- Page 1 FILE NO. SVM-06039-2 SERVICE MANUAL AIR CONDITIONER SPLIT WALL TYPE RAS-10GKHP-ES2 / RAS-10GAH-ES2 RAS-10GKP-ES2 / RAS-10GA-ES2 RAS-10GKHP-AS2 / RAS-10GAH-AS2 RAS-10GKP-AS2 / RAS-10GA-AS2 June 2006...
-
Page 2: Table Of Contents
RAS-10GKHP-ES2 / RAS-10GAH-ES2 3-2 RAS-10GKHP-AS2 / RAS-10GAH-AS2 RAS-10GKP-ES2 / RAS-10GA-ES2 3-4 RAS-10GKP-AS2 / RAS-10GA-AS2 SPECIFICATION OF ELECTRICAL PARTS 4-1 Indoor Unit (RAS-10GKHP-ES2, RAS-10GKHP-AS2) 4-2 Outdoor Unit (RAS-10GAH-ES2, RAS-10GAH-AS2) 4-3 Indoor Unit (RAS-10GKP-ES2, RAS-10GKP-AS2) 4-4 Outdoor Unit (RAS-10GA-ES2, RAS-10GA-AS2) REFRIGERATION CYCLE DIAGRAM... - Page 3 9-6 Troubleshooting for Remote Control (Including The Indoor P.C. Board) 10. PARTS REPLACEMENT 10-1 Indoor Unit 10-2 Outdoor Unit 11. EXPLODED VIEWS AND PARTS LIST 11-1 Indoor Unit (E-Parts Assy) (For RAS-10GKHP-ES2, RAS-10GKP-ES2) 11-2 Indoor Unit (E-Parts Assy) (For RAS-10GKHP-AS2, RAS-10GKP-AS2) 11-3 Indoor Unit 11-4 Outdoor Unit (RAS-10GAH-ES2, RAS-10GNAH-AS2) 11-5 Outdoor Unit (RAS-10GA-ES2, RAS-10GA-AS2) •...
- Page 4 FILE NO. SVM-06039 1. SPECIFICATIONS MODEL RAS-10GKHP-ES2 / RAS-10GAH-ES2 RAS-10GKP-ES2 / RAS-10GA-ES2 RAS-10GKHP-AS2 / RAS-10GAH-AS2 RAS-10GKP-AS2 / RAS-10GA-AS2 ITEM Cooling Heating Cooling 220V 240V 220V 240V 220V 240V Capacity 2.73 2.73 2.92 2.96 2.73 2.73 Phase 1∅ Power source 220 − 240 Power consumption 0.83...
- Page 5 FILE NO. SVM-06039 Note : 1 • Capacity is based on the following temperature conditions. JIS B8615-1 Condition Temperature Cooling Heating (DB) 27°C 20°C Indoor unit inlet air temperature (WB) 19°C 15°C (DB) 35°C 7°C Outdoor unit inlet air temperature (WB) 24°C 6°C...
- Page 6 FILE NO. SVM-06039 2. CONSTRUCTION VIEWS 2-1. Indoor Unit Wireless remote control (Flare ∅ 9.52) – 5 –...
- Page 7 FILE NO. SVM-06039 2-2. Outdoor Unit Ø6 hole R5.5 Ø6 hole Ø11x14 hole A detail Drawing (Back leg) Ø 11 x 14 Hole 25 Drain outlet Ø B Detail Drawing (Front leg) (For 8 - 10 anchor bolt) Ø Ø FAN-GUARD Ø...
-
Page 8: Wiring Diagram
FILE NO. SVM-06039-2 3. WIRING DIAGRAM 3-1. RAS-10GKHP-ES2 / RAS-10GAH-ES2 LOUVER INFRARED RAYS RECEIVE 73 C x2 AND INDICATION PARTS MOTOR THERMAL FUSE CN25 CN14 2 CN04 CN07 SG01 Micro DC5V VARISTOR Voltage Power Regulator Module DC12V GRN & YEL T6.3A 250VAC... -
Page 9: Ras-10Gkhp-As2 / Ras-10Gah-As2
FILE NO. SVM-06039-2 3-2. RAS-10GKHP-AS2 / RAS-10GAH-AS2 LOUVER INFRARED RAYS RECEIVE 73 C x2 AND INDICATION PARTS MOTOR THERMAL FUSE CN25 CN14 2 CN04 CN07 SG01 Micro DC5V VARISTOR Voltage Power Regulator Module DC12V GRN & YEL T6.3A 250VAC CN31 R319 RY01 DB01... -
Page 10: Ras-10Gkp-Es2 / Ras-10Ga-Es2
FILE NO. SVM-06039-2 3-3. RAS-10GKP-ES2 / RAS-10GA-ES2 LOUVER INFRARED RAYS RECEIVE 73 C x2 AND INDICATION PARTS MOTOR THERMAL FUSE 1 2 3 4 5 6 CN25 1 2 3 4 5 6 1 2 3 4 5 6 CN14 CN04 1 2 3 4 5 6... -
Page 11: Ras-10Gkp-As2 / Ras-10Ga-As2
FILE NO. SVM-06039-2 3-4. RAS-10GKP-AS2 / RAS-10GA-AS2 LOUVER INFRARED RAYS RECEIVE 73 C x2 AND INDICATION PARTS MOTOR THERMAL FUSE 1 2 3 4 5 6 CN25 1 2 3 4 5 6 1 2 3 4 5 6 CN14 CN04 1 2 3 4 5 6... -
Page 12: Specification Of Electrical Parts
FILE NO. SVM-06039 4. SPECIFICATION OF ELECTRICAL PARTS 4-1. Indoor Unit (RAS-10GKHP-ES2, RAS-10GKHP-AS2) Parts name Type Specifications Fan motor (for indoor) AC Motor with 135°C thermo fuse MMF-240-20-4B Thermo sensor (T A-sensor) 10kΩ at 25°C µ Micro power module (M01) -
Page 13: Indoor Unit (Ras-10Gkp-Es2, Ras-10Gkp-As2)
FILE NO. SVM-06039 4-3. Indoor Unit (RAS-10GKP-ES2, RAS-10GKP-AS2) Parts name Type Specifications Fan motor (for indoor) AC Motor with 135°C thermo fuse MMF-240-20-4B Thermo sensor (TA-sensor) 10kΩ at 25°C µ Micro power module (M01) RM1260V TMP87CM40AFG-6G61 Microcontroller unit (IC30) Heat exchanger sensor 10kΩ... -
Page 14: Refrigeration Cycle Diagram
FILE NO. SVM-06039 5. REFRIGERATION CYCLE DIAGRAM 5-1. RAS-10GKHP-ES2 / RAS-10GAH-ES2 RAS-10GKHP-AS2 / RAS-10GAH-AS2 Indoor unit Heat exchanger Cooling 0.39m 0.49m Heating (Connecting pipe) (Connecting pipe) ∅9.52 ∅6.35 Cross flow fan O.D.:9.52mm O.D.:6.35mm Packed valve Packed valve (∅9.52) (∅6.35) Heating... - Page 15 FILE NO. SVM-06039 5-2. RAS-10GKP-ES2 / RAS-10GA-ES2 RAS-10GKP-AS2 / RAS-10GA-AS2 Indoor unit Heat exchanger Cooling 0.39m 0.49m (Connecting pipe) (Connecting pipe) ∅9.52 ∅6.35 Cross flow fan O.D.:9.52mm O.D.:6.35mm Packed valve Packed valve (∅9.52) (∅6.35) Cooling Cooling Compressor PA108X1C-4FZDN Capillary tube ∅1.5x1100l Heat exchanger Refrigerant...
-
Page 16: Control Block Diagram
FILE NO. SVM-06039 6. CONTROL BLOCK DIAGRAM 6-1. RAS-10GKHP-ES2 / RAS-10GAH-ES2, RAS-10GKHP-AS2 / RAS-10GAH-AS2 M.C.U. Main Unit Control Panel Heat Exchange sensor Functions Operation Display Thermo. Sensor • Louver Control Current Sensor • 3-minutes Delay at Restart Timer for Compressor... -
Page 17: Ras-10Gkp-Es2 / Ras-10Ga-Es2
FILE NO. SVM-06039 6-2. RAS-10GKP-ES2 / RAS-10GA-ES2, RAS-10GKP-AS2 / RAS-10GA-AS2 Main Unit Control Panel M.C.U. Operation Heat Exchange sensor Functions Display Thermo. Sensor • Louver Control Timer Display Infrared Rays Signal Reciver • 3-minutes Delay at Restart for Compressor Fan Only Sign Display Initiallizing Circuit •... -
Page 18: Operation Description
FILE NO. SVM-06039 7. OPERATION DESCRIPTION 7-1. Outline of Air Conditioner Control 7-1-1. Louver control (1) Vertical air flow louver This is a fixed capacity type air conditioner, which uses Position of veritcal air flow louver is automatically AC motor for an indoor fan. The AC motor drive controlled according to the operation mode. -
Page 19: Description Of Operation Circuit
FILE NO. SVM-06039 7-2. Description of Operation Circuit 7-2-2. Cooling operation ([MODE] button on the remote control is set (1) When turning on the breaker, the operation lamp to the cooling operation.) blinks. This means that the power supply is on. (1) The compressor, 4-way valve, outdoor fan and (2) When pressing [ ] button on the remote control,... - Page 20 FILE NO. SVM-06039 7-2-3. Dry operation 7-2-4. Heating operation *Heat pump model only ([MODE] button on the remote control is set ([MODE] button on the remote control is set to the dry operation.) to the heating operation.) (1) The compressor, 4-way valve, outdoor fan and (1) The compressor, 4-way valve, outdoor fan and operation display on the remote control are operation display on the remote control are...
- Page 21 FILE NO. SVM-06039 (3) The indoor heat exchanger restricts revolving *5 and *6: Table 7-2-1 speed of the fan motor to prevent a cold draft. The upper limit of the revolving speed is shown in Fig. 7-2-8 and Table 7-2-1. speed Starting period Stabilized period...
-
Page 22: Hi Power Mode
FILE NO. SVM-06039 7-3. Hi POWER Mode 7-4. High-Temperature Limit Control ([Hi POWER] button on the remote *Heat pump model only control is pressed.) The microcontroller detects the indoor heat exchanger temperature to prevent pressure of a refrigerating cycle When [Hi POWER] button is pressed while the indoor from increasing excessively. -
Page 23: Defrost Operation
FILE NO. SVM-06039 7-6. Defrost Operation * <In case of C> Heat pump model only (1) The heating operation is performed for at least 90 During the heating operation, the outdoor heat minutes. exchanger temperature goes down and sometimes it is frozen. -
Page 24: Current Limit Control
FILE NO. SVM-06039 7-7. Current Limit Control *Heat pump model only The microcontroller detects the input current so as to prevent it exceeds a specified value by means of controlling the outdoor fan control as described in (1) and (2). (1) Current limit control (Cooling operation) Control is performed as shown below by detecting the compressor operating current with a current... -
Page 25: Auto Restart Function
FILE NO. SVM-06039 7-8. Auto Restart Function 7-8-1. How to set auto restart function To set the auto restart function, proceed as follows: The indoor unit is equipped with an automatic The power supply to the unit must be on; the function restarting function which allows the unit to restart will not set if the power is off. - Page 26 FILE NO. SVM-06039 7-8-2. How to cancel auto restart function To cancel auto restart function, proceed as follows: Repeat the setting prodedure: the unit receives the signal and beeps three times. The unit will be required to be turned on with the remote control after the main power supply is turned off.
-
Page 27: Self-Cleaning Function
FILE NO. SVM-06039 7-9. Self-Cleaning function Self-Cleaning function is designed to reduce humidity that causes mold to form inside the air conditioning unit. This advanced, efficient system reduces moisture in the coil. When air conditioner is turned off, the internal fan activates and dries the moisture in the coil for 20 minutes, then it turns off automatically. -
Page 28: Quiet Mode
FILE NO. SVM-06039 7-10. QUIET Mode 7-11-1. Cooling mode • The fan speed of indoor unit operates automatically, Quiet mode is the system which, control the it relates with the compressor's operation. revolving speed of indoor fan to work constantly at lower than speed L. -
Page 29: Installation Procedure
FILE NO. SVM-06039 8. INSTALLATION PROCEDURE 8-1. Safety Cautions For general public use Power supply cord of parts of appliance for Outdoor use shall be at least polychloroprene sheathed flexible cord (design H07 RN-F), or cord designation 245 IEC66. CAUTION New Refrigerant Air conditioner Installation •... - Page 30 Also, make sure the equipment is properly earthed. • Appliance shall be installed in accordance with national wiring regulations. If you detect any damage, do not install the unit. Contact your TOSHIBA dealer immediately. CAUTION • Exposure of unit to water or other moisture before installation could result in electric shock.
-
Page 31: Installation Diagram Of Indoor And Outdoor Units
FILE NO. SVM-06039 8-2. Installation Diagram of Indoor and Outdoor Units INSTALLATION DIAGRAM OF INDOOR AND OUTDOOR UNITS For the rear left and left piping Hook Wall Installation plate Insert the cushion between the indoor unit and wall, and tilt the indoor unit for better operation. -
Page 32: Installation
FILE NO. SVM-06039 8-3. Installation 8-3-1. Optional installation parts Part Parts name Q'ty Code Refrigerant piping Liquid side : ∅6.35 mm : ∅9.52 mm Gas side each Pipe insulating material (polyethylene foam, 6 mm thick) Putty, PVC tapes each <Fixing bolt arrangement of outdoor unit> 109 mm 124 mm 28 mm... - Page 33 FILE NO. SVM-06039 8-3-2. Accessory and installation parts Part Part Part Part name (Q'ty) Part name (Q'ty) Part name (Q'ty) Mounting screw ∅4 x 25 s x 6 Installation plate x 1 Remote control holder x 1 Pan head wood screw ∅3.1 x 16 s x 2 Sasa-Zeolite Vitamin C filter x 1 Wireless remote control x 1...
-
Page 34: Indoor Unit
FILE NO. SVM-06039 8-4-2. Cutting a hole and mounting installation 8-4. Indoor Unit plate 8-4-1. Installation place <Cutting a hole> • A place which provides the spaces around the When installing the refrigerant pipes from the rear. indoor unit as shown in the above diagram. •... - Page 35 FILE NO. SVM-06039 8-3-3. Installation/Servicing tools <Changes in the product and components> In the case of an air conditioner using R410A, in order to prevent any other refrigerant from being charged accidentally, the service port diameter of the outdoor unit control valve (3 way valve) has been changed. (1/2 UNF 20 threads per inch) •...
- Page 36 Anchor bolt NOTE • Ensure all wiring is used within its electrical rating. Projection 15 mm or less 5 mm dia. hole RAS-10GKHP-ES2 RAS-10GKP-ES2 Model 7 Mounting RAS-10GKHP-AS2 screw ∅4 x 25s s s s s RAS-10GKP-AS2 Power source 50 Hz, 220 −...
- Page 37 FILE NO. SVM-06039 <How to connect the connecting cable> For RAS-10GK Wiring of the connecting cable can be carried out Cord clamp Terminal Terminal block without removing the front panel. cover 1. Remove the air inlet grille. Screw Open the air inlet grille upward and pull it toward Connecting cable you.
- Page 38 FILE NO. SVM-06039 8-4-4. Piping and drain hose installation How to fix the drains cap 1) Insert hexagonal wrench (4 mm) in a center <Piping and drain hose forming> head. * Since dewing results in a machine trouble, make sure to insulate both the connecting pipes. (Use polyethylene foam as insulating material.) 4 mm Rear right...
- Page 39 FILE NO. SVM-06039 <Left-hand connection with piping> 8-4-5. Indoor unit fixing Bend the connecting pipe so that it is laid within 43 mm 1. Pass the pipe through the hole in the wall, and hook above the wall surface. If the connecting pipe is laid the indoor unit on the installation plate at the upper exceeding 43 mm above the wall surface, the indoor hooks.
-
Page 40: Outdoor Unit
FILE NO. SVM-06039 8-4-6. Drainage 8-5. Outdoor Unit 1. Run the drain hose sloped downwards. 8-5-1. Installation place • A place which provides the spaces around the NOTE outdoor unit as shown in the left diagram. • Hole should be made at a slight downward slant on •... - Page 41 FILE NO. SVM-06039 8-5-2. Refrigerant piping connection (Unit : N·m) Outer dia. 1. Cut the pipe with a pipe cutter. Tightening torque of copper pipe ∅6.35 Roughness Warp Obliquity 16 to 18 (1.6 to 1.8 kgf·m) 90° ∅9.52 30 to 42 (3.0 to 4.2 kgf·m) Fig.
- Page 42 FILE NO. SVM-06039 8-5-3. Evacuating <Packed valve handling precautions> After the piping has been connected to the indoor unit, • Open the valve stem all the way out; but do not try you can perform the air purge together at once. to open it beyond the stopper.
-
Page 43: How To Set Remote Control Selector Switch
FILE NO. SVM-06039 8-5-4. Wiring connection 8-6. How to Set Remote Control Selector Switch 1. Remove the valve cover from the outdoor unit. 2. Connect the connecting cable to the terminal as When two indoor units ae installed in seperated rooms, identified with their respective matched numbers on there is no need to change the selector switch. -
Page 44: Others
FILE NO. SVM-06039 2. Set the remote control selector switch with the 8-7. Others remote control 8-7-1. Gas leak test [B] is indicated on the liquid crystal display when setting remote control selector switch to B. [A] is not indicated on the display even if the selector switch is set to A. -
Page 45: Troubleshooting Chart
FILE NO. SVM-06039 9. TROUBLESHOOTING CHART 9-1. Troubleshooting Procedure 9-2-2. Incorrect cable connection between Indoor and outdoor units Follow the details of 9-2. Basic Check Items. The indoor unit is connected to the outdoor unit with If there is no troub le corresponding to 9-2, check 5 cables (Heat pump model) or 3 cables (Cooling Only whether or not there are faulty parts following model). -
Page 46: Primary Judgement
FILE NO. SVM-06039 9-3. Primary Judgement 9-3-2. Failure diagnosis The indoor unit diagnoses the operation condition and 9-3-1. Role of indoor unit controller indicates the information of the self-diagnosis with the The indoor unit controller receives the operation lamps on the display panel of the indoor unit. commands from the remote control and executes them. -
Page 47: Self-Diagnosis By Remote Control (Check Code)
FILE NO. SVM-06039 9-4. Self-Diagnosis by Remote Control (Check Code) (1) If the lamps are indicated as shown B to G in Table 9-3-1, exchanger the self-diagnosis by the remote control. (2) When the remote control is set to the service mode, the indoor controller diagnoses the operation condition and indicate the information of the self-diagnosis on the display of the remote... - Page 48 FILE NO. SVM-06039 Table 9-4-1 Block level Diagnosis function Judgement and action Check Check Block Symptom Conditioner Condition code code status Indoor Thermo. sensor Indicated Continued 1.Check thermo sensor. P.C. board short/break. when detected operation. 2.If it is OK, check abnormal P.C.
-
Page 49: Troubleshooting Flowcharts
FILE NO. SVM-06039 9-5. Troubleshooting Flowcharts 9-5-1. Power can not be turned on (No operation at all) <Preliminary checks> Operation (1) Is the supply voltage normal? (2) Is the connection to the AC output OK.? Check Items Heat pump Model Main cause Shut off the power supply from AC outlet once and... - Page 50 FILE NO. SVM-06039 Cooling Model Operation Check Items Main cause Shut off the power supply from AC outlet once and Countermeasure turn it on after 5 seconds. Symptom Does the OPERATION lamp blink? Does the power turn on Does the transmission by pushing the [ indicator of remote Remote control is...
- Page 51 RAS-10GKP-ES2 CN31 Indoor Terminal Block Green & yellow RY01 Supply AC 220 ~ 240 V 50 / 60 Hz RAS-10GKHP-ES2 CN31 Indoor Terminal Block Green & yellow RY01 Supply AC 220 ~ 240 V 50 / 60 Hz − 48 −...
- Page 52 FILE NO. SVM-06039 RAS-10GKP-AS2 Black White CN31 Indoor Terminal Block Brown Blue Green / Yellow RY01 9-5-3. Outdoor unit does not operate RAS-10GKHP-AS2 CN31 Indoor Terminal Block Green & yellow RY01 - 49 -...
- Page 53 FILE NO. SVM-06039 9-5-3. Outdoor unit does not operate Shut off the power supply from AC outlet once and turn it on after 5 seconds. Does the OPERATION lamp blink? See "Power can not be turned on". Does the power turn on by pushing See "Power can not be turned on".
- Page 54 FILE NO. SVM-06039 9-5-4. Only compressor does not operate Shut off the power supply from AC outlet once and turn it on after 5 seconds. Does the OPERATION lamp blink? See "Power can not be turned on". Does the power turn on by See "Power can not be turned on".
- Page 55 FILE NO. SVM-06039 9-5-5. Only outdoor fan does not operate Shut off the power supply from AC outlet once and turn it on after 5 seconds. Does the OPERATION lamp blink? See "Power can not be turned on". Does the power turn on by See "Power can not be turned on".
- Page 56 FILE NO. SVM-05020 9-5-6. Only 4-Way valve does not operate (During heating operation) Heat Pump Model Shut off the power supply from AC outlet once and turn it on after 5 seconds. Does the OPERATION lamp blink? See "Power can not be turned on". Does the power turn on by See "Power can not be turned on".
- Page 57 FILE NO. SVM-06039 9-5-7. Only the indoor fan does not operate <Check procedure> Heat Pump Model Shut off the power supply once. Turn ON the power supply. Does the fan stop in Replace the P.C. board. Control P.C. board is defective. no operating status? Start the operation with low fan setting...
- Page 58 FILE NO. SVM-06039 Cooling Model Shut off the power supply once. Turn ON the power supply. Does the fan stop in Replace the P.C. board. Control P.C. board is defective. no operating status? Start the operation with low fan setting in cool operation.
-
Page 59: Troubleshooting For Remote Control (Including The Indoor P.c. Board)
FILE NO. SVM-06039 9-6. Troubleshooting for Remote Control (Including the Indoor P.C. Board) There is no been from the indoor unit. Push the [ ] button. The operation lamp of the air conditioner main unit does not light. Does the transmission indicator blink? Reset the remote control by use the tip pencil push... - Page 60 FILE NO. SVM-06039 9-6-1 How to check the P.C. board (2) Inspection procedres 1) When a P.C. board is judged to be defective, (1) Operating precautions check for disconnection, burning, or discolora- 1) When removing the front panel or the P.C. board, tion of the copper foil pattern or this P.C.
- Page 61 FILE NO. SVM-06039 (3) Checking procedure Heat Pump Model Table 9-6-1 Procedure Check Point (Symptom) Causes Shut off the power supply and 1. Is the fuse blown? 1. • Application of shock voltage. remove the P.C. board assembly • Overload by short-circuit of the from the electronic parts base.
- Page 62 FILE NO. SVM-06039 Cooling Model Table 9-6-2 Procedure Check Point (Symptom) Causes Shut off the power supply and 1. Is the fuse blown? 1. • Application of shock voltage. remove the P.C. board assembly • Overload by short-circuit of the from the electronic parts base.
- Page 63 FILE NO. SVM-06039 Table 9-6-3 Approximate resistance value of thermo sensor (kΩ) Temperature 0°C 10°C 20°C 25°C 30°C Resistance value 33.8 20.35 12.59 10.00 7.99 9-6-3. How to shorten time of restart delay timer Press [CLR] button while pressing [CHK] button with a tip of a pencil.
-
Page 64: Parts Replacement
FILE NO. SVM-06039 10. PART REPLACEMENT 10-1. Indoor Unit Part name Procedures Remarks Front panel How to remove the front panel 1) Stop the operation of the air conditioner and turn off its main power supply. 2) Pull the air inlet grille toward you to open it and remove the air inlet grille. - Page 65 FILE NO. SVM-06039 Part name Procedures Remarks Heat exchanger 1) Remove the front panel, electrical part and the horizontal louver following procedure 3. 2) Remove the pipe holder at the rear side of main unit. 3) Remove the 2 screws on the heat exchanger at the base bearing.
-
Page 66: Outdoor Unit
FILE NO. SVM-06039 10-2. Outdoor Unit Part name Procedures Remarks Cord clamp 2-Screws Ø4 x 16L Common 1) Stop the operation of air-conditioner, and procedure disconnect the power cord from the AC supply. 2) Remove packed valve cover and Electric parts cover. -
Page 67: Exploded Views And Parts List
FILE NO. SVM-06039 11. EXPLODED VIEWS AND PARTS LIST 11-1. Indoor Unit (E-Parts Assy) (For RAS-10GKHP-ES2, RAS-10GKP-ES2) Location Part Location Part Description Description 43T60001 TERMINAL 43T69542 PC BOARD ASSY ; WRS-LED 43T60002 TERMINAL BLOCK; 3P 43T60077 FUSE, TEMPERATURE, 73°C 43T69371 SENSOR;HEAT EXCHANGER... - Page 68 FILE NO. SVM-06039 11. EXPLODED VIEWS AND PARTS LIST 11-2. Indoor Unit (E-Parts Assy) (For RAS-10GKHP-AS2, RAS-10GKP-AS2) Location Part Part Location Description Description 43T60001 TERMINAL 43T69542 PC BOARD ASSY ; WRS-LED 43T69371 SENSOR;HEAT EXCHANGER 43T69364 FUSE,TEMPERATURE 43T50314 SENSOR;THERMOSTAT 43T62003 CORD CLAMP 43T69544 PC BOARD(RAS-10GKHP-AS2) (RAS-10GKHP-AS2)
-
Page 69: Indoor Unit (E-Parts Assy) (For Ras-10Gkhp-As2, Ras-10Gkp-As2)
DRAIN-HOSE 43T11318 VIBRATION-PROOF RUBBER 43T79301 CAP-DRAIN 43T82309 INSTALLATION PLATE 43T21372 MOTOR; STEPPING 43T69421 WIRELESS-REMOCO 43T44387 REFRIGERATION CYCLE ASSY (RAS-10GKHP-ES2,RAS-10GKHP-AS2) 43T47353 PIPE; SUCTION (RAS-13) WIRELESS-REMOCO 43T69422 43T47355 PIPE; SUCTION (U1U2_GD) (RAS-10GKP-ES2,RAS-10GKP-AS2) 43T11319 PIPE SHIELD 43T83003 HOLDER; REMOTE CONTROLLER 43T44319 REFRIGERATION ASSY... -
Page 70: Outdoor Unit (Ras-10Gah-Es2, Ras-10Gnah-As2)
FILE NO. SVM-06039 11-4. Outdoor Unit (RAS-10GAH-ES2, RAS-10GAH-AS2) Location Part Location Part Description Description 43T42327 BASE PLATE ASSEMBLY 43T19329 FAN GUARD 43T41379 COMPRESSOR(Made in China) 43T04301 PARTITION 43T49327 CUSHION,RUBBER 43T39317 MOTOR BASE CONNECTION PLATE 43T47354 BOLT COMPRESSOR (M6) 43T39318 MOTOR BASE 43T43397 CONDENSER ASSEMBLY 43T19330... -
Page 71: Outdoor Unit (Ras-10Ga-Es2, Ras-10Ga-As2)
FILE NO. SVM-06039 11-5. Outdoor Unit (RAS-10GA-ES2, RAS-10GA-AS2) Location Part Location Part Description Description 43T42327 BASE PLATE ASSEMBLY 43T47001 NUT FLANGE 43T41379 COMPRESSOR(Made in China) 43T19329 FAN GUARD 43T49327 CUSHION,RUBBER 43T04301 PARTITION 43T47354 BOLT COMPRESSOR (M6) 43T39317 MOTOR BASE CONNECTION PLATE 43T43396 CONDENSER ASSEMBLY 43T00448... - Page 72 FILE NO. SVM-03001(1) TOSHIBA CARRIER (THAILAND) CO.,LTD. 144/9 MOO 5, BANGKADI INDUSTRIAL PARK, TIVANON ROAD, TAMBOL BANGKADI, AMPHUR MUANG, PATHUMTHANI 12000,THAILAND. – 72 –...
