MTX SW1 Owner's Manual page 3

SPECIFICATION
Amplifier Type: Class A/B
Frequency response: 40 Hz - 160 Hz
Lo-pass xover 60 Hz - 160 Hz at 18 dB per octave
Inputs: Line level and speaker level full range
Outputs: Line level
Hi-pass subsonic filter: 18 dB per octave below 30 Hz
Polarity switch: Normal (0 degrees)/reverse (180 degrees)
Amplifier
Power: (continuous)
Driver
Size:
Voice coil diameter:
Dimensions
Height:
Width:
Depth:
Weight
System:
Shipping:
Specifications subject to change without notice.
14
100 watts
10"
1-1/2"
15-1/2"
15"
17"
34.5 lbs
41.5 lbs
SAFETY SYMBOLS AND STATEMENTS
