NETGEAR GA511 User Manual page 34

NETGEAR 10/100/1000 Mbps CardBus Adapter GA511 User Manual
2. Double-click the Network icon.
The Network window opens, which displays a list of installed components.
Figure B-1
You must have an Ethernet adapter or an GA511, the TCP/IP protocol, and the Client for
Microsoft Networks.
Note: It is not necessary to remove any other network components shown in the
Network window in order to install the adapter, TCP/IP, or Client for Microsoft
Networks.
If you need to add TCP/IP:
a. Click the Add button.
b. Select Protocol, and then click Add.
c. Select Microsoft.
d. Select TCP/IP, and then click OK.
If you need to add the Client for Microsoft Networks:
a. Click the Add button.
b. Select Client, and then click Add.
B-2
v2.0, March 2007
