Yaesu FT-8800R Basic Operations

These instructions are not a substitute for reading the manual
FT-8800R Front Panel: 1) Left Dial Knob, 2) Left VOL/SQL Knob, 3) Hyper Memory Buttons, 4)
Left Side Keys 5) Set Key, 6) Right Side Keys, 7) Right VOL/SQL Knob, 8) Right Dial Knob
FT-8800R LCD Panel: Of note: ENC = Tone Encode (TX T), DEC = Tone Decode (RX
T), Main = Main (current TX) band will only appear on left or right, depending on which
side is "active," MT = Memory Tune Mode
NOTE: The FT-8800 is a dual receive radio with a left and right side and set of keys and
knobs. The active side is identified by a MAIN icon in the top "right" corner of the ac-
tive display. When the instructions refer to MAIN key or knob, they refer to the active
transceiver side and do not affect the inactive side until the inactive side is made active.
To select the MAIN band, either press the P1 key on the mic or the DIAL knob on the
side you wish to set active.
Yaesu FT-8800R Basic Operations
MH-48 Mic: 1) PTT Switch,
2) Keypad, 3) P buttons,
4) Lamp switch, 5) Lock
switch, 6) Up/down button.
Prince William County ARES
FT-8800 Quick Reference Guide v.1.4
