Air Conditioning Technical Data Floor standing unit with radiant heat panel EEDEN14-100 FVXG-K... -
Page 3: Table Of Contents
......... . 10 • Split - Sky Air • FVXG-K... -
Page 4: Features
Outdoor unit Vertical auto Auto fan speed Fan speed Dry programmeTitanium apatite Auto-restart Self diagnosis Multi model silent operation swing steps photocatalytic application air purification filter VRV for residential application • Split - Sky Air • FVXG-K... -
Page 5: Specifications
Sound power level Cooling Heating Sound pressure level Cooling High/Nom./Low/ 38/32/26/23 39/33/27/24 44/40/36/32 Silent operation Heating Super high/High/ -/39/32/26/22/19 -/40/33/27/23/19 -/46/40/34/30/26 Nom./Low/Silent operation/Radiant heat Refrigerant Type R-410A Piping connections Liquid 9.50 12.70 Drain • Split - Sky Air • FVXG-K... -
Page 6: Electrical Specifications
(4) SL: The silent fan level of the air flow rate setting (5) When connected to a multi outdoor unit, the sound pressure level in silent operation and radiant heat equals above values + 1dB. • Split - Sky Air • FVXG-K... -
Page 7: Options
• Indoor Unit • FVXG-K Options 3 - 1 Options • Split - Sky Air • FVXG-K... -
Page 8: Dimensional Drawings
• Indoor Unit • FVXG-K Dimensional drawings 4 - 1 Dimensional Drawings • Split - Sky Air • FVXG-K... -
Page 9: Centre Of Gravity
• Indoor Unit • FVXG-K Centre of gravity 5 - 1 Centre of Gravity • Split - Sky Air • FVXG-K... -
Page 10: Piping Diagrams
• Indoor Unit • FVXG-K Piping diagrams 6 - 1 Piping Diagrams • Split - Sky Air • FVXG-K... -
Page 11: Wiring Diagrams
• Indoor Unit • FVXG-K Wiring diagrams 7 - 1 Wiring Diagrams - Single Phase ∼ ∼ ∼ ∼ • Split - Sky Air • FVXG-K... -
Page 12: Sound Data
• Indoor Unit • FVXG-K Sound data 8 - 1 Sound Pressure Spectrum • Split - Sky Air • FVXG-K... - Page 13 • Indoor Unit • FVXG-K Sound data 8 - 1 Sound Pressure Spectrum • Split - Sky Air • FVXG-K...
