Page 1: Microwave Oven
Microwave Oven INSTRUCTION MANUAL Model: MT642K3JSM Read these instructions carefully before using your microwave oven. If you follow these instructions, your oven will provide you with many years of good service. SAVE THESE INSTRUCTIONS... -
Page 2: Precautions To Avoid Possible Exposure To Excessive Microwave Energy
ADDENDUM If the appliance is not maintained in a good state of cleanliness, its surface could be degraded and affect the lifespan of the appliance and possibly lead to a hazardous situation Specifications MT642K3JSM Model: Rated Voltage: 2 0V~ 0Hz... -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS To reduce the risk of fire, electric shock, injury to persons WARNING or exposure to excessive microwave oven energy when using your appliance, follow basic precautions including the following: 1. Warning: Liquids and other foods must 13. Install or locate this oven only in not be heated in sealed containers since accordance with the installation they are liable to explode. - Page 4 23. Microwave heating of beverages can result in delayed eruptive boiling, therefore take care when handling the container. 24.The appliance is not intended for use by persons (including children) with reduced physical , sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
-
Page 5: To Reduce The Risk Of Injury To Persons
To Reduce the Risk of Injury to Persons Grounding Installation DANGER Electric Shock Hazard Touching some of the internal components can cause serious personal injury or death. Do not disassemble this appliance. This appliance must be grounded. In the event of WARNING an electrical short circuit, grounding reduces the risk of electric shock by providing an escape wire... -
Page 6: Materials You Can Use In Microwave Oven
CAUTION UTENSILS Personal Injury Hazard See the instructions on “Materials you can use in microwave oven” or “Materials to be avoided in It is hazardous for anyone microwave oven”. There may be certain non-metallic other than a competent person utensils that are not safe to use for microwaving. If to carry out any service or repair in doubt, you can test the utensil in question following operation that involves the removal... -
Page 7: Materials To Be Avoided In Microwave Oven
Materials to be avoided in microwave oven Utensils Remarks Aluminum tray May cause arcing. Transfer food into microwave-safe dish. Food carton with May cause arcing. Transfer food into microwave-safe dish. metal handle Metal or metal- Metal shields the food from microwave energy. Metal trim may trimmed utensils cause arcing. -
Page 8: Turntable Installation
Turntable Installation a. Never place the glass tray upside down. The glass Hub (underside) tray should never be restricted. b. Both glass tray and turntable ring assembly must always be used during cooking. Glass tray c. All food and containers of food are always placed on the glass tray for cooking. -
Page 9: Operation
OPERATION 1. Power Level 11 power levels are available. Level Power 100% Display PL10 2. Clock Setting (1) Press " CLOCK/TIMER "once, "00:00" will display. (2) Press the number keys and enter the current time. For example, time is 12:10 now, please press "1,2,1,0" in turn. (3) Press "... - Page 10 Example: to cook the food with 50% microwave power for 15 minutes. a. Press "TIME COOK" once."00:00" displays. b.Press "1","5","0","0" in order. c.Press "POWER" once,then press "5" to select 50% microwave power. d.Press "START/+30SEC." to start cooking. Note:1) In the process of cooking, if the " STOP/CLEAR" button is pressed or if there is no operation within 1 minute, the oven will go back to the former setting automatically.
- Page 11 7. Speedy Cooking (1) In waiting state, instant cooking at 100% power level can be started by select a cooking time from 1 to 6 minutes by pressing number pads1 to 6. Press " START/+30SEC." to increase the cooking time; the maximum cooking time is 99 minutes and 99 seconds. (2) In waiting state, instant cooking at 100% power level with 30 seconds' cooking time can be started by pressing "...
-
Page 12: Frozen Vegetable
POTATOES a) Press " POTATO " repeatedly until the number you wish appears in the display. "1","2","3" will display in order. "1"SET : 1 potato (approximately 230 gram) "2"SETS: 2 potatoes (approximately 460 gram) "3"SETS: 3 potatoes (approximately 690 gram) For example, press "POTATO"... -
Page 13: Dinner Plate
C. PORK menu a) Press " MEAT " three times to choose pork menu,"PO" displays. b) Press " START/+30 SEC. " to confirm the menu. "150" displays. c) Keep pressing " MEAT " to choose pork weight."300","450","600" or "750" grams can be selected. -
Page 14: Memory Function
19. MEMORY FUNCTION (1) Press "0/MEMORY" to choose memory 1-3 procedure. The LED will display 1,2,3. (2) If the procedure has been set, press " START/ +30 SEC." to use it. If not, continue to set the procedure. Only one or two stages can be set. (3) After finishing the setting, press “START/+30 SEC”... -
Page 15: Troubleshooting
Trouble-shooting Microwave oven interfering Radio and TV reception may be interfered with with TV reception when Microwave oven is operating. It is similar to the Interference of small electrical appliances like mixers, vacuum cleaners, and electric fans. It is normal. In cooking, steam may come out of the food.Most Steam accumulating on door.
