Frigidaire FGDS3065PF Installation Instructions Manual

INSTALLATION INSTRUCTIONS
30" DUAL FUEL SLIDE-IN RANGE
INSTALLATION AND SERVICE MUST BE PERFORMED BY A QUALIFIED INSTALLER.
IMPORTANT: SAVE FOR LOCAL ELECTRICAL INSPECTOR'S USE.
READ AND SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
United States
Canada
Refer to your serial
plate for applicable
agency certification.

Table of Contents

Important Safety Instructions ....................................... 2-3
Cabinet & Product Dimensions.................................... 3-4
To Avoid Breakage .......................................................... 5
Factory Connected Power Supply Cord (Canada only).. 6
Power Supply Cord Kit (U.S.A.)...................................... 6
Access to Terminal Block & Grounding Strap (U.S.A.) ... 6
Electrical Connection to the Range (U.S.A.) ............... 7-8
Cabinet Construction ...................................................... 9
Gas Supply - Installation............................................ 9-10
Important Notes to the Installer
1. Read all instructions contained in these installation
instructions before installing range.
2. Remove all packing material from the oven and the
drawer compartments before connecting the gas and
electrical supply to the range.
3. Observe all governing codes and ordinances.
4. Be sure to leave these instructions with the consumer.
5. Note: For operation at 2000 ft. elevations above see
level, appliance rating shall be reduced by 4 percent for
each additional 1000 ft.
Important Note to the Consumer
Keep these instructions with your owner's guide for the
local electrical inspector's use and future reference.
P/N 318201635 (1305) Rev. A
English - pages 1-16; Spanish - pages 17-32; Français - pages 33-48
If the information in this manual is not followed exactly, a fire
or explosion may result causing property damage, personal injury or death.
FOR YOUR SAFETY:
- Do not store or use gasoline or other flammable vapors and liquids in
the vicinity of this or any other appliance.
- WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your
building.
• Immediately call your gas supplier from a neighbor's phone. Follow the
gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire department.
- Installation and service must be performed by a qualified installer,
service agency or the gas supplier.
LP/Propane Gas Conversion ........................................ 10
Moving the Appliance for servicing and Cleaning ..........11
Range Installation .................................................... 11-12
Leveling the Range....................................................... 12
Check Operation...................................................... 12-14
When All Hookups are Complete.................................. 14
Model and Serial Number Location .............................. 14
Before You Call for Service........................................... 14
Anti-Tip Brackets Installation ................................... 15-16
Appliances Installed in the state of
Massachusetts:
This Appliance can only be installed in the state of
Massachusetts by a Massachusetts licensed plumber or
gasfitter.
This appliance must be installed with a three (3) foot / 36
in. long flexible gas connector.
A"T" handle type manual gas valve must be installed in
the gas supply line to this appliance.
Cold temperature can damage the
electronic control. When using the appliance for the
first time, or when the appliance has not been used
for an extended period, be certain the unit has been
in temperatures above 32°F (0°C) for at least 3 hours
before turning on the power to the appliance.
Printed in United States
