INSTALLATION MANUAL
Warranty Registration and Inquiry
For product warranty registration, TOTO U.S.A. Inc. recommends online Warranty Registration. Please visit our web site http://www.totousa.com. If you have questions regarding warranty policy or
coverage, please contact TOTO U.S.A. Inc., Customer Service Department, 1155 Southern Road, Morrow, GA 30260 (888) 295 8134 or (678)466-1300 when calling from outside of U.S.A.
Important Safeguards
(For your safety, please follow the instructions below.)
In this Instruction Manual, the following symbols are shown for safe and proper use of
the product and to alert you of the possibility of personal injury and damage to your
property.
The symbols and their meanings are as follows:
Ignoring these symbols may cause
Warning
personal injury and/or property damage.
Ignoring these symbols may cause
Caution
severe injury and/or property damage.
*Some models may have different components from the ones illustrated below.
Do not install the unit in the places where corrosive
or combustible gas can be present.
Do not
This may cause product failure or damage.
Never attempt to disassemble for repair or
modification.
Do not
This may cause electric shock, fire, injury or failure
disassemble
Do not install outdoors or where it is exposed to
water.
Do not use in
This may cause current leakage, electric shock, fire, or failure.
humid area
0GU3049E 2009.04
Warning
HandDryerSupply.com | 804-859-2498 | sales@handdryersupply.com
High Speed Concealed Hand Dryer
It is necessary to install a circuit-breaker in the power supply
Failure to do this may cause electric shock during overload or short
Important
circuit.
The chassis assembly must be installed on a smooth and even
wall surface which has enough strength.
Important
Failure to do this may cause damage or personal injury if it falls down.
Specification
Product
HDR110#SS
Power Rating
120V AC, 4.25 Amps, 60 Hz, 510 W
Power Connection
Hardwiring
Power Saving Function
Automatically turns OFF after 60 seconds of use
Decibel Rating
58 dB
Air Speed
224 mph (100 meters/second)
Dry Time
12 seconds
Drain Tray Capacity
0.27 gal (950 ml)
Ambient temperature
32° - 104°F (0° - 40°C)
9-5/8" x 18-1/2" x 6-5/16"
Size
Weight
22.2 lbs (10kg)
Clean Dry™
Warning
Caution
Advertisement
Related Manuals for Toto Clean Dry HDR110#SS
Summary of Contents for Toto Clean Dry HDR110#SS
-
Page 1: Important Safeguards
For product warranty registration, TOTO U.S.A. Inc. recommends online Warranty Registration. Please visit our web site http://www.totousa.com. If you have questions regarding warranty policy or coverage, please contact TOTO U.S.A. Inc., Customer Service Department, 1155 Southern Road, Morrow, GA 30260 (888) 295 8134 or (678)466-1300 when calling from outside of U.S.A. -
Page 2: Before Installing
Set-up Drawing Before Installing Some models may have different components as illustrated below. 1. Precautions 3-9/16″ (90mm) Confirm the rough-in, major dimensions and wiring diagram before installation 2-3/8″ (60mm) 1-9/16″ (40mm) in order to properly install the hand dryer and electrical wiring. 2-3/8″... -
Page 3: Installation
Installation *Some models may have different component as illustrated below. Hand Dryer Unit w/o Top Cover Top cover Junction box Sensor (Connection type) Color : White,Black,Green Air nozzles Size : AWG16×3 Power Cable Wall surface Wiring Hole Chassis Assy <Bottom view> Filter case Filter <View with cover removed>... -
Page 4: Installation Procedure
Installation Procedure STEP 1 Using template provided, mark the wall for locations and install Mark the wall with template and install the bracket STEP 1 the mounting bracket. Chassis Assy. must be installed on a rigid and even surface 1-9/16 ″ 3-9/16″... - Page 5 STEP 2 STEP 3 － STEP 2 Complete the electrical wiring STEP 3 Mount the Chassis Assembly and Drain Tray Assembly ・Place chassis assembly onto the bottom bracket. Make sure all electrical wiring is placed away inside the junction box. ・Using wire nuts, connect power cable from hand dryer to power supply in the ・...
-
Page 6: Function Test
Function Test 1. Checking after installation Wiring Diagram Sensor Test the product as follows after the installation is complete. ■ First peel off the seal on the filter. ・ (The seal is used to protect the filter from scratches during shipment;...
