- Page 1 User Manual GETTING STARTED? EASY. ZDT24001FA EN User Manual Dishwasher...
-
Page 2: Safety Information
SAFETY INFORMATION Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible if an incorrect installation and use causes injuries and damages. Always keep the instructions with the appliance for future reference. CHILDREN AND VULNERABLE PEOPLE SAFETY This appliance can be used by children aged from 8 years and •... -
Page 3: Safety Instructions
Do not keep the appliance door open without supervision to • prevent to fall on it. Before maintenance, deactivate the appliance and disconnect • the mains plug from the mains socket. Do not use water spray and steam to clean the appliance. •... - Page 4 DISPOSAL WARNING! Risk of injury or suffocation. • Disconnect the appliance from the mains supply. • Cut off the mains cable and discard it. • Remove the door catch to prevent children and pets to get closed in the appliance.
-
Page 5: Easy Start
EASY START On/off button Indicators Programme buttons Delay button INDICATORS Indicator Description End indicator. Multitab indicator. Salt indicator. It is always off while the programme operates. PROGRAMMES Consumption values Degree of soil Programme Programme phases Type of load Duration Energy Water (min) (kWh) -
Page 6: Programme Selection Mode
Consumption values Degree of soil Programme Programme phases Type of load Duration Energy Water (min) (kWh) Heavy soil • Prewash 140 - 1.3 - 1.5 13 - 15 Crockery, cut- • Wash 70 °C lery, pots and • Rinses pans •... -
Page 7: Cancel Function
CANCEL FUNCTION Press and hold simultaneously until the appliance is in programme selection mode. With this function you can cancel the running programme or the delay start. USER MODE While the appliance is in programme selection mode: 1. Press and hold •... -
Page 8: The Water Hardness Table
2. Press to change the setting. Each time you press , the level increases. After level 10 you will start again from level by 1. 3. Press the on/off button to confirm the setting. THE WATER HARDNESS TABLE German degrees French degrees Water softener mmol/l... -
Page 9: Deactivating The Rinse Aid Dispenser
DEACTIVATING THE RINSE AID DISPENSER While the appliance is in user mode: 1. Press • The indicators goes off. • The indicator starts to flash. • The end indicator indicates the current setting: End indicator on = rinse aid dispenser activated. 2. -
Page 10: Daily Use
ADDING RINSE AID The rinse aid helps to dry the dishes without streaks and stains. It is automatically released during the hot rinse phase. Fill the rinse aid dispenser when the indicator ( A) becomes clear. DAILY USE 1. Open the water tap. 3. - Page 11 The function comes into operation: • 5 minutes after the completion of the programme. • After 5 minutes if the programme has not started. Starting a programme 1. Keep the appliance door ajar. 2. Press the on/off button to activate the appliance. Make sure that the appliance is in programme selection mode.
-
Page 12: Hints And Tips
With the use of this option the programme duration is prolonged to increase the cleaning and drying results with the use of multi-tablets. Opening the door while the appliance operates If you open the door while a programme is running, the appliance stops. When you close the door, the appliance continues from the point of interruption. -
Page 13: Unloading The Baskets
the tableware, we recommend that you use the • Make sure that cutlery and dishes do not bond tablets with long programmes. together. Mix spoons with other cutlery. • Do not use more than the correct quantity of • Make sure that glasses do not touch other detergent. -
Page 14: Troubleshooting
• Make sure that there are no residues of food or soil in or around the edge of the sump. • Put back in place the flat filter (C). Make sure that it is correctly positioned under the 2 guides. •... -
Page 15: The Washing And Drying Results Are Not Satisfactory
Problem and alarm code Possible solution The appliance does not fill with water. • Make sure that the water tap is open. • The end indicator flashes 1 time inter- • Make sure that the pressure of the water supply is mittently. -
Page 16: Technical Information
TECHNICAL INFORMATION Dimensions Width / height / depth (mm) 596 / 818-898 / 555 Voltage (V) 220 - 240 Electrical connection Frequency (Hz) Water supply pressure Min. / max. bar (MPa) 0.5 (0.05) / 8 (0.8) Water supply max 60 °C Cold water or hot water Capacity Place settings... - Page 20 WWW.ZANUSSI.COM/SHOP...
