Installation Instructions
BMW CD changer installation kit
BMW X5 (E 53)
These installation instructions are only valid for cars with a production date before
10/01
Technical and electrical knowledge required
The installation time is 0.5 - 3.5 hours but this may vary depending on the condition
of the car and the equipment in it.
Retrofit/Installation kit No.
Retrofit / Installation kit No. 65 12 0 029 883 (others see cover sheet)
Installation Instructions No. 01 29 0 029 576
65 12 0 029 883
65 12 0 029 886
65 12 0 140 746
65 12 0 140 747
Issue date: 05.2001
F 53 0751 B
Advertisement
Table of Contents
Related Manuals for BMW 65 12 0 029 883
Summary of Contents for BMW 65 12 0 029 883
- Page 1 65 12 0 029 886 65 12 0 140 746 65 12 0 140 747 Retrofit / Installation kit No. 65 12 0 029 883 (others see cover sheet) Issue date: 05.2001 Installation Instructions No. 01 29 0 029 576...
-
Page 2: Table Of Contents
14. Circuit diagram ........... . Retrofit / Installation kit No. 65 12 0 029 883 (others see cover sheet) Issue date: 05.2001... -
Page 3: Important Information On Installing The Cd Changer In The E53
In cars with an on-board monitor radio the control cable is only installed in the boot. In cars with a BMW Professional hi-fi system DSP amplifier only the coaxial cable for the Professional hi-fi system DSP amplifier/CD change must be installed in the boot. -
Page 4: Preparations
Remove the boot ventilation grille on the left. 51 47 151 Remove the left boot trim 51 47 151 EN/4 Retrofit / Installation kit No. 65 12 0 029 883 (others see cover sheet) Issue date: 05.2002 Installation Instructions No. 01 29 0 029 576... -
Page 5: Parts List
Parts list F 53 0752 B EN/5 Retrofit / Installation kit No. 65 12 0 029 883 (others see cover sheet) Issue date: 05.2002 Installation Instructions No. 01 29 0 029 576... -
Page 6: Connection Diagram
****** Part not required for cars with a Professional radio SA663 with a production date before 03/01 EN/6 Retrofit / Installation kit No. 65 12 0 029 883 (others see cover sheet) Issue date: 05.2002 Installation Instructions No. 01 29 0 029 576... - Page 7 Black 6-pin socket casing To the CD changer in the boot on the left EN/7 Retrofit / Installation kit No. 65 12 0 029 883 (others see cover sheet) Issue date: 05.2002 Installation Instructions No. 01 29 0 029 576...
- Page 8 Silver 10-pin plug casing To silver 10-pin socket casing on the control cable B or EN/8 Retrofit / Installation kit No. 65 12 0 029 883 (others see cover sheet) Issue date: 05.2002 Installation Instructions No. 01 29 0 029 576...
-
Page 9: Installation And Cabling Diagram
Branch E2 to branch B1 or branch C1 EN/9 Retrofit / Installation kit No. 65 12 0 029 883 (others see cover sheet) Issue date: 05.2002 Installation Instructions No. 01 29 0 029 576... -
Page 10: To Install The Audio Module Holder (Only Required In Cars Without An Audio Module Holder)
Place two speed nuts M5 (14) into the hole in the holder for the boot at the rear left (7). F 53 0758 B EN/10 Retrofit / Installation kit No. 65 12 0 029 883 (others see cover sheet) Issue date: 05.2002 Installation Instructions No. 01 29 0 029 576... - Page 11 M5 (14) on to the holder for the boot at the front left (9). F 53 0760 B EN/11 Retrofit / Installation kit No. 65 12 0 029 883 (others see cover sheet) Issue date: 05.2002 Installation Instructions No. 01 29 0 029 576...
-
Page 12: To Install The Cd Changer (Cars Without An On-Board Monitor, Without A Dsp Amplifier And With Professional Radio Sa663 Up To Production Date 03/01 Only)
A, to the installation location of the CD changer. F 53 0764 B EN/12 Retrofit / Installation kit No. 65 12 0 029 883 (others see cover sheet) Issue date: 05.2002 Installation Instructions No. 01 29 0 029 576... - Page 13 H (horizontal installation) and then re-affix both covers (31). F 39 0769 B EN/13 Retrofit / Installation kit No. 65 12 0 029 883 (others see cover sheet) Issue date: 05.2002 Installation Instructions No. 01 29 0 029 576...
- Page 14 M5x14 (13). F 53 0772 B EN/14 Retrofit / Installation kit No. 65 12 0 029 883 (others see cover sheet) Issue date: 05.2002 Installation Instructions No. 01 29 0 029 576...
-
Page 15: To Install The Cd Changer (Cars Without An On-Board Monitor, Without A Dsp Amplifier And With Professional Radio Sa663 After Production Date 04/01 Only)
A, to the installation location of the CD changer. F 53 0764 B EN/15 Retrofit / Installation kit No. 65 12 0 029 883 (others see cover sheet) Issue date: 05.2002 Installation Instructions No. 01 29 0 029 576... - Page 16 X18126 CD changer (1). 053 0135 B EN/16 Retrofit / Installation kit No. 65 12 0 029 883 (others see cover sheet) Issue date: 05.2002 Installation Instructions No. 01 29 0 029 576...
- Page 17 (31) on the CD changer (1). B2/X18729 F 53 0771 B EN/17 Retrofit / Installation kit No. 65 12 0 029 883 (others see cover sheet) Issue date: 05.2002 Installation Instructions No. 01 29 0 029 576...
- Page 18 M5x14 (13). F 53 0772 B EN/18 Retrofit / Installation kit No. 65 12 0 029 883 (others see cover sheet) Issue date: 05.2002 Installation Instructions No. 01 29 0 029 576...
-
Page 19: To Install The Cd Changer (Cars With An On-Board Monitor And Without A Dsp Amplifier Only)
A, to the installation location of the CD changer. F 53 0776 B EN/19 Retrofit / Installation kit No. 65 12 0 029 883 (others see cover sheet) Issue date: 05.2002 Installation Instructions No. 01 29 0 029 576... - Page 20 CD changer (1). F 53 0779 B EN/20 Retrofit / Installation kit No. 65 12 0 029 883 (others see cover sheet) Issue date: 05.2002 Installation Instructions No. 01 29 0 029 576...
- Page 21 (31) on the CD changer (1). C2/X18729 F 53 0783 B EN/21 Retrofit / Installation kit No. 65 12 0 029 883 (others see cover sheet) Issue date: 05.2002 Installation Instructions No. 01 29 0 029 576...
- Page 22 M5x14 (13). F 53 0784 B EN/22 Retrofit / Installation kit No. 65 12 0 029 883 (others see cover sheet) Issue date: 05.2002 Installation Instructions No. 01 29 0 029 576...
-
Page 23: To Install The Cd Changer (Only Required For Cars With A Dsp Amplifier)
(1). Secure the coaxial cable D with cable ties. F 39 0788 B EN/23 Retrofit / Installation kit No. 65 12 0 029 883 (others see cover sheet) Issue date: 05.2002 Installation Instructions No. 01 29 0 029 576... - Page 24 M5x14 (13). F 53 0789 B EN/24 Retrofit / Installation kit No. 65 12 0 029 883 (others see cover sheet) Issue date: 05.2002 Installation Instructions No. 01 29 0 029 576...
-
Page 25: To Install The Cd Changer (Only Required For Cars With Cd Changer Preparation)
M5x14 (13). F 53 0793 B EN/25 Retrofit / Installation kit No. 65 12 0 029 883 (others see cover sheet) Issue date: 05.2002 Installation Instructions No. 01 29 0 029 576... -
Page 26: Coding And Concluding Work
Reassemble the car by following the instructions for its dismantling in reverse order Print out error memory EN/26 Retrofit / Installation kit No. 65 12 0 029 883 (others see cover sheet) Issue date: 05.2002 Installation Instructions No. 01 29 0 029 576... -
Page 27: Function
13. Function The function of the CD changer is described in the radio owner’s manual. EN/27 Retrofit / Installation kit No. 65 12 0 029 883 (others see cover sheet) Issue date: 05.2002 Installation Instructions No. 01 29 0 029 576... -
Page 28: Circuit Diagram
4,0 RTGN 0.5 WSGRGE 0.5 RTGN 0.5 BR X18180 I-BUS 30<56 F 53 0794 B EN/28 Retrofit / Installation kit No. 65 12 0 029 883 (others see cover sheet) Issue date: 05.2002 Installation Instructions No. 01 29 0 029 576... - Page 29 = Grey = Orange = Red SW = Black = Violet WS = White EN/29 Retrofit / Installation kit No. 65 12 0 029 883 (others see cover sheet) Issue date: 05.2002 Installation Instructions No. 01 29 0 029 576...
