Page 2
DECLARATION OF CONFORMITY Hereby, NOKIA CORPORATION declares that this RM-166 product is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. A copy of the Declaration of Conformity can be found at http://www.nokia.com/phones/declaration_of_conformity/. 0434 The crossed-out wheeled bin means that within the European Union the product must be taken to separate collection at the product end-of life.
Page 3
This Nokia device complies with Directive 2002/95/EC on the restriction of the use of certain hazardous substances in electrical and electronic equipment. Under no circumstances shall Nokia be responsible for any loss of data or income or any special, incidental, consequential or indirect damages howsoever caused.
F o r y o u r s a f e t y For your safety Read these simple guidelines. Not following them may be dangerous or illegal. Read the complete user guide for further information. SWITCH ON SAFELY Do not switch the phone on when wireless phone use is prohibited or when it may cause interference or danger.
WATER-RESISTANCE Your phone is not water-resistant. Keep it dry. BACK-UP COPIES Remember to make back-up copies or keep a written record of all important information stored in your phone. CONNECTING TO OTHER DEVICES When connecting to any other device, read its user guide for detailed safety instructions.
F o r y o u r s a f e t y configuration may include changes in menu names, menu order, and icons. Contact your service provider for more information. This device supports WAP 2.0 protocols (HTTP and SSL) that run on TCP/IP protocols.
• Push to talk. See “Push to talk,” p. 73. • Presence-enhanced contacts. See “My presence,” p. 45. • Java 2 Platform, Micro Edition (J2ME • Synchronization and file transfer with PC Suite. See “Nokia PC Suite,” p. 91. ■ Access codes...
The service provider may provide a PIN that is needed to save the settings. For more information on availability, contact your network operator, service provider, nearest authorized Nokia dealer, or visit the support area on the Nokia Web site at www.nokia.com/support.
Nokia product. On the Web site, you can get information on the use of Nokia products and services. If you need to contact customer service, check the list of local Nokia contact centers at www.nokia.com/customerservice.
SIM card into the SIM card holder until it snaps into position (3). Insert the battery (4). Observe the battery contacts. Always use original Nokia batteries. See “Nokia battery authentication guidelines,” p. 92. Align the top of the back cover with the top of the phone (5), and press the bottom of the back cover to lock it (6).
■ Charge the battery Warning: Use only batteries, chargers, and enhancements approved by Nokia for use with this particular model. The use of any other types may invalidate any approval or warranty, and may be dangerous. Check the model number of any charger before use with this device. This device is intended for use when supplied with power from an AC-3, AC-4, and DC-4 charger, and from an LCH-9 charger when used with the CA-44 charger adapter.
G e t s t a r t e d ■ Switch the phone on and off Warning: Do not switch the phone on when wireless phone use is prohibited or when it may cause interference or danger. To switch the phone on, press and hold the power key. If the phone asks for a PIN or a UPIN code, enter the code (displayed as ****), and select OK.
G e t s t a r t e d ■ Wrist strap To attach a wrist strap to the bottom of the phone, open the back cover. Thread the lace around the hook (1) as shown in the picture. Hold the lace in its position and close the back cover (2).
Y o u r p h o n e 2. Your phone ■ Keys and parts • Power key (1) • Earpiece (2) • Loudspeaker (3) • Display (4) • Volume up and push to talk (PTT) key (5) • Volume down and voice command key (6) •...
■ Standby mode When the phone is ready for use, and you have not entered any characters, the phone is in the standby mode. 1 Name of the network or operator logo 2 Signal strength of the cellular network 3 Battery charge level 4 Left selection key (Go to) 5 Middle selection key (Menu) 6 Right selection key (Names)
Y o u r p h o n e Power saving A digital clock view overwrites the display when no function of the phone has been used for a certain period of time. To activate the power saver, see Power saver in “Display,” p. 52. To deactivate the screen saver, press any key.
Y o u r p h o n e ■ Keypad lock (keyguard) To prevent the keys from being accidentally pressed, select Menu, and press * within 3.5 seconds to lock the keypad. To unlock the keypad, select Unlock, and press * within 1.5 seconds. If the Security keyguard is set On, enter the security code if requested.
C a l l f u n c t i o n s 3. Call functions ■ Make a call 1. Enter the phone number, including the area code. For international calls, press * twice for the international prefix (the + character replaces the international access code), then enter the country code, the area code without the leading 0, if necessary, and the phone number.
Tip: If the Divert if busy function is activated to divert the calls (for example, to your voice mailbox), rejecting an incoming call also diverts the call. See “Call,” p. 54. If a compatible headset with a headset key is connected to the phone, to answer and end a call, press the headset key.
W r i t e t e x t 4. Write text You can enter text (for example, when writing messages) using traditional or predictive text input. When using traditional text input, press a number key, 1 to 9, repeatedly until the desired character appears.
If ? is displayed after the word, the word you intended to write is not in the dictionary. To add the word to the dictionary, select Spell. Enter the word (traditional text input is used), and select Save. To enter a full stop, press 1. 3.
N a v i g a t e t h e m e n u s 5. Navigate the menus The phone offers you an extensive range of functions, which are grouped into menus. 1. To access the menu, select Menu. To change the menu view, select Options >...
6. Messages The message services can only be used if they are supported by your network or your service provider. Note: When sending messages, your phone may display Message sent. This is an indication that the message has been sent by your device to the message center number programmed into your device.
Page 26
M e s s a g e s Write and send an SMS message 1. Select Menu > Messaging > Create message > Text message. 2. Enter a message. See “Write text,” p. 22. At the top of the display, the message length indicator tracks the number of available characters.
replying to an e-mail, first confirm or edit the e-mail address and subject. 4. To send the message to the displayed number, select Send > OK. Templates Your phone has text templates can use in text, picture, or SMS e-mail messages. To access the template list, select Menu >...
Page 28
M e s s a g e s New sound clip — to make a new recording to be added to the message Business card or Calendar note — to insert a business card or a calendar note in the message Slide —...
Read and reply to an MMS message Important: Exercise caution when opening messages. Multimedia message objects may contain malicious software or otherwise be harmful to your device or PC. When your phone receives a multimedia message, the animated displayed. When the message has been received, Multimedia message received are shown.
M e s s a g e s ■ Folders The phone saves received text and multimedia messages in the Inbox folder. Multimedia messages that have not yet been sent are moved to the Outbox folder. If you have selected Message settings > Text messages > Save sent messages >...
To save the message, select Save and the folder in which you want to save the message. ■ Nokia Xpress audio messaging With this menu, use the multimedia message service to create and send a voice message in a convenient way. Multimedia messaging service...
M e s s a g e s Create and send an audio message 1. Select Menu > Messaging > Create message > Audio message. The recorder opens. To use the recorder, see “Recorder,” p. 64. 2. When the message is ready to send, select Options > Play to check the message before sending, Replace sound clip to repeat the recording, Save message (to Saved items), Save sound clip to save the recording in Gallery, Edit subject to insert a subject to the message,...
Depending on the network, the active instant messaging conversation may consume the phone battery faster, and you may need to connect the phone to a charger. Access the IM menu To access the menu while still offline, select Menu > Messaging > Instant messages.
M e s s a g e s The icons and texts on the display may vary, depending on the instant messaging service. • Select IM contacts to view the contacts that you have added. Scroll to the contact with whom you would like to chat, and select Chat or Open if a new contact is shown in the list.
Read a received instant message In the standby mode, when you are connected to the instant messaging service, and you receive a new message that is not a message associated with an active conversation, New instant message is displayed. To read it, select Read.
M e s s a g e s Contacts for IM To add contacts to the instant messaging contacts list, connect to the instant messaging service, and select IM contacts. To add a contact to the list, select Options > Add contact, or if you have no contacts added, select Add.
To search for a group, select Groups > Public groups > Search groups. You can search for a group by a member in the group, group name, topic, or ID. Private groups Connect to the instant messaging service, and select Groups > Create group.
M e s s a g e s Download e-mail 1. To access the e-mail application, select Menu > Messaging > E-mail. 2. To download e-mail messages that have been sent to your e-mail account, select Retrieve. To download new e-mail messages and to send e-mail that has been saved in the Outbox folder, select Options >...
M e s s a g e s Delete e-mail messages Select Menu > Messaging > E-mail > Options > Manage folder and the desired folder. Mark the messages that you want to delete. To delete them, select Options > Delete. Deleting an e-mail from your phone does not delete it from the e-mail server.
M e s s a g e s ■ Message settings Text and SMS e-mail The message settings affect the sending, receiving, and viewing of messages. Select Menu > Messaging > Message settings > Text messages and from the following options: Sending profile —...
Page 41
M e s s a g e s Incoming multimedia messages > Retrieve, Retrieve manually, or Reject — to allow the reception of multimedia messages automatically, manually after being prompted, or to reject the reception Configuration settings > Configuration — Only the configurations that support multimedia messaging are shown.
M e s s a g e s Display terminal window — Select Yes to perform manual user authentication for intranet connections. Incoming server type — Select POP3 or IMAP4, depending on the type of e-mail system that you use. If both types are supported, select IMAP4. Incoming mail settings —...
7. Contacts You can save names and phone numbers (Contacts) in the phone memory and in the SIM card memory. The phone memory may save contacts with numbers and text items. You can also save an image for a certain number of names. Names and numbers saved in the SIM card memory are indicated by ■...
C o n t a c t s To search for an ID from the server of your service provider if you have connected to the presence service, select User ID > Search. See “My presence,” p. 45. If only one ID is found, it is automatically saved.
C o n t a c t s To delete a number, text item, or an image attached to the contact, search for the contact, and select Details. Scroll to the desired detail, and select Options > Delete > Delete number, Delete detail, or Delete image.
C o n t a c t s Select Menu > Contacts > My presence and from the following options: Connect to 'My presence' service or Disconnect from service — to connect to or disconnect from the service View my presence — to view the status in Private pres. and Public presence Edit my presence —...
The status information of the first contact on the subscribed names list is displayed. The information that the person wants to give to the others may include text and some of the following icons: , or indicates that the person is available, not visible to others, or not available.
C o n t a c t s ■ Voice dialing You can make a phone call by saying a voice tag that has been added to a phone number. Any spoken words, such as a name, can be a voice tag. The number of voice tags you can create is limited.
Make a call with a voice tag If the phone has an application running that is sending or receiving data using a packet data connection, you must end the application before voice dialing. 1. In the standby mode, press and hold the volume down key. A short tone is heard, and Speak now is displayed.
L o g 8. Log The phone registers the phone numbers of identified missed, received, and dialed calls; and the approximate length of your calls. Select Menu > Log. The phone registers if it is switched on and within the network service area, and the network supports these functions.
S e t t i n g s 9. Settings ■ Profiles Your phone has various setting groups, called profiles, for which you can customize the phone tones for different events and environments. Select Menu > Settings > Profiles. Scroll to a profile, and select it. To activate the selected profile, select Activate.
S e t t i n g s Warning tones. You can find the same settings in the Profiles menu. See “Profiles,” p. 51. If you select the highest ringing tone level, the ringing tone reaches its highest level after a few seconds. To set the phone to ring only for calls from phone numbers that belong to a selected caller group, select Alert for.
S e t t i n g s Select wallpaper to select an image from the Gallery or Select slide set and a folder in the Gallery to use the images in the folder as a slide set. To download more images for wallpaper, select Graphic downloads. Screen saver >...
S e t t i n g s ■ Call Select Menu > Settings > Call and from the following options: Automatic volume control — to set the phone to automatically adjust the output volume according to the background noise Call divert (network service) —...
S e t t i n g s Security keyguard — to set the phone to ask for the security code when you unlock the keyguard. Enter the security code, and select On. When the keyguard is on, calls still may be possible to the official emergency number programmed into your device.
Page 56
S e t t i n g s To activate the IR port of your phone to receive data using IR, select Menu > Settings > Connectivity > Infrared. To deactivate the IR connection, select Menu > Settings > Connectivity > Infrared. When the phone displays Deactivate infrared?, select Yes.
You can also set the dial-up service settings (access point name) on your PC using the Nokia Modem Options software. See “Nokia PC Suite,” p. 91. If you have set the settings both on the PC and on your phone, the PC settings are used.
S e t t i n g s ■ Configuration You can configure your phone with settings that are required for certain services to function correctly. The services are browser, multimedia messaging, remote Internet server synchronization, presence, and e-mail application. Get the settings from your SIM card, from a service provider as a configuration message, or enter your personal settings manually.
S e t t i n g s ■ Security When security features that restrict calls are in use (such as call barring, closed user group and fixed dialing) calls still may be possible to the official emergency number programmed into your device. Select Menu >...
O p e r a t o r m e n u 10. Operator menu This menu lets you access a portal to services provided by your network operator. The name and the icon depend on the operator. For more information, contact your network operator.
G a l l e r y 11. Gallery In this menu you can manage graphics, images, recordings, video clips, themes, and tones. These files are arranged in folders. Your phone supports an activation key system to protect acquired content. Always check the delivery terms of any content and activation key before acquiring them, as they may be subject to a fee.
M e d i a 12. Media Copyright protections may prevent some images, music (including ringing tones), and other content from being copied, modified, transferred or forwarded. ■ Camera You can take photos or record video clips with the built-in camera. The camera produces pictures in JPEG format and video clips in 3GP format.
Select Menu > Media > Radio. To use the graphical keys on the display, scroll left or right to the desired key, and select it. To change the volume, press the volume keys. Save radio stations 1. To start the station search, select and hold the radio frequency in 0.05 MHz steps, briefly press 2.
M e d i a When an application using a packet data or HSCSD connection is sending or receiving data, it may interfere with the radio. ■ Recorder You can record pieces of speech, sound, or an active call for up to 5 minutes.
O r g a n i z e r 13. Organizer ■ Alarm clock You can set the phone to alarm at a desired time. Select Menu > Organiser > Alarm clock. To set the alarm, select Alarm time, and enter the alarm time. To change the alarm time when the alarm time is set, select On.
O r g a n i z e r week, select Options > Week view. To delete all notes in the calendar, select the month or week view, and select Options > Delete all notes. Other options for the day view may be Make a note, Delete, Edit, Move, or Repeat a note;...
■ Notes To use this application for writing and sending notes, select Menu > Organiser > Notes. To create a note if no note is added, select Add note; otherwise, select Options > Make a note. Write a note, and select Save. Other options for notes include deleting and editing a note.
Synchronize from a compatible PC To synchronize Contacts, Calendar, and Notes from a compatible PC, use an IR or data cable connection. You also need Nokia PC Suite software of your phone installed on the PC. Start the synchronization from the PC using Nokia PC Suite.
O r g a n i z e r point. Select Options > Add, Subtract, Multiply, Divide, Square, Square root, or Change sign. Enter the second number, if needed. For a total, select Equals. Repeat this sequence as many times as it is necessary. To start a new calculation, select and hold Clear.
O r g a n i z e r ■ Countdown timer Select Menu > Organiser > Timer. Enter the alarm time in hours, minutes, and seconds, and select OK. If you wish, write your own note text that is displayed when the time expires. To start the countdown timer, select Start.
Menu > Applications > Options > App. settings. ■ Collection Your phone software includes some Java applications specially designed for this Nokia phone. To launch an application, select Menu > Applications > Collection. Scroll to an application, and select Open.
Your device may have some bookmarks loaded for sites not affiliated with Nokia. Nokia does not warrant or endorse these sites. If you choose to access them, you should take the same precautions, for security or content, as you would with any Internet site.
P u s h t o t a l k 15. Push to talk Push to talk (PTT) over cellular is a two-way radio service available over a GSM/GPRS cellular network (network service). PTT provides direct voice communication. To connect, press and hold the volume up (PTT) key.
P u s h t o t a l k To set the PTT settings for use, select PTT settings. To set the required settings for the PTT connection, select Config. settings. To open the browser and to connect to the PTT network portal provided by the service provider, select Web.
P u s h t o t a l k The icon behind the contact in the list denotes current login status: , or indicate that the person is available, unavailable, or unknown; indicates that the login status is not available. The login status is only available for subscribed contacts.
P u s h t o t a l k To start a one-to-one call from the list of PTT channels, select Channel list, and scroll to the desired channel. Select Options > Active members, scroll to the desired contact, and press and hold the volume up (PTT) key. To start a one-to-one call from the list of callback requests you have received, select Callback inbox.
Send a callback request You can send a callback request in the following ways: • To send a callback request from the contacts list in the Push to talk menu, select Contacts list. Scroll to a contact, and select Options > Send callback.
P u s h t o t a l k ■ Add a one-to-one contact You can save the names of persons to whom you often make one-to-one calls in the following ways: • To add a PTT address to a name in Contacts, search for the desired contact, and select Options >...
Add a channel Select Menu > Push to talk > Add channel. Select from the following options: Guided — to add a new channel. To set the security level for the channel, select Public channel or Private channel. If you select Private channel, the phone automatically creates a scrambled part to the channel address that the members cannot view when they receive the invitation to the channel.
P u s h t o t a l k ■ PTT settings There are two kinds of PTT settings: settings for connecting to the service and settings for use. You may receive the settings for connecting to the service from your service provider.
16. Web You can access various mobile Internet services with your phone browser (network service). Important: Use only services that you trust and that offer adequate security and protection against harmful software. Check the availability of these services, pricing, tariffs, and instructions with your service provider.
To enter letters and numbers, press the keys, 0 to 9. To enter special characters, press *. Options while browsing Nokia.com, Home, Add bookmark, Bookmarks, Page options, History, Downloads, Other options, Reload, and Quit may be available. The service provider may also offer other options.
W e b empty the cache after each use. The information or services you have accessed is stored in the cache. To empty the cache, see “Cache memory,” p. 86. Direct calling The browser supports functions that you can access while browsing. You can make a phone call, and save a name and a phone number from a page.
Your device may have some bookmarks loaded for sites not affiliated with Nokia. Nokia does not warrant or endorse these sites. If you choose to access them, you should take the same precautions, for security or content, as you would with any Internet site.
Save. To view or delete the bookmark, select Options > View or Delete. To discard the bookmark directly after you have received the bookmark, select Exit > OK. ■ Download files To download more tones, images, games, or applications to your phone (network service), select Menu >...
W e b Service inbox settings Select Menu > Web > Settings > Service inbox settings. To set whether you want to receive service messages, select Service messages > On or Off. To set the phone to receive service messages only from content authors approved by the service provider, select Message filter >...
Page 87
Select Menu > Web > Settings > Security settings > Security module settings and from the following options: Security module details — to show the security module title, status, manufacturer, and serial number Module PIN request — to set the phone to ask for the module PIN when using services provided by the security module.
W e b The security indicator is displayed during a connection, if the data transmission between the phone and the content server is encrypted. The security icon does not indicate that the data transmission between the gateway and the content server (or place where the requested resource is stored) is secure.
Page 89
W e b service provider. The phone displays 1 missed position request. To view the missed location request, select Show. To view the information on the 10 most recent privacy notifications and requests or to delete them, select Menu > Web > Positioning > Position log >...
S I M s e r v i c e s 17. SIM services Your SIM card may provide additional services that you can access. This menu is shown only if it is supported by your SIM card. The name and contents of the menu depend on the SIM card.
With Nokia PC Suite you can synchronize Contacts, Calendar, To-do list, and Notes between your phone and the compatible PC. You may find more information about Nokia PC Suite, for example downloadable files, in the support area on the Nokia Web site at www.nokia.com/support. ■ Packet data, HSCSD, and CSD With your phone you can use packet data, high-speed circuit switched data (HSCSD), and circuit switched data (CSD, GSM data).
Do not dispose as household waste. ■ Nokia battery authentication guidelines Always use original Nokia batteries for your safety. To check that you are getting an original Nokia battery, purchase it from an authorized Nokia dealer, look for...
Page 93
If you have any reason to believe that your battery is not an authentic original Nokia battery, you should refrain from using it and take it to the nearest authorized Nokia service point or dealer for assistance. Your authorized Nokia service point or dealer will inspect the battery for authenticity.
Page 94
B a t t e r y i n f o r m a t i o n What if your battery is not authentic? If you cannot confirm that your Nokia battery with the hologram on the label is an authentic Nokia battery, please do not use the battery. Take it to the nearest authorized Nokia service point or dealer for assistance.
Care and maintenance Your device is a product of superior design and craftsmanship and should be treated with care. The suggestions below will help you protect your warranty coverage. • Keep the device dry. Precipitation, humidity, and all types of liquids or moisture can contain minerals that will corrode electronic circuits.
A d d i t i o n a l s a f e t y i n f o r m a t i o n Additional safety information Your device and its enhancements may contain small parts. Keep them out of the reach of small children.
• Always keep the device more than 15.3 centimeters (6 inches) from the pacemaker • Not carry the device in a breast pocket • Hold the device to the ear opposite the pacemaker to minimize the potential for interference. If you suspect interference, switch off your device, and move the device away. Hearing aids Some digital wireless devices may interfere with some hearing aids.
A d d i t i o n a l s a f e t y i n f o r m a t i o n depots, storage, and distribution areas; chemical plants; or where blasting operations are in progress. Areas with a potentially explosive atmosphere are often, but not always, clearly marked.
Page 99
0.84 W/kg. Use of device accessories and enhancements may result in different SAR values. SAR values may vary depending on national reporting and testing requirements and the network band. Additional SAR information may be provided under product information at www.nokia.com.
