Summary of Contents for Nextar T30
-
Page 2: Table Of Contents
Power on... 10 Power off... 10 Lock & unlock ... 10 Connect to the PC... 10 Download files ... 11 Loading DRM protected WMA audio tracks with Windows Media Player 10 ... 11 Copying audio tracks to the player from PC ... 11 Disconnect from the PC ... - Page 3 Pause ... 16 Volume Adjustment ... 17 Moving Previous/ Next File ... 17 Fast Forward/Fast Rewind ... 17 Section Repeat ... 17 Lyrics Synchronization ... 17 Music High-Fi Output ... 18 WATCHING VIDEO ... 19 Convert Video File ... 19 Install the AVI converter...
- Page 4 Viewing Image ... 26 Move Previous/Next File ... 26 Play/Pause... 26 E-BOOK ... 26 Download Text ... 26 Reading Book ... 26 Page up/Page down... 26 Auto slide show... 26 Bookmark... 27 Save bookmark ... 27 Load bookmark ... 27 Read book while listening to music...
- Page 5 Setting Display... 31 Setting Auto Slide Show... 32 Setting System... 32 Setting Sleep Timer... 32 Load Default ... 32 UPGRADING THE PLAYER ... 32 TROUBLESHOOTING... 39 PRODUCT SPECIFICATIONS... 40 PRECAUTIONS AND MAINTENANCE... 41 TAKING PRECAUTIONS ... 41 CLEANING THE DEVICE ... 41 FIRMWARE OF THE DEVICE ...
-
Page 6: Introduction
INTRODUCTION Congratulations on your purchase of this PMP (Portable Media Player). Before operating the player, please read this manual thoroughly and keep it for future reference. This manual will help you use many of the exciting features to make your player view more enjoyable. This manual contains important safety measures and information for correct usage. -
Page 7: System Requirement
SYSTEM REQUIREMENT Microsoft Windows 2000 and XP ® Pentium II 350MHz or Higher 64MB RAM (128MB Recommended) USB port 120MB Free Hard Disk Space or more CD-ROM driver MAIN FEATURES 3.5” 262k color TFT QVGA (320×240) ----High-quality flat panel LCD, a brighter display and a smoother motion show, can be clear seen under sunshine. - Page 8 conversing to AVI video format. (AVI converter software is in the bundled CD) Photo preview: JEPG and BMP E-BOOK ----Support txt.format e-book, listen to music while reading e-book, support bookmark function. FM tuner ----FM-radio playback and recording. Digital voice recorder ID3 tag / Lyrics display ----Provide the basic information of titles, artists and albums of music file.
-
Page 9: Player Overview
PLAYER OVERVIEW 1 Previous 2 Power 3 Record 4 USB port 5 Charging indicator 6 Earphone jack 7 Reset 8 Power supply 9 Next 10 SD / MMC card slot 11 Return 12 TFT display 13 Volume up 14 Play/pause 15 Volume down 16 Loud speaker... -
Page 10: Description Of Buttons
DESCRIPTION OF BUTTONS Button Function Press to turn the player on/off. Press to start/pause playback. Press together with In music mode, press to create or release repeat section. In FM mode, press and hold to start FM recording. In E-book mode, press to save/load bookmark. In record mode, press to start/pause voice record. -
Page 11: Power On/ Power Off/ Lock & Unlock Key
POWER ON/ POWER OFF/ LOCK & UNLOCK KEY Power on Press the for one second or more to turn on the player, then you can see the starting screen. Power off Press the for three seconds or more to turn off the power. Then you can see the ending screen. Lock &... -
Page 12: Download Files
finish the installation. Two new “Removable Disks” will appear. One for internal memory card and one for SD card. The removable disk for SD card is only available when SD card is inserted. Download files Note that this player will build the play list by scanning all files which are sorted by letter order. In Windows 2000 and Windows XP, music with DRM9 should be transferred by Windows Media Player version 9.0 or 10.0 later version (version 10.0 later version is for Windows XP only) to the PMP. -
Page 13: Managing Battery
After selecting the USB device, click the [Stop] button. When you see the [Safely Remove Hardware] window, click [OK] and then unplug the USB cable. MANAGING BATTERY Charging battery You can charge the battery either with the USB cable or power adaptor. If you charge the battery while player is connected to computer, it displays the following picture. - Page 14 If you safely remove the player from computer while keeping the USB cable connected or use power adapter to charge, it displays the following picture while the battery is charging. Press any key now leads you to such a mode, in this mode you can use the normal function of the player such as listening to music or watching video while the charging is going on.
-
Page 15: Low Battery
Low battery If there is not enough energy in battery, the system will show you the following warning. If you still use the player in low battery state, the player will turn off automatically with power off message. Cautions: Make sure that the battery is fully charged before first use. Please recharge the battery when there is a message that battery voltage is low and when the player shuts down. -
Page 16: Main Menu
MAIN MENU The nine functions are showed in main menu. Press to move in between, to confirm selection. To return to main menu, long press ( When you are in Recording or Setting mode, press for a short time to return to main menu). -
Page 17: Listening To Music
LISTENING TO MUSIC Display in Play Mode Repeat mode Playback Press for a long time, select music mode, then press Pause Press to pause the playback. Press again to restart the playback. -
Page 18: Volume Adjustment
Volume Adjustment While a music file is in play, press Moving Previous/ Next File While a music file is in play, press Fast Forward/Fast Rewind While a music file is in play, press Section Repeat Use section repeating function when you want to repeat a certain range of file in play. Define start point (A point) of the repeat range for the music file in play by pressing Press again at the point where you want to stop repeat. -
Page 19: Music High-Fi Output
Choose an MP3 or WMA file, for example “lovemusic.mp3”. Download a lyrics file from internet. The lyrics file must be with the file name extension LRC, example “lovemusic-2007.lrc”. Rename the lyrics file, example “lovemusic.lrc”. Make sure the lyrics filename is the same as the corresponding music filename. -
Page 20: Watching Video
WATCHING VIDEO Convert Video File This player only support AVI video format. Other formats such as RM/ VOB/ DAT/ RMVB/ MPG/ MPEG/ MP4/ ASF/ WMV/ MKV can be played after being converted to AVI video format. (AVI converter software is in the bundled CD) Install the AVI converter Insert the attached installation disk into the CD-ROM, select and run “AVIConverter Package Setup.exe”, enter the installation interface, and then click [Next] to display the following dialogs:... - Page 21 After selecting the installation routine, click [Install] to complete installation (shown below) After the installation is complete, click [Finish] to finish the software installation.
-
Page 22: Conversion
Conversion: This player can convert rm, rmvb, mpg, mpeg, mp4, asf, wmv, mkv, dat, and vob into AVI video format via the included video convert software. Run the “AVI Converter 2.0” program and click “Add”, then select your desired video/audio file and the AVI video file routine to be generated, shown as follow:... - Page 23 Select and set your desired parameters, click “Save”. After finishing your selections, click “Close” to exit this window and click “Convert Now”. The player will now begin to convert your files to AVI file format. After finishing the conversion, click “Close” to exit. The successfully converted AVI video files can now be played in the PMP.
-
Page 24: Play Video
Play Video Press for a long time, select video mode, then press video files to play in video mode. Press Pause Press to pause the playback. Press Volume Adjustment While a video file is in play, press Moving Previous/ Next File While a video file is in play, press Fast Forward/Fast Rewind While a video file is in play, press... -
Page 25: Radio Function
RADIO FUNCTION Enter Radio Press for a long time, select radio mode, then press Submenu Press to enter submenu. There are five settings in the submenu: manual, preset, save, delete, auto. Press to select, to confirm selection. Manual: To search channel manually. Press Preset: To listen to stored channels. -
Page 26: Fm Record
to move between “Yes” and “No”, saved, press to enter submenu again, choose under which mode you would like to listen to FM radio, manual or preset. Delete: To delete a particular saved channel. Press warning window will pop out asking you whether to delete or not. Press “No”, to confirm selection. -
Page 27: Photo
PHOTO Viewing Image Press for a long time, select photo mode, then press photo files to play in photo mode. Press Move Previous/Next File During picture seeing, press Play/Pause Press to start/pause picture slide show. E-BOOK Download Text Connect player to the computer and select your desired file to download. Open the file with “Notepad” (Windows start Program Accessories Notepad), then save as TXT format and ANSI format in your hard disk. -
Page 28: Bookmark
Press to start/pause text slide show. Bookmark Bookmark helps you to mark your place in the text. Save bookmark While reading text, long press to save bookmark. A window pops out at the left corner. Press to ma rk current page. -
Page 29: Record
RECORD Press for a long time, select record mode, then press the same file. Press and hold and return to main menu. Listen t o the re EXPLORE Press for a long time, select “Explore” mode, then press In explore mode, you can: Navigate all the fold ers and files stored in the player. -
Page 30: Sd/Mmc Card
SD/MMC CARD After connecting the player to the computer, you will find two “Removable Devices”. One is the built-in memory of the PMP and the other is the external SD / MMC card. Inserting Memory Card: Insert the SD / MMC SD card with its top side up into the PMP. Removing Memory Card: Push the SD / MMC SD card slightly to eject. -
Page 31: Settings
A. Connect player to PC. B. Choose the desired music with DRM. C. Right-click and select “Add to Sync list”. D. In the resulting dialog, select “Sync”. E. In the “Sync” window, select the desired music with DRM as step B and choose “Removable Disk”. F. -
Page 32: Setting Fm Radio
Order Shuffle Preset EQ: There are eight EQ effects to choose from—Normal/3D/Rock/Pop/Classic/Bass/Jazz/User EQ User EQ: You can set you own EQ effect here. Press to adjust and Setting FM Radio Stereo SW: Choose to turn on stereo or not. If you choose “no”, the sound output in FM will be monolateral. FM Region: Three regions to choose from—Europe (87.5-108.0MHz), Japan (76.0-90.0MHz) and U.S.A (87.5-108.0MHz). -
Page 33: Setting Auto Slide Show
Setting Auto Slide Show Setting the auto slide show time alternation for text reading and photo seeing. Both have five options to choose from, from 1 second to 5 seconds. Setting System Language: There are eight options in language—English/Dutch/Italian/Spanish/French/Portuguese/Korean About: Display the firmware version of the player, the date of firmware designing, the remain/total memory of flash memory and card memory. - Page 34 The first time you upgrade the player, insert the disk into the CD-ROM drive of your computer. Open the “Customer upgrade tooling ” program, select the required language and enter the installation Interface. 2.8.1.6.rar...
- Page 35 Click ”I accept the terms in the license agreement” on the license agreement interface.
- Page 36 Click Next as prompted until installation is complete (refer to Fig.).
- Page 37 Upgrading When the installation of programs required by the computer is complete, you can begin the upgrade. Select and run the upgrading tool (shown below), then select and open the upgrading software.
- Page 38 Hold the button and connect the player to the PC, Click “Open” to choose the latest firmware you want to update (shown as below). Note: you can release button after connecting to the PC.
- Page 39 Click “Update”, and the device will check for the latest software and update it automatically. Update information appears in the “Update Info” area until it is successfully updated. When the update is finished, this area will display “Successful” (shown on as below). Click “Exit”...
-
Page 40: Troubleshooting
Note: After updating, you must format the player before using it. A firmware upgrade is to improve and optimize the performance of the player. The normal operations of the player would not be affected even if the firmware isn't upgraded. If the firmware upgrade is interrupted, the PMP may not work. -
Page 41: Product Specifications
Note: Features and Specifications are subject to change without any prior notice. PRODUCT SPECIFICATIONS Bit rate 32Kbs~480Kbs Voice recording Sample rate DVR format Memory Optional 85dB Distortion <0.5% Output power 5mW*2 Battery life 8 Hrs for MP3 usage / 4 Hrs for video usage USB port USB 2.0 high speed Music format... -
Page 42: Precautions And Maintenance
File-saving conditions Humidity<90%; normal temperature Work condition Humidity<85%; -10~40℃ Weight: About 105g PRECAUTIONS AND MAINTENANCE TAKING PRECAUTIONS Before powering on the player, please plug in the earphone to avoid damaging the earphone as well as maintenance of the player. Turn off the player when you stop using it. Do not place it near a heat resource or subject to direct sunlight, dust, humidity or rain. - Page 43 loss of data. Due to different memory calculating method and since the firmware is stored in the device flash memory, it will cause the difference between flash memory marked capacity and real capacity. The real flash memory capacity is lesser than the marked memory capacity of this device.
-
Page 44: Listening Caution
Listening Caution Do not play your headphones or earphones at a high volume. Hearing experts advise against continuous extended play. If you experience a ringing in your ears, reduce volume or discontinue use. Do not use while operating a motorized vehicle. It may create a traffic hazard and is illegal in many areas. -
Page 45: Precautions
Precautions 1). When not using the player for an extended period of time, remove the batteries to avoid damage due to leakage. (Apply to Models that come with AAA or AA battery) 2). Do not use the player in extremely hot, cold, dusty or damp environments. 3). -
Page 46: Fcc Caution
FCC Caution This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. - Page 47 accept any interference received, including interference that may cause undesired operation. This product may receive radio interference caused by mobile telephones or other products during operation. If such interference is apparent, please increase separation between the product and the mobile telephone or other product. This product may receive radio interference caused by mobile telephones or other products during operation.
- Page 48 No part of this manual may be copied, republished, reproduced, transmitted or distributed in any way without prior written consent of Nextar, Inc. Any unauthorized distribution of this manual is expressly forbidden.
