Ryobi 705r Parts List

3
38
5
2
1 3
8
Item Part No. Description
1 753-04511 Air Cleaner Assembly (includes 2 & 38)
2 791-180350B Air Cleaner Filter
3 791-180351 Carburetor Mounting Screw
4 791-180226 Wavey Washer
5 791-182070 Choke Knob and Screw
6 753-04418 Choke Lever Assembly (includes 5)
7 753-04419 Choke Plate Assembly (includes 6)
8 753-04333 Carburetor Assembly (includes 9 & 20)
9 791-610675 Carburetor Gasket
10 791-181860 Carb Mount Screw
11 791-683974B Primer and Hose Assembly
12 753-1196 Carb Mount Assembly (includes 10)
13 791-684451 Reed Assembly
14 753-1208 Carburetor Mount Gasket
15 753-04332 Crank Case Service Assembly
16 791-612134 Rear Mounting Pad
17 753-04311 Fuel Tank Assembly (includes 18-20)
18 791-182438 Fuel Cap
19 791-181086 Fuel Return Line
20 791-682039 Fuel Line Assembly
21 791-145308 Front Mounting Pad
22 753-04702 Shroud Extension and Stand (includes 38)
23 791-182739 Flywheel
24 791-181065 Spacer
25 753-04232 Recoil Pulley
26 791-613102 Recoil Spring
27 791-611061 Rope Guide
28 791-181441 Pulley Retainer Assembly
29 791-181442 Switch Assembly (includes 40)
30 791-181079 Pull Handle
4
6
7
11
13
9
10
12
14
15
49
43
45
46
47
48
17
18
16
20
21
19
53
51
52
50
41
44
42
40
29
Item Part No.
31 791-613103
32 791-181443
33 791-181862
34 791-182368
35 791-181445
36 791-153592
37 791-182797
38 791-181345
39 791-182519
40 791-180036
41 753-04324
42 791-610311B Spark Plug
43 753-04618
44 753-04619
45 753-04689
46 753-04690
47 753-04691
48 753-04315
49 753-04620
50 753-04323
51 753-1207
52 753-1197
53 791-182723
* 753-04134
* 753-1209
* 753-04334
* 791-181599
* Items Not Shown
ENGINE PARTS - MODEL 705r
2-CYCLE GAS TRIMMER
34
35
36
23
24
25
29
26
27
28
32
22
Description
Rope
Starter Housing Assembly
(includes 25-31, 33 & 38)
Housing Screw
Clutch Washer
Clutch Rotor Assembly
Clutch Drum
Clutch Cover Assembly (includes 38 & 39)
Screw
Anti-Rotation Screw
Wire Lead
Module Assembly
Muffler Assembly (includes 44-49)
Exhaust Gasket
Spark Arrestor Screen
Exhaust Hood Diverter
Exhaust Hood
Screws
Muffler Mounting Bolt Assembly
Cylinder Assembly (includes 52 & 53)
Piston and Rod Assembly
Cylinder Gasket
Cylinder Bolt
Engine Gasket
Piston Ring
Short Block Assembly
(includes 10, 15, 42 & 50-53)
Clutch Springs (Qty 2)
PPN 41BD705G734
38
39
38
37
38
30
31
29
33
Issued 1/04
