Patent Pending
Model No. NTTL15020
Serial No.
Find the serial number in the location
shown below. Write the serial number
in the space above for reference.
Serial Number Decal
QUESTIONS?
If you have questions, or if there
are missing parts, we will guar-
antee complete satisfaction
through direct assistance from
our factory.
TO AVOID UNNECESSARY DE-
LAYS, PLEASE CALL DIRECT TO
OUR TOLL-FREE CUSTOMER
HOT LINE. The trained techni-
cians on our Customer Hot Line
will provide immediate assis-
tance, free of charge to you.
CUSTOMER HOT LINE:
1-888-825-2588
Mon.–Fri., 6 a.m.–6 p.m. MST
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
USER'S MANUAL
Visit our website at
www.nordictrack.com
new products, prizes,
fitness tips, and much more!
Advertisement
Table of Contents
Related Manuals for NordicTrack Summit NTTL15020
Summary of Contents for NordicTrack Summit NTTL15020
- Page 1 Mon.–Fri., 6 a.m.–6 p.m. MST CAUTION Read all precautions and instruc- tions in this manual before using this equipment. Save this manual for future reference. USER'S MANUAL Visit our website at www.nordictrack.com new products, prizes, fitness tips, and much more!
-
Page 2: Table Of Contents
LIMITED WARRANTY ............. . .Back Cover Note: An EXPLODED DRAWING is attached in the center of this manual. NordicTrack is a registered trademark of ICON Health & Fitness, Inc. -
Page 3: Important Precautions
11. Use only a single-outlet surge suppressor that meets all of the specifications described on page 8. To purchase a surge suppressor, see your local NordicTrack dealer or call 1-800- 806-3651 and order part number 146148. 12. Failure to use a properly functioning surge suppressor could result in damage to the con- trol system of the treadmill. - Page 4 21. Do not change the incline of the treadmill by placing objects under the treadmill. 22. When folding or moving the treadmill, make sure that the storage latch is fully closed. 23. When using iFIT.com CDs and videos, an electronic “chirping” sound will alert you when the speed and/or incline of the treadmill is about to change.
-
Page 5: Before You Begin
BEFORE YOU BEGIN Thank you for selecting the revolutionary NordicTrack SUMMIT 4500 X treadmill. The SUMMIT 4500 X tread- mill combines advanced technology with innovative de- sign to help you get the most from your exercise pro- gram in the convenience of your home. And when you’re not exercising, the unique SUMMIT 4500 X can... -
Page 6: Assembly
ASSEMBLY Assembly requires two people. Set the treadmill in a cleared area and remove all packing materials. Do not dispose of the packing materials until assembly is completed. Assembly requires the included allen wrench and your own phillips screwdriver Note: The underside of the treadmill walking belt is coated with high-performance lubricant. During shipping, a small amount of lubricant may be transferred to the top of the walking belt or the shipping carton. - Page 7 4. Slide the Grounding Bracket (107) onto one of the Handrail Spacers (65) in the location shown. See inset drawing A. Pinch the tabs on the Grounding Bracket (107) so that the tabs will fit into the hole in the Upright (69, see inset drawing B).
-
Page 8: Operation And Adjustment
(see drawing 1 at the right). To purchase a surge suppressor, see your local NordicTrack dealer or call 1-800-806- 3651 and order part number 146148. Use only a single-outlet surge suppressor that is UL 1449 listed as a transient voltage surge sup- pressor (TVSS). - Page 9 Program Display Pulse Sensor Note: If there is a thin sheet of clear plastic on the face of the console, remove it. FEATURES OF THE CONSOLE The advanced console offers an impressive selection of features to help you get the most from your exercise. When the console is in the manual mode, the speed and incline of the treadmill can be changed with a touch of a button.
- Page 10 CAUTION: Before operating the console, read the following precautions. • Do not stand on the walking belt when turn- ing on the power. • Always wear the clip (see the drawing below) while operating the treadmill. • Adjust the speed in small increments to avoid sudden jumps in speed.
- Page 11 HOW TO USE THE MANUAL MODE Insert the key fully into the console. See GETTING STARTED on page 10. Select the manual mode. When the key is in- serted, the manual mode will be selected and the Manual indica- tor will light. If a program has been selected, press the Select Pro- gram button repeatedly to select the manual mode.
- Page 12 Speed/Pace display— This display shows the speed of the walking belt and your current pace (pace is mea- sured in minutes per mile). Every seven seconds, the display will change from one number to the other. Note: The console can display speed and dis- tance in either miles or kilometers.
- Page 13 Each program is divided into several time seg- ments of different lengths. The Time display shows both the time remaining in the program and the time remaining in the current segment. One speed setting and one incline setting are pro- grammed for each segment.
- Page 14 HOW TO CREATE CUSTOM PROGRAMS Insert the key fully into the console. See GETTING STARTED on page 10. Select one of the custom programs. When the key is in- serted, the manual mode will be selected and the Manual indica- tor will light.
- Page 15 HOW TO USE CUSTOM PROGRAMS Insert the key fully into the console. See GETTING STARTED on page 10. Select one of the custom programs. When the key is in- serted, the manual mode will be selected and the Manual indica- tor will light.
- Page 16 HOW TO USE THE FITNESS TEST PROGRAM The fitness test program is designed to measure your relative fitness level. For the best results, the fitness test program should be used at a time when your en- ergy level is high; the fitness test program should not be used if you have already exercised during the day.
- Page 17 When the cool-down segment is completed, the walking belt will slow to a stop. After the fitness test program is com- pleted, your fitness level will be shown in the Time display. There are ten fitness levels— fitness level 10 (FL:10) is the highest.
- Page 18 Press the Start Program button or the Speed + button to start the program. A moment after the button is pressed, the tread- mill will automatically adjust to the first speed and incline settings for the program. Hold the handrails and begin walking.
- Page 19 HOW TO CONNECT THE TREADMILL TO YOUR CD PLAYER, VCR, OR COMPUTER To use iFIT.com CDs, the treadmill must be con- nected to your portable CD player, portable stereo, home stereo, or computer with CD player. See pages 19 and 20 for connecting instructions. To use iFIT.com videocassettes, the treadmill must be connected to your VCR.
- Page 20 HOW TO CONNECT YOUR HOME STEREO Note: If your stereo has an unused LINE OUT jack, see instruction A below. If the LINE OUT jack is being used, see instruction B. A. Plug one end of the audio cable into the jack on the front of the treadmill near the power cord.
- Page 21 HOW TO CONNECT YOUR VCR Note: If your VCR has an unused AUDIO OUT jack, see instruction A below. If the AUDIO OUT jack is being used, see instruction B. If you have a TV with a built-in VCR, see instruction B. If your VCR is connected to your home stereo, see HOW TO CONNECT YOUR HOME STEREO on page 20.
- Page 22 If the speed or incline settings are too high or too low, you can manually override the settings at any time by pressing the Speed or Incline buttons on the console. However, when the next “chirp” is heard, the speed and/or incline will change to the next settings of the CD or video program.
- Page 23 HOW TO USE PROGRAMS DIRECTLY FROM OUR INTERNET SITE Our Web site at www.iFIT.com allows you to access basic programs, audio programs, and video programs directly from the internet. Additional options are soon to be available. See www.iFIT.com for details. To use programs from our Web site, the treadmill must be connected to your home computer.
- Page 24 THE INFORMATION MODE/DEMO MODE The console features an information mode that keeps track of the total number of hours that the treadmill has been operated and the total number of miles that the walking belt has moved. The information mode also allows you to switch the console from miles per hour to kilometers per hour.
-
Page 25: How To Fold And Move The Treadmill
HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL FOR STORAGE Before folding the treadmill, adjust the incline to the lowest position. If this is not done, the treadmill may be per- manently damaged. Remove the key and unplug the power cord. -
Page 26: Troubleshooting
TROUBLESHOOTING Most treadmill problems can be solved by following the steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, please call our Customer Service Department toll- free at 1-888-825-2588, Monday through Friday, 6 a.m. until 6 p.m. Mountain Time (excluding holidays). PROBLEM: The power does not turn on SOLUTION: a. - Page 27 PROBLEM: The walking belt slows when walked on SOLUTION: a. Use only a single-outlet surge suppressor that meets all of the specifications described on page 8. b. If the walking belt is overtightened, treadmill perfor- mance may decrease and the walking belt may be- come damaged.
-
Page 28: Conditioning Guidelines
CONDITIONING GUIDELINES WARNING: Before beginning this or any exercise program, consult your physi- cian. This is especially important for individu- als over the age of 35 or individuals with pre- existing health problems. The pulse sensor is not a medical device. Various factors, including your movement, may affect the accuracy of heart rate readings. - Page 29 SUGGESTED STRETCHES The correct form for several basic stretches is shown at the right. Move slowly as you stretch—never bounce. 1. Toe Touch Stretch Stand with your knees bent slightly and slowly bend forward from your hips. Allow your back and shoulders to relax as you reach down toward your toes as far as possible.
-
Page 30: Part List
PART LIST—Model No. NTTL15020 To locate the parts listed below, refer to the EXPLODED DRAWING attached in the center of this manual. Key No. Qty. Description Foot Rail Insert Foot Rail Foot Rail Cap Screw Left Foot Rail Cap Frame Pivot Bolt Frame Pivot Spacer Magnet Front Roller/Pulley... -
Page 31: Ordering Replacement Parts
• The MODEL NUMBER OF THE PRODUCT (NTTL15020) • The NAME OF THE PRODUCT (NordicTrack • The SERIAL NUMBER OF THE PRODUCT (see the front cover of this manual) • The KEY NUMBER AND DESCRIPTION OF THE PART(S) (see the PART LIST on pages 30 and 31 and the EXPLODED DRAWING attached in the center of this manual) Key No. -
Page 32: Limited Warranty
LIMITED WARRANTY WHAT IS COVERED—The entire NordicTrack ® SUMMIT 4500 X treadmill (“Product”) is warranted to be free of all de- fects in material and workmanship. WHO IS COVERED—The original purchaser or any person receiving the Product as a gift from the original purchaser. - Page 33 EXPLODED DRAWING—Model No. NTTL15020 R0302A...
