MTX THUNDERFORM Installation Instructions

Mtx amplified thunderform enclosures chevy s10 regular cab trucks gmc sonoma and isuzu hombre subwoofer enclosure

Hide thumbs Also See for THUNDERFORM:

Download this manual

Enlarged version

Warranty Statement

ThunderForm Loaded Enclosures purchased in the United States from an authorized MTX dealer

are guaranteed against defects in material and workmanship for a period of two years from the date

purchased by the end user, and limited to the original retail purchaser of the product.

Amplified ThunderForm Enclosures purchased in the United States from an authorized MTX dealer

are guaranteed against defects in material and workmanship for a period of one year from the date

purchased by the end user, and limited to the original retail purchaser of the product.

Product found to be defective during that period will be repaired or replaced by MTX at no charge.

This warranty is void if it is determined that unauthorized parties have attempted repairs or altera-

tions of any nature. Warranty does not extend to cosmetics or finish. Before presuming a defect is

present in the product, be certain that all related equipment and wiring is functioning properly. MTX

disclaims any liability for other incurred damages resulting from product defects. Any expenses

incurred in the removal and reinstallation of products are not covered by this warranty. MTX's total

liability will not exceed the purchase price of the product. If a defect is present, your authorized MTX

dealer may be able to effect repairs.

Proof of purchase is required when requesting service, so please retain your sales receipt and take

a moment to register your product online at www.mtx.com.

One Mitek Plaza, Winslow, IL. 61089

1-800-225-5689 www.mtx.com

Vehicle Specific Subwoofer Enclosure

21A7240

CHEVY S-10 REG CAB

GMC Sonoma/Isuzu Hombre

Made in the USA

Page 1 Warranty Statement ThunderForm Loaded Enclosures purchased in the United States from an authorized MTX dealer are guaranteed against defects in material and workmanship for a period of two years from the date purchased by the end user, and limited to the original retail purchaser of the product.
Page 2 Connect speaker wires from amplifier to enclosure, positive to red terminal knob and negative to black terminal knob. Refer to Step 25 for mounting directions. AMPLIFIED THUNDERFORM Routing Power Wire; we recommend a connection directly to the battery. 3. Remove driver side threshold trim; pull up on trim, it will remove eas- ily.
Page 3 “clip” before the unit reaches maximum volume. Reduce volume to the loudest listening level before distortion. Turn the gain knob on the Thunderform pre-amp clockwise until the speaker starts to distort and reduce gain to loudest listening level before distortion.
Page 4 11. Ground amplifier to chassis of vehicle; connect the terminal provided to the 10ga black wire from furnished wiring harness. A good ground is as important as the power connection. The ground should be as short as possible and the contact point should be free of paint and debris. SPEAKER WIRES 12.
