In the event that you should require service for your Nikon RIFLESCOPE, in case
of U.S.A. market, please send it directly to:
Nikon Scope Service
841 Apollo Street, Suite 100
El Segundo, CA. 90245-4721
1-800-Nikon SV.
In case of outside U.S.A. please bring it to dealer from which you purchased it.
Manufacturer:
3-25, Futaba 1-chome, Shinagawa-ku, Tokyo 142-0043, Japan
Tel:+81-3-3788-7697 Fax:+81-3-3788-7698
Printed in Japan (506B) 72-1Y/1E
Riflescope
MONARCH X
2.5-10x44 SF
2.5-10x44 SF IL
4-16x50 SF
Instruction manual
E
Advertisement
Related Manuals for Nikon 10x44 SF
Summary of Contents for Nikon 10x44 SF
- Page 1 In the event that you should require service for your Nikon RIFLESCOPE, in case of U.S.A. market, please send it directly to: Nikon Scope Service 841 Apollo Street, Suite 100 El Segundo, CA. 90245-4721 1-800-Nikon SV. In case of outside U.S.A. please bring it to dealer from which you purchased it.
- Page 2 Congratulations on your choice of a Nikon RIFLESCOPE. Your new scope is the finest example of Nikon's rugged and durable construction and precision bright optics; important qualities for a serious shooter's riflescope. Whether you use your scope for hunting or for target shooting, the procedure for mounting is identical. You should acquire a set of high quality steel mounting rings which have a diameter of 30 mm.
-
Page 3: Specifications
(in) 2.05 2.29 (mm) Your Nikon Monarch X 2.5-10x44 SF Dual Illuminated Reticle is powered by one 3V lithium battery (CR2032 or equivalent). When your reticle grows dim or not light at all, you (in) 13.88 14.78 need to replace the battery. - Page 4 (2) Focusing 笊Look through the eyepiece with your eye positioned about 10cm (4 in) away from the eyepiece lens (Fig. 3-1), and you will see the Nikoplex reticle (Fig. 3-2) or Milliradian Dot reticle (Fig. 3-3). Be sure your eye is positioned within proper alignment and proper eye relief otherwise the view will "black out". 笆Point the objective end of the scope at the sky (Do not point at the sun) or at a plain unpatterned wall.
- Page 5 (3) Magnification ●The riflescope 2.5-10x44 SF have a variable magnification from 2.5 to 10x, 4-16x50 SF from 4 to 16x. ●To change powers. just rotate the power selector ring until the desired magnification appears adjacent to the power index dot.
-
Page 6: Maintenance
Note: ●The windage and elevation scales of the riflescope 2.5-10x44 SF and 4-16x50 SF are calibrated in division of 1/4 minute of angle with a click at intervals of 1/4 minute of angle (one division). ●When adjusting the reticle to the point of aim, remember that one minute of angle equals approximately one inch (2.54 cm) at 100 yards (91.44 m). Therefore, if the impact point is two inches (5.08 cm) low and one inch (2.54 cm) right at 100 yds (91.44 m) Parallax Setting, you should adjust two minutes of angle up one minute of angle left.
