  • Page 1 Nokia 9000il Owner’s Manual Owner’s Manual 9357106 Issue 2 US...
  • Page 2 Nokia is a registered trademark of Nokia Corporation, Finland. Copyright ©1995-1998 Nokia Mobile Phones. All rights reserved. Nokia Mobile Phones operates a policy of continuous improvement. Therefore, we reserve the right to make changes and improvements to any of the products described in this guide without prior notice.
  • Page 3 FOR YOUR SAFETY Read these simple guidelines. Breaking the rules may be dangerous or illegal. More details are included in Chapter 16 "Important safety information" on page 16-1. ROAD SAFETY COMES FIRST Don’t use the communicator while driving; park! SWITCH OFF IN HOSPITALS Follow any regulations or rules.

  • Page 4: Table Of Contents

    Table of contents Table of contents Introduction ......1-1 Things to remember ......1-2 Facts about wireless data transmission.
  • Page 5 Sending messages ......6-3 Received messages ......6-5 Business cards .
  • Page 6 Table of contents Import/Export calendar data ....10-10 Data removal .......10-10 Memory .

  • Page 7: Introduction

    Congratulations on purchasing the Nokia 9000il Communicator, the versatile communications tool you need to stay connected to the office when you are out. The Nokia 9000il Communica- tor, with a mobile phone, messaging device, In- ternet access terminal and palmtop organizer all in one compact unit, is more than just the sum of its components.

  • Page 8: Things To Remember

    (Figure 1-2) is under the cover. The word “interface” emphasizes the fact that both of these two aspects of the Nokia 9000il Communicator use the same resources and work closely together — they are not separate devices.
  • Page 9 Chapter 1 - Introduction The Internet applications use passwords and user names to protect from unauthorized use of your Internet services. To change the password for an Internet access point, go to the Internet main screen, press Settings, scroll to Internet access and press Change, then press Edit and scroll to Password.

  • Page 10: Facts About Wireless Data Transmission

    Facts about wireless data transmission The Nokia 9000il Communicator employs the digital data transmission capabilities of the GSM network to send faxes, short messages, e-mail and to establish connections with remote computers. Wireless data connections can be made from most locations where your mobile phone oper- ates.

  • Page 11: Getting Started

    The following steps, however, occur only the first time the communi- cator is activated, or after it has been reformatted. For information about other Nokia 9000il Com- municator accessories, see the Accessories Guide. This chapter covers the following topics: •...

  • Page 12: Sim Card

    have a SIM card yet, ignore this step. Although you do not need a SIM card to use the communi- cator interface, a SIM card is required to send and receive calls and documents. ‚ Open the cover. This activates the communi- cator interface.

  • Page 13: Contact Cards

    Chapter 2 - Getting started SIM card contents Normally, a new SIM card will not contain any contact information. After the personalization procedure, if the SIM does contain stored names or numbers, you will be asked if you want to copy the SIM card contents into the communi- cator’s memory.

  • Page 14: Connectors

    Note: The battery does not fit into place if the SIM card is not correctly installed. Do not force the battery into place! Check that Connectors (1) IrDA-SIR infrared port for connecting to a PC or a printer (Figure 2-5). For more information on infrared connections, see Chapter 10 "System: Connecting to a PC"...

  • Page 15: Battery

    Chapter 2 - Getting started Battery Your Nokia 9000il Communicator is powered by a rechargeable Lithium-Ion battery. The Extended Li-Ion Battery provides up to three hours of talk/ fax/terminal time or up to 30 hours of standby time. Use only batteries approved by the com- municator manufacturer.

  • Page 16: Communicator Interface

    Note: No information or user data will be lost if the battery is removed or completely discharged. User data is automatically retained by the flash memory and is unaffected by the status of the battery. Using the battery Use only batteries approved by the communicator manufacturer.

  • Page 17: Communicator Interface

    Chapter 2 - Getting started Communicator interface To activate the communicator interface press the cover lock catch and open the cover (Figure 2-9). The applications are run in the middle of the dis- play. The indicators (Figure 2-10) show applica- tion and system-related information (see ”Indicators”...
  • Page 18 Communicator interface conventions The following figures illustrate certain communi- cator interface conventions (Figure 2-11, 2-12). Figure 2-11: Example of commands (1) When a command appears dimmed, the com- mand cannot be used. (2) When a value appears on a dotted line with a cursor, enter a new value manually via the keyboard.

  • Page 19: Communicator Applications

    Information need not be specifically saved (there is no “Save” command). The Nokia 9000il Com- municator saves all data automatically. To send or receive with any of the communica- tions applications, remember that the phone in-...

  • Page 20: Indicators

    2-10 Indicators The application icon and the application name show the currently active application, i.e., the application you are in at the moment. The icons which appear on the Call status and In- box/Outbox indicator rows, change according to the application and current situation. The battery level and field strength indicators are the same as are shown on the phone interface display when the phone interface is on (see Chapter 13 "Phone...

  • Page 21: Battery Level

    Chapter 2 - Getting started Battery level – Battery is low. The battery should be recharged. – Battery is charging (the bar scrolls until it is fully charged). The outlet plug icon indicates that the commu- nicator is connected to an external power source (usually a wall outlet).

  • Page 22: Special Features

    2-12 once you have pressed the shift key, the next key press always generates a shifted character. In most text editors, the shift and arrow keys (see number 7 in Figure 2-13) can be used to select text (see "Special features: Settings and Menus" on page 2-13).

  • Page 23: Shortcut Function

    Chapter 2 - Getting started Backlight To activate the backlight within the communica- tor interface, press the light will be activated for the amount of time set in the Backlight settings (System application set- tings). Multi-select function Where multi-selection is available, you can select several items at once.
  • Page 24 2-14 Naming a document When you close a new document for the first time, you will be asked to enter the name of the document in the input field. The communicator will suggest a name for the document. The name can be seen highlighted in the input field.

  • Page 25: Useful Settings Information

    Chapter 2 - Getting started Useful settings information The following chart contains settings information for various features of your communicator. All paths take you from the application main view. Following the conventions of the Owner’s Manual, the command names appear in bold, and item names, entries and values shown in the application area are in italics.

  • Page 26: Contacts

    The Telephone, Fax, SMS and E-mail applications all use information found in the Contacts application. Nokia HelpLine You will find the Nokia HelpLine contact cards for both the USA and Canada in the Contacts directory. The Nokia HelpLine answers questions and offers instructions over the phone.

  • Page 27: Contact Cards

    ƒ To change the label name press Change label. Choose the new label and press OK. „ When your contact card template is satisfac- tory, press Close. To change the Record duration: • Highlight Record duration and press Change. Contact cards Contacts directory The main view within the Contacts application is the Contacts directory.
  • Page 28 Chapter 3 - Contacts You may delete or add lines to the Address and Note fields by using the delete or enter keys. To save changes and go back to the Contacts direc- tory main view, press Close. The +, #, *, p, w, -, [space] characters The communicator allows you to insert special tones or pauses within a string of numbers for communications that require more complex...

  • Page 29: Records

    Speed dials The Speed dials command (see Figure 3-1) lets you assign speed dials to eight phone numbers. Number 1 is reserved for calling your voice mail- box (see Chapter 4 "Telephone: Making a call - Calling your voice mailbox" on page 4-7). For in- formation on how to use the speed dials, see Chapter 13 "Phone interface: Using memory - Dialing shortcuts"...
  • Page 30 Chapter 3 - Contacts • Number contacted (inbound or outbound). • Type of call (voice, SMS, fax, data). • Inbound/outbound call. • Date and time of call. • Duration of call. The General record lists all communications, while the Individual record lists only communi- cations relating to the individual contact you have selected.
  • Page 31 The phone numbers from the SIM card memory locations will appear in the Tel field of the contact card. If the number you have copied is a GSM number, be aware that you will need to edit the field label in the Contacts application from the communi- cator interface in order to send SMS messages to this contact.

  • Page 32: Telephone

    Chapter 4 - Telephone To make phone calls, the following requirements must be met: • An activated SIM card must be inserted. • The phone interface must be switched on. For a description of the phone interface keys and especially the button, see Chapter 13 ”Phone interface”...
  • Page 33 Ringing volume — This setting adjusts the ring- ing volume (1 is the lowest, 5 the highest). Ringing tone — You can choose from among the list of ringing tones stored in the communicator. To compose your own ringing tones, see Chapter 11 "Extras: Composer"...

  • Page 34: Call Waiting

    Chapter 4 - Telephone Call waiting Call waiting is a network service which must be ac- tivated through your network operator before you can use it (see ”Telephone settings” on page 4-1). When the voice call waiting network service is on, the network will notify you of a new incoming voice call while you have a call in progress.
  • Page 35 turn on the phone interface by pressing your short messages, faxes and mail will be sent automatically once the communicator receives a GSM1900 network signal. When the communicator is in the flight mode, emergency calls must be made from the phone interface: •...

  • Page 36: Making A Call

    Chapter 4 - Telephone Making a call There are three ways to make a call: 1. Use the search field: Simply enter the phone number using the number keys across the top of the keyboard. The number will be written to the search field.

  • Page 37: Calling Card Call

    Calling card call A phone calling card is a credit or debit card especially for phone charges. The calling card service you subscribe to is most often separate from your mobile phone service. A calling card may be especially useful when making long dis- tance calls while traveling, to benefit from the discounted rates offered by certain calling card companies.

  • Page 38: Calling Your Voice Mailbox

    Chapter 4 - Telephone Making a new call during an active call You have the option of making another call while you have call in progress. To make a new call during an active call: Press New call and make the new call normally. To cancel the new call, press Cancel.

  • Page 39: Sending Dtmf Tones

    To talk privately to one of the conference call participants: • Press Conference commands. ‚ Select a participant from the list of partici- pants and press One to one. The conference call is now split into two calls: the one-to-one call is the active call and the conference is on hold.
  • Page 40 Chapter 4 - Telephone Select a DTMF sequence. You can edit the se- quence, or, if there are no stored sequences, you can manually enter the DTMF string into the field. Press Send to send the DTMF sequence shown in the input field, at the bottom of the display.

  • Page 41: Fax

    Chapter 5 - Fax Activate the Fax application by pressing the but- ton labeled “Fax” on the communicator interface keyboard. To send and receive faxes the following require- ments must be met: • The phone interface must be on. • The network you are using must support fax calls.
  • Page 42 [File name] — All the available GIF and JPG files in the Downloaded files folder are listed here. Select which one you want to attach to the fax. Signature file — None (default) / [File name]. Allows you to add your signature to the fax cover page.

  • Page 43: Sending Faxes

    Chapter 5 - Fax Sending faxes You can send any previously created (or received) document as a fax, or you can create a new one. You can send faxes from the: • Fax application • Notes application (see Chapter 8 "Notes: Sending documents"...
  • Page 44 tor. For information on file transfer, see Chapter 10, "System: File transfer - Transferring files to the communicator" on page 10-8. • Press Settings in the Fax application main screen. ‚ Scroll to Logo file or Signature file and press Change.

  • Page 45: Received Faxes

    Chapter 5 - Fax Received faxes To receive a fax, the following requirements must be met: • You must have subscribed to fax service with your network operator. • The phone must be on. • You must have adequate signal strength. All faxes will be received automatically, and will go to the Received faxes folder.

  • Page 46: Short Messages

    Chapter 6 - Short messages 6. Short messages Activate the Short Message Service (SMS) appli- cation by pressing the button labeled “SMS” on the communicator interface keyboard. To send and receive SMS the following require- ments must be met: • Short Message Service (SMS) must be supported by the network you are using.

  • Page 47: Sms Settings

    SMS settings To view the SMS application settings: Press Settings in the SMS main view. The list of default settings will open. To change the settings: Select a setting and press Change to open it. The settings you define here will be used until you change them again.

  • Page 48: Sending Messages

    Chapter 6 - Short messages • Validity period — 1h / 6h / 24h (default)/ One week / Maximum • Message conversion — None (default)/ Fax / X.400 / Paging / E-mail / ERMES / Speech • Request delivery report — Yes / No (default) Press Change to set a new value for the current message.
  • Page 49 The short message in the editor resembles a post- card. A character counter indicating the number of characters typed and number still available (see Figure 6-1) appears at the top of the editor. In a received SMS message, the time and date the message was sent are shown below the sender’s name or number.

  • Page 50: Received Messages

    Chapter 6 - Short messages Received messages To receive short messages the following require- ments must be met: • Service must be available from the network operator. • Phone interface must be on. • You must be within network coverage area. All messages are received automatically and go to the Received messages folder.

  • Page 51: Business Cards

    You can send any contact card as a business card. Business cards sent from a device that supports the Nokia 9000il Communicator contact card format can be saved directly as new contact cards in the Contacts directory: •...

  • Page 52: Internet

    Inter- net button. To close an active application, press Close. Nokia IAP Info Online For online Information about Internet connec- tivity, go to the Internet application and select WWW. From the Hotlist, highlight Access Point Info- Retrieve Now! and press Retrieve.

  • Page 53: Internet Glossary

    The terms “domain name” and “host name” are sometimes, slightly inaccurately, used synonymously. In a fully qualified domain name (e.g., www.club.nokia.com), the first part of the name is the name of the host and the following parts are names of domains the host belongs to.

  • Page 54: Internet Settings

    WWW host computer. The URL usually starts with http:// followed by www. For example, the Club.Nokia home page can be found at: http:/ /www.club.nokia.com. URLs are often re- ferred to with phrases like “Home page loca- tion,”...
  • Page 55 Custom — When a data call is established, the modem is first set to the factory defaults and then initialized according to the string you enter here. For Terminal connections, see ”Define Terminal connections” on page 7-18. Data call restrictions — Initiates a data call re- strictions dialog, similar to that in the Telephone application (see Chapter 4 "Telephone: Tele- phone settings - Voice call forward, call restric-...

  • Page 56: E-Mail Settings

    Chapter 7 - Internet E-mail The Nokia 9000il Communicator e-mail system is compliant with the Internet standards SMTP, IMAP4, POP3, MIME1 and MIME2. E-mail is started in the Internet main view by selecting E-mail and pressing the Select com- mand button. The E-mail main view shows the following folders: Own texts —...

  • Page 57: Sending E-Mail

    CC: own e-mail address — Yes / No (default). If the setting is Yes, the mail will be automat- ically sent to the address defined in Own e-mail address. MIME character encoding — On (default) / Off. MIME encoding allows another MIME compli- ant e-mail system to read the character set used in your communicator.
  • Page 58 Chapter 7 - Internet When the message is ready to be sent, press Recipient (Figure 7-2). The e-mail directory will open and you may select an address from the list or manually enter the address on the line provided (see "Sending e-mail: E-mail di- rectory"...
  • Page 59 The e-mail envelope will open if the contact has only one e-mail address. If the contact has several e-mail addresses, a pop-up box opens, listing the available addresses. Select an address and press Select to open the e-mail envelope (Figure 7-3). To enter the recipient’s address manually, press Enter e-mail address.

  • Page 60: Receiving E-Mail

    Chapter 7 - Internet When you press Send in the E-mail envelope, the e-mail message will go to the Document outbox, but will not be sent immediately (see Chapter 12 ”Document outbox” on page 12-1). Receiving e-mail Your incoming e-mail is received by the remote mailbox (Figure 7-4).
  • Page 61 7-10 To set the amount of information shown in the header fields, go to the E-mail main view, select Settings, and scroll down to Show header fields. From the Received mail folder, when you open a received e-mail the following command buttons are displayed: Menu —...

  • Page 62: Www Settings

    No proxy for – You may define domains for which the proxy must not be used. Domain names are delimited by commas (for exam- ple, nokia.com, cal.edu). You may specify Go to the Internet application main view. Select WWW and press Select.

  • Page 63: Hotlist

    Enter the Item name you want for your new Hotlist item, then tab to the URL field. Enter the HTTP address (e.g., www.nokia.com). The Autoselect IAP field is for those who want to use a specific Internet access point (IAP) to connect to a certain web site. If you have no preferences about which IAP is used, leave the Autoselect IAP at Yes.

  • Page 64: Connecting To Www

    Chapter 7 - Internet Connecting to WWW Select a WWW page from the Hotlist or enter a URL address in the URL entry field (see "Connecting to WWW: Navigating in WWW" on page 7-14). Press Retrieve. If the WWW page has been downloaded and re- mains in the communicator’s temporary working memory (or “cache”), the page is retrieved from there.

  • Page 65: Navigating In Www

    7-14 Locally stored WWW pages To store downloaded WWW pages locally (i.e., on your communicator): From the WWW page you have retrieved, press Save. A new set of commands is acti- vated. Press Copy source. The current WWW page HTML code will be stored in the Downloaded files folder and a link pointing to this WWW page will be added on the hotlist.

  • Page 66: Viewing Images

    Zoom out. The Image viewer is similar to the Fax viewer (see Chapter 5 "Fax: Received faxes" on page 5-5). Plug-ins The Nokia 9000il Communicator is capable of accepting software plug-ins which can increase web browser functionality. To download a plug-in: Move the cursor over the hypertext link that points to the plug-in and press Retrieve.

  • Page 67: Define Telnet Connections

    7-16 Telnet To activate the Telnet application: Go to the Internet applications main view. Scroll down to Telnet and press Select. The Telnet application is used to make a connec- tion to a remote computer via the Internet. The Telnet application is similar to the Terminal application, in that both applications emulate the VT100 terminal display (see Figure 7-8).

  • Page 68: Text Transfers

    Chapter 7 - Internet In a Telnet connection, these special keys include the following commands (can be used in remote systems that support them): Interrupt — For interrupting the current pro- cess on the remote computer. Skip command output — To prevent com- mand output from being displayed on the screen.

  • Page 69: Define Terminal Connections

    7-18 Terminal To activate the Terminal application: Go to the Internet applications main view. Scroll down to Terminal and press Select. The Terminal application is used to connect directly (not via Internet) to a remote computer by way of a data call. The Terminal main view shows defined Terminal connections.

  • Page 70: Terminal Connection

    Chapter 7 - Internet Modem initialization — Any modem initialization string containing AT commands may be entered here, if needed. The initialization string in the Internet settings (Modem initialization: Custom view) is executed first, then the modem initializa- tion string. Backspace key —...

  • Page 71: Notes

    Chapter 8 - Notes Figure 8-1: Notes application main view Notes is used for writing notes and managing various documents stored on the communicator. All folders as well as the Document outbox are shown in the Notes main view. Folders within the Notes main view are (see Figure 8-1): Own texts —...
  • Page 72 Menu Each folder has a Menu command, which pro- vides the following options: Write note — This option is available only inside Own texts folder. Rename — With this option you can rename the selected subfolder or document. Memos cannot be renamed. Copy —...

  • Page 73: Sending Documents

    Chapter 8 - Notes Received faxes and downloaded figures The contents of a received fax cannot be con- verted into text or edited. Opening a fax acti- vates the fax viewer (see Chapter 5 "Fax: Received faxes" on page 5-5) and opening an image activates the image viewer (see Chapter 7 "Internet: Connecting to WWW - Navigating in WWW"...

  • Page 74: Printing Documents

    For more information on the printers supported, read the readme.txt file on the diskette supplied in the communicator sales package, or see the Club.Nokia home page at www.club.nokia.com. For specific information on the printer you are using, please refer to the manufacturer’s User’s Guide.

  • Page 75: Calendar

    Chapter 9 - Calendar In the Calendar application, you can see your calendar of scheduled events, keep a list of tasks in the To-do list, set calendar alarms and link memos to events (see "Daily schedule: Memos" on page 9-3). The Calendar main screen contains your monthly schedule along with the events of a selected day.

  • Page 76: Daily Schedule

    • Edit the schedule of a day by highlighting the date using the scroll keys and pressing Day. • Events which are not be associated with a specific time are indicated with a horizontal bar in the daily schedule (e.g., Mom’s birthday in Figure 9-1).
  • Page 77 Chapter 9 - Calendar Start time — The time the event starts. The default start time is the selected time row in the daily events list. End date — The date the event ends (optional). End time — The time the event ends (optional). Alarm —...

  • Page 78: Weekly Schedule

    The alarm options are: None (default) / At start time / . . . minutes before event (enter a value). An active alarm is indicated by an icon in the daily schedule (in Figure 9-2, the 8:00 event). When the alarm occurs, an alarm note is shown Weekly schedule The weekly schedule shows one week at a time.

  • Page 79: Calendar Booking

    Chapter 9 - Calendar Calendar booking Calendar booking enables you to send event re- quests or reservations to other communicator calendars using special SMS messages. Note: The difference between an event request and an event reservation is that the recip- ient may decide whether to accept or discard an event request, but event reservations can only be accepted.

  • Page 80: To-Do List

    To-do list To access the To-do list: 1. Press To-do in the monthly or weekly schedule. 2. Press Menu in any of the schedules. The To-do list is a list of tasks that are not con- nected to any specific time or day. After a calen- dar alarm has occurred, you have the opportunity to move the event to the To-do list by pressing the Move to To-do list command button.

  • Page 81: System

    Select. If one System application is active, you must close it by pressing Close in the applica- tion’s main view before you can start another. The Nokia 9000il Communicator’s applications for PC connectivity include: • File transfer • Install/Remove software •...

  • Page 82: Security

    10-2 Contrast control — The contrast view shows a test figure and a set of commands which can be used to adjust the figure. The ’+’ command but- ton increases the contrast. The ‘–’ command but- ton performs the opposite function. When the setting is satisfactory, press OK.
  • Page 83 Chapter 10 - System Unlocking the communicator After the communicator has been locked, it can- not be used until the correct lock code is given. Incoming voice calls can, however, be answered via the phone interface. Note: When the communicator is locked, it may be possible to make a call via the phone interface to the emergency number pro- grammed into your phone (e.g., 911 or...
  • Page 84 10-4 If the SIM card has been changed and the new SIM card has not previously been used with your communicator, the communicator locks itself until the lock code, supplied with the communicator sales package, is correctly entered. The communicator recognizes five different SIM cards as the owner’s cards.

  • Page 85: User Data

    Name, Company, Job title, Address, Tel, Fax, Tel(GSM), Fax(GSM), E-mail and URL fields. Fax modem The Nokia 9000il Communicator can be used as a 9600 bps PC fax modem if: • Data calls are supported by the network you are using.

  • Page 86: Connecting To A Pc

    10-6 To change the Fax modem settings: • Press Settings. ‚ Select Connection type: Infrared (default, recommended)/ Cable. The cable connection is intended for use with the communicator’s own PC connectivity appli- Connecting to a PC To use the PC connectivity features found in the System application (such as File transfer, Backup /Restore, etc.), the Nserver connectivity software, provided on a diskette in the communicator sales...

  • Page 87: File Transfer

    PC window). The following files can be transferred: Text files — Nokia 9000il Communicator text files transferred to a PC can be read and edited in a PC environment with standard Windows or MS-DOS text editors.

  • Page 88: Install/Remove Software

    10-8 … Press Open to open the folder containing the file(s) you want to transfer. Select a file by moving the selection frame over it. If the file you want is in a different folder, press Close and select another folder. If you want to copy more than one file, use multi-selection (Ctrl+space bar) or repeat the procedure from step 1.

  • Page 89: Backup/Restore

    Chapter 10 - System Caution: Beware of viruses. Install into the Nokia 9000il Communicator only software you have Backup/Restore The Backup/Restore application enables you to make backups of various data on your communi- cator, as well as restore to the communicator data you have saved.

  • Page 90: Import/Export Calendar Data

    10-10 To import contacts: Press Import in the Import/Export contacts main view. When the data in the defined PC directory has been copied to the communicator, you will be asked to confirm the conversion of the imported data as contact cards. The imported contacts will be added to your Import/Export calendar data The Import/Export calendar data application al-...

  • Page 91: Memory

    About this product This section displays information about the Nokia 9000il Communicator. of memory each of them uses. The list is updated every time it is opened. If the memory is getting low, you should delete some documents.

  • Page 92: Extras

    To select one of these services, choose the service with the scroll or arrow keys and press Select. To change the access numbers of Nokia and Op- erator services, or to change, add or delete serv- ice access points that you have defined yourself, press Settings.

  • Page 93: Calculator

    11-2 the service, the server number (SMSC phone num- ber for this service) and the access number. To retrieve information: • In the Text Web main view, scroll to one of the service access points that you have de- fined and press Select. ‚...

  • Page 94: Clock

    Chapter 11 - Extras All data and calculation commands are entered from the keyboard. The following characters can be used for the corresponding operations: Numbers 0 to 9 . (period) decimal point can be entered, ignored in (space) the calculation addition –...

  • Page 95: World Time

    11-4 There can only be one active alarm. If an alarm is already active, the command names are differ- ent. A counter on the lower right side of the screen shows how much time remains to the time of the alarm. •...

  • Page 96: Composer

    Chapter 11 - Extras To create a new city card, press Add. To remove a city from the database, press Delete. The current home location cannot be deleted (change the home location, then delete the old one from the list). Clock settings The Clock application related settings are ad- justed with Settings in the Clock main view.
  • Page 97 11-6 Custom tune options Press Options to do one of the following: Tempo opens the tempo pop-up box with a new set of commands. Tempo is measured in beats per minute. To alter the tempo, use backspace and enter a new value in the box. To accept the tempo, press OK.

  • Page 98: Converter

    Chapter 11 - Extras Converter This application allows you to make conversions between different units of measure, which in- clude: length, area, volume, mass, velocity, tem- perature, power, energy, and currency. The converter main screen shows two identical lists containing the units that may be converted. From this application, you can convert, for example, inches to feet, inches to centimeters, kilometers to miles, etc.

  • Page 99: Wireless Data Backup

    11-8 … Select the currency from which you want to convert in the list on the left, and the curren- cy to which you want to convert in the list on the right. Wireless Data Backup Wireless Data Backup allows you to backup and restore data over the GSM network via a data call.

  • Page 100: Document Outbox

    Chapter 12 - Document outbox 12. Document outbox All documents you send go through the Docu- ment outbox, which sends the documents when- ever it is possible (see Chapter 1 "Introduction: Things to remember" on page 1-2). Once a document is in the document outbox, it will remain there until it is successfully sent or you manually cancel the send.
  • Page 101 12-2 sent until you select one and press Start. All email with the Upon request status will be sent during the same connection. To speed up the process and manually send documents that have the Waiting, Retry or Upon request status: •...

  • Page 102: Phone Interface

    Chapter 13 - Phone interface 13-1 13. Phone interface When operating the phone interface, keys must be pressed one at a time. Two keys are never to be pressed simultaneously. switches the phone interface on and off. Note: This button does not function when the device cover is open.

  • Page 103: Display Indicators

    13-2 Using the selection keys When this Owner’s Manual instructs you to “press” a key (the name of the function appears in bold), it means that you should press the selection key under the function name; for example, press- ing Menu (the selection key under the text Menu) gains access to the menu functions, and Memory (the selection key under the text Memory) to the memory functions.

  • Page 104: Making A Call

    Chapter 13 - Phone interface Making a call The communicator can make and receive calls only when all the following requirements are met: • The phone interface is switched on. • The communicator has a valid SIM card fitted. • The communicator is located in the network service area ( is shown).

  • Page 105: Using Memory

    13-4 Automatic sending In order to send DTMF tones automatically, you must store them first. Storing DTMF strings is most conveniently done in the communicator in- terface, see Chapter 3 "Contacts: Contact cards - Storing DTMF tones" on page 3-4. If you want to store DTMF strings in the phone interface, see "Using memory: Storing information via the phone interface"...

  • Page 106: Dialing Shortcuts

    Chapter 13 - Phone interface 2. If the next required character is located on the same key as the present one, wait one second. The vertical cursor will appear to the right of the character just pressed. Or, press to move the cursor and select the charac- ter without waiting for the cursor to appear.

  • Page 107: Menu Shortcuts

    13-6 Key in the number of the memory or speed dial location where you have stored the phone num- ber and press The phone interface will recall the number from the memory, display it briefly, and then dial it. If the speed dial location is empty, an error message will be displayed.

  • Page 108: Main Menu Structure

    Chapter 13 - Phone interface ‚ Press either to scroll the list of menus until you reach the desired menu. ƒ Press Select to enter the menu. If the menu contains any submenus, you can go to the one you want with „...

  • Page 109: Detailed Menus List

    13-8 Detailed menus list When you have reached the correct menu, use to scroll through the menu options. Recent calls (Menu 01) Within this menu, you can review and erase the phone numbers stored automatically. Note that the Received calls and Missed calls functions are network services which work only in networks that allow you to view the caller’s phone number.

  • Page 110: Call Forward Settings

    Chapter 13 - Phone interface the text NO MESSAGE ON THE TOPIC is displayed. You can scroll the text with Option gives you the following options: Use number — Copies the phone number from the current message onto the display, from which you can dial it or store it elsewhere.
  • Page 111 13-10 Phone settings (Menu 4) Lights (Menu 4 1) The keypad and display of the phone interface are fitted with lights to make them easy to read. When the communicator is used as a handport- able phone or is connected to a charger, this set- ting determines whether the lights remain on for 15 seconds after the last keystroke or an incoming call alert (On) or remain permanently off (Off).
  • Page 112 Chapter 13 - Phone interface Call waiting (Menu 4 12) Call waiting is a network service. Contact your operator for subscription. See Chapter 4 "Tele- phone: Telephone settings - Voice call forward, call restrictions and call waiting" on page 4-2. Choose Activate to set call waiting on, Cancel to set call waiting off or Status to show the types of calls with which call waiting may be used.
  • Page 113 13-12 Change access codes (Menu 5 6) Within this submenu, you can change the fol- lowing access codes: lock code (Menu 5 6 1), PIN code (Menu 5 6 2), PIN2 code (Menu 5 6 3), Network password (Menu 5 6 4). See Chapter 10 "System: Security"...
  • Page 114 Chapter 13 - Phone interface Call costs (Menu 6 2) This network service allows you to check various call costs. The costs are shown in charging units or units of currency that you have set within Menu 6 4. The call cost is shown for each SIM card separately.
  • Page 115 13-14 The memory selection does not affect the communicator interface applications, which will always use “B” memory. SIM card memory status (Menu 8 2) Within this submenu, you may review the num- ber of empty and full memory locations on the SIM card.

  • Page 116: Help

    Chapter 13 - Phone interface from voice to fax (see Chapter 4 "Telephone: Con- ference call - Alternating calls" on page 4-8). Speech — When you have an alternating call active, this option changes the mode of the call from fax or data to voice.

  • Page 117: Troubleshooting

    +113°F (+45°C). Wait for a while, disconnect the charger, connect it again and retry. If charg- ing still fails, contact your local Nokia retailer. 2. Power comes on, but the phone interface does not work Remove the battery and replace it again (reboot).

  • Page 118: Establishing Communication

    Remember that backed up data can be re- stored in all cases. If these measures do not help, contact your local Nokia retailer. If you get the message INVALID SIM CARD, your SIM cannot be used in the communica- tor.
  • Page 119 Chapter 14 - Troubleshooting Check the status of your call restrictions and call forwarding, see Chapter 4 "Telephone: Telephone settings - Voice call forward, call restrictions and call waiting" on page 4-2. The phone interface is already busy (data or fax being sent or received, the communicator is used as a fax modem).

  • Page 120: Connectivity And Printing

    ATS35=6, which defines the remote modem as a V.32 modem. Common AT commands (based on the ETSI 07.07 standard) supported by the Nokia 9000il Communicator are listed in the file atcomm.txt on the diskette sup- plied with the product. For information on...

  • Page 121: Miscellaneous

    The lock code is included in the communica- tor sales package. If you forget or lose the lock code, contact your Nokia retailer. If you forget or lose a PIN or PUK code, or you have not received such a code, contact your network operator.

  • Page 122: Care And Maintenance

    Chapter 15 - Care and maintenance 15. Care and maintenance Your Nokia 9000il Communicator is a product of superior design and craftsmanship and should be treated with care. The suggestions below will help you to fulfil any warranty obligations and to enjoy this product for many years.
  • Page 123 15-2 5. Upon request from NMPI, the Consumer must provide information to reasonably prove the date of purchase. 6. The Consumer shall bear the cost of shipping the Product to the Customer Service Depart- ment of NMPI. NMPI shall bear the cost of shipping the Product back to the Consumer after the completion of service under this limited warranty.
  • Page 124 Department at Nokia, 6200 Courtney Campbell Causeway, Suite 900, Tampa, FL 33630. Tele- phone (813) 288-3800 or 1-800-456-5553, Fax: (813) 287-6612. 14. The limited warranty period for Nokia Product Corp. supplied attachments and accessories are specifically defined within their own warranty cards and packaging.

  • Page 125: Important Safety Information

    • Operation of any radio transmitting equipment, including the Nokia 9000il Communicator, may interfere with the func- tionality of inadequately protected medical devices. Consult a physician or the manufac- turer of the medical device if you have any questions.

  • Page 126: Emergency Calls

    Using this manual The mobile phone described in this manual is ap- proved for use in GSM1900 digital networks. This manual is used for the Nokia 9000il Com- municator GSM1900 model. A number of features described in this manual are called Network Services. They are special services provided by network operators.

  • Page 127: Index

    Symbols + character 3-3 Access codes 1-2 Alarm calendar 9-3 clock 11-3 Area codes 11-4 Backlight backlight period 10-1 button 2-12 Backup/Restore 10-9 Battery charge indicator 13-2 charging 2-5 Calendar application alarms 9-3 booking 9-5 icons 9-2 memos 9-3 password 9-5 Call records messages 13-8 recent calls 4-5, 13-8...
  • Page 128 Index - ii reply all 7-10 retrieving 7-9 sending 7-7 sending upon request 7-8 settings 7-5 viewing 7-10 writing 7-6 E-mail directory 7-7 Emergency calls 16-2 Fax application cover page 5-2 directory 5-4 forwarding 5-2 receiving 5-5 restrictions 5-2 sending 5-3 viewing 5-5 writing 5-3 zooming 5-5...
  • Page 129 PC connectivity cable connection 10-6 infrared connection 14-4 Phone interface 1-1 display indicators 13-2 keypad functions 13-1 lights 13-10 memory button 13-2 menu button 13-2 PIN code 10-3, 10-4 PIN2 code 10-4 Plus (+) character 3-3 PUK code 10-4 Read-only documents 8-2 Rebooting the communicator 14-1 Reception (call quality) 14-5 Record function 3-4...
  • Page 130 Index - iv Voice mailbox calling 4-4 setting number 4-4, 13-9 Volume phone interface 13-10 speakerphone 4-4 World time 11-4 downloading software 7-15 Hotlist 7-12 Navigation index 7-14 saving information 7-13 settings 7-11 URL addresses 7-12 viewing images 7-15...

Table of Contents
