Page 1: Air Conditioning
Air Conditioning Technical Data VRVIII-S heat pump EEDEN14-100 RXYSQ-P8V1... -
Page 3: Table Of Contents
• Outdoor Unit • RXYSQ-P8V1 TABLE OF CONTENTS RXYSQ-P8V1 Features ............. 2 Specifications . -
Page 4: Features
• Outdoor Unit • RXYSQ-P8V1 Features U n i e m s P 8 V d o o S Q - O u t V R V V R V R X Y Inverter • VRV Systems • RXYSQ-P8V1... -
Page 5: Specifications
• Outdoor Unit • RXYSQ-P8V1 Specifications 2-1 Technical Specifications RXYSQ4P8V1 RXYSQ5P8V1 RXYSQ6P8V1 Capacity range Cooling capacity Nom. 12.6 14.0 15.5 Heating capacity Nom. 14.2 16.0 18.0 Power input - 50Hz Cooling Nom. 3.24 (1) 3.51 (1) 4.53 (1) Heating Nom. -
Page 6: Electrical Specifications
• Outdoor Unit • RXYSQ-P8V1 Specifications 2-1 Technical Specifications RXYSQ4P8V1 RXYSQ5P8V1 RXYSQ6P8V1 Fan motor 2 Model Brushless DC motor Speed Cooling Nom. Heating Nom. Drive Direct drive Output Sound power level Cooling Nom. Sound pressure level Cooling Nom. Heating Nom. - Page 7 • Outdoor Unit • RXYSQ-P8V1 Specifications 2-2 Electrical Specifications RXYSQ4P8V1 RXYSQ5P8V1 RXYSQ6P8V1 Current - 50Hz Maximum running current 27.0 Starting current (MSC) 15.9 20.2 22.2 Zmax List No requirements Minimum circuit amps (MCA) 27.0 Maximum fuse amps (MFA) 32.0 Full load amps...
-
Page 8: Options
• Outdoor Unit • RXYSQ-P8V1 Options 3 - 1 Options RXYSQ-P8V1 Item RXYSQ4 RXYSQ5 RXYSQ6 Cool / Heat selector KRC19-26A6 Fixing box KJB111A Refnet header KHRQ22M29H Refnet joint KHRQ22M20TA Central drain plug KKPJ5F180 Branch provider (2 rooms) BPMKS967B2B Branch provider (3 rooms) -
Page 9: Capacity Tables
• Outdoor Unit • RXYSQ-P8V1 Capacity tables 4 - 1 Capacity Table Legend • VRV Systems • RXYSQ-P8V1... -
Page 10: Integrated Heating Capacity Correction Factor
• Outdoor Unit • RXYSQ-P8V1 Capacity tables 4 - 2 Integrated Heating Capacity Correction Factor RXYSQ-P8V1 INTEGRATED HEATING CAPACITY COEFFICIENT The heating capacity tables do not take account of the reduction in capacity, when frost has accumulated or while the defrosting operation is in progress. -
Page 11: Capacity Correction Factor
• Outdoor Unit • RXYSQ-P8V1 Capacity tables 4 - 3 Capacity Correction Factor • VRV Systems • RXYSQ-P8V1... - Page 12 • Outdoor Unit • RXYSQ-P8V1 Capacity tables 4 - 3 Capacity Correction Factor RXYSQ4,5P8V1 1. Rate of change in cooling capacity 2. Rate of change in heating capacity [ Diameter of pipes ] [ Explanation of symbols ] Model Liquid...
- Page 13 • Outdoor Unit • RXYSQ-P8V1 Capacity tables 4 - 3 Capacity Correction Factor RXYSQ6P8V1 1. Rate of change in cooling capacity 2. Rate of change in heating capacity [ Explanation of symbols ] [ Diameter of pipes ] Hp: Level difference (m) between indoor and outdoor units...
-
Page 14: Dimensional Drawings
• Outdoor Unit • RXYSQ-P8V1 Dimensional drawings 5 - 1 Dimensional Drawings RXYSQ-P8V1 Hole for anchor bolt 4-M12 1 Gas pipe connection A 2 Liquid connection pipe Ø9.5 À are 3 Service port (in the unit) (2x) 4 Electronic connection and grounding terminal M5 (in switch box) -
Page 15: Centre Of Gravity
• Outdoor Unit • RXYSQ-P8V1 Centre of gravity 6 - 1 Centre of Gravity 4D052604B • VRV Systems • RXYSQ-P8V1... -
Page 16: Piping Diagrams
• Outdoor Unit • RXYSQ-P8V1 Piping diagrams 7 - 1 Piping Diagrams RXYSQ-P8V1 Electronic expansion valve Double pipe Electronic heat exchanger expansion valve Filter Heat exchanger Pressure regulating valve Filter Service port Four way valve High pressure Service port sensor... -
Page 17: Wiring Diagrams
• Outdoor Unit • RXYSQ-P8V1 Wiring diagrams 8 - 1 Wiring Diagrams - Single Phase RXYSQ-P8V1 1N~50Hz 220-240V outdoor C/H SELECTOR Position of TO IN/D UNIT TO OUT/D UNIT compressor COOL/HEAT COMPONENT terminal LOCATION SELECTOR HEAT Wire entrance AIR CONTROL... -
Page 18: External Connection Diagrams
• Outdoor Unit • RXYSQ-P8V1 External connection diagrams 9 - 1 External Connection Diagrams RXYSQ-P8V1 < When the power source is supplied to each bp unit individually > < When the power source is connected in series between the units>... -
Page 19: Sound Data
• Outdoor Unit • RXYSQ-P8V1 Sound data 10 - 1 Sound Power Spectrum RXYSQ4P8V1 RXYSQ5P8V1 Octave band center frequency (Hz) Octave band center frequency (Hz) 3TW27647-3 3TW27637-3 NOTES NOTES dBA = A-weighted sound power level. (A-scale according to IEC) dBA = A-weighted sound power level. (A-scale according to IEC) -
Page 20: Sound Pressure Spectrum - Cooling
• Outdoor Unit • RXYSQ-P8V1 Sound data 10 - 2 Sound Pressure Spectrum - Cooling • VRV Systems • RXYSQ-P8V1... -
Page 21: Sound Pressure Spectrum - Heating
• Outdoor Unit • RXYSQ-P8V1 Sound data 10 - 3 Sound Pressure Spectrum - Heating • VRV Systems • RXYSQ-P8V1... -
Page 22: Installation
• Outdoor Unit • RXYSQ-P8V1 Installation 11 - 1 Installation Method • VRV Systems • RXYSQ-P8V1... -
Page 23: Refrigerant Pipe Selection
• Outdoor Unit • RXYSQ-P8V1 Installation 11 - 2 Refrigerant Pipe Selection 4PW68122-1_1 • VRV Systems • RXYSQ-P8V1... -
Page 24: Operation Range
• Outdoor Unit • RXYSQ-P8V1 Operation range 12 - 1 Operation Range 3D045713F • VRV Systems • RXYSQ-P8V1... - Page 25 All content is copy- righted by Daikin Europe N.V. Naamloze Vennootschap - Zandvoordestraat 300, B-8400 Oostende - Belgium - www.daikin.eu - BE 0412 120 336 - RPR Oostende...
