Summary of Contents for Pioneer DEH-4200SD
- Page 1 Internet store of PHONES (044) 360-7-130 294-0-130 autogoods (050) 336-0-130 597-0-130 (063) 788-0-130 SKYPE (067) 233-0-130 km-130 (068) 282-0-130 CAR RECEIVERS — Receivers • Media receivers and stations • Native receivers • CD/DVD changers • FM-modulators/USB adapters • Flash memory • Facia plates and adapters • Antennas • Accessories | CAR AUDIO —...
- Page 2 CD RDS RECEIVER Operation Manual DEH-4200SD DEH-3200UB Visit www.pioneer.co.uk (or www.pioneer.eu) to register your product Autogood products internet store http://130.com.ua...
-
Page 3: Table Of Contents
Contents Installation Thank you for purchasing this PIONEER product Notes • Check all connections and systems before final installation. • Do not use unauthorized parts. The use of unauthorized parts may cause To ensure proper use, please read through this manual before using this product. It is malfunctions. -
Page 4: Din Rear-Mount
Installation 3. Install the unit as illustrated. Removing the unit 1. Extend top and bottom of the trim ring outwards to remove the trim ring. (When reattaching the trim ring, point the side with the groove down.) Firewall or metal support Metal strap Screw Screw (M4 x 8) -
Page 5: Connections
Connections For DEH-4200SD Rear output or Notes subwoofer output To subwoofer output • Change the initial setting of this unit (refer to the (DEH-3200UB) Power amp (sold Power amp (sold operation manual). The subwoofer output of this unit This product... -
Page 6: Before You Start
Refer all servicing to qualified personnel. it to the antenna booster power supply terminal. • The Pioneer CarStereo-Pass is for use only in Germany. • Never connect blue/white cable to external power amp’s power terminal. Also, never connect it to the power terminal of the auto antenna. Otherwise, battery drain or malfunction •... -
Page 7: In Case Of Trouble
This manual describes operations of both DEH-4200SD and DEH-3200UB. Only unit is turned off. Turning off the unit does not cancel demo mode. To cancel the demo DEH-4200SD features SD memory card functions, so the explanations for those mode, press /DISP/SCRL. -
Page 8: Operating This Unit
Press to select functions. Press and hold to recall the initial setting menu when the sources Use an optional Pioneer USB cable (CD-U51E) to connect the USB audio player/USB are off. memory to the USB port. Since the USB audio player/USB memory is projected forward from the unit, it is dangerous to connect directly. -
Page 9: Display Indication
Shuffle or shuffle all function is on while the iPod source is being selected. (sound retriever) The sound retriever function is on. iPod CTRL (control mode) is set to iPod. (SD memory card) Only for DEH-4200SD. SD/SDHC memory card is inserted. Basic Operations Indicator State Important... -
Page 10: Menu Operations Identical For Function Settings/Audio Adjustments/ Initial Settings/Lists
Selecting a source displayed. * Press SRC/OFF to cycle between: Manual tuning (step by step) DEH-4200SD * Push M.C. left or right. TUNER (tuner) – CD (built-in CD player) – USB (USB)/USB-iPod (iPod) – SD (SD memory card) – AUX (AUX) -
Page 11: Storing And Recalling Stations
Operating this unit Storing and recalling stations 4. Press TA/NEWS while a traffic announcement is being received to cancel the announcement. You can easily store up to six stations for each band as presets. The tuner returns to the original source but remains in the standby mode until TA/ Using preset tuning buttons NEWS is pressed again. -
Page 12: Pty List
If no station is broadcasting the type of program you searched for, NOT FOUND is displayed for about two seconds and then the tuner returns to the original station. The SD memory card is only available for DEH-4200SD. Traffic (traffic announcement standby) Basic Operations * Press M.C. -
Page 13: Displaying Text Information
Operating this unit Ejecting a CD/CD-R/CD-RW Returning to root folder * Press 0 (eject). * Press and hold BAND/ESC. Playing songs on a USB storage device Switching between compressed audio and CD-DA * Press BAND/ESC. 1. Open the USB connector cover. 2. -
Page 14: Selecting And Playing Files/Tracks From The Name List
Operating this unit Selecting and playing files/tracks from the name list Pausing playback * Press 6/PAUSE to pause or resume. 1. Press to switch to the file/track name list mode. 2. Use M.C. to select the desired file name (or folder name). Enhancing compressed audio and restoring rich sound (sound retriever) Changing file or folder name * Press S.Rtrv to cycle between:... -
Page 15: Ipod
Operating this unit iPod Changing the name of song or category * Turn M.C. Basic Operations Playlists – artists – albums – songs – podcasts – genres – composers – audiobooks Playing songs on iPod Playing * When a song is selected, press M.C. 1. -
Page 16: Function Settings
Operating this unit Playing songs related to the currently playing song Function settings You can play songs from the following lists. 1. Press M.C. to display the main menu. – Album list of currently playing artist 2. Turn M.C. to change the menu option and press to select FUNCTION. –... -
Page 17: Audio Adjustments
Operating this unit Pause (pause) FAD/BAL (fader/balance adjustment) • Refer to “Pause (pause)” on page 13. 1. Press M.C. to display the setting mode. Audiobooks (audiobook speed) 2. Press M.C. to cycle between fader and balance. The playback speed of audiobook can be changed. 3. - Page 18 Operating this unit Loudness (loudness) HPF setting (high pass filter adjustment) Loudness compensates for deficiencies in the low- and high-frequency ranges at low volume. When you do not want low sounds from the subwoofer output frequency range to play from the front or rear speakers, turn on the HPF (high pass filter). Only frequencies 1.
-
Page 19: Initial Settings
SW control (rear output and subwoofer setting) 1. Press M.C. to display the setting mode. Only for DEH-4200SD. 2. Turn M.C. to select the FM tuning step. This unit’s rear output (rear speaker leads output) can be used for full-range speaker 100kHz (100 kHz) –... -
Page 20: Other Functions
Operating this unit Initially, Rear SP is set for rear full-range speaker connection (Full). When Rear SP 1. Press M.C. to display the setting mode. :Full is selected, you can connect the RCA output to a subwoofer. In this case, you 2. -
Page 21: Additional Information
Transfer audio files not embedded device are embedded with with Windows Media DRM 9/10 to When you contact your dealer or your nearest Pioneer Service Center, be sure to note Windows Media DRM 9/10 the external storage device and connect. -
Page 22: Handling Guideline
Additional Information External storage device (USB, SD) Message Cause Action Message Cause Action CHECK USB iPod operates correctly but does Check if the connection cable for not charge iPod shorted out (e.g., not caught N/A SD Not compatible SD storage Remove your device and replace in metal objects). - Page 23 Additional Information • Condensation may temporarily impair the player’s performance. Leave it to adjust to • Do not touch the connectors of the SD memory card directly with your fingers or with the warmer temperature for about one hour. Also, wipe any damp discs with a soft any metal device.
-
Page 24: (Disc, Usb, Sd)
Additional Information DualDiscs DualDiscs are two-sided discs that have a recordable CD for audio on one side and a • Compatible format: AAC encoded by iTunes recordable DVD for video on the other. • File extension: .m4a Since the CD side of DualDiscs is not physically compatible with the general CD •... -
Page 25: Ipod Compatibility
• There may be a slight delay when starting playback of audio files on an external Pioneer accepts no responsibility for data lost on the iPod even if that data is lost while storage device (USB, SD) with numerous folder hierarchies. -
Page 26: Copyright And Trademark
Additional Information Disc Folder selection sequence or other operation may differ depending on the encoding or writing software. External storage device (USB, SD) Playback sequence is the same as recorded sequence in the external storage device (USB, SD). To specify the playback sequence, the following method is recommended. Windows Media and the Windows logo are trademarks or registered trademarks of 1 Create the file name including numbers that specify the playback sequence (e.g., Microsoft Corporation in the United States and/or other countries. -
Page 27: Specifications
Additional Information Specifications iPod General CD player Power source........14.4 V DC System ....Compact disc audio system (10.8 V to 15.1 V allowable) Usable discs ........ Compact disc Grounding system ...... Negative type Signal-to-noise ratio ....94 dB (1 kHz) Maximum current consumption .... - Page 28 Usable sensitivity ....9 dBf (0.8 µV/75 $, mono, S/N: 30 dB) Signal-to-noise ratio ..72 dB (IEC-A network) Notes • The SD memory card is only available for DEH-4200SD. • Specifications and the design are subject to modifications without notice. Autogood products internet store http://130.com.ua...
