Summary of Contents for Teac DAB400
-
Page 2: Warranty Registration
The warranty does not cover freight or insurance. In all cases of transit damage or lost, a claim must be filed against the carrier by the purchaser, even if shipment is arranged by TEAC. TEAC in- home service may also be available at a fee upon request. - Page 3 10. No one is authorised to assume any liability on behalf of TEAC or impose any obligation on it, in connection with the sale of any equipment other than as stated in this warranty and outlined above.
- Page 4 Dealer’s Address Postcode Please ensure that your product is packed appropriately upon return to the service centre. If you have any other queries regarding service or warranty please contact the TEAC Customer Care Centre below: service@teac.com.au www.teac.com.au 1800 656 700...
-
Page 5: Safety Precautions
Safety Precautions To achieve the utmost in enjoyment and performance, and in order to become familiar with its features, please read this manual carefully before attempting to operate the unit. This will assure you years of faithful, trouble free performance and listening pleasure. Important Notes •... -
Page 6: Safety Information
Safety Information Some Do’s And Don’ts On the Safe Use Of Equipment This equipment has been designed and manufactured to meet international safety standards but, like any electrical equipment, care must be taken if you are to obtain the best results and safety is to be assured. -
Page 7: Table Of Contents
Contents Package Content Controls Overview (a) ....................2 Controls Overview (b) ....................3 Getting Started DAB+, DAB mode Scanning DAB+, DAB stations ..................5 How to Show Signal Strength ..................6 How to Browse Station Information ................7 DAB Menu Options ....................... 8 How to Shift to Other Program .................. -
Page 8: Package Content
Package Content Digital Radio DC Adapter Instruction manual... -
Page 9: Controls Overview (A)
Controls Overview (a) DIGITAL RADIO BACK VIEW Note: While operating via batteries only, alarm will not function if unit is in standby mode. Note: The 3.5mm headphone jack is provided to use with either headphones or an earpiece. Inserting a plug automatically mutes the internal loudspeaker. DIGITAL RADIO TOP VIEW... -
Page 10: Controls Overview (B)
Controls Overview (b) DIGITAL RADIO TOP VIEW Control DAB +, DAB and FM MODE Press and hold one of the Preset buttons to store preset to 1-5, Preset 1-10 Press one of the Preset buttons to loading. (for detail, please refer page16 ) ON/OFF Press to on/off the digital radio When alarm is sound, press to turn it off. -
Page 11: Getting Started
Getting Started • Battery Operation (Batteries Not Included) Note: Before installing batteries, ensure that the radio is disconnected from the mains supply. Never mix old and new batteries. 1. Remove the battery compartment cover at the back of the radio, refer below picture 2. -
Page 12: Dab+, Dab Mode
DAB+, DAB mode Scanning DAB+, DAB stations 1. Extend the antenna on the rear of radio, press the ON/OFF button to switch it on. For initial use, it will automatically run a full scan and save the stations in its memory. The tuning process may require a few minutes. -
Page 13: How To Show Signal Strength
How to Show Signal Strength 1. Signal Strength Display will only function in DAB. Please switch to DAB mode by pressing the DAB/FM button 2. Press the DISPLAY button repeatedly until a signal bar shows up. The signal bar indicates the signal strength, and the indicator on the signal bar shows the minimum acceptable signal level. -
Page 14: How To Browse Station Information
How to Browse Station Information To view station information, just need simply press the DISPLAY button repeatedly, and this is a circularly switched order. Signal Strength: Show a signal bar with the strength of the current station. Program Type (PTY): This is a description of the type of program provided by the DAB station or by broadcaster. -
Page 15: Dab Menu Options
DAB Menu Options... -
Page 16: How To Shift To Other Program
How to Shift to Other Program 1. Press the MENU button. 2. While cursor point to ‘Station list’, press the SELECT button to confirm. 3. Press the BACK or NEXT button to the program you preferred, press the SELECT button to confirm. How to Find and Add New Stations 1. -
Page 17: Manual Tune
Manual Tune It allows you to manually tune in the DAB station. 1. Press the MENU button, and then press the BACK or NEXT button until Manual tune is display on the unit. 2. Press the SELECT button to confirm , display will show the channel number and frequency as follow: Press the BACK or NEXT button to cycle through channels and press the SELECT button to access to current channel. -
Page 18: To Change Station Order
To change station order 1. Press the MENU button, and then press the BACK or NEXT button to this option. 2. Press the SELECT button to confirm. 3. Press the BACK or NEXT button to cycle through station order options. Note: there are Alphanumeric, Ensemble and Valid available. -
Page 19: Fm Mode
FM Mode Prime Operation 1. To listen to FM radio stations switch radio on and press the DAB/FM button to switch to FM Mode. Once in FM mode, it will start at the beginning of the FM frequency range (87.50MHz) or it will play the last FM station you were listening to. -
Page 20: Fm Menu Options
FM Menu Options... -
Page 21: Displaying Fm Station Information
Displaying FM Station Information To view station information, need simply press the DISPLAY button repeatedly, and this is a circularly switched order. Program Type: This is a description of the type of program provided by the FM station and it is provided by the broadcaster. Station name: This displays the transmission station name of current listening to. -
Page 22: Scan Setting
Scan Setting 1. Press the MENU button, and then press the BACK or NEXT button to ‘Scan Setting’. 2. Press the SELECT button to confirm. Note: you can choose between Strong stations only and All Stations, a. if you choose Strong Stations only, it will show only the stations with strong signal strength. b. -
Page 23: Common Operation
Common Operation Setting Station Presets Your radio can store 10 DAB+ & 10 FM station presets. To store presets 1-5: 1. While playing your favourite station, press and hold one of the PRESET buttons, and it will say: “Preset # stored”. To store presets 6-10: While playing your favourite station, press the SHIFT button, and then press and hold one of the PRESET buttons, and it will say: “Preset # stored”. -
Page 24: System Setup
System setup Enter system setup 1. Press the MENU button, then press the BACK or NEXT button to < System >, press the SELECT button to confirm. 2. Press the BACK or NEXT button to cycle through options, in which you can find ‘Sleep’, ‘Alarm’, ‘Time’, ‘Backlight’, ‘Factory Reset’, ‘SW version’... -
Page 25: Set Time
Set Time • Manually set time 1. It can be activated from < System > à < Time >, and then press the SELECT button to confirm. Note: Press the BACK or NEXT button to switch between <Set 12/24 hour format>, <Set Time/date>, <Auto update>, and <Set date format>. -
Page 26: Setting Alarm
Setting Alarm Note: a. Please set the time before setting the alarm. b. While operating via batteries only, alarm will not function if unit is in standby mode. It can be activate from < System > à< Alarm >, press the SELECT button to confirm. 2. - Page 27 8. Press the BACK or NEXT button to adjust the alarm volume level, press the SELECT button to confirm . In standby mode, the Alarm icon ( ) will shown on-screen. • To cancel Alarm temporarily and snooze operation When alarm is ringing, press ON/OFF to switch off alarm. You may press the SELECT button repeatedly to postpone it, by which the interval time is 5, 10, 15, 30 minutes in turn.
-
Page 28: Set Backlight
Set Backlight Setting for ‘On level’ ------------- (for power on condition) It can be activated from < System > à < Backlight >, press the SELECT button to confirm. 2. While cursor point to ‘On level’, press the SELECT button to confirm. 3. -
Page 29: Specification
Specification ITEMS DESCRIPTION Specifications: FM, DAB and DAB+ Digital Radio DC Adapter: Input: 100-240 VAC, 50-60Hz Power Requirements: Output: 9V/1000mA (FM) 87.5-108MHz FM Frequency Range (DAB, DAB+) 174 – 240MHz Speaker Output Power: 2Wrms x 2 Impedance: 8 ohm Headphone Jack: 32 ohm Dimension: 267 x 123 x 168mm... - Page 30 TEAC CUSTOMER CARE CENTRE (TCCC) Free call: 1800 656 700 Between Monday to Friday – EST 9AM to 5PM...
