Page 1 Contents Connections Playback Settings Tips Appendix AVR-X2200W INTEGRATED NETWORK AV RECEIVER Owner’s Manual You can print more than one page of a PDF onto a single sheet of paper. Front panel Display Rear panel Remote Index...
Page 2: Table Of Contents
Contents Contents Connections Playback Settings Tips Appendix Accessories Connecting a playback device Inserting the batteries Connecting a set-top box (Satellite tuner/cable TV) Operating range of the remote control unit Connecting a DVD player or Blu-ray Disc player Features Connecting a video camcorder or game console High quality sound Connecting an iPod or USB memory device to the USB port High performance...
Page 3 Contents Connections Playback Settings Tips Appendix Playing an iPod Listening to Internet Radio Listening to music on an iPod Listening to Internet Radio iPod Browse Mode settings Playing the last played Internet Radio station Performing repeat playback Using vTuner to add Internet Radio stations to favorites Performing random playback Playing back files stored on a PC and NAS Playing a USB memory device...
Page 4 Contents Connections Playback Settings Tips Appendix AirPlay function Selecting a sound mode Playing songs from your iPhone, iPod touch or iPad Selecting a sound mode Playing iTunes music with this unit Direct playback Selecting multiple speakers (devices) Pure Direct playback Perform iTunes playback operations with the remote control unit Auto surround playback of this unit...
Page 5 Contents Connections Playback Settings Tips Appendix Settings Inputs Input Assign Menu map Source Rename Menu operations Hide Sources Inputting characters Source Level Using the keyboard screen Input Select Audio Speakers Dialog Level Adjust Audyssey ® Setup Subwoofer Level Adjust Procedure for speaker settings (Audyssey ®...
Page 6 Contents Connections Playback Settings Tips Appendix Tips Network Information Tips Connection Troubleshooting Wi-Fi Setup Resetting factory settings Settings Appendix Network Control Friendly Name About HDMI Diagnostics Video conversion function Maintenance Mode Playing back a USB memory devices General Playing back a Bluetooth device Language Playing back a file saved on a PC or NAS Playing back Internet Radio...
Page 7: Accessories
Playback Settings Tips Appendix Thank you for purchasing this Denon product. To ensure proper operation, please read this owner’s manual carefully before using the product. After reading this manual, be sure to keep it for future reference. Accessories Check that the following parts are supplied with the product.
Page 8: Inserting The Batteries
Contents Connections Playback Settings Tips Appendix Inserting the batteries NOTE 0 To prevent damage or leakage of battery fluid: 0 Do not use a new battery together with an old one. Remove the rear lid in the direction of the arrow and 0 Do not use two different types of batteries.
Page 9: Features
Contents Connections Playback Settings Tips Appendix Features High quality sound High performance With discrete circuit technology, the power amplifier provides 4K 60Hz input/output supported identical quality for all 7-channels (125 Watts x 7-channels) For optimum realism and stunning dynamic range, the power amplifier section features discrete power devices (not integrated circuitry).
Page 10 Contents Connections Playback Settings Tips Appendix Digital video processor upscales analog video signals (SD HDMI connections enable connection to various digital AV resolution) to HD (720p/1080p) and 4K (v p. 166) devices (8 inputs, 2 outputs) Up to 1080p Up scaling This unit is equipped with a 4K video upscaling function that allows analog video or SD (Standard Definition) video to be output via HDMI at 4K (3840 ×...
Page 11 Download the appropriate “Denon 2015 AVR Remote” for your iOS or Android devices. This unit needs to be connected to the same LAN or Wi-Fi (wireless LAN) network that the iPhone or iPod touch is connected to.
Page 12: Easy Operation
Contents Connections Playback Settings Tips Appendix Multi-Room audio (v p. 111) Easy operation GMAIN ZONEH GZONE2H “Setup Assistant” provides easy-to-follow setup instructions First select the language when prompted. Then simply follow the instructions displayed on the TV screen to set up the speakers, network, etc.
Page 13: Part Names And Functions
Contents Connections Playback Settings Tips Appendix Part names and functions Front panel MASTER VOLUME SOURCE SELECT TUNER ZONE2 ZONE2 MEDIA CBL/SAT Blu-ray ONLINE DIMMER STATUS PLAYER PRESET CH ON/OFF SOURCE QUICK SELECT PHONES AUX 1 - HDMI SETUP MIC Front panel Display Rear panel Remote...
Page 14 Contents Connections Playback Settings Tips Appendix C SOURCE SELECT knob This selects the input source. (v p. 63) MASTER VOLUME D Remote control sensor SOURCE SELECT This receives signals from the remote control unit. (v p. 8) E Display TUNER ZONE2 ZONE2 CBL/SAT...
Page 15 Contents Connections Playback Settings Tips Appendix N AUX1-HDMI connector This is used to connect HDMI output compatible devices such as video camcorders and game consoles. (v p. 54) MASTER VOLUME SOURCE SELECT O USB port (T) This is used to connect USB storages (such as USB memory devices) TUNER ZONE2 ZONE2...
Page 16: Display
Contents Connections Playback Settings Tips Appendix Display Q1 Q2 A Input mode indicators E Tuner reception mode indicators These light according to the audio input mode settings of each input These light up according to the reception conditions when the input source.
Page 17 Contents Connections Playback Settings Tips Appendix H Volume indicator I MUTE indicator This blinks while the sound is muted. (v p. 64) J Information display The input source name, sound mode, setting values and other information are displayed here. K Input signal indicators The respective indicator will light corresponding to the input signal.
Page 18: Rear Panel
Contents Connections Playback Settings Tips Appendix Rear panel w e r Front panel Display Rear panel Remote Index...
Page 19 Contents Connections Playback Settings Tips Appendix 0 The antenna clip can be removed from the rear panel. w er A Rotate the antenna clip 90 degrees to the left. B Pull the antenna clip out towards yourself. 0 The antenna clip is needed when transporting this unit. Keep it in a safe place.
Page 20 Contents Connections Playback Settings Tips Appendix F HDMI connectors Used to connect devices equipped with HDMI connectors. “Connection 1 : TV equipped with an HDMI connector and compatible with the ARC (Audio Return Channel)” (v p. 49) “Connection 2 : TV equipped with an HDMI connector and incompatible with the ARC (Audio Return Channel)”...
Page 21 Contents Connections Playback Settings Tips Appendix Q0 Q1 J PRE OUT connectors Used to connect a subwoofer with built-in amplifier or an external power amplifier. “Connecting the subwoofer” (v p. 34) “Connection 2 : Connection using an external amplifier” (v p. 135) K Component video connectors (COMPONENT VIDEO) Used to connect devices equipped with component video connectors.
Page 22: Remote Control Unit
Contents Connections Playback Settings Tips Appendix Remote control unit A ZONE SELECT buttons These switch the zone (MAIN ZONE, ZONE2) that is operated through the remote control unit. “Playback in ZONE2” (v p. 136) “Menu operations” (v p. 141) B Input source select buttons These selects the input source.
Page 23: Connections
Contents Connections Playback Settings Tips Appendix G BACK button This returns to the previous screen. H System buttons These perform playback related operations. Tuning up / Tuning down buttons (TUNE +, –) These select either FM broadcast or AM broadcast. (v p. 79) I QUICK SELECT buttons (1 –...
Page 24: Connections
Contents Connections Playback Settings Tips Appendix M POWER button (X) This turns the power on/off. “Turning the power on” (v p. 63) “Playback in ZONE2” (v p. 136) N ECO Mode button (G) This switches to ECO Mode. (v p. 205) O VOLUME buttons (df) These adjusts the volume level.
Page 25: Connections
Contents Connections Connections Playback Settings Tips Appendix o Contents o Cables used for connections Provide necessary cables according to the devices you want to Connecting speakers connect. Connecting a TV Connecting a playback device Speaker cable Connecting an iPod or USB memory device to the USB port Connecting an FM/AM antenna Connecting to a home network (LAN) Subwoofer cable...
Page 26: Connecting Speakers
Contents Connections Playback Settings Tips Appendix Connecting speakers Install speakers and connect them to this unit. (“Speaker installation” (v p. 26), “Speaker connection” (v p. 33)) Speaker installation Determine the speaker system depending on the number of speakers you Place the FRONT left and right speakers an are using and install each speaker and subwoofer in the room.
Page 27 Contents Connections Playback Settings Tips Appendix Place the FRONT HEIGHT left and right speakers FHL/FHR directly above the front speakers. Mount them as (Front height speaker close to the ceiling as possible and aim them left/right): towards the main listening position. Mount the TOP FRONT left and right speakers on TFL/TFR the ceiling slightly in front of your main listening...
Page 28 Contents Connections Playback Settings Tips Appendix About Dolby Atmos Enabled speakers Dolby Atmos Enabled speakers reflect the sound off the ceiling to allow the sound to come from over your head by using a special upward- pointing speaker that is placed on the floor. You can enjoy the Dolby Atmos 3D sound even in an environment where speakers cannot be installed on the ceiling.
Page 29 Contents Connections Playback Settings Tips Appendix Height speakers layout 0 This unit is compatible with Dolby Atmos and DTS:X which offers an even wider and deeper surround sensation. 0 Use the illustration below as a guide for how high each speaker should be installed.
Page 30: Surround Back Speakers
Contents Connections Playback Settings Tips Appendix o When 7.1-channel speakers are installed using o When 5.1-channel speakers are installed surround back speakers SW C 1:22° - 30° 2:120° Listening position 1:22° - 30° 2:90° - 110° 3:135° - 150° 0 When using a single surround back speaker, place it directly behind the listening position.
Page 31 Contents Connections Playback Settings Tips Appendix o Layout including height speakers and top n Top speaker layout example speakers Combination of 5.1-channel layout and top middle speakers. n Height speaker layout example Combination of 5.1-channel layout and front height speakers. Front panel Display Rear panel...
Page 32 Contents Connections Playback Settings Tips Appendix n Dolby Atmos Enabled speaker layout example Combination of 5.1-channel layout and front Dolby speakers. Front panel Display Rear panel Remote Index...
Page 33: Speaker Connection
Contents Connections Playback Settings Tips Appendix Speaker connection NOTE 0 Carry out the following settings when using a speaker with an impedance of 4 – 6 Here we connect the speakers in the room to this unit. Ω/ohms. This section explains how to connect them using typical examples. Press and hold the main unit’s ZONE2 SOURCE and STATUS at the same time for at least 3 seconds.
Page 34: Connecting The Speaker Cables
Contents Connections Playback Settings Tips Appendix o Connecting the speaker cables o Connecting the subwoofer Carefully check the left (L) and right (R) channels and + (red) and – Use a subwoofer cable to connect the subwoofer. Two subwoofers can (black) polarities on the speakers being connected to this unit, and be be connected to this unit.
Page 35 Contents Connections Playback Settings Tips Appendix o About the cable label (supplied) for channel Speaker Color identification FRONT L White FRONT R The channel display section for speaker terminals on the rear panel is CENTER Green color-coded for each channel to be identifiable. SURROUND L Light blue Attach the cable label corresponding to each speaker to each speaker...
Page 36 Contents Connections Playback Settings Tips Appendix Attach the cable label for each channel to its speaker cable as shown in the diagram. Refer to the table and attach the label to each speaker cable. Then, make connection so that the color of the speaker terminal matches that of the cable label.
Page 37: Speaker Configuration And "Amp Assign" Settings
Contents Connections Playback Settings Tips Appendix Speaker configuration and “Amp Assign” settings This unit has a built-in 7-channel power amplifier. In addition to the basic 5.1-channel system, a variety of speaker systems can be configured by changing the “Amp Assign” settings to suit the application, such as 7.1-channel systems, bi-amp connections and 2-channel systems for multi-zone playback. (v p.
Page 38 Contents Connections Playback Settings Tips Appendix o Standard configuration and connection 5.1-channel This serves as a basic 5.1-channel surround system. Front panel Display Rear panel Remote Index...
Page 39 Contents Connections Playback Settings Tips Appendix 7.1-channel (surround back) This 7.1-channel surround system is the same as a basic 5.1-channel system but with surround back speakers. 0 When using a single surround back speaker, connect it to the SURROUND BACK L terminal.
Page 40 Contents Connections Playback Settings Tips Appendix 7.1-channel (front height) This 7.1-channel surround system is the same as a basic 5.1-channel system but with front height speakers. Front panel Display Rear panel Remote Index...
Page 41 Contents Connections Playback Settings Tips Appendix 7.1-channel (top front) This 7.1-channel surround system is the same as a basic 5.1-channel system but with top front speakers. Front panel Display Rear panel Remote Index...
Page 42 Contents Connections Playback Settings Tips Appendix 7.1-channel (top middle) This 7.1-channel surround system is the same as a basic 5.1-channel system but with top middle speakers. Front panel Display Rear panel Remote Index...
Page 43 Contents Connections Playback Settings Tips Appendix 7.1-channel (front Dolby Atmos Enabled) This 7.1-channel surround system is the same as a basic 5.1-channel system but with front Dolby Atmos Enabled speakers. Front panel Display Rear panel Remote Index...
Page 44 Contents Connections Playback Settings Tips Appendix 7.1-channel (surround Dolby Atmos Enabled speaker) This 7.1-channel surround system is the same as a basic 5.1-channel system but with surround Dolby Atmos Enabled speakers. Front panel Display Rear panel Remote Index...
Page 45 Contents Connections Playback Settings Tips Appendix o Applied configuration and connection 5.1-channel (bi-amp connection of front speaker) This is a method of connecting separate amplifiers to the tweeter terminals and woofer terminals of bi-amp compatible speakers. This connection enables back EMF (power returned without being output) from the woofer to flow into the tweeter without affecting the sound quality, producing a higher sound quality.
Page 46 Contents Connections Playback Settings Tips Appendix 5.1-channel + front speaker of second unit This system enables switching playback between front speakers A and B as desired. FR (A) FL (A) FR (B) FL (B) Front panel Display Rear panel Remote Index...
Page 47 Contents Connections Playback Settings Tips Appendix 5.1-channel (MAIN ZONE) + 2-channel (ZONE2) This connection method constructs a 5.1-channel speaker system in the MAIN ZONE and a 2-channel system in ZONE2. MAIN ZONE ZONE2 ZONE2 ZONE2 ZONE2 ZONE2 Front panel Display Rear panel Remote Index...
Page 48: Connecting A Tv
Contents Connections Playback Settings Tips Appendix Connecting a TV Connect a TV to this unit so that the input video is output to the TV. You can also enjoy audio from the TV on this unit. How to connect a TV depends on the connectors and functions equipped on the TV. ARC (Audio Return Channel) function plays TV audio on this unit by sending the TV audio signal to this unit via HDMI cable.
Page 49: Connection 1 : Tv Equipped With An Hdmi Connector And Compatible With The Arc (Audio Return Channel)
Contents Connections Playback Settings Tips Appendix Connection 1 : TV equipped with an HDMI connector and compatible with the ARC (Audio Return Channel) Use an HDMI cable to connect a TV that is compatible with the ARC function to this unit. Set “HDMI Control”...
Page 50: Connection 2 : Tv Equipped With An Hdmi Connector And Incompatible With The Arc (Audio Return Channel)
Contents Connections Playback Settings Tips Appendix Connection 2 : TV equipped with an HDMI connector and incompatible with the ARC (Audio Return Channel) Use an HDMI cable to connect the TV to this unit. To listen to audio from TV on this unit, use an optical cable to connect the TV to this unit. OPTICAL HDMI Front panel...
Page 51: Connecting A Playback Device
Contents Connections Playback Settings Tips Appendix Connecting a playback device This unit is equipped with three types of video input connectors (HDMI, component video and composite video) and three types of audio input connectors (HDMI, digital audio and audio). Select input connectors on this unit according to the connectors equipped on the device you want to connect. If the device connected to this unit is equipped with an HDMI connector, it is recommended to use HDMI connections.
Page 52: Connecting A Set-Top Box (Satellite Tuner/Cable Tv)
Contents Connections Playback Settings Tips Appendix Connecting a set-top box (Satellite tuner/cable TV) This explanation uses the connection with a satellite tuner/cable TV STB as an example. Select the input connectors on this unit to match the connectors on the device that you want to connect to. (HDMI incompatible device) Satellite tuner/ Satellite tuner/...
Page 53: Connecting A Dvd Player Or Blu-Ray Disc Player
Contents Connections Playback Settings Tips Appendix Connecting a DVD player or Blu-ray Disc player This explanation uses the connection with a DVD player or Blu-ray Disc player as an example. Select the input connectors on this unit to match the connectors on the device that you want to connect to. (HDMI incompatible device) DVD player DVD player...
Page 54: Connecting A Video Camcorder Or Game Console
Contents Connections Playback Settings Tips Appendix Connecting a video camcorder or game console This explanation uses the connection with a video camcorders as an example. Connect a playback device to this unit, such as a video camcorder or game console. Video camcorder HDMI...
Page 55: Connecting An Ipod Or Usb Memory Device To The Usb Port
AUX - HDMI SETUP MIC 0 Denon does not guarantee that all USB memory devices will operate or receive power. When using a portable USB hard disk drive (HDD) which came with an AC adapter, use that device’s supplied AC adapter.
Page 56 Contents Connections Playback Settings Tips Appendix o Supported iPod/iPhone models • iPod classic • iPod nano • iPod touch • iPhone Front panel Display Rear panel Remote Index...
Page 57: Connecting An Fm/Am Antenna
Contents Connections Playback Settings Tips Appendix Connecting an FM/AM antenna Connect the antenna, tune in to a broadcast and then move the antenna to AM loop antenna the location where there is least noise. Then use tape, etc. to fix the antenna in this location.
Page 58 Contents Connections Playback Settings Tips Appendix o AM loop antenna assembly o Using the AM loop antenna Suspending on a wall Put the stand section through the bottom of the loop Suspend directly on a wall without assembling. antenna from the rear and bend it forward. Insert the projecting part into the square hole in the stand.
Page 59: Connecting To A Home Network (Lan)
Contents Connections Playback Settings Tips Appendix Connecting to a home network (LAN) This unit can connect to a network using a wired LAN or wireless LAN. Wired LAN You can connect this unit to your home network (LAN) to enable various types of playback and operations as described below.
Page 60: Wireless Lan
Contents Connections Playback Settings Tips Appendix Wireless LAN 0 When using this unit, we recommend you use a router equipped with the following When connecting to a wireless LAN network, stand the rod antenna for functions: Bluetooth/wireless LAN connection upright on the rear panel. 0 Built-in DHCP server See “Wi-Fi Setup”...
Page 61: Connecting The Power Cord
Contents Connections Playback Settings Tips Appendix Connecting the power cord After completing all the connections, insert the power plug into the power outlet. Power cord (supplied) To household power outlet (AC 230 V, 50/60 Hz) Front panel Display Rear panel Remote Index...
Page 62: Playback
Contents Connections Playback Playback Settings Tips Appendix o Contents Playback network audio/service Listening to Internet Radio Basic operation Playing back files stored on a PC and NAS Turning the power on AirPlay function Selecting the input source Spotify Connect function Adjusting the volume Convenience functions Turning off the sound temporarily (Muting)
Page 63: Basic Operation
Contents Connections Playback Settings Tips Appendix Basic operation Turning the power on POWER Press POWER X to turn on power to the unit. Input source select buttons 0 You can press the input source select button when the unit is in standby mode to turn on the power.
Page 64: Adjusting The Volume
Contents Connections Playback Settings Tips Appendix Adjusting the volume Playback a DVD player/Blu-ray Disc player Use VOLUME df to adjust the volume. The following describes the procedure for playing DVD player/Blu-ray Disc player. 0 The variable range differs according to the input signal and channel level setting. Prepare for playback.
Page 65: Playing An Ipod
Contents Connections Playback Settings Tips Appendix Playing an iPod You can use the USB cable provided with the iPod to connect the iPod with the unit’s USB port and enjoy music stored on the iPod. For information on the iPod models that can be played back with this unit, see “Supported iPod/iPhone models”...
Page 66: Listening To Music On An Ipod
0 Depending on the type of iPod and the software version, some functions may not operate. 0 Note that Denon will accept no responsibility whatsoever for any problems arising with the data on an iPod when using this unit in conjunction with the iPod.
Page 67: Ipod Browse Mode Settings
Contents Connections Playback Settings Tips Appendix iPod Browse Mode settings Operation buttons Function Playback / Pause In this mode, various lists and screens during playback on the iPod are Skip to previous track / Skip to next track displayed on the TV screen. (Press and hold) Fast-reverse/Fast-forward This section describes the steps up to playing back tracks on the iPod in “On-Screen”.
Page 68 Contents Connections Playback Settings Tips Appendix o Operations accessible through the option menu This can be operated when the “iPod Browse Mode” is set to “On- Screen”. (v p. 67) “iPod Browse Mode settings” (v p. 67) “Performing repeat playback” (v p. 69) “Performing random playback”...
Page 69: Performing Repeat Playback
Contents Connections Playback Settings Tips Appendix Performing repeat playback Performing random playback Press OPTION with “iPod Browse Mode” set to “On- Press OPTION with “iPod Browse Mode” set to “On- Screen”. Screen”. The option menu screen is displayed. The option menu screen is displayed. Use ui to select “Repeat”, then press ENTER.
Page 70: Playing A Usb Memory Device
Contents Connections Playback Settings Tips Appendix Playing a USB memory device Playing back music or viewing still picture (JPEG) files stored on a USB memory device. Only USB memory devices conforming to mass storage class standards can be played on this unit. This unit is compatible with USB memory devices in “FAT16”...
Page 71: Playing Files Stored On Usb Memory Devices
Use ui p to select the file to be played, then press NOTE ENTER. 0 Note that Denon will accept no responsibility whatsoever for any problems arising with the data on a USB memory device when using this unit in conjunction with the USB Playback starts.
Page 72 Contents Connections Playback Settings Tips Appendix o Operations accessible through the option menu “Performing repeat playback” (v p. 102) “Performing random playback” (v p. 102) “Searching content with keywords (Text Search)” (v p. 104) “Playing back music and a favorite picture at the same time (Slideshow)”...
Page 73: Listening To Music On A Bluetooth Device
Contents Connections Playback Settings Tips Appendix Listening to music on a Bluetooth device Music files stored on Bluetooth devices such as smartphones, digital music players, etc. can be enjoyed on this unit by pairing and connecting this unit with the Bluetooth device. Communication is possible up to a range of about 10 m.
Page 74: Playing Music From Bluetooth Device
Turn on Bluetooth from your mobile device’s this unit. settings menu, then select “Denon AVR-X2200W” when it appears in the device list. Play music using any app on your Bluetooth device. The Bluetooth device can also be operated with the remote Cancel control of this unit.
Page 75 Contents Connections Playback Settings Tips Appendix Operation buttons Function NOTE Playback / Pause 0 To operate the Bluetooth device with the remote control of this unit, the Bluetooth Skip to previous track / Skip to next track device needs to support the AVRCP profile. 0 The remote control of this unit is not guaranteed to work with all Bluetooth devices.
Page 76: Pairing With Other Bluetooth Devices
Contents Connections Playback Settings Tips Appendix Pairing with other Bluetooth devices 0 This unit can be paired with a maximum of 8 Bluetooth devices. When a 9th Pair a Bluetooth device with this unit. Bluetooth device is paired, it will be registered in place of the oldest registered device.
Page 77: Reconnecting To This Unit From A Bluetooth Device
Contents Connections Playback Settings Tips Appendix Reconnecting to this unit from a Bluetooth device After pairing is completed, the Bluetooth device can be connected without performing any operations on this unit. This operation also needs to be performed when switching the Bluetooth device for playback.
Page 78: Listening To Fm/Am Broadcasts
Contents Connections Playback Settings Tips Appendix Listening to FM/AM broadcasts You can use the built-in tuner of this unit to listen to FM broadcasts and AM broadcasts. Make sure the FM antenna and AM loop antenna are connected to this unit first.
Page 79: Listening To Fm/Am Broadcasts
Contents Connections Playback Settings Tips Appendix Listening to FM/AM broadcasts Use o p to select “FM” or “AM”, then press ENTER. When listening to an FM broadcast. Connect the antenna. (“Connecting an FM/AM antenna” (v p. 57)) When listening to an AM broadcast. Press TUNER to switch the input source to “Tuner”.
Page 80 Contents Connections Playback Settings Tips Appendix o Operations accessible through the option menu “Tuning in by entering the frequency (Direct Tune)” (v p. 81) “RDS search” (v p. 81) “PTY search” (v p. 82) “TP search” (v p. 83) “Radio Text” (v p. 83) “Changing the tune mode (Tune Mode)”...
Page 81: Tuning In By Entering The Frequency (Direct Tune)
Contents Connections Playback Settings Tips Appendix Tuning in by entering the frequency RDS search (Direct Tune) RDS is a broadcasting service which allows a station to send additional information along with the regular radio program signal. You can enter the receiving frequency directly to tune in. Use this function to automatically tune to FM stations that provide the RDS service.
Page 82: Pty Search
Contents Connections Playback Settings Tips Appendix PTY search Press OPTION when the input source is “Tuner”. The option menu screen is displayed. Use this function to find RDS stations broadcasting a designated program type (PTY). Use ui to select “PTY Search”, then press ENTER. PTY identifies the type of RDS program.
Page 83: Tp Search
Contents Connections Playback Settings Tips Appendix TP search Radio Text TP identifies programs that carry traffic announcements. RT allows RDS stations to send text messages that appear on the display. This allows you to easily find out the latest traffic conditions in your area “Radio text”...
Page 84: Changing The Tune Mode (Tune Mode)
Contents Connections Playback Settings Tips Appendix Changing the tune mode (Tune Mode) Tuning in to stations and presetting them automatically (Auto Preset You can change the mode for tuning into FM and AM broadcasts. If you Memory) cannot tune in automatically with “Auto” mode, change the mode to “Manual”...
Page 85: Presetting The Current Broadcast Station (Preset Memory)
Contents Connections Playback Settings Tips Appendix Presetting the current broadcast Channel Default settings 87.50 / 89.10 / 98.10 / 108.00 / 90.10 / 90.10 / 90.10 / station (Preset Memory) 1 – 8 90.10 MHz 90.10 / 90.10 / 90.10 / 90.10 / 90.10 / 90.10 / 90.10 / 90.10 Your favorite broadcast stations can be preset so that you can tune them 9 –...
Page 86: Specify A Name For The Preset Broadcast Station (Preset Name)
Contents Connections Playback Settings Tips Appendix Specify a name for the preset Use ui to select a name label, then press ENTER. broadcast station (Preset Name) The screen that lets you edit the Preset Name is displayed. If you select “Set Defaults”, then the unit returns to displaying the You can set the name to the preset broadcast station or change it.
Page 87: Skipping Preset Broadcast Stations (Preset Skip)
Contents Connections Playback Settings Tips Appendix Skipping preset broadcast stations To set the stations you want to skip by stations (Preset Skip) A Use o p to select the group of broadcast stations you want to skip. Perform auto preset memory to save all the broadcasting stations that can B Use ui to select the broadcast station you want to skip.
Page 88: Cancelling Preset Skip
Contents Connections Playback Settings Tips Appendix Cancelling Preset Skip While the “Preset Skip” screen is displayed, use o p to select a group containing a broadcast station to cancel the skip for. Use ui to select a broadcast station to cancel the skip for.
Page 89: Listening To Internet Radio
Contents Connections Playback Settings Tips Appendix Listening to Internet Radio Internet Radio refers to radio broadcasts distributed over the Internet. Internet Radio stations from around the world can be received. The Internet radio station list on this unit the database service provided by vTuner radio station.
Page 90: Listening To Internet Radio
Contents Connections Playback Settings Tips Appendix Listening to Internet Radio Use ui to select the search method for the radio station that you wish to playback and then press ENTER. Prepare for playback. Check the network environment, then turn on this unit’s power. Select the various regions.
Page 91: Playing The Last Played Internet Radio Station
Contents Connections Playback Settings Tips Appendix Playing the last played Internet Radio Use ui p to select the station, then press ENTER. station Playback starts once buffering reaches “100%”. Operation buttons Function Press INTERNET RADIO. Playback / Stop The source switches to “Internet Radio” and the last played radio ENTER (Press and hold) Stop station plays.
Page 92: Using Vtuner To Add Internet Radio Stations To Favorites
Contents Connections Playback Settings Tips Appendix Using vTuner to add Internet Radio Enter your E-mail address and a password of your stations to favorites choice. Select the search criteria (genre, region, language, There are many Internet Radio stations in the world, and this unit can tune etc.) of your choice.
Page 93: Playing Back Files Stored On A Pc And Nas
Contents Connections Playback Settings Tips Appendix Playing back files stored on a PC and NAS This unit can play back music files and playlists (m3u, wpl) stored on a PC and on Network Attached Storage (NAS) that supports DLNA. The network audio playback function of this unit connects to the server using technologies shown below.
Page 94: Applying Media Sharing Settings
Start up Windows Media Player 12 on the PC. Select “Media Sharing” in the “Library”. Select “More streaming options...” in the “Stream”. Click the “Share my media” check box, select “Denon AVR-X2200W”, and then click “Allow”. Select “Allowed” in the “Denon AVR-X2200W” drop- down list.
Page 95: Playing Back Files Stored On A Pc And Nas
Contents Connections Playback Settings Tips Appendix Playing back files stored on a PC and Use ui to select the server including the file to be played, then press ENTER. Use iu p to select the file, then press ENTER. Use this procedure to play music files, image files or playlists. Playback starts once buffering reaches “100%”.
Page 96 Contents Connections Playback Settings Tips Appendix o Operations accessible through the option menu 0 The display switches between track title, artist name, and album title each time the main unit’s STATUS is pressed. “Performing repeat playback” (v p. 102) 0 When a WMA (Windows Media Audio), MP3 or MPEG-4 AAC file includes album “Performing random playback”...
Page 97: Airplay Function
Contents Connections Playback Settings Tips Appendix AirPlay function Music files stored on your iPhone, iPod touch, iPad or iTunes can be played on this unit via the network. Router This unit 0 + is displayed on the menu screen while AirPlay is being operated. 0 Source input will be switched to “Online Music”...
Page 98: Playing Songs From Your Iphone, Ipod Touch Or Ipad
Contents Connections Playback Settings Tips Appendix Playing songs from your iPhone, iPod Playing iTunes music with this unit touch or iPad Install iTunes 10, or later, on a Mac or Windows PC that If you update your “iPhone/iPod touch/iPad” to iOS 4.2.1 or later, you can is connected to the same network as this unit.
Page 99: Selecting Multiple Speakers (Devices)
Contents Connections Playback Settings Tips Appendix Selecting multiple speakers (devices) Perform iTunes playback operations with the remote control unit of this unit It is possible to play iTunes songs on your home’s AirPlay compatible speakers (devices) other than those of this unit. With this unit’s remote control unit, you can perform iTunes song play, pause, and auto search (cue) operations.
Page 100: Spotify Connect Function
Contents Connections Playback Settings Tips Appendix Spotify Connect function Spotify is the world’s most popular streaming service. If you subscribe to Playing Spotify music with this unit Spotify Premium, you can control your new speaker with your phone or tablet. Because Spotify is built-in to your speaker, you can still take calls or Download the “Spotify App”...
Page 101: Convenience Functions
Contents Connections Playback Settings Tips Appendix Convenience functions This section explains how to use convenient functions that can be used for each input source. These functions can only be set in the MAIN ZONE. MAIN ONLINE MUSIC OPTION uio p ENTER Front panel Display...
Page 102: Performing Repeat Playback
Contents Connections Playback Settings Tips Appendix Performing repeat playback Performing random playback n Supported input sources: n Supported input sources : USB / Media Server / Bluetooth USB / Media Server / Bluetooth While content is playing, press OPTION. While content is playing, press OPTION. The option menu screen is displayed.
Page 103: Registering To Favorites
Contents Connections Playback Settings Tips Appendix Registering to Favorites Playing back content added to the “Save to Favorites” You can register a total of 100 favorites. n Supported input sources: Press ONLINE MUSIC. Internet Radio / Media Server Use uio p to select “Favorites”, then press ENTER. While content is playing, press OPTION.
Page 104: Deleting Content Added To Favorites
Contents Connections Playback Settings Tips Appendix Deleting content added to favorites Searching content with keywords (Text Search) Press ONLINE MUSIC. n Supported input sources : Use uio p to select “Favorites”, then press ENTER. USB / Internet Radio / Media Server Use ui to select the content you want to delete from While the content is playing, press OPTION.
Page 105 Contents Connections Playback Settings Tips Appendix Playing back music and a favorite picture at the same time (Slideshow) n Supported input sources : n Supported input sources : Internet Radio / Media Server Play back a still picture. Play back a still picture. Playing back still pictures stored on USB memory devices.
Page 106: Setting The Slideshow Interval
Contents Connections Playback Settings Tips Appendix Setting the Slideshow Interval 0 The “Slideshow Interval” settings are reflected for all input sources. Set the playback interval when playing back a slideshow of still picture (JPEG) files stored on a USB memory device or media server. n Supported input sources: USB / Media Server While the list is displayed, press OPTION.
Page 107 Contents Connections Playback Settings Tips Appendix Adjusting the volume of each channel to match the input source (Channel 0 Select “Reset” and press ENTER if you want to restore the adjustment values of the various channels to “0.0 dB” (default). Level Adjust) 0 Headphone volume can be adjusted when a headphone is connected.
Page 108: Adjusting The Tone (Tone)
Contents Connections Playback Settings Tips Appendix Adjusting the tone (Tone) Select “On” in step 3 and press i to select the sound range to be adjusted. Adjusts the tonal quality of the sound. Bass: Adjust bass. Press OPTION. Treble: Adjust treble. The option menu screen is displayed.
Page 109: Displaying Your Desired Video During Audio Playback (Video Select)
Contents Connections Playback Settings Tips Appendix Displaying your desired video during If you selected “On” in step 3, press i and select audio playback (Video Select) “Source”. Use o p to select the input source for video you want This unit can display video from a different source on TV during audio to play back, then press ENTER.
Page 110 Contents Connections Playback Settings Tips Appendix Adjusting the picture quality for your Use o p to select picture mode. viewing environment (Picture Mode) No picture quality adjustment is done Off: with this unit. Supported input sources : The standard mode suited for most Standard: CBL/SAT / DVD / Blu-ray / Game / AUX1 / living room viewing environments.
Page 111: Playing The Same Music In All Zones (All Zone Stereo)
Contents Connections Playback Settings Tips Appendix o Stopping the All Zone Stereo mode Playing the same music in all zones (All Zone Stereo) During playback in All Zone Stereo mode, press OPTION. You can play back the music being played back in MAIN ZONE The option menu screen is displayed.
Page 112: Selecting A Sound Mode
Contents Connections Playback Settings Tips Appendix Selecting a sound mode This unit allows you to enjoy various kinds of surround and stereo playback modes. Disc formats such as Blu-ray Disc and DVD, as well as being supported by digital broadcasting, and even by streaming movies and music from internet-based subscription services.
Page 113: Selecting A Sound Mode
Contents Connections Playback Settings Tips Appendix o Switching the sound mode Selecting a sound mode Press MOVIE, MUSIC or GAME to display a list of the sound modes that can be selected. Each time you press MOVIE, MUSIC or GAME, Press MOVIE, MUSIC or GAME to select a sound mode.
Page 114: Direct Playback
Contents Connections Playback Settings Tips Appendix Direct playback Pure Direct playback Sound recorded in source is played as is. This mode is for playback with higher sound quality than in Direct playback mode. Press PURE to select “Direct”. This mode turns off the main unit display and analog video circuit. Doing so suppresses noise sources that affect sound quality.
Page 115: Auto Surround Playback
Contents Connections Playback Settings Tips Appendix Auto surround playback This mode detects the type of input digital signal, and automatically selects the corresponding mode for playback. Perform stereo playback when the input signal is PCM. When the input signal is Dolby Digital or DTS, the music is played back according to the respective channel number.
Page 116 Contents Connections Playback Settings Tips Appendix o Description of sound mode types Dolby sound mode Sound mode type Description Dolby Surround This mode uses Dolby Surround Upmixer to extend various sources to natural and realistic multi channels for playback. Use ceiling speakers such as top middle speakers to realize a three-dimensional sound field. Dolby Digital This mode can be selected when playing sources recorded in Dolby Digital.
Page 117 Contents Connections Playback Settings Tips Appendix DTS sound mode Sound mode type Description DTS Surround This mode can be selected when playing sources recorded in DTS. This mode is suitable for playing discs recorded in DTS-ES. DTS ES Dscrt6.1 The surround back channel added using the discrete method is played as an independent channel. Since all channels are independent, the 360-degree spacial expressiveness and sound localization are enhanced.
Page 118 Contents Connections Playback Settings Tips Appendix Original sound mode Sound mode type Description Multi Ch Stereo This mode is for enjoying stereo sound from all speakers. Stereo audio (2-channel) sources are played back via the front (L/R) speakers, the surround speakers and surround back speakers (if connected).
Page 119 Contents Connections Playback Settings Tips Appendix Stereo sound mode Sound mode type Description Stereo This mode plays 2-channel stereo audio with no additional surround sound processing. Sound is output from the front left and right speakers, and subwoofer if connected. When multi-channel signals are inputted, they are mixed down to 2-channel audio and are played back with no additional surround sound processing.
Page 120 Contents Connections Playback Settings Tips Appendix o Sound mode that can be selected for each input signal The following sound modes can be selected using the MOVIE, MUSIC and GAME buttons. Adjust the sound field effect with the menu “Surround Parameter” to enjoy surround sound the way you like it. (v p. 145) Input signal Sound mode MOVIE button...
Page 121 Contents Connections Playback Settings Tips Appendix Input signal Sound mode MOVIE button MUSIC button GAME button Stereo Multi-channel Dolby Digital Dolby Digital Dolby Digital + Dolby Surround Dolby TrueHD Dolby TrueHD Dolby TrueHD + Dolby Surround Dolby Digital Plus Dolby Digital Plus Dolby Digital Plus + Dolby Surround Dolby Atmos Dolby Atmos...
Page 122 Contents Connections Playback Settings Tips Appendix Input signal Sound mode MOVIE button MUSIC button GAME button DTS-HD HI RES DTS-HD MSTR DTS-HD/ DTS Express DTS Express DTS-HD + Neural:X DTS:X DTS:X DTS:X MSTR Multi Ch In Multi Ch In 7.1 PCM multi-channel Multi In + Dolby Surround Multi Ch In + Neural:X...
Page 123 Contents Connections Playback Settings Tips Appendix o Views on the display S DVD A Shows a decoder to be used. In the case of the Dolby Digital Plus decoder, “H” is displayed. B Shows a decoder that creates sound output. “k”...
Page 124: Hdmi Control Function
Contents Connections Playback Settings Tips Appendix HDMI control function A recent addition to the HDMI standard is CEC (Consumer Electronics Control), which allows control signals from one device to communicate with another device via the HDMI cable connection. Setting procedure Enable the HDMI control function of this unit.
Page 125: Smart Menu Function
Contents Connections Playback Settings Tips Appendix Smart Menu function This function can be used to configure the settings of this unit, select an o Now Playing input source and set Tuner and Internet Radio stations using the TV remote control. Enjoy content from the input source currently selected on this unit.
Page 126: Setup Menu
Contents Connections Playback Settings Tips Appendix o Setup Menu Displays a setup menu for configuring the settings of this unit. o Quick Select Calls up the QUICK SELECT items registered to this unit. NOTE 0 If the “HDMI Control” or “Smart Menu” settings have been changed, always reset the power to connected devices after the change.
Page 127: Sleep Timer Function
Contents Connections Playback Settings Tips Appendix Sleep timer function You can have the power automatically switched to standby once a set time has elapsed. This is convenient for viewing and listening while going to sleep. The sleep timer function can be set for each zone. MAIN SLEEP ZONE2...
Page 128: Using The Sleep Timer
Contents Connections Playback Settings Tips Appendix o Checking the remaining time Using the sleep timer Press SLEEP when the sleep timer is in operation. The remaining time appears on the display. Press MAIN or ZONE2 to select the operating zone with the remote control.
Page 129: Quick Select Plus Function
Contents Connections Playback Settings Tips Appendix Quick select plus function Settings such as the input source, volume level and sound mode can be registered to the QUICK SELECT 1 - 4 buttons. You can simply press one of the registered QUICK SELECT buttons in MAIN subsequent playbacks to switch to the group of saved settings in a batch.
Page 130: Calling Up The Settings
Contents Connections Playback Settings Tips Appendix Calling up the settings Press MAIN or ZONE2 to select the operating zone with the remote control. The button for the selected zone is lit. Press QUICK SELECT. The Quick Select settings registered to the button you pressed are called up.
Page 131: Changing The Settings
Contents Connections Playback Settings Tips Appendix Changing the settings Press MAIN or ZONE2 to select the operating zone with the remote control. The button for the selected zone is lit. Set the items below to the settings you want to register.
Page 132: Web Control Function
Switch the “Network Control” setting to “Always On”. This unit (v p. 202) Check the IP address of this unit with “Information”. (v p. 196) Network/Information Friendly Name Denon AVR-X2200W DHCP Connection Wired (Ethernet) IP Address 192.168.100.19 zzzzzz-000000 MAC Address Checking the IP address.
Page 133 Contents Connections Playback Settings Tips Appendix Enter the IP address of this unit in browser’s address When the top menu is displayed, click on the menu box. item you want to operate. For example, if the IP address of this unit is “192.168.100.19”, enter “http://192.168.100.19”.
Page 134: Playback In Zone2 (Separate Room)
Contents Connections Playback Settings Tips Appendix Playback in ZONE2 (Separate room) You can operate this unit to enjoy audio in a room (ZONE2) that is different from the room where this unit is placed (MAIN ZONE). You can simultaneously play back the same source in both the MAIN ZONE and ZONE2. You can also play back separate sources in the MAIN ZONE and ZONE2.
Page 135 Contents Connections Playback Settings Tips Appendix o Connection 2 : Connection using an external amplifier The audio signals of this unit’s ZONE2 audio output connectors are output to the ZONE2 amplifiers and played on these amplifiers. MAIN ZONE ZONE2 Power This unit amplifier AUX IN...
Page 136: Playback In Zone2
Contents Connections Playback Settings Tips Appendix Playback in ZONE2 Press ZONE2 to set the operating zone to ZONE2 with the remote control. The ZONE2 button lights. POWER Press POWER X to turn on the ZONE2 power. ZONE2 The ( indicator on the display lights. Power in ZONE2 can be turned on or off by pressing ZONE2 ON/OFF on the main unit.
Page 137 Contents Connections Playback Settings Tips Appendix o Adjusting the volume Use VOLUME df to adjust the volume. At time of purchase, “Volume Limit” is set to “70 （–10 dB） ”. (v p. 208) 0 Turn MASTER VOLUME after pressing ZONE2 SOURCE on the main unit to adjust the volume.
Page 138: Menu Map
Contents Connections Playback Settings Settings Tips Appendix Menu map When using menu operations, connect this unit to a TV and operate this unit while viewing the TV. The recommended settings are configured for this unit by default. You can customize this unit based on your existing system and your preferences. Setting items Detailed items Description...
Page 139: Source Rename
Used to check the network connection. Maintenance Mode Used when receiving maintenance from a Denon service engineer or custom installer. This mode is not designed for use by the end user, and should only be used by a trained service technician or custom installation professional.
Page 140: Speakers
Information Shows information about this unit settings, input signals, etc. Usage Data Selects whether or not to send anonymous usage data to Denon. Setup Lock Protects settings from inadvertent changes. Begin Setup...
Page 141 Contents Connections Playback Settings Tips Appendix Menu operations MAIN Press MAIN on the remote control unit to set the operating zone to the MAIN ZONE. The MAIN button lights. Press SETUP. The menu is displayed on the TV screen. Use ui p to select the menu to be set or operated, then press ENTER.
Page 142: Inputting Characters
Contents Connections Playback Settings Tips Appendix Inputting characters On this unit, you can change the name displayed on the following screens to the names that you prefer. Preset Name (v p. 86) Text Search (v p. 104) Source Rename (v p. 172) Friendly Name (v p.
Page 143 Contents Connections Playback Settings Tips Appendix Using the keyboard screen Display the screen for inputting characters. Press ENTER to move the cursor to the character that you wish to change. GExampleH “Source Rename” screen Each time ENTER is pressed, the cursor moves by one character.
Page 144: Subwoofer Level
Contents Connections Playback Settings Tips Appendix Audio Make audio-related settings. Dialog Level Adjust Subwoofer Level Adjust This setting adjusts the output level to clarify the dialogue output from the This setting adjusts the volume level for the subwoofer. center channel. o Subwoofer Level Adjust o Dialog Level Adjust Set whether to adjust the subwoofer level.
Page 145 Contents Connections Playback Settings Tips Appendix o Loudness Management Surround Parameter This sets whether to output as specified in “Dynamic Compression” or You can adjust the surround audio sound field effects to match your output directly without compressing the dynamic range of audio preferences.
Page 146 Contents Connections Playback Settings Tips Appendix o Dynamic Compression o Low Frequency Effects Compress dynamic range (difference between loud and soft sounds). Adjust the low frequency effects level (LFE). Automatic dynamic range compression Auto: -10 dB – 0 dB (Default : 0 dB) on/off control according to source.
Page 147: Delay Time
Contents Connections Playback Settings Tips Appendix o Center Spread o Delay Time Center spread expands the center channel signal to left and right front Adjust the audio delay time against video to extend the sound field speakers to create a wider frontal audio image for the listener. It is image.
Page 148 Contents Connections Playback Settings Tips Appendix o Room Size o Subwoofer Determine size of acoustic environment. Turn subwoofer output on and off. Small: Simulate acoustics of a small room. The subwoofer is used. (Default): Simulate acoustics of a medium-small Medium small: room.
Page 149 Contents Connections Playback Settings Tips Appendix Restorer 0 This item can be set with analog signals or PCM signal (Sample Rate = Compressed audio formats such as MP3, WMA (Windows Media Audio) 44.1/48 kHz) is input. and MPEG-4 AAC reduce the amount of data by eliminating signal 0 This item default setting for “Online Music”, “iPod/USB”...
Page 150 Contents Connections Playback Settings Tips Appendix o Limit Audio Delay Make a setting for maximum volume. Compensates for incorrect timing between video and audio. 60 (–20 dB) / 70 (–10 dB) / 80 (0 dB) 0 ms – 200 ms (Default : 0 ms) Off (Default) o Power On Level 0 Audio Delay for game mode can be set when “Video Mode”...
Page 151 Contents Connections Playback Settings Tips Appendix o Mute Level Audyssey ® Set the amount of attenuation when muting is on. Set Audyssey MultEQ XT, Audyssey Dynamic EQ and Audyssey ® ® Full Dynamic Volume . These can be selected after Audyssey Setup has ®...
Page 152 Contents Connections Playback Settings Tips Appendix o Dynamic EQ o MultEQ ® Solves the problem of deteriorating sound quality as volume is MultEQ ® XT compensates for both time and frequency characteristics decreased by taking into account human perception and room of the listening area based on Audyssey ®...
Page 153: Dynamic Volume
Contents Connections Playback Settings Tips Appendix o Reference Level Offset o Dynamic Volume Solves the problem of large variations in volume level between TV, Audyssey Dynamic EQ ® is referenced to the standard film mix level. It movies and other content (between quiet passages and loud makes adjustments to maintain the reference response and surround passages, etc.) by automatically adjusting to the user’s preferred envelopment when the volume is turned down from 0 dB.
Page 154: Speaker Selection
Contents Connections Playback Settings Tips Appendix o When using headphones Graphic EQ n Headphone EQ Uses the graphic equalizer to adjust the tone of each speaker. Set whether to use the graphic equalizer for headphones or not. Use the graphic equalizer for 0 Speakers for which “Graphic EQ”...
Page 155 Contents Connections Playback Settings Tips Appendix o Adjust EQ o Curve Copy Adjust tonal balance for each frequency band. Copy the Flat correction curve created in the Audyssey ® Setup. 1. Select the speaker. 2. Select the adjustment frequency band. 0 “Curve Copy”...
Page 156 Contents Connections Playback Settings Tips Appendix Video Make video-related settings. o Picture Mode Picture Adjust Select the desired picture mode according to the video content and Picture quality can be adjusted. your viewing environment. The standard mode suited for most living Standard: room viewing environments.
Page 157 Contents Connections Playback Settings Tips Appendix o Contrast Adjust picture contrast. 0 The two special adjustment modes, ISF Day and ISF Night, should be used by a certified technician to adjust the color calibration to match the installation -50 – +50 (Default : 0) conditions.
Page 158: Noise Reduction
Contents Connections Playback Settings Tips Appendix o Noise Reduction HDMI Setup Reduce overall video noise. Make settings for HDMI video/audio output. Low / Medium / High / Off (Default : Off) NOTE 0 When “HDMI Control” and “HDMI Pass Through” is set to “On”, it consumes more o Enhancer standby power.
Page 159: Hdmi Audio Out
Contents Connections Playback Settings Tips Appendix o HDMI Audio Out o Video Output Select HDMI audio output device. Select the HDMI monitor connector to be used. Play back through speakers connected to The presence of a TV connected to the (Default): the unit.
Page 160: Hdmi Control
Contents Connections Playback Settings Tips Appendix o HDMI Control o ARC You can link operations with devices connected to HDMI and On the TV connected to the HDMI MONITOR 1 connector, set whether compatible with HDMI Control. to receive sound from the TV via HDMI. Use HDMI control function.
Page 161 Contents Connections Playback Settings Tips Appendix o HDMI Pass Through o Pass Through Source Selects how this unit will transmit HDMI signals to the HDMI output in Sets the HDMI connector that inputs HDMI signals when in standby. standby power mode. Last The most recently used input source will (Default):...
Page 162 Contents Connections Playback Settings Tips Appendix o TV Audio Switching o Power Off Control Sets automatic switching to the “TV Audio” input when a TV connected Links the power standby of this unit to external devices. via HDMI sends an appropriate CEC control command to the AVR. If power to a connected TV is turned off independently of the input source, power Select the “TV Audio”...
Page 163 Contents Connections Playback Settings Tips Appendix o Power Saving o Smart Menu If “TV Speaker” is set as the audio output setting of your TV, this unit is This function can be used to configure the settings of this unit, select automatically set to standby mode to reduce power consumption.
Page 164: Video Mode
Contents Connections Playback Settings Tips Appendix o Video Mode Output Settings Configure the video processing method to match the type of video Makes settings for video output. content. Auto Process video automatically based on (Default): the HDMI content information. 0 Can be set when “HDMI”, “COMP” or “VIDEO” is assigned for each input source. (v p.
Page 165: Video Conversion
Contents Connections Playback Settings Tips Appendix o Video Conversion o i/p Scaler The input video signal is converted automatically in conjunction with Set the video input signal to be subjected to i/p scaler processing. the connected TV. (v p. 240) i/p Scaler will convert the resolution of the input video signal to the value set in “Resolution”.
Page 166 Contents Connections Playback Settings Tips Appendix o Resolution n When the input source is set to “iPod/USB” and “Online Music” Set the output resolution. You can set “Resolution” separately for HDMI output of the analog video input and HDMI input. Use i/p scaler function.
Page 167: Progressive Mode
Contents Connections Playback Settings Tips Appendix o Progressive Mode o Aspect Ratio Set an appropriate progressive conversion mode for the source video Set the aspect ratio for the video signals output to the HDMI. signal. 16:9 Output at 16:9 aspect ratio. The video signal is automatically (Default): Auto...
Page 168 Contents Connections Playback Settings Tips Appendix o Now Playing On Screen Display Sets the display time for the playback display when the input source is Select the on-screen display user interface preferences. “Online Music”, “iPod/USB”, “Bluetooth” or “Tuner”. o Volume Always On Show display continuously.
Page 169 Contents Connections Playback Settings Tips Appendix TV Format Set the video signal format to be output for the TV you are using. o Format Select PAL output. (Default): NTSC: Select NTSC output. 0 “Format” can also be set by the following procedure. However, the menu screen is not displayed.
Page 170 Contents Connections Playback Settings Tips Appendix Inputs Perform settings related to input source playback. You do not have to change the settings to use the unit. Make settings when needed. Input Assign 0 By default, each item is set as follows. By making connections as indicated by the input sources printed on the Input connector audio/video input connectors of this unit, you can just press one of the...
Page 171 Contents Connections Playback Settings Tips Appendix o HDMI o ANALOG Set this to change the HDMI input connectors assigned to the input Set this to change the analog audio input connectors assigned to the sources. input sources. Assign a analog audio input connector to 1 / 2 / 3 / 4 / 5 / 6 / 7 / Assign an HDMI input connector to the 1 / 2 / 3 / 4:...
Page 172 Contents Connections Playback Settings Tips Appendix o VIDEO Source Rename Set this to change the composite video input connectors assigned to Change the display name for input source. the input sources. This is convenient when the name of your device and the input source Assign the video input connector to the name of this unit are different.
Page 173: Input Mode
Contents Connections Playback Settings Tips Appendix Hide Sources Input Select Remove from the display input sources that are not used. Set the audio input mode and decode mode of each input source. The input modes available for selection may vary depending on the input Show Use this source.
Page 174 Contents Connections Playback Settings Tips Appendix o Decode Mode Set the audio decode mode for input source. It is normally recommended to set the audio input mode to “Auto”. But we recommend changing it to “PCM” or “DTS” if the start of the source is clipped or noise occurs.
Page 175 Contents Connections Playback Settings Tips Appendix Speakers The acoustic characteristics of the connected speakers and listening room are measured and the optimum settings are made automatically. This is called “Audyssey ® Setup”. You do not have to perform Audyssey Setup when you have already performed “Speaker Calibration” in “Setup Assistant”. ®...
Page 176 Contents Connections Playback Settings Tips Appendix o About the main listening position NOTE The main listening position is the position where listeners would 0 Make the room as quiet as possible. Background noise can disrupt the room measurements. Close windows and turn off the power on electronic devices normally sit or where one would normally sit alone within the listening (radios, air conditioners, fluorescent lights, etc.).
Page 177 Contents Connections Playback Settings Tips Appendix Procedure for speaker settings Attach the Sound calibration microphone to the supplied microphone stand or own tripod and install it (Audyssey ® Setup) at the main listening position. When installing the Sound calibration microphone, point the tip of Preparation the microphone toward the ceiling and adjust the height to match the height of the ears of a listener in a seated position.
Page 178 Contents Connections Playback Settings Tips Appendix Connect the Sound calibration microphone to the Select “Start”, then press ENTER. SETUP MIC jack of this unit. Audyssey ® Setup can also make the following settings. Amp Assign The signals output from the SURROUND BACK speaker terminals can be switched in accordance with your speaker environment.
Page 179 Contents Connections Playback Settings Tips Appendix When the following screen is displayed, select “Begin When the detected speaker is displayed, select “Next” Test” and then press ENTER. and then press ENTER. Start the measurement of the first position. Audyssey Setup Speaker Detection Audyssey Setup Select “Begin Test”...
Page 180 Contents Connections Playback Settings Tips Appendix Move the Sound calibration microphone to position 2, Repeat step 8, measuring positions 3 to 8. select “Continue”, then press ENTER. The measurement of the second position starts. Measurements can be made in up to eight positions. 0 To skip measuring the fourth and subsequent listening position, press o to select “Complete”...
Page 181 Contents Connections Playback Settings Tips Appendix When the analysis and storage ends, unplug the Sound Perform the settings for Audyssey Dynamic EQ ® calibration microphone from the SETUP MIC jack on the Audyssey Dynamic Volume ® main unit and then press “Next”. The following screen is displayed during the analysis.
Page 182 Contents Connections Playback Settings Tips Appendix Select “Details” and press ENTER to verify the measurement results. Subwoofers may measure a greater reported distance than the actual distance due to added electrical delay common in subwoofers. NOTE 0 Do not change the speaker connection or subwoofer volume after Audyssey ®...
Page 183 Contents Connections Playback Settings Tips Appendix Error messages An error message is displayed if Audyssey ® Setup could not be completed due to speaker placement, the measurement environment, etc. If an error message is displayed, check the relevant items and perform the necessary measures. Be sure to turn off the power before checking speaker connections. Examples Error details Measures...
Page 184 Contents Connections Playback Settings Tips Appendix Retrieving Audyssey ® Setup settings If you set “Restore...” to “Restore”, you can return to Audyssey Setup ® measurement result (value calculated at the start by MultEQ XT) even ® when you have changed each setting manually. Audyssey Setup Your AV receiver can automatically measure the acoustics of your room then optimize your speakers using the included...
Page 185: Manual Setup
Contents Connections Playback Settings Tips Appendix Manual Setup Amp Assign Perform when setting the speakers manually or when changing settings Select the power amplifier usage method to match your speaker system. made in Audyssey ® Setup. See “Speaker configuration and “Amp Assign” settings” (v p. 37) regarding the speaker configuration and connection.
Page 186: Speaker Config
Contents Connections Playback Settings Tips Appendix Speaker Config. Setting to assign the unit’s built-in power ZONE2: amplifier for ZONE2 and output the audio in stereo. Select whether or not speakers are present, playback capacity for low bass frequencies and speaker size. Setting to use the front speakers via the Bi-Amp: bi-amp connection.
Page 187 Contents Connections Playback Settings Tips Appendix o Center o Surround Set the presence and size of the center speaker. Set the presence and size of the surround speakers. Use a large speaker that can adequately Use a large speaker that can adequately Large: Large: play back very low bass frequencies.
Page 188 Contents Connections Playback Settings Tips Appendix o Surr. Back o Front Height Set the presence, size and number of surround back speakers. Set the presence and size of the front height speakers. Use a large speaker that can adequately Use a large speaker that can adequately Large: Large: play back very low bass frequencies.
Page 189 Contents Connections Playback Settings Tips Appendix o Top Front o Top Middle Set the presence and size of the top front speakers. Set the presence and size of the top middle speakers. Use a large speaker that can adequately Use a large speaker that can adequately Large: Large: play back very low bass frequencies.
Page 190 Contents Connections Playback Settings Tips Appendix o Front Dolby o Surround Dolby Set the presence and size of the front Dolby speakers. Set the presence and size of the surround Dolby speakers. Use a large speaker that can adequately Use a large speaker that can adequately Large: Large: play back very low bass frequencies.
Page 191: Distances
Contents Connections Playback Settings Tips Appendix o Set the distance Distances 0.00 m – 18.00 m / 0.0 ft – 60.0 ft Set distance from listening position to speakers. Measure beforehand the distance from the listening position to each speaker. 0 The speakers that can be selected differ depending on the “Amp Assign”...
Page 192: Levels
Contents Connections Playback Settings Tips Appendix o Dolby Speaker Setup Levels Set the distance between the Dolby Atmos Enabled speaker and the Set the volume of the test tone to be the same at the listening position ceiling. when it is output from each speaker. 0.90 m - 3.30 m / 3.0 ft - 11.0 ft o Test Tone Start (Default : 1.80 m / 6.0 ft)
Page 193: Front Speaker
Contents Connections Playback Settings Tips Appendix o Set the crossover frequency Crossovers 40 Hz / 60 Hz / 80 Hz / 90 Hz / 100 Hz / 110 Hz / 120 Hz / 150 Hz / Set in accordance with the lower limit frequency of the base frequencies 200 Hz / 250 Hz (Default : 80 Hz) that can be played back through each speaker.
Page 194 Contents Connections Playback Settings Tips Appendix o LPF for LFE Bass Set LFE signal playback range. Set this when you want to change the Set subwoofer and LFE signal range playback. playback frequency (low pass filter point) of the subwoofer. o Subwoofer Mode 80 Hz / 90 Hz / 100 Hz / 110 Hz / 120 Hz / 150 Hz / 200 Hz / 250 Hz (Default : 120 Hz)
Page 195 Contents Connections Playback Settings Tips Appendix Front Speaker Set the front speaker A/B to use for every sound mode. Front speaker A is used. (Default): Front speaker B is used. A+B : Both front speakers A and B are used. 0 This can be set when “Assign Mode”...
Page 196: Tips
Contents Connections Playback Settings Tips Appendix Network To use this unit by connecting it to a home network (LAN), you must configure network settings. If you set up your home network (LAN) via DHCP, set “DHCP” to “On”. (Use the default setting.) This allows this unit to use your home network (LAN). When assigning an IP address to each device manually, you need to assign an IP address to this unit using the “IP Address”...
Page 197: Wi-Fi Setup
Contents Connections Playback Settings Tips Appendix o Connect Using Wi-Fi Setup Select the method for connecting to the home network (LAN). Connect to a wireless LAN (Wi-Fi) router. Wired (Ethernet): Use a LAN cable to connect to a network. The router can be connected in the following ways. Select the connection Use the wireless LAN (Wi-Fi) function to method to suit your home environment.
Page 198 2. Check that your iOS device is connected to the wireless LAN There are two ways to connect, using the push button method or the (Wi-Fi) router and select “Denon AVR-X2200W” from “SET UP PIN code method. Select the connection method to match your router.
Page 199 (SSID). seconds when the power of the unit is on. 2. Connect the wireless LAN of the PC or tablet used to “Denon AVR-X2200W” Select the encryption method according when the message “Connect your Wi-Fi device to Wi-Fi network called “Denon...
Page 200: Subnet Mask
Contents Connections Playback Settings Tips Appendix o DHCP Settings Selects how to connect to the network. Configure the proxy settings and IP address. Configure the network settings If you are using a broadband router (DHCP function), the information (Default): automatically from your router. required for network connection such as the IP address will be automatically configured since the DHCP function is set to “On”...
Page 201: Default Gateway
Contents Connections Playback Settings Tips Appendix o Default Gateway o Port When connected to a gateway (router), input its IP address. Enter port number. o Primary DNS, Secondary DNS 0 If you cannot connect to the Internet, recheck the connections and settings. If there is only one DNS address indicated in the documentation (v p.
Page 202: Friendly Name
Home Theater / Living Room / Family Room / Guest Room / Kitchen / Dining Room / Master Bedroom / Bedroom / Den / 0 When using the web control function or Denon 2015 AVR Remote, use with the Office / Other “Network Control”...
Page 203: Physical Connection
Contents Connections Playback Settings Tips Appendix o Internet Access Diagnostics Checks whether this unit has access to the Internet (WAN). Used to check the network connection. o Physical Connection Failed to connect to the Internet. Check Error: the Internet connection environment or Checks the physical LAN port connection.
Page 204 Ordinarily, this mode isn’t suitable for use by the end user, only by a trained service technician or custom installation professional. NOTE 0 Only use this function if so instructed by a Denon serviceperson or installer. Front panel Display Rear panel...
Page 205: Eco Mode
Contents Connections Playback Settings Tips Appendix General Make various other settings. Language Set the language for display the menu on the TV screen. Configure the settings of the ECO Mode and auto standby mode. English / Deutsch / Français / Italiano / Español / Nederlands / o ECO Mode Svenska / Pусский...
Page 206: On Screen Display
Contents Connections Playback Settings Tips Appendix o Power On Default o On Screen Display Set the mode to ECO when the power is on. Display the power consumption of this unit using a meter on the TV screen. The ECO Mode will be set to the previous Last setting before the power was switched Always display the meter on the TV...
Page 207: Auto Standby
Contents Connections Playback Settings Tips Appendix o Auto Standby n ZONE2 When there are no operations for a certain period of time as set here, Set so the unit power automatically switches to standby. the power is automatically shut off even if there is audio or video input. n MAIN ZONE Put ZONE2 in the standby state after 8 hours:...
Page 208: Volume Level
Contents Connections Playback Settings Tips Appendix o Volume Level ZONE2 Setup Set the volume output level. Makes settings for audio playback with ZONE2. Variable Volume can be adjusted. (Default): 0 Values set for “Volume Limit” and “Power On Volume” are displayed according to Volume is fixed at the desired level.
Page 209 Contents Connections Playback Settings Tips Appendix o Power On Volume Zone Rename Define the volume setting that is active when the power is turned on. Change the display title of each zone to one you prefer. Last Use the memorized setting from the last MAIN ZONE / ZONE2 (Default): session.
Page 210 Contents Connections Playback Settings Tips Appendix Front Display Makes settings related to the display on this unit. o Dimmer Adjust the display brightness of this unit. Bright Normal display brightness. (Default): Dim: Reduced display brightness. Dark: Very low display brightness. Off: Turns the display off.
Page 211 Contents Connections Playback Settings Tips Appendix o Notifications Firmware When the latest firmware is available, a notification message is Checks for the latest firmware information about updates and upgrades, displayed on the TV screen at power on. updates the firmware, and sets up the notification message display for The notification message is displayed for about 40 seconds when the updates and upgrades.
Page 212 0 Information regarding the “Update” function and “Add New Feature” will be procedure. announced on the Denon website each time related plans are defined. The ID number can also be displayed by pressing and holding the main unit’s TUNER PRESET CH + and STATUS for at least 3 seconds.
Page 213 Contents Connections Playback Settings Tips Appendix o Video Information Show the HDMI input/output signals and HDMI monitor information for Show information about this unit settings, input signals, etc. MAIN ZONE. o Audio HDMI Signal Info. Resolution / Color Space / Pixel Depth Show the audio information for MAIN ZONE.
Page 214 Usage Data Displays and sets notifications. To help us improve our products and customer service, Denon collects Also, sets whether or not to display the notification when the power is anonymous information about how you use your AV receiver (such as turned on.
Page 215 Contents Connections Playback Settings Tips Appendix Setup Lock Protect settings from inadvertent changes. o Lock Turn protection on. Turn protection off. (Default): 0 When cancelling the setting, set “Lock” to “Off”. NOTE 0 When “Lock” is set to “On”, no setting items are displayed except for “Setup Lock”.
Page 216: Limiting The Operating Zone With The Remote Control
Contents Connections Playback Settings Tips Appendix Limiting the operating zone with the remote control ZONE2 operations can be disabled using the remote control. Press and hold ZONE2 and SETUP. ZONE2 The MAIN and ZONE2 buttons blink. o Canceling the settings Press and hold ZONE2 and SETUP while configuring the setting.
Page 217: Troubleshooting
Contents Connections Playback Settings Tips Tips Appendix o Contents Troubleshooting Power does not turn on / Power is turned off Tips Operations cannot be performed through the remote control unit I want the volume not to become too loud by mistake Display on this unit shows nothing I want to keep the volume at the same level when I turn the power on No sound comes out...
Page 218 Contents Connections Playback Settings Tips Appendix Tips I want the volume not to become too loud by mistake Set the volume upper limit for “Volume Limit” in the menu beforehand. This prevents children or others from increasing the volume too much by mistake. You can set this for each zone.
Page 219 Contents Connections Playback Settings Tips Appendix I want to set the optimized listening environment after changing the configuration/position of the speakers or changing a speaker to a new one. Perform Audyssey ® Setup. This automatically makes the optimized speaker settings for the new listening environment. (v p. 175) I want to combine a desired video with the current music Set “Video Select”...
Page 220: Troubleshooting
Contents Connections Playback Settings Tips Appendix Troubleshooting If a problem should arise, first check the following: 1. Are the connections correct? 2. Is the set being operated as described in the owner’s manual? 3. Are the other devices operating properly? If this unit does not operate properly, check the corresponding symptoms in this section.
Page 221 Contents Connections Playback Settings Tips Appendix o Power does not turn on / Power is turned off Symptom Cause / Solution Page Power does not turn on. Check whether the power plug is correctly inserted into the power outlet. Power automatically turns The sleep timer is set.
Page 222: Operations Cannot Be Performed Through The Remote Control Unit
Contents Connections Playback Settings Tips Appendix o Operations cannot be performed through the remote control unit Symptom Cause / Solution Page Operations cannot be Batteries are worn out. Replace with new batteries. performed through the Operate the remote control unit within a distance of about 7 m from this unit and at an angle of within 30°. remote control unit.
Page 223: No Sound Comes Out
Contents Connections Playback Settings Tips Appendix o No sound comes out Symptom Cause / Solution Page No sound comes out of Check the connections for all devices. speakers. Insert connection cables all the way in. － Check that input connectors and output connectors are not reversely connected. －...
Page 224: Desired Sound Does Not Come Out
Contents Connections Playback Settings Tips Appendix o Desired sound does not come out Symptom Cause / Solution Page The maximum volume is set too low. Set the maximum volume using “Limit” on the menu. The volume does not increase. Appropriate volume correction processing is performed according to the input audio format and settings, －...
Page 225 Contents Connections Playback Settings Tips Appendix Symptom Cause / Solution Page DTS Neural:X cannot be selected when using the headphones. DTS Neural:X mode cannot － be selected. Dolby Surround mode Dolby Surround cannot be selected when using the headphones. － cannot be selected.
Page 226: Sound Is Interrupted Or Noise Occurs
Contents Connections Playback Settings Tips Appendix o Sound is interrupted or noise occurs Symptom Cause / Solution Page During playback from the When the transfer speed of the USB memory device is slow, sound may occasionally be interrupted. － Internet radio or USB The network communication speed is slow or the radio station is busy.
Page 227: Video Conversion Function
Contents Connections Playback Settings Tips Appendix o No video is shown on the TV Symptom Cause / Solution Page Check the connections for all devices. No picture appears. Insert connection cables all the way in. － Check that input connectors and output connectors are not reversely connected. －...
Page 228: The Menu Screen Is Not Displayed On The Tv
Contents Connections Playback Settings Tips Appendix o The menu screen is not displayed on the TV Symptom Cause / Solution Page The menu screen or status The menu screen is only displayed on this unit and a TV connected with an HDMI cable. If this unit is －...
Page 229: Ipod Cannot Be Played Back
Contents Connections Playback Settings Tips Appendix o iPod cannot be played back Symptom Cause / Solution Page iPod cannot be connected. When using iPod by connecting it to the USB port, some iPod variations are not supported. When iPod is connected by using a USB cable other than the genuine cable, iPod may not be －...
Page 230: Usb Memory Devices Cannot Be Played Back
Contents Connections Playback Settings Tips Appendix o USB memory devices cannot be played back Symptom Cause / Solution Page “No connection” is This unit cannot recognize the USB memory device. Disconnect and reconnect the USB memory device. displayed. Mass storage class compatible USB memory devices are supported. －...
Page 231: Bluetooth Cannot Be Played Back
Contents Connections Playback Settings Tips Appendix o File names on the iPod/USB memory device are not displayed properly Symptom Cause / Solution Page The file names are not Characters that cannot be displayed have been used. On this unit, characters that cannot be displayed －...
Page 232: The Internet Radio Cannot Be Played Back
Contents Connections Playback Settings Tips Appendix o The Internet radio cannot be played back Symptom Cause / Solution Page A list of broadcasting The LAN cable is not properly connected, or the network is disconnected. Check the connection status. stations is not displayed. Perform the network diagnostic mode.
Page 233: Music Files On Pc Or Nas Cannot Be Played Back
Contents Connections Playback Settings Tips Appendix o Music files on PC or NAS cannot be played back Symptom Cause / Solution Page Files stored on a computer Files are stored in a non-compatible format. Record in a compatible format. cannot be played. Files that are copyright protected cannot be played on this unit.
Page 234: The Hdmi Control Function Does Not Work
Contents Connections Playback Settings Tips Appendix o The HDMI control function does not work Symptom Cause / Solution Page The HDMI control function Check that “HDMI Control” in the menu is set to “On”. does not work. You cannot operate devices that are not compatible with the HDMI control function. In addition, depending on the connected device or the settings, the HDMI control function may not work.
Page 235: Cannot Connect To A Wireless Lan Network
Contents Connections Playback Settings Tips Appendix o Cannot connect to a wireless LAN network Symptom Cause / Solution Page Cannot connect to the The network name (SSID), password and encryption setting have not been set up correctly. Configure the network. network settings according to the setting details of this unit.
Page 236: Resetting Factory Settings
Contents Connections Playback Settings Tips Appendix Resetting factory settings Perform this procedure if the display is abnormal or if operations cannot be performed. Various settings are reset to the factory default values. Make settings again. Turn off the power using X. TUNER PRESET CH –...
Page 237: About Hdmi
Contents Connections Playback Settings Tips Appendix Appendix About HDMI HDMI is an abbreviation of High-Definition Multimedia Interface, which is an AV digital interface that can be connected to a TV or amplifier. This unit supports input and output of 3D (3 dimensional) video signals With the HDMI connection, high definition video and high quality audio of HDMI.
Page 238 Contents Connections Playback Settings Tips Appendix Auto Lip Sync ARC (Audio Return Channel) This function can automatically correct delay between the audio and This function transmits audio signals from the TV to this unit through video. the HDMI cable and plays back the audio from the TV on this unit Use a TV that is compatible with the Auto Lip Sync function.
Page 239 Contents Connections Playback Settings Tips Appendix o Supported audio formats Copyright protection system In order to play back digital video and audio such as BD video or DVD 2-channel Linear 2-channel, 32 kHz – 192 kHz, 16/20/24 bit video via HDMI connection, both this unit and the TV or player must to support the copyright protection system known as HDCP (High- Multi-channel 7.1-channel, 32 kHz –...
Page 240 Contents Connections Playback Settings Tips Appendix Video conversion function This unit automatically converts the input video signals as shown in the diagram before outputting them to the TV. This unit HDMI-compatible TV Video device Output Input (IN) (MONITOR OUT) Output HDMI signal HDMI signal HDMI connector...
Page 241 Contents Connections Playback Settings Tips Appendix This unit can convert the input video signals to the resolution that is set for “Resolution” in the menu before outputting them to the TV. (v p. 166) HDMI Output signal Input signal 480i/576i 480p/576p 720p 1080i 1080p...
Page 242: Playing Back A Usb Memory Devices
Contents Connections Playback Settings Tips Appendix Playing back a USB memory devices This unit is compatible with MP3 ID3-Tag (Ver. 2) standard. This unit can show the artwork that was embedded by using MP3 ID3-Tag Ver. 2.3 or 2.4. This unit is compatible with WMA META tags. If the image size (pixels) of an album artwork exceeds 500 ×...
Page 243: Playing Back A Bluetooth Device
Contents Connections Playback Settings Tips Appendix Playing back a Bluetooth device o Maximum number of playable files and folder The limits on the number of folders and files that can be displayed by This unit supports the following Bluetooth profile. this unit are as follows.
Page 244: Playing Back A File Saved On A Pc Or Nas
Contents Connections Playback Settings Tips Appendix Playing back a file saved on a PC or NAS This unit is compatible with MP3 ID3-Tag (Ver. 2) standard. This unit can show the artwork that was embedded by using MP3 ID3-Tag Ver. 2.3 or 2.4. This unit is compatible with WMA META tags.
Page 245: Playing Back Internet Radio
Contents Connections Playback Settings Tips Appendix Playing back Internet Radio Personal memory plus function The most recently used settings (input mode, HDMI output mode, sound o Playable broadcast station specifications mode, tone control, channel level, MultEQ ® XT, Dynamic EQ, Dynamic Volume, Restorer and audio delay, etc.) are saved for each input source.
Page 246: Sound Modes And Channel Output
Contents Connections Playback Settings Tips Appendix Sound modes and channel output S This indicates the audio output channels or surround parameters that can be set. D This indicates the audio output channels. The output channels depend on the settings of “Speaker Config.”. (v p. 186) Channel output Front Dolby Surround Dolby...
Page 247: Sound Modes And Surround Parameters
Contents Connections Playback Settings Tips Appendix Sound modes and surround parameters Surround Parameter Loudness Dynamic Dialog Low Frequency Sound mode Dialog Level Subwoofer Cinema EQ Management Compression Control Delay Time Adjust Level Adjust Direct/Pure Direct (2-channel) z5 Direct/Pure Direct (Multi-channel) z5 Stereo Multi Ch In Dolby Surround...
Page 248 Contents Connections Playback Settings Tips Appendix Surround Parameter Audyssey Tone Restorer Sound mode MultEQ® XT Dynamic EQ Dynamic Volume Room Size Center Spread DTS Neural:X Direct/Pure Direct (2-channel) z5 Direct/Pure Direct (Multi-channel) z5 Stereo Multi Ch In Dolby Surround DTS Neural:X Dolby Digital Dolby Digital Plus Dolby TrueHD...
Page 249 Contents Connections Playback Settings Tips Appendix z1 This item can be selected when a Dolby Digital, Dolby Digital Plus, Dolby TrueHD, Dolby Atmos, DTS:X or DTS signal is played. z2 This item can be selected when a Dolby TrueHD, Dolby Digital or DTS signal is played. z3 This item can be selected when a DTS:X signal that is compatible with the Dialog Control function is input.
Page 250: Types Of Input Signals, And Corresponding Sound Modes
Contents Connections Playback Settings Tips Appendix Types of input signals, and corresponding sound modes F This indicates the default sound mode. S This indicates the selectable sound mode. 2-channel signal Multi-channel signal Dolby Dolby Dolby Sound mode NOTE Analog / DTS ES DTS ES Dolby...
Page 251 Contents Connections Playback Settings Tips Appendix 2-channel signal Multi-channel signal Dolby Dolby Dolby Sound mode NOTE Analog / DTS ES DTS ES Dolby Dolby Digital DTS:X DTS-HD Digital Digital (-HD) Multi Express Dscrt6.1 Mtrx6.1 Atmos TrueHD (+/HD) Plus (EX) Multi Ch In Multi Ch In Multi Ch In + Dolby Surround Multi Ch In 7.1...
Page 252 Contents Connections Playback Settings Tips Appendix z1 This item can be selected when using any of the Surround Back, Front Height, Top Front, Top Middle, Front Dolby or Surround Dolby speaker. z2 This item can be selected when surround back speakers are used. z3 This item can be selected when the input signal is DTS-HD Master Audio.
Page 253: Explanation Of Terms
Contents Connections Playback Settings Tips Appendix Explanation of terms o Audyssey Audyssey MultEQ ® Audyssey MultEQ ® XT is a room equalization solution that calibrates any Audyssey Dynamic EQ ® audio system so that it can achieve optimum performance for every Dynamic EQ solves the problem of deteriorating sound quality as volume listener in a large listening area.
Page 254 Contents Connections Playback Settings Tips Appendix Dolby Atmos Stream Dolby Digital Plus Dolby Atmos content will be delivered to your Dolby Atmos enabled AV Dolby Digital Plus is an improved Dolby Digital signal format that is receiver via Dolby Digital Plus or Dolby TrueHD on Blu-ray Disc, compatible with up to 7.1-channels of discrete digital sound and also downloadable files and streaming media.
Page 255 Contents Connections Playback Settings Tips Appendix o DTS Dolby Speaker Technology (Dolby Atmos Enabled speakers) A convenient alternative to speakers built into the ceiling, Dolby Atmos Dialog Control Enabled speakers employ the ceiling above you as a reflective surface for Gives you control of the listening experience.
Page 256 Contents Connections Playback Settings Tips Appendix DTS-ES™ Discrete 6.1 DTS-HD High Resolution Audio DTS-ES™ Discrete 6.1 is a 6.1-channel discrete digital audio format DTS-HD High Resolution Audio is an improved version of the conventional adding a surround back (SB) channel to the DTS digital surround sound. DTS, DTS-ES and DTS 96/24 signals formats, compatible with sampling Decoding of conventional 5.1-channel audio signals is also possible frequencies of 96 or 48 kHz and up to 7.1-channels of discrete digital...
Page 257 Contents Connections Playback Settings Tips Appendix o Audio THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND CONTRIBUTORS “AS IS” AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED ALAC (Apple Lossless Audio Codec) WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A This is a codec for lossless audio compression method developed by PARTICULAR PURPOSE ARE DISCLAIMED.
Page 258 Contents Connections Playback Settings Tips Appendix MPEG (Moving Picture Experts Group), MPEG-2, MPEG-4 Speaker impedance These are the names for digital compression format standards used for This is an AC resistance value, indicated in Ω (ohms). the encoding of video and audio. Video standards include “MPEG-1 Greater power can be obtained when this value is smaller.
Page 259 Contents Connections Playback Settings Tips Appendix o Video o Network AirPlay ISF (Imaging Science Foundation) is an organization that certifies video AirPlay sends (plays) contents recorded in iTunes or on an iPhone/iPod technicians who are then qualified to carry out calibration and adjustment touch/iPad to a compatible device via the network.
Page 260 Contents Connections Playback Settings Tips Appendix WEP Key (network key) WPA-PSK/WPA2-PSK (Pre-shared Key) This is key information used for encrypting data when conducting data This is a simple authentication system for mutual authentication when a transfer. On this unit, the same WEP key is used for data encryption and preset character string matches on the wireless LAN access point and decryption, so the same WEP key must be set on both devices in order for client.
Page 261 Contents Connections Playback Settings Tips Appendix o Others Pairing Pairing (registration) is an operation that is required in order to connect a HDCP Bluetooth device to this unit using Bluetooth. When paired, the devices When transmitting digital signals between devices, this copyright authenticate each other and can connect without mistaken connections protection technology encrypts the signals to prevent content from being occurring.
Page 262: Trademark Information
Contents Connections Playback Settings Tips Appendix Trademark information Manufactured under license from Audyssey Laboratories™. U.S. and “Made for iPod” and “Made for iPhone” mean that an electronic accessory foreign patents pending. Audyssey MultEQ ® XT, Audyssey Dynamic EQ ® has been designed to connect specifically to iPod, or iPhone, and Audyssey Dynamic Volume ®...
Page 263 Contents Connections Playback Settings Tips Appendix For DTS patents, see http://patents.dts.com. Manufactured under license from DTS, Inc. DTS, the Symbol, DTS in combination with the Symbol, DTS:X, and the DTSX logo are registered trademarks or trademarks of The Wi-Fi CERTIFIED logo is a registered trademark of the Wi-Fi DTS, Inc.
Page 264: Specifications
Contents Connections Playback Settings Tips Appendix Specifications o Audio section Power amplifier Rated output: Front: 95 W + 95 W (8 Ω/ohms, 20 Hz – 20 kHz with 0.08 % T.H.D.) 125 W + 125 W (6 Ω/ohms, 1 kHz with 0.7 % T.H.D.) Center: 95 W (8 Ω/ohms, 20 Hz –...
Page 265: Video Section
Contents Connections Playback Settings Tips Appendix o Video section Color component video connector Input level and impedance: Y signal — 1 Vp-p, 75 Ω/ohms signal — 0.7 Vp-p, 75 Ω/ohms signal — 0.7 Vp-p, 75 Ω/ohms Frequency response: 5 Hz – 60 MHz — 0, –3 dB o Tuner section [FM] [AM]...
Page 266 Contents Connections Playback Settings Tips Appendix o Wireless LAN section Network type (wireless LAN standard): Conforming to IEEE 802.11b Conforming to IEEE 802.11g Conforming to IEEE 802.11n (Wi-Fi ® compliant) Security: WEP 64 bit, WEP 128 bit WPA/WPA2-PSK (AES) WPA/WPA2-PSK (TKIP) Radio frequency: 2.4 GHz No.
Page 267: Bluetooth Section
Contents Connections Playback Settings Tips Appendix o Bluetooth section Communications system: Bluetooth Version 2.1 + EDR (Enhanced Data Rate) Transmission power: Maximum 2.5 mW (Class 2) Maximum communication range: Approx. 10 m in line of sight Frequency band: 2.4 GHz band Modulation scheme: FHSS (Frequency-Hopping Spread Spectrum) Supported profiles:...
Page 268 Contents Connections Playback Settings Tips Appendix Dimensions (Unit : mm) Weight: 9.4 kg Front panel Display Rear panel Remote Index...
Page 269 Contents Connections Playback Settings Tips Appendix Index Bi-amp ............45 Favorites ..........103, 104 Bluetooth device ..........74 Firmware Update .......... 211 v Numerics Blu-ray Disc player ........53, 64 FM/AM antenna ........57, 79 3D ..............237 Front panel ............. 13 4K ..............
Page 270 Contents Connections Playback Settings Tips Appendix Input Assign ..........170 NAS ............... 93 Random playback ........69, 102 Input settings ........139, 170 Network settings .......... 196 Rear panel ............18 Input signal ........... 250 Remote control unit ........22 Input source ...........
Page 271 Contents Connections Playback Settings Tips Appendix Text Search ..........104 Web control ..........132 Tips .............. 218 Wi-Fi settings ..........197 Troubleshooting ........... 220 Wired LAN ..........59, 197 TV ............49, 50 ZONE2 ........... 47, 134 USB memory device ........ 55, 70 Video camcorder ..........
Page 272 Contents Connections Playback Settings Tips Appendix License This section describes software license used for this unit. To maintain the correct content, the original (English) is used. Permission is hereby granted, free of charge, to any person obtaining a copy of this Boost software and associated documentation files (the “Software”), to deal in the Software http://www.boost.org/...
Page 273 Contents Connections Playback Settings Tips Appendix Definitions. “Articles” means, collectively, all articles written by Author which You may otherwise modify Your copy of this Work (excluding the Articles) in any way describes how the Source Code and Executable Files for the Work may be used by a to create a Derivative Work, provided that You insert a prominent notice in each user.
Page 274 Contents Connections Playback Settings Tips Appendix You may distribute the Executable Files and Source Code only under the terms of This License and the rights granted hereunder will terminate automatically upon any this License, and You must include a copy of, or the Uniform Resource Identifier for, breach by You of any term of this License.
Page 275 Contents Connections Playback Settings Tips Appendix libvorbis No term or provision of this License shall be deemed waived and no breach consented to unless such waiver or consent shall be in writing and signed by the http://www.xiph.org/vorbis/ party to be charged with such waiver or consent. Copyright (c) 2002-2004 Xiph.org Foundation This License constitutes the entire agreement between the parties with respect to the Work licensed herein.
Page 276 Contents Connections Playback Settings Tips Appendix 0 Redistributions of source code must retain the above copyright notice, this list of THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND conditions and the following disclaimer. CONTRIBUTORS “AS IS” AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF 0 Redistributions in binary form must reproduce the above copyright notice, this list MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE...
Page 277 Contents Connections Playback Settings Tips Appendix cURL THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND CONTRIBUTORS “AS IS” AND ANY EXPRESS OR IMPLIED WARRANTIES, http://curl.haxx.se INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF COPYRIGHT AND PERMISSION NOTICE MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED.
Page 278: Front Panel Display Rear Panel
After you purchase this product, you may procure, modify or distribute the source code of the GPL/LGPL software that is used in the product. Denon provides the source code based on the GPL and LPGL licenses at the actual cost upon your request to our customer service center.

Denon AVR-X2200W Owner's Manual

Accessories

Features

Part Names and Functions

Display

Rear Panel

Connections

Connections

Connecting Speakers

Connecting a TV

Playback Settings

Connecting a Playback Device

Connecting an Ipod or USB Memory Device to the USB Port

Connecting an FM/AM Antenna

Connecting to a Home Network (LAN)

13 Wired LAN

Playback

Playing an Ipod

Playing a USB Memory Device

Listening to Music on a Bluetooth Device

Listening to FM/AM Broadcasts

Playback Settings

Listening to Internet Radio

Playing Back Files Stored on a PC and NAS

Airplay Function

Spotify Connect Function

Convenience Functions

Selecting a Sound Mode

HDMI Control Function

Smart Menu Function

Sleep Timer Function

Quick Select Plus Function

Web Control Function

Playback in ZONE2 (Separate Room)

Menu Map

Inputs

Speakers

Inputting Characters

Audio

Manual Setup

Tips

Limiting the Operating Zone with the Remote Control

Video Conversion Function

Resetting Factory Settings

Appendix

About Hdmi

Playing Back a Usb Memory Devices

Playing Back a Bluetooth Device

Playing Back a File Saved on a PC or NAS

Playing Back Internet Radio

Last Function Memory

Personal Memory Plus Function

Sound Modes and Channel Output

Sound Modes and Surround Parameters

Types of Input Signals, and Corresponding Sound Modes

Explanation of Terms

Trademark Information

Specifications

Quick Links

Troubleshooting

Related Manuals for Denon AVR-X2200W

Summary of Contents for Denon AVR-X2200W
