Summary of Contents for Beko HII 64400 AT

  • Page 1 Built-In Hob HII 64400 AT...
  • Page 2 Please read this manual first. Dear Customer, We would like you to obtain best performance with your product that has been manufactured in modern facilities and passed through strict quality control procedures. Therefore, we advise you to read through this User Manual carefully before using your product and keep it for future reference.

  • Page 3: Table Of Contents

    Table of Contents Tips for saving energy ......14 General information Initial use ..........14 Overview ..........4 First cleaning of the appliance ..14 Technical specifications ....... 4 How to use the hob Important safety instructions 6 General information about cooking ..15 General safety ........

  • Page 4: General Information Overview

    General information Overview Induction cooking plate Vitroceramic surface Assembly clamp Base cover Technical specifications Voltage / frequency 220-240 V~/380-415 V 2N ~ 50 Hz Total power consumption max. 7200 W Fuse min. 16 A x 2 / 32 A Cable type / section H05VV-FG 5 x 1,5 mm or equivalent...
  • Page 5 Dimension 210 mm Power 2000/2300 W IMPORTANT IMPORTANT Technical specifications may be Values stated on the product labels changed without prior notice to or in the documentation improve the quality of the product. accompanying it are obtained in laboratory conditions in IMPORTANT accordance with relevant Figures in this manual are...

  • Page 6: Important Safety Instructions

    Important safety instructions This section contains safety • Do not operate the product if it is instructions that will help you avoid defective or has any visible risk of injury and damage. All damage. warranties will become void if you do •...

  • Page 7: Intended Use

    • Vapour pressure that build up due Safety for children to the moisture on the hob surface • Electrical and/or gas products are or at the bottom of the pot can dangerous to children. Keep cause the pot to move. Therefore, children away from the product make sure that the oven surface when it is operating and do not...

  • Page 8: Installation

    Installation Product must be installed by a Before installation qualified person in accordance with the regulations in force. The The hob is designed for installation in a manufacturer shall not be held commercial worktop. A safety distance responsible for damages arising from must be left between the appliance procedures carried out by and the kitchen walls and furniture.

  • Page 9: Installation And Connection

    min. installation in accordance with the local regulations. Installation and connection DANGER • The product must be installed in The product must be connected to the mains supply only by an accordance with all local gas and authorised and qualified person. electrical regulations.
  • Page 10 • Connection must comply with national regulations. • The mains supply data must correspond to the data specified on the type label of the product. Type label is at the rear housing of the product. • Power cable of your product must comply with the values in "Technical specifications"...
  • Page 11 If the board is below: min. 30 mm min. IMPORTANT min. 70 mm When installing the hob onto a cabinet, a shelf must be installed in During installation of your induction order to separate the cabinet from hob, place the product parallel to the the hob as illustrated in the above installation surface.

  • Page 12: Disposal

    Disposal Disposing of packaging material Packaging materials are dangerous to children. Keep packaging materials in a safe place out of reach of children. Packaging materials of the product are manufactured from recyclable min. 40 mm materials. Dispose of them properly and sort in accordance with recycled Installation clamp waste instructions.
  • Page 13 information, please contact local or Before disposing of the product, cut regional authorities. off the power cable plug and make the door lock (if any) unusable to avoid Refer to your local dealer or solid dangerous conditions to children. waste collection centre in your area to learn how to dispose of your product.

  • Page 14: Preparation

    Preparation • Keep the cooking zones and Tips for saving energy bottom of the pots clean. Dirt will decrease the heat conduction The following information will help you between the cooking zone and to use your appliance in an ecological bottom of the pot.

  • Page 15: How To Use The Hob

    How to use the hob Clean any melted such materials General information about on the surface immediately. cooking Such vessels should not be used to keep foods either. DANGER • Use flat bottomed saucepans or vessels only. Never fill the pan with oil more than one third of it.
  • Page 16 Do not use vessels Saucepan recognition-focusing with concave or system convex bottoms. In induction cooking, only the area covered by the vessel on the relevant Use only the cooking zone is energised. The saucepans and vessel's bottom is recognised by the pans with flat system and only this area is heated bottoms.

  • Page 17: Using The Hobs

    Selecting cooking zone suitable to the vessel Large cooking zone Normal cooking zone Small cooking zone Large cooking zone Normal cooking zone Small cooking zone • Automatically fits to • Automatically fits to • Used for slow the saucepan. the saucepan. cookings (sauces, creams) •...
  • Page 18 Rear Left Cooking Zone IMPORTANT Selection key If no operation is performed Rear Right Cooking Zone within 10 seconds, the hob will Selection key automatically return to Standby Front Right Cooking Zone mode. Selection key Turning off the hob IMPORTANT 1.
  • Page 19 2. Touch the selection key of the the control panel to silence the cooking zone you want to turn on. audible alarm. "0" symbol appears on the cooking High Power (Booster) zone display and the related display For rapid heating, you can use booster illuminates more brightly.
  • Page 20 activated and deactivated in Standby Keylock mode. You can activate the keylock to avoid changing the functions by mistake Activating the childlock when the hob is operating. 1. Touch " " key to turn on the hob. Activating the keylock 2.
  • Page 21 2. Select the desired cooking zone by IMPORTANT touching the cooking zone Timer cannot be adjusted unless selection keys. the cooking zone and the temperature value for the cooking zone are selected. IMPORTANT When the cooking zone for which a timer was set is selected, you can see the remaining time by touching the "...
  • Page 22 operates more efficiently and the hob Temperature level Operation time surface does not heat up. limit - hour Induction hob is equipped with superior safety systems that will provide you maximum usage safety. 20 minutes IMPORTANT P (Booster) 5 minutes (*) Your hob can be equipped with (*) The hob will drop to level 9 after 5 induction cooking zones with a...
  • Page 23 • Noise becomes prominent in high • The noise of the fan that cools temperature levels. electric system can be heard. • Alloy of the saucepan can cause IMPORTANT noise. If the surface of the touch control • In low levels, a regular on/off panel is exposed to intense vapor, sound can be heard because of entire control system may become...

  • Page 24: Maintenance And Care General Information

    Maintenance and care wipe those parts clean, paying General information attention to sweep in one direction. Service life of the product will extend NOTICE and the possibility of problems will The surface might get damaged by decrease if the product is cleaned at some detergents or cleaning materials.
  • Page 25 clean the surface of the hob with a Slight color fading may occur on damp cloth. coatings or other surfaces in time. This will not affect operation of the product. IMPORTANT Color fading and stains on the glass Sugar-based foods such as thick ceramic surface is a normal condition, cream and syrup must be cleaned and not a defect.

  • Page 26: Troubleshooting

    Troubleshooting Product does not operate. The mains fuse is defective or has tripped. Check fuses in the fuse box. If necessary, replace or reset them. If the display does not light up when you Disconnect the appliance at the circuit switch the hob on again.
  • Page 27 Envelope IV 27 | EN...
