Harman Kardon AVR 139/230 Service Manual page 13

harman/kardon
FRONT PCB ASSY
Ref. # Part Number
R904 CRD20TJ102T
R905 CRD20TJ104T
R906 CRD20TJ104T
R907 CRD20TJ472T
R908 CRD20TJ472T
R909 CRD20TJ221T
R910 CRD20TJ221T
R911 CRD20TJ221T
R912 CRD20TJ221T
R913 CRD20TJ102T
R915 CRD20TJ473T
R918 CRD20TJ472T
R919 CRD20TJ472T
S701 CST1A024ZT
S702 CST1A024ZT
S703 CST1A024ZT
S704 CST1A024ZT
S705 CST1A024ZT
S706 CST1A024ZT
S707 CST1A024ZT
S711 CST1A024ZT
S712 CST1A024ZT
S713 CST1A024ZT
S714 CST1A024ZT
S715 CST1A024ZT
BK71 CMD1A468
BK72 CMD1A468
BN10 CWB1B009450BM001
BN81 CWB1C007200BM
BN84 CWB1B005080BM
BN85 CWB1B013200EN001
BN88 CWB1B005100BM
BN89 CWB1B003080MM
CN72 CJP31GA41ZM
CN84 CJP05GB03ZY
CN85 CJP13GA19ZY
CN86 CJP02GA89ZM
CN88 CJP05GB03ZY
C906 KCKDKS471ME
D701 CVD52CSBBCEAB2
D703 CVD52CSBBCEAB2
D705 CVD52CSBBCEAB2
D727 CVD50BOBBWGA
D728 CVD50BOBBWGA
D778 HVD1N5819T
FIP2 CFL162BD01GINK
IC73 HRVNJL34H380A
IC75 HVI74ACT04MTR
IC76 HVI74HCU04AFNG
IC86 HVINJM4556AL
JK43 HJJ2D003Y
JK81 CJJ4M041Y
JK82 HJSTORX177L
JK83 CJJ2E026Z
JK86 CJJ4S023Y
SW1 CSH1A008ZV
VR74 CSR2A037Z
BOTTOM CHASSIS ASS'Y
Ref. # Part Number
CUAAVR142/230
CHD1A012ZR
CHD1A023R
CHD4A012R
CHE170
CHE36-3
CHG1A160Z
CHG1A360
CHR301
CHS1A032
CJA2B043ZA
CKL2A069H43
CLT5U036ZE
CNVM9004MS1J75L
CTB3+10JFZR
CTB3+6FFZR
CTB3+8JFZR
CTW3+12JR
CUA2A294
KBA2C4000TLEY
KHR1A028
CN12 CWC4C4A27B120B10
CN13 CWC4C4A13B100B10
CN14 CWC4C4A11B100B10
CN45 CWC4F2A07A060B10
CN83 CWB4F232450UU
Description
RES , CARBON
RES , CARBON
RES , CARBON
RES , CARBON
RES , CARBON
RES , CARBON
RES , CARBON
RES , CARBON
RES , CARBON
RES , CARBON
RES , CARBON
RES , CARBON
RES , CARBON
SW , TACT
SW , TACT
SW , TACT
SW , TACT
SW , TACT
SW , TACT
SW , TACT
SW , TACT
SW , TACT
SW , TACT
SW , TACT
SW , TACT
BRACKET , FLT
BRACKET , FLT
WIRE ASS'Y (9P,2.5MM,450MM,Shield)
WIRE ASS'Y
WIRE ASS'Y (5P,2.5MM,80MM)
WIRE ASS'Y (13P,2.0MM,200MM,Shield)
WIRE ASS'Y (5P,2.5MM,100MM)
WIRE ASS'Y (3P,2.5MM,80MM)
WAFER (1.25MM, CARD CABLE, STRAIGHT 31P)
WAFER , ANGLE (2.5mm)
WAFER, STRAIGHT, 13PIN
WAFER
WAFER , ANGLE (2.5mm)
CAP , CERAMIC(KH TYPE)
L.E.D , BLUE
L.E.D , BLUE
L.E.D , BLUE
L.E.D , 2 COLOR (ORG , BLUE)
L.E.D , 2 COLOR (ORG , BLUE)
DIODE , SCHOTTKY
V.F.D
SENSOR , REMOCON
I.C , HEX
I.C , INVERTER
I.C , HEADPHONE
JACK , HEADPHONE (SILVER)
JACK , BOARD (COAX)
MODULE , OPTICAL(RX)
JACK , HEADPHONE(SILVER PLATE)
JACK , BOARD
SW , PUSH (MOMS)
ENCODER
Description
BOTTOM CHASSIS ASS'Y
SCREW , SPECIAL
SCREW , SPECIAL
SCREW , SPECIAL
HOLDER , PCB
CLAMPER , WIRE
CUSHION , RUBBER
CUSHION , FOOT
CLAMPER
TAPE , HEMELON
CORD , POWER(EUR)
FOOT
TRANS , MAIN AVR139/230
MODULE , TUNER EUR
SCREW
SCREW
SCREW
SCREW
CHASSIS , BOTTOM
FUSE
BUSHING , AC CORD
CABLE , CARD (11P,1.25MM,120MM,B,10MM)
CABLE , CARD (13P,1.25MM,100MM,B,10MM)
CABLE , CARD (11P,1.25MM,100MM,B,10MM)
CABLE , CARD (7P,1.0MM,60MM,B,10MM)
2P WIRE ASS'Y (450MM UL1617)
AVR 139-141-142/230 Service Manual
Value
1K OHM 1/5W J
100K OHM 1/5W J
100K OHM 1/5W J
4.7K OHM 1/5W J
4.7K OHM 1/5W J
220 OHM 1/5W J
220 OHM 1/5W J
220 OHM 1/5W J
220 OHM 1/5W J
1K OHM 1/5W J
47K OHM 1/5W J
4.7K OHM 1/5W J
4.7K OHM 1/5W J
MOLEX 52045-**45
DKS471ME
TOL-50BOBBWGA
TOL-50BOBBWGA
1N5819
162-BD-01GINK
TC74HCU04AFNG(TOSHIBA)
NJM4556AL
TORX177L
Value
QDR-7100CC
KST-M9004MS1-J75L(WO/19KHZ)
4A/250V(EUR)
Page 13 of 83
