Select Title “2” Step 4: Select Chapter “1” Step 5: Press to add Chapter “1”... -
Page 17: Example Shows How To Create Program And Delete The Last Selection For Cd
Step 7: Press to delete the last selection Step 8: Select “Done” to save the “Program List” and start to play Example shows how to create program and delete the last selection for CD Step 1: Select Track “1” Step 2: Press to add Track “1”... - Page 18 Step 4: Press to add Track “3” Step 5: Select “Done” to save the “Program List” and start to play Step 6: Press to delete the last selection Step 7: Select “Done” to save the “Program List” and start to play Page 17...
-
Page 19: Playing Mp3 / Wma / Jpeg Disc
PLAYING MP3 / WMA / JPEG DISC General • Press twice to stop MP3/WMA playback and display the main menu. • Use Navigation Keys to select the menu Main menu: for MP3/WMA disc only Standard > Random > Program • Press twice to stop JPEG playback and display Main menu: for MP3+JPEG or JPEG disc only the main menu. -
Page 20: Controls (Mp3 / Wma / Jpeg Disc)
CONTROLS (MP3 / WMA / JPEG DISC) 1. Open / Close • Press to open the tray Note: Load disc on the tray with label facing upward. • Press to close the tray and play automatically 2. Play • Press to start playing 3. -
Page 21: Play Modes (Mp3 /Wma Disc)
PLAY MODES (MP3 / WMA DISC) 1. Standard Press OK to set unit playing tracks in default order. 2. Random Press OK to set unit playing tracks in random Random Program order. Standard Note: Applicable to MP3/WMA disc only 3. Program Press OK to select program in main menu. -
Page 22: Disc You Can Play
DISC YOU CAN PLAY While advances have been made to ensure that your disc player is compatible with the largest number of discs possible, it cannot be guaranteed that you will be able to play discs which might not be compliant with audio CD standards. -
Page 23: Problems
PROBLEMS If it appears that your DVD-Video player is faulty, first consult this checklist. It may be that something simple has been overlooked. Under no circumstances should you try to repair the player yourself; as this will invalidate the warranty. Only qualified service personnel can remove the cover or service this player.
