MITSUBISHI
ELECTRIC
INVERTER
FR-E700
INSTALLATION GUIDELINE
FR-E740-016 to 300-EC
Thank you for choosing this Mitsubishi Inverter.
Please read through this Instruction Manual and the enclosed CD ROM to operate this inverter correctly
- The enclosed CD ROM contains the Installation Guideline in additional languages.
- Die CD-ROM enthält die deutsche Installationsbeschreibung.
- Il CD-ROM incluso contiene la guida di riferimento dell'installazione in lingua italiana.
- Le CD-ROM ci-joint contient cette documentation en français.
- El CD-ROM incluido contiene la pauta de la instalación en lengua española.
-
Приложенный CD-ROM содержит инструкцию по инсталяции на дополнительных языках.
Do not use this product until you have a full knowledge of the equipment, the safety information and the
instructions.
Please forward this manual and the CD ROM to the end user.
INSTALLATION OF THE INVERTER AND INSTRUCTIONS ...................................1
1
OUTLINE DIMENSION DRAWING ............................................................................3
2
WIRING ......................................................................................................................4
3
PRECAUTIONS FOR USE OF THE INVERTER .......................................................9
4
FAILSAFE OF THE SYSTEM WHICH USES THE INVERTER ...............................11
5
PARAMETER ...........................................................................................................12
6
TROUBLESHOOTING .............................................................................................17
7
CONTENTS
700

Advertisement

Table of Contents
loading

Related Manuals for Mitsubishi Electric FR-E700

Summary of Contents for Mitsubishi Electric FR-E700

  • Page 1: Table Of Contents

    MITSUBISHI ELECTRIC INVERTER FR-E700 INSTALLATION GUIDELINE FR-E740-016 to 300-EC Thank you for choosing this Mitsubishi Inverter. Please read through this Instruction Manual and the enclosed CD ROM to operate this inverter correctly – The enclosed CD ROM contains the Installation Guideline in additional languages.
  • Page 2 Print Date Manual Number Revision 01/2008 pdp-gb 209035 First edition For Maximum Safety Mitsubishi transistorized inverters are not designed or manufactured to be used in equipment or systems in situations that can affect or endanger human life. When considering this product for operation in special applications such as machinery or systems used in passenger transportation, medical, aerospace, atomic power, electric power, or submarine repeating applications, please contact your nearest Mitsubishi sales representative.
  • Page 3 This section is specifically about safety matters Do not attempt to install, operate, maintain or inspect the inverter until you have read through this Installation Guideline and appended documents carefully and can use the equipment correctly. Do not use the inverter until you have a full knowledge of the equipment, safety information and instructions.
  • Page 4 Wiring CAUTION Do not install assemblies or components (e. g. power factor correction capacitors) on the inverter output side, which are not approved from Mitsubishi. The direction of rotation of the motor corresponds to the direction of rotation commands (STF/STR) only if the phase sequence (U, V, W) is maintained Test operation and adjustment CAUTION...

  • Page 5: Installation Of The Inverter And Instructions

    1 INSTALLATION OF THE INVERTER AND INSTRUCTIONS Unpack the inverter and check the capacity plate on the front cover and the rating plate on the inverter side face to ensure that the product agrees with your order and the inverter is intact. 1.1 Inverter Type Symbol Voltage Class...
  • Page 6 INSTALLATION OF THE INVERTER AND INSTRUCTIONS 1.3 General Precaution The bus capacitor discharge time is 10 minutes. Before starting wiring or inspection, switch power off, wait for more than 10 minutes, and check for residual voltage between terminal P/+ and N/ with a meter etc., to avoid a hazard of electrical −...

  • Page 7: Outline Dimension Drawing

    2 OUTLINE DIMENSION DRAWING When used with plug-in option When the FR-A7NC is mounted, a terminal block protrudes making the depth approx 2mm greater. (Unit: mm) Inverter Type FR-E740-016 129.1 FR-E740-026 FR-E740-040 FR-E740-060 150.1 FR-E740-095 FR-E740-120 162.1 FR-E740-170 FR-E740-230 205.1 FR-E740-300...

  • Page 8: Wiring

    3 WIRING 3.1 Terminal connection diagram Source logic Brake unit (Option) Main circuit terminal Control circuit terminal *6 Brake resistor (FR-ABR, MRS, MYS) Install a thermal relay to prevent an overheat *1. DC reactor (FR-HEL) and burnout of the brake resistor. Earth When connecting a DC reactor, remove the jumper across P1-P/+.

  • Page 9: Main Circuit Terminal Specifications

    WIRING 3.2 Main circuit terminal specifications 3.2.1 Terminal arrangement of the main circuit terminal, power supply and the motor wiring FR-E740-016 to 095 FR-E740-120, 170 Jumper Jumper Screw size (M4) Screw size (M4) Screw size (M4) L1L2L3 Screw size Motor Power supply L1L2L3 (M4)
  • Page 10 WIRING 3.3 Cables and wiring lenght 3.3.1 Cable size Select the recommended cable size to ensure that a voltage drop will be 2% max. If the wiring distance is long between the inverter and motor, a main circuit cable voltage drop will cause the motor torque to decrease especially at the output of a low frequency.
  • Page 11 WIRING 3.3.2 Maximum permissible motor wiring length The maximum permissible length of the motor cables depends on the capacity of the inverter and the selected carrier frequency. The lengths in the following table are for unshielded cables. When shielded cables are used divide the values listed in the table by 2.
  • Page 12 WIRING 3.4 Control circuit specification 3.4.1 Standard control circuit terminal layout Terminal screw size M3: (Terminal A, B, C) M2: (Other than the above) 3.4.2 Wiring method Strip off the sheath of the cable of the control circuit to wire. Strip off the sheath about the size below.

  • Page 13: Precautions For Use Of The Inverter

    4 PRECAUTIONS FOR USE OF THE INVERTER The FR-E700 series is a highly reliable product, but incorrect peripheral circuit making or operation/handling method may shorten the product life or damage the product. Before starting operation, always recheck the following items.
  • Page 14 PRECAUTIONS FOR USE OF THE INVERTER Do not apply a voltage higher than the permissible voltage to the inverter I/O signal circuits. Application of a voltage higher than the permissible voltage to the inverter I/O signal circuits or opposite polarity may damage the I/O devices.

  • Page 15: Failsafe Of The System Which Uses The Inverter

    5 FAILSAFE OF THE SYSTEM WHICH USES THE INVERTER When a fault occurs, the inverter trips to output a fault signal. However, a fault output signal may not be output at an inverter fault occurrence when the detection circuit or output circuit fails, etc. Although Mitsubishi assures best quality products, provide an interlock which uses inverter status output signals to prevent accidents such as damage to machine when the inverter fails for some reason and at the same time consider the system configuration where failsafe from outside the inverter, without using the inverter, is enabled even if the inverter fails.

  • Page 16: Parameter

    6 PARAMETER For simple variable-speed operation of the inverter, the initial setting of the parameters may be used as they are. Set the necessary parameters to meet the load and operational specifications. Parameter setting, change and check can be made from the operation panel.
  • Page 17 PARAMETER Parameters Name Setting Range Initial Value Parameters Name Setting Range Initial Value Output frequency Reset selection/ 0 to 400Hz, 9999 detection for reverse disconnected PU 9999 0 to 3, 14 to 17 rotation detection/PU stop selection 5s/10s/ Second acceleration/ 0 to 3600/360s 15s * deceleration time...
  • Page 18 PARAMETER Parameters Name Setting Range Initial Value Parameters Name Setting Range Initial Value Terminal 2 frequency User group 0 to 999, 9999 9999 0 to 400Hz 50Hz setting gain registration frequency 0 to 999, 9999 9999 User group clear Terminal 4 frequency 0 to 5, 7, 8, 10, 0 to 400Hz 50Hz...
  • Page 19 PARAMETER Parameters Name Setting Range Initial Value Parameters Name Setting Range Initial Value Inrush current Communication (0 to 100%) 100% 0, 1, 10 suppression circuit startup mode life display selection Control circuit Communication (0 to 100%) 100% 0, 1 capacitor life display EEPROM write selection Main circuit...
  • Page 20 PARAMETER Parameters Name Setting Range Initial Value Parameters Name Setting Range Initial Value Regeneration Terminal 4 frequency 300 to 800V 760VDC 0 to 400Hz avoidance operation setting bias (904) level frequency Regeneration Terminal 4 frequency 0 to 300% 0 to 10Hz, avoidance setting bias (904)

  • Page 21: Troubleshooting

    7 TROUBLESHOOTING When an fault occurs in the inverter, the protective function is activated bringing the inverter to an alarm stop and the PU display automatically changes to any of the following fault (alarm) indications. If your fault does not correspond to any of the following faults or if you have any other problem, please contact your sales representative.

  • Page 22: List Of Alarm Display

    TROUBLESHOOTING 7.2 List of alarm display Operation Panel Indication Meaning Operation Panel Indication Meaning E - - - Faults history E.ILF* Input phase loss HOLD Operation panel lock E.OLT Stall prevention E.BE Brake transistor alarm detection Er1 to 4 Parameter write error Output side earth (ground) fault E.GF overcurrent protection...
  • Page 23 A APPENDIX A.1 Instructions for Compliance with the European Directives A.1.1 EMC Directive Our view of transistorized inverters for the EMC Directive A transistorized inverter is a component designed for installation in an enclosure and for use with the other equipment to control the equipment/device.

  • Page 24: Fr-E740

    APPENDIX To use the inverter (IP20) outside of an enclosure in the enviroment of pollution degree 2, fix a fan cover with the fan cover fixing srews enclosed. FR-E740-095 or less FR-E740-120 or more Fan cover fixing Fan cover fixing screws screws Fan cover...
  • Page 25 APPENDIX A.2 Instructions for UL and cUL (UL 508C, CSA C22.2 No.14) A.2.1 General precaution The bus capacitor discharge time is 10 minutes. Before starting wiring or inspection, switch power off, wait for more than 10 minutes, and check for residual voltage between terminal P/+ and N/− with a meter etc., to avoid a hazard of electrical shock. A.2.2 Installation The below types of inverter have been approved as products for use in enclosure and approval tests were conducted under the following conditions.
  • Page 26 APPENDIX A.2.5 Motor overload protection When using the electronic thermal relay as motor overload protection, set the rated motor current to Pr.9 Electronic thermal O/L relay. Electronic thermal relay function characteristic This function detects the overload (overheat) of the Pr. 9 = 100% setting of Pr.
  • Page 27 The copyright and other rights of this enclosed CD ROM all belong to Mitsubishi Electric Corporation. No part of this CD ROM may be copied or reproduced without the permission of Mitsubishi Electric Corporation. Specifications of this CD ROM are subject to change without notice.
  • Page 28 Fax: +380 (0)44 / 494-33-66 MITSUBISHI ELECTRIC Mitsubishi Electric Europe B.V. /// FA - European Business Group /// Gothaer Straße 8 /// D-40880 Ratingen /// Germany Tel.: +49(0)2102-4860 /// Fax: +49(0)2102-4861120 /// info@mitsubishi-automation.com /// www.mitsubishi-automation.com FACTORY AUTOMATION Specifications subject to change /// Art. no. 209035-A /// 01.2008...
