Atlantis Land A02-RAV211 User Manual

Atlantis land voip router user's manual
Hide thumbs Also See for A02-RAV211:
Table of Contents

Advertisement

Quick Links

Download this manual
VoIP ROUTER
ADSL
A02-RAV211
USER'S MANUAL
A02-RAV211_ME01

Advertisement

Table of Contents
loading

Related Manuals for Atlantis Land A02-RAV211

Summary of Contents for Atlantis Land A02-RAV211

  • Page 1 VoIP ROUTER ADSL A02-RAV211 USER’S MANUAL A02-RAV211_ME01...
  • Page 3 VoIP ROUTER ADSL Copyright The Atlantis Land logo is a registered trademark of Atlantis Land SpA. All other names mentioned mat be trademarks or registered trademarks of their respective owners. Subject to change without notice. No liability for technical errors and/or omissions.

  • Page 4: Table Of Contents

    TABLE OF CONTENTS CHAPTER 1 ... 1 1.1 A VERVIEW OF THE 1.2 P ... 2 ACKAGE ONTENTS 1.3 V IP R ADSL F OUTER 1.4 V IP R ADSL A OUTER CHAPTER 2 ... 5 2.1 C AUTIONS FOR USING THE 2.2 T ...
  • Page 5 3.6.3.3.4 A DVANCED ELEPHONY 3.6.3.3.5 R & T ONFIGURATION 3.6.3.3.7 T ... 39 IMEOUTS 3.6.3.4 S ... 40 YSTEM 3.6.3.4.1 P ... 41 ASSWORD 3.6.3.4.2 T ... 41 3.6.3.4.3 U ... 42 PGRADE 3.6.3.4.4 F ACTORY ETTING 3.6.3.4.5 R ... 42 ESTART 3.6.3.5 F ...

  • Page 7: Chapter 1

    Introduction 1.1 An Overview of the VoIP Router ADSL A02-RAV211 VoIP ADSL Modem/Router provides a high-speed Ethernet port for high-speed Internet browsing. It can support downstream transmission rates of up to 8Mbps and upstream transmission rates of up to 1024Kbps. It is compliant with Multi-Mode standard (ANSI T1.413, Issue 2; G.dmt (G.992.1);...

  • Page 8: Package Contents

    Real-time Transport Protocol (RTP) for transport of multimedia data and Session Initiation Protocol (SIP) or H.323 for call signaling and control. A02-RAV211 extracts the maximum benefit from Voice over IP (VoIP) and Fax over IP (FoIP) technologies. It interfaces analog telephones with IP-based telephony networks. The integration of VoIP technology and ADSL Modem/Router is undoubtedly the most economic and practical solution to modern society.
  • Page 9 VoIP ROUTER ADSL Universal Plug and Play (UPnP) and UPnP NAT Traversal: This protocol is used to enable simple and robust connectivity among stand-alone devices and PCs from many different vendors. It makes network simple and affordable for users. UPnP architecture leverages TCP/IP and the Web to enable seamless proximity networking in addition to control and data transfer among networked devices.

  • Page 10: Oip Router Adsl Application

    VoIP ROUTER ADSL 1.4 VoIP Router ADSL Application...

  • Page 11: Chapter 2

    Place the ADSL VoIP Router on a stable surface. Only use the power adapter that comes with the package. Do NOT upgrade firmware on any Atlantis Land product over a VoIP connection. Failure of the device may result. Use only hard-wired network connections.

  • Page 12: Cabling

    PORT Power Switch Power Jack Reset VoIP (RJ-45 connector) 2.4 Cabling The most common problem is bad cabling or ADSL line. Make sure that all connected devices are turned on. On the front of the product is a bank of LEDs. As a first check, verify that the LAN Link and ADSL line LEDs are lit and SYS is blanking.

  • Page 13: Chapter 3

    The ADSL VoIP Router can be configured with your Web browser. The web browser is included as a standard application in the following operation systems, UNIX, Linux, Mac OS, Windows 95/98/NT/2000/Me, and etc. The product provides a very easy and user-friendly interface for configuration.

  • Page 14: Configuring Pc In Windows

    3.3 Configuring PC in Windows For Windows 95/98/ME 1. Go to Start / Settings / Control Panel. In the Control Panel, double-click on Network and choose the Configuration tab. 2. Select TCP / IP -> NE2000 Compatible, or the name of any Network Interface Card (NIC) in your PC.
  • Page 15 VoIP ROUTER ADSL 5. Then select the DNS Configuration tab. 6. Select the Disable DNS radio button and click “OK” to finish the configuration.

  • Page 16: For Windows Nt4.0

    VoIP ROUTER ADSL For Windows NT4.0 1. Go to Start / Settings / Control Panel. In the Control Panel, double-click on Network and choose the Protocols tab. 2. Select TCP/IP Protocol and click Properties. 3. Select the Obtain an IP address from a DHCP server radio button and click “OK”.

  • Page 17: For Windows 2000

    VoIP ROUTER ADSL For Windows 2000 1. Go to Start / Settings / Control Panel. In the Control Panel, double-click on Network and Dial-up Connections. 2. Double-click LAN Area Connection. 3. In the LAN Area Connection Status window, click Properties.
  • Page 18 Select Internet Protocol (TCP/IP) and click Properties. Select the Obtain an IP address automatically and the Obtain DNS server address automatically radio buttons. Click “OK” to finish the configuration. VoIP ROUTER ADSL...

  • Page 19: For Windows Xp

    VoIP ROUTER ADSL For Windows XP 1. Go to Start / Control Panel (in Classic View). In the Control Panel, double-click on Network Connections. 2. Double-click Local Area Connection 3. In the LAN Area Connection Status window, click Properties.
  • Page 20 VoIP ROUTER ADSL 4. Select Internet Protocol (TCP/IP) and click Properties. 5. Select the Obtain an IP address automatically and the Obtain DNS server address automatically radio buttons 6. Click “OK” to finish the configuration.

  • Page 21: Factory Default Settings

    3.4 Factory Default Settings Before configurating this ADSL VoIP Router, you need to know the following default settings. • Username: admin • Password : atlantis • IP Address : 192.168.1.254 • Subnet Mask : 255.255.255.0 • DHCP server is enabled. 3.4.1 Username and Password The default username and password are admin and atlantis respectively.

  • Page 22: Information From The Isp

    LAN Port IP address Subnet Mask DHCP server function 3.5 Information from the ISP Before configuring this device, you have to check with your ISP (Internet Service Provider) what kind of service is provided such as PPPoE, PPPoA, RFC1483, IpoA. Gather the information as illustrated in the following table and keep it for reference.

  • Page 23: Status

    VoIP ROUTER ADSL You will get a status report web page when login successfully. At the configuration homepage, the left navigation page where bookmarks are provided links you directly to the desired setup page, including: • Status (ADSL Status, LAN Status, PPP Status, Learned MAC Table, Routing Table, System Log, Security Log) •...

  • Page 24: Status - Adsl Status

    VoIP ROUTER ADSL 3.6.1.1 Status – ADSL Status Displays the status of your ADSL connection. It will refresh every two seconds.

  • Page 25: Adsl Status - Wan Status

    VoIP ROUTER ADSL 3.6.1.1.1 ADSL Status – WAN Status 3.4.1.1.2 ADSL Status – ATM Status...

  • Page 26: Status - Lan Status

    VoIP ROUTER ADSL 3.6.1.2 Status – LAN Status Displays the status of your Local Area Network (LAN) connection. 3.6.1.2.1 LAN Status – TCP Status...

  • Page 27: Status- Ppp Status

    3.6.1.3 Status- PPP Status Displays the status of your PPP connection. It will refresh every ten seconds. 3.6.1.4 Status- Learned MAC Table Aging Timeout: Enter the time period for the router to memorize MAC addresses. VoIP ROUTER ADSL...

  • Page 28: Routing Table

    3.6.1.5 Routing Table Display the current routing paths of A02-RAV211. 3.6.1.6 System Log Display the system logs cumulated till the present time. You can trace the historical information through this function. VoIP ROUTER ADSL...

  • Page 29: Security Logs

    VoIP ROUTER ADSL 3.6.1.7 Security Logs Display the information of security logs. If hacker attacks your sever, he will be isolated by the firewall function and the router will record related information. Hence, you know where the hacker comes from. 3.6.2 Quick Start If you use this device to access the Internet through the ISP, this web page is enough for you to configure this router to access the Internet and enable VoIP service without a problem.

  • Page 30: Oip Quick Start

    If you have a VoIP SIP account, you may configure it to enable this service. Please refer to the sections (VoIP configuration) below for more information. 3.6.3 Configuration When you click this item, you get following sub-items to configure A02-RAV211. • WAN • LAN •...

  • Page 31: Wan

    VoIP ROUTER ADSL 3.6.3.1 WAN The screens below contain settings for the WAN interface toward Internet. Select Adapter Select the item of PVCs you want to configure. Then, press the Submit button.
  • Page 32 VoIP ROUTER ADSL Virtual Circuit Virtual Circuit: Enable/Disable the settings of this VC. Bridge: If you set this device to be bridge mode, select Enable; if not, please select Disable. IGMP: You can Enable or Disable this function.
  • Page 33 VoIP ROUTER ADSL Encapsulation: There are eleven ways ─ PPPoE VC-Mux, PPPoE LLC, PPPoE None, PPPoA VC-Mux, PPPoA LLC, 1483 Bridged IP VC-Mux, 1483 Bridged IP LLC, 1483 Routed IP VC- Mux, 1483 Routed IP LLC, Classical IP over ATM, Native ATM ─ for the device to have a public IP address and then to access Internet.
  • Page 34 VoIP ROUTER ADSL line for a predetermined period of time. You can input any number from 0 to 32767. The default value is 0 seconds. MRU: Maximum Receive Unit indicates the peer of PPP connection the maximum size of the PPP information field this device can be received.
  • Page 35 VoIP ROUTER ADSL Device IP Address IP Address: Default at 192.168.1.254. This is the device IP address in LAN site. If you plan to change it to another IP address to a different range of IP subnet. Please make sure your PC is also located at the same IP subnet. Otherwise, you may not be able to access the router.

  • Page 36: Oip

    VoIP ROUTER ADSL 3.6.3.3 VoIP The screens below contain settings for the VoIP module. This will create the telephone like service in the Internet. Most of VoIP services are free when surfing in the Internet. Enable SIP Registration: Yes/No to register a SIP account in the SIP server or not. Service provider to use: Select the right setting for the service provider in use.
  • Page 37 Registration Interval: specify the re-registration interval in seconds. Authentication Method: specify the authentication method, currently MD5 is supported only. Registrar Address: indicate the SIP registrar IP address RegistrarPort: specify the port of the SIP registrar on which it will listen for register requests from VoIP device.

  • Page 38: Configuration

    Login account list: Allow to select the desired profile. New account name: Inser the name of a new account. UserID: This parameter holds the registration ID of the user within the SIP registrar. Password: This parameter holds the password used for authentication within SIP registrar. AuthorizationUserID: Same as UserID.

  • Page 39: Phone Book

    VoIP ROUTER ADSL SIP: Enable/Disable to use SIP as VoIP call signaling protocol. LocalSIPPort: Enter the local SIP port which device listens incoming request. (range from 5000 to 65535, default value is 5060) Start Media Port: It is known as RTP port, provide the based value from the media (RTP) ports that are assigned for various endpoints and the different call sessions that may exist within an end- point.

  • Page 40: Call Feature

    VoIP ROUTER ADSL Abstract Description: indicate the purpose or useful information for this entry. Remote UserID: This is the UserID you want to contact. Refer UserID in VoIP -> Configuration -> UserID. IP Address / Domain: indicate remote user’s IP address or domain name if this remote user does not register in the SIP server.

  • Page 41: Advanced Telephony Settings

    VoIP ROUTER ADSL CallReturn: Enable/Disable the call return feature. 3.6.3.3.4 Advanced Telephony Settings This section is for you to do some advanced settings to the VoIP ADSL Router.
  • Page 42 VoIP ROUTER ADSL Configure Caller ID info: Modulation: This is Caller ID Modulation (Bell 202.V23). You can select between CID_BELL202 and CID_V23. Delay: Delay , in milliseconds , between the end of the first ring and beginning of the CID transmission.
  • Page 43 Echo Cancellation Tail Length: Setting the Tail Length. Configure DTMF Relay: DTMF (Dual Tone Multi Frequency). None: selecting none for sending DTMF tone in original audio form. RFC 2833: sending voice with RTP packets Configure Hook Flash Time: This parameter specifies the maximum time in mSec of Hook flash. For a Hook flash to be detected , there should be an on-hook followd by an off-hook within “...

  • Page 44: Ring & Tone Configuration

    VoIP ROUTER ADSL 3.6.3.3.5 Ring & Tone Configuration This screen contains settings for creating different ring tone patterns. Working Country: This selection is a drop-down box, which allows user to select the country for which the VoIP device must work. When a country is selected, the country parameters are automatically displayed.

  • Page 45: Timeouts

    BusyTone: Defined by six fields, Frequency1, Frequency2, On Time1, Off Time1, On Time2, Off Time2. Frequency is given in hertz. Time is given in milliseconds. RingBackTone: Defined by six fields, Frequency1, Frequency2, On Time1, Off Time1, On Time2, Off Time2. Frequency is given in hertz. Time is given in milliseconds. CallWaitingTone: Defined by six fields, Frequency1, Frequency2, On Time1, Off Time1, On Time2, Off Time2.

  • Page 46: System

    VoIP ROUTER ADSL RedialTimer: indicate the time period through which the dial tone is heard once the phone is lifted off the hook. At the end of this period, if no digits have been pressed, VoIP device will start playing fast-busy tone.

  • Page 47: Password

    Caps Lock is off. Moreover, please do not use the sign “&” in the passwords. 3.6.3.4.2 Time Zone A02-RAV211 does not have a real time clock on board; instead, it uses the simple network time protocol (SNTP) to get the current time from the SNTP server in outside network. Please choose your local time zone and click Submit.

  • Page 48: Upgrade

    VoIP ROUTER ADSL 3.6.3.4.3 Upgrade To upgrade the firmware of A02-RAV211, you should download or copy the firmware to your local environment first. Press the “Browse…” button to specify the path of the firmware file. Then, click “Upgrade” to start upgrading. When the procedure is completed, A02-RAV211 will reset automatically to make the new firmware work.

  • Page 49: Firewall

    VoIP ROUTER ADSL 3.6.3.5 Firewall User can decide to enable this firewall function including Packet Filter, Block Hacker Attack, and Block WAN request features for better security control or not. But be noted, it wastes network processor computation power. The performance will be lower about 10% to 15%. More firewall features will be added continually, please visit our web site to download latest firmware.
  • Page 50 VoIP ROUTER ADSL Incoming: Determine whether the rule is for outgoing packets or for incoming Outgoing packets. Active: Choose “Yes” to enable the rule, or choose “No” to disable the rule. Packet Type: Specify the packet type (TCP, UDP, ICMP or any) that the rule will be applied to. Select TCP if you want to scope for the connection-based application service on the remote server using the port number.

  • Page 51: Bridge Filtering

    If the DHCP server option is enabled, you have to be very careful in assigning the IP addresses of filtered private IP range in order to avoid conflicts because you do not know which PC in LAN is assigned to which IP address.

  • Page 52: Block Wan Request

    access the network resources. There are few samples of hacker patterns implemented as below. IP Spoofing Ping of Death (Length > 65535) Land Attack (Same source / destination IP address) IP with zero length Sync flooding Smurf Attack (ICMP Echo with x.x.x.0 or x.x.x.255) Snork Attack UDP port loop-back TCP NULL scan...

  • Page 53: Virtual Server

    VoIP ROUTER ADSL 3.6.3.6 Virtual Server Being a natural Internet firewall, the ADSL Router protects your network from being accessed by outside users. When it needs to allow outside users to access internal servers, e.g. Web server, FTP server, E-mail server or News server, this product can act as a virtual server. You can set up a local server with specific port number that stands for the service, e.g.

  • Page 54: Adsl

    VoIP ROUTER ADSL 3.6.3.7.1 ADSL Trellis: Default at Enabled. Handshake Protocol: Default at Autosense – G.dmt first. You can also choose other protocols, such as Autosense – T1.413 first, G.dmt/G.lite, T1.413, G.dmt, G.lite. Wiring Selection: Default at Tip/Ring. Select Auto or A/A1 if necessary. 3.6.3.7.2 DNS A Domain Name System (DNS) contains a mapping table for domain name and IP address.

  • Page 55: Dynamic Dns

    VoIP ROUTER ADSL 3.6.3.7.3 Dynamic DNS With Dynamic DNS service, a domain name can be translated into a dynamic IP address, which is often issued by ISP for dial-up service. A local server, such as Web server, Email server or FTP server, can then be easily accessed without knowing the changing IP address.

  • Page 56: Nat

    VoIP ROUTER ADSL addition to update periodically according to this period setting, A02-RAV211 will take the same action automatically whenever the assigned IP changes 3.6.3.7.4 NAT The NAT Configuration page allows the user to set the configuration for the Network Address Translation.
  • Page 57 VoIP ROUTER ADSL Session Name status will be displayed at the middle of this page to show the corresponding Session Name with its IP address. Click Session Name Configuration, the following screen displays. Session Name: Enter the desired session name. Interface: This field allows the user to choose specific WAN interface (PVC or PPP Session) for NAT session.

  • Page 58: Rip

    VoIP ROUTER ADSL 3.6.3.7.5 RIP RIP: Default is Disabled. Border Gateway: Default is Enabled. Supply Interval seconds: The default value is 30 seconds. Expire Timeout seconds: The default value is 180 seconds. Garbage Timeout seconds: The default value is 120 seconds.

  • Page 59: Static Route

    VoIP ROUTER ADSL 3.6.3.7.6 Static Route If you have another router with a LAN-to-LAN connection, you may create a static routing on the router that is the gateway to Internet. Add: Click this button to add a new static routing. When you click this button, the next figure appears.

  • Page 60: Misc Configuration

    3.6.3.7.7 MISC Configuration HTTP server access: Default at Restricted. HTTP server port: Default at 80. FTP server: Default at Enabled. TFTP server: Default at Disabled. DMZ: Regarding the DMZ Host, it is a local computer exposed to the Internet. Therefore, an incoming packet will be checked by NAT algorithms in the ADSL Router, then passed to the DMZ host when the packet is not sent by hacker or not limited by the virtual server list.

  • Page 61: Diagnostic Test

    IGMP Proxy: Default at Disabled. PPP Half Bridge: Default at Disabled. PPP reconnect on WAN access: Default at Disabled. Select Enabled if you want to automatically re- establish the PPPoE/PPPoA session when disconnected by ISP. Enable/Disable the UpnP function, refer to the UPnP: 3.6.3.7.8 Diagnostic Test As soon as you enter the test program, all tests will run automatically to diagnose the connection status of...
  • Page 62 VoIP ROUTER ADSL If this test returns FAIL, please try the test again a few minutes after this test is completed. Since your DSL modem need a couple of seconds to a few minutes to establish the DSL connection depending on your phone line quality. If this test returns FAIL, make sure your phone line is connected to your DSL modem securely, and also check with your service provider to see if your service is activated.

  • Page 63: Save Config

    VoIP ROUTER ADSL service provider. If this test returns FAIL consistently and your DSL modem is statically assigned an IP address, make sure the IP address is the correct one assigned by your service provider. This test returns SKIPPED if “Ethernet connect to AAL5” test does not return PASS. Test Internet connection This test returns PASS if the gateway can be reached through ping request.

  • Page 64: Chapter 4

    If the VoIP ADSL Router is not functioning properly, you can refer first to this chapter for simple troubleshooting before contacting your service provider. This could save you time and effort but if the symptoms persist, then consult your service provider. Problems with the WAN Interface Problem Initialization...

  • Page 65: Technical Features

    Technical Features Protocols LAN port WAN port External buttons LED Indicators Standard ADSL Compliance ANSI T1.413 Issue 2, ITU-T G.992.1(Full Rate DMT), ITU-T Protocols ADSL VoIP Firewall Input Power Power Consumption Agency and Regulatory Dimensions Weight Operating Temperature Storage Temperature Operating Humidity IP, NAT, ARP, ICMP, DHCP(server, relay and client), RIP1/2 , SNMP, SNTP client, UPnP, Telnet server...

  • Page 66: Appendix B

    If you have any problems with the VoIP Router ADSL, please consult this manual. If you continue to have problems you should contact the dealer where you bought this ADSL Router. If you have any other questions you can contact the Atlantis Land company directly at the following address:...
