- Page 1 SX-AVR2700 SX-AV1700 Y YU SX-C1700 Y YU SX-R1700 Y YU aiwa aiwa aiwa aiwa aiwa aiwa aiwa aiwa aiwa aiwa SX-AVR2700 SX-AV1700 SX-R1700 SX-C1700 SERVICE MANUAL SPEAKER SYSTEM S/M Code No. 09-993-328-1O1...
-
Page 2: Specifications
SPECIFICATIONS SX-AVR2700 Speaker Full-range: 100 mm x 2, cone type Impedance 8 ohms Maximum input power 150 W (peak) Dimensions (W x H x D) Front: 120 x 230 x 110 mm (4 x 4 in.) Center: 360 x 120 x 110 mm (14 x 4 in.) - Page 3 SPEAKER DISASSEMBLY INSTRUCTIONS Type.1 Type.4 Insert a flat-bladed screwdriver into the position indicated by the TOOLS arrows and remove the panel. Remove the screws of each speaker 1 Plastic head hammer unit andthen remove the speaker units. 2 (-) flat head screwdriver 3 Cut chisel Type.2 How to Remove the PANEL, FR...
- Page 4 SPEAKER PARTS LIST SX-AVR2700 (SX-AV2700, SX-C2700, SX-R2700) REF. NO PART NO. KANRI DESCRIPTION 1 8Z-AS1-001-010 CABI,FR<AV,R> 2 8Z-AS1-003-010 GRILLE,FRAME ASSY<AV,R> 3 8Z-AS1-006-010 CABI,FR C 4 8Z-AS1-008-010 GRILLE,FRAME ASSY C 5 8Z-AS1-601-010 SPKR, 100<R> 6 8Z-AS1-602-010 SPKR, 100<AV,C> 7 8Z-AS1-011-010 TERMINAL,ASSY...
