Packing Checklist
1 AF-142/ AF-241
1 User's Manual
1 3.5" Floppy (for AF-142 only)
Please read this manual thoroughly and follow the installation procedures carefully to prevent any damage to the
AF-142/AF-241 and/or the devices it connects to.
Introduction
AF-142 and AF-241, ParaHubs, are automatic and first-come-first-served data switches. They scan for print
job requests from both computers and send data to the printer. When one computer is printing, the other
computer can not send print job until the current one is finished. The File Transfer feature enables you to
access the other computer directly through the ParaHub and requires no special cables. Besides, the AF-142
can operate as a 1-to-2 selector enabling you to connect the LPT port to two parallel devices.
Features
Supports IEEE-1284 nibble mode.
Transfers files between computers.
Shares peripherals between computers.
Selects ports by button and software code operation.
Selectable timeout: 15 or 45 seconds.
First-come-first-served.
Non-power operation
AF-142 extras:
1 of 5
©Copyright 1997 Aten® International Co., Ltd.
Manual Part No. PAPE-1106-200
All brand names and trademarks are the registered property of their respective owners.
2-In-1-Out / 1-In-2-Out
(Reversible)
ParaHub
AF-142/AF-241
User's Manual
Printed in Taiwan 06/97
Advertisement
Related Manuals for ATEN AF-241
Summary of Contents for ATEN AF-241
- Page 1 All brand names and trademarks are the registered property of their respective owners. Introduction AF-142 and AF-241, ParaHubs, are automatic and first-come-first-served data switches. They scan for print job requests from both computers and send data to the printer. When one computer is printing, the other computer can not send print job until the current one is finished.
-
Page 2: Installation
Set the slide switch, located on the side of the ParaHub, to 2 > 1 mode with a time out of either 15 or 45 seconds. (The AF-241 does not have a 1 > 2 mark). Turn on your computers and the printer. The two LEDs should flash alternately as it is scanning for print jobs. -
Page 3: Operation
Operation 2-to-1 Mode (for AF-142 & AF-241) Auto Mode: The ParaHub scans for print jobs with two LEDs flashing alternately. When a print job is sensed, it locks onto the computer on a first-come-first-served basis until it finishes the job. Then, it returns to Auto mode again. - Page 4 The ParaHub is low on power, turn on one more device, or apply power adapter. The printer status Windows shows "printer not responding" or "cable not connected" intermittently: AF-142 and AF-241 do not emulate printer responses. Therefore, when status Windows poll for printer status at the same time, these messages show up.
- Page 5 LOGITEC: ADDONICS: Preventing Radio & TV Interference WARNING!!! This equipment generates, uses, and can radiate radio frequency energy and if not installed and used in accordance with the instruction manual, may cause interference to radio communications. It has been tested and found to comply with the limits for a Class A computing device pursuant to Subpart J of Part 15 of FCC Rules, which are designed to provide reasonable protection against such interference when operated in a commercial environment.
