19" LCD Color Monitor
Service
Service
Service
Description
Table Of Contents.....................................................1
Revision List........................................................2
Important Safety Notice.............................................3
1. Monitor Specifications..............................................4
2. LCD Monitor Description..........................................5
3.1General Instructions........................................6
3.2 Control buttons...............................................6
3.3 Adjusting the Picture...............................................8
3.4 Connecting to the PC ........................................10
4. Input/Output Specification......................................11
4.1 Input Signal Connector.........................................11
4.2 Factory Preset Display Modes...............................12
4.3 Pixel Defect Policy..........................................13
4.4 Failure Mode Of Panel ....................................16
5. Block Diagram.................................................17
5.1 Software Flow Chart.............................................17
5.2 Electrical Block Diagram....................................19
6. Schematic Diagram.............................................21
ANY PERSON ATTEMPTING TO SERVICE THIS CHASSIS MUST FAMILIARIZE HIMSELF WITH THE
CHASSIS AND BE AWARE OF THE NECESSARY SAFETY PRECAUTIONS TO BE USED WHEN
SERVICING ELECTRONIC EQUIPMENT CONTAINING HIGH VOLTAGES.
CAUTION: USE A SEPARATE ISOLATION TRANSFOMER FOR THIS UNIT WHEN SERVICING
REFER TO BACK COVER FOR IMPORTANT SAFETY GUIDELINES
Copyright 2008 Philips Consumer Lifestyle
190SW9FB/69
190SW9FB/27
190SW9FB/75
190SW9FB/93
190SW9FB/97
190SW9FS/00
Page
Description
6.1 Main Board.................................................21
6.2 Power Board...............................................25
6.3 Key Board...................................................27
7. PCB Layout........................................................28
7.1 Main Board........................................................28
7.2 Power Board......................................................30
7.3 Key Board...................................................32
8. Wiring Diagram................................................33
9. Scalar Board Overview.....................................34
10. Mechanical Instructions......................................35
11. Trouble shooting...........................................39
12. Repair Flow Chart.........................................41
13. ISP Instructions....................................................47
14. DDC Instructions................................................54
15. White Balance, Luminance Adjustment.................64
16. Monitor Exploded View......................................66
17. Recommended & Spare Parts List.........................67
18. Different Parts List.............................................69
19. General Product Specification..........................71
SAFETY NOTICE
Subject to modification ○
K
Chassis: HUDSON 9
GB
Jun, 26, 2008
312278518070
Page
Advertisement
Chapters
Table of Contents
Related Manuals for Philips 190SW9FB/69
Summary of Contents for Philips 190SW9FB/69
-
Page 1: Table Of Contents
CHASSIS AND BE AWARE OF THE NECESSARY SAFETY PRECAUTIONS TO BE USED WHEN SERVICING ELECTRONIC EQUIPMENT CONTAINING HIGH VOLTAGES. CAUTION: USE A SEPARATE ISOLATION TRANSFOMER FOR THIS UNIT WHEN SERVICING REFER TO BACK COVER FOR IMPORTANT SAFETY GUIDELINES Copyright 2008 Philips Consumer Lifestyle Subject to modification ○ Jun, 26, 2008 312278518070... -
Page 2: Revision List
HUDSON 9 Revision List Version Release Date Revision History Jun.26, 2008 Initial release, Draft Version Add CTV Model 190SW9FS/00,190SW9FB/75,190SW9FB/93, July.01.2008 190SW9FB/97... -
Page 3: Important Safety Notice
HUDSON 9 Important Safety Notice Proper service and repair is important to the safe, reliable operation of all Philips Company Equipment. The service procedures recommended by Philips and described in this service manual are effective methods of performing service operations. Some of these service operations require the use of tools specially designed for the purpose. -
Page 4: Monitor Specifications
HUDSON 9 1. Monitor Specifications... -
Page 5: Lcd Monitor Description
HUDSON 9 2. LCD Monitor Description The LCD monitor will contain a main board, a power board and a key board which house the flat panel control logic, brightness control logic and DDC. The power board will provide AC to DC Inverter voltage to drive the backlight of panel and the main board chips each voltage. -
Page 6: Operating Instructions
HUDSON 9 3. Operating Instructions 3.1 General Instructions Press the power button to turn the monitor on or off. The other control buttons are located at the front of the panel of the monitor. By changing these settings, the picture can be adjusted to your personal preferences. The power cord should be connected. - Page 7 HUDSON 9 Rear View...
-
Page 8: Adjusting The Picture
Description of the On Screen Display On-Screen Display (OSD) is a feature in all Philips LCD monitors. It allows an end user to adjust screen performance or select functions of the monitors directly through an on-screen instruction window. A user friendly on screen display... - Page 9 HUDSON 9 The OSD Tree Below is an overall view of the structure of the On-Screen Display. You can use this as a reference when you want to work your way around the different adjustments later on.
-
Page 10: Connecting To The Pc
HUDSON 9 3.4 Connecting to the PC 1) Connect the power cord to the back of the monitor firmly. *available for selective models *available for selective models 2) Connect to PC (a) Turn off your computer and unplug its power cable. (b) Connect the monitor signal cable to the video connector on the back of your computer. -
Page 11: Input/Output Specification
HUDSON 9 4. Input/ Output Specification 4.1 Input Signal Connector Analog connectors Pin No. Description Pin No. Description Red video input DDC + 5 V Green video input Logic Ground Blue video input Ground Sense (GND) Serial data line (SDA) Cable detect (GND) H. -
Page 12: Factory Preset Display Modes
HUDSON 9 4.2 Factory Preset Display Modes... -
Page 13: Pixel Defect Policy
HUDSON 9 4.3 Pixel Defect Policy... - Page 14 HUDSON 9...
- Page 15 HUDSON 9...
-
Page 16: Failure Mode Of Panel
HUDSON 9 4.4 Failure Mode Of Panel Quick reference for failure mode of LCD panel this page presents problems that could be made by LCD panel. It is not necessary to repair circuit board. Simply follow the mechanical Polarizer has bubbles instruction on this manual to eliminate failure by replace LCD panel. -
Page 17: Block Diagram
HUDSON 9 5. Block Diagram 5.1 Software Flow Chat... - Page 18 HUDSON 9 1) MCU initializes. 2) Is the EPROM blank? 3) Program the EPROM by default values. 4) Get the PWM value of brightness from EPROM. 5) Is the power key pressed? 6) Clear all global flags. 7) Are the AUTO and SELECT keys pressed? 8) Enter factory mode.
-
Page 19: Electrical Block Diagram
HUDSON 9 5.2 Electrical Block Diagram 5.2.1 Main Board Panel Interface (CN403) Scalar IC NT68667FG EEPROM Keypad Interface (Include MCU, ADC, OSD) M24C16 (CN402) (U401) (U403) H sync D-Data V sync D-Clock D-Sub Flash Memory Crystal Connector Connector PM25LV010A-100SCE 12MHz (CN102) (CN101) (U402) - Page 20 HUDSON 9 5.2.2 Inverter/Power Board AC input Bridge Rectifier Transformer Rectifier diodes EMI filter and Filter Start Circuit: R904、R905 CN902 Feedback Circuit Control IC ON/OFF Output MOSFET Transformer Circuit Lamp Over Voltage Feedback ON/OFF Circuit Control Control IC...
-
Page 21: Schematic Diagram
HUDSON 9 6. Schematic 6.1 Main Board 715G3108 1 POWER field CN701 A1 C701 B2 C702 C1 C703 A2 5VCC C704 B5 CN701 C705 B5 C706 C4 SM340A 5VCC C707 C5 D701 C708 C4 R701 C709 C4 BKLT-VBRI C710 A2 BKLT-EN C711 B4 R710... - Page 22 HUDSON 9 FB102 INPUT CN101 A2 VGA_B+ R105 100R 1/16W 5% C102 CN102 B1 DSUB_B+ BEAD 0.047uF C101 B3 H_Sync R102 0R05 1/10W 5% R103 1K 1/16W 5% DSUB_H C102 A5 V_Sync R104 1K 1/16W 5% R108 C105 DSUB_V C103 A2 5pF/50V E5VCC 75R 1/16W 5%...
- Page 23 HUDSON 9 SCALER FB401 FB406 FB403 AVCC PVCC VCC1.8 CVDD 300OHM 300OHM 300OHM DVDD C440 C403 C404 C448 C406 C407 C442 C401 R414 U402 1uF 16V 0.1uF/16V 0.1uF/16V 0.1uF/16V 0.1uF/16V 0.1uF/16V 0.1uF/16V 0.22uF16V 10K 1/16W 5% SPI_CE VCC3.3 SPI_SO HOLD# R409 100R 1/16W 5% SPI_CK...
- Page 24 HUDSON 9 OUTPUT CN301 TCLK1M TCLK1P CN301 C301 C302 C303 C304 C305 C306 Q301 Q302 TCLK2M TCLK2P R301 R303 R303 C302 R304 R305 10K 1/16W 5% 0.1uF/16V R306 R304 R307 PANEL_VCC Q301 47K 1/16W 5% AO3401 C303 R307 47K 1/16W 5% R301 C301 CONN...
-
Page 25: Power Board
HUDSON9 HUDSON9 6 2 Power Board 715G2986 1 2 BD901 A1 POWER CN901 D1 L904 CN902 C3 100 OHM 1/4W R918 C900 C901 100 OHM 1/4W R919 Coil R946 C902 +12V C912 ZD902 C903 BD901 0.001uF 150OHM2W C905 KBP208G 100 OHM 1/4W R920 RLZ13B C906... - Page 26 HUDSON 9 12K 1/8W INVERTER R812 C813 100pF C819 47pF/3KV NC CN801 CONN Q805 +12V 11K OHM 1/8W ON/OFF ZD802 R813 RLZ5.6B ZD803 C814 R817 RLZ5.6B PT801 C820 100pF 1K 1/8W C823 AM4502C-T1-PF POWER X'FMR R803 R804 0.1uF CN802 47pF/3KV NC 5K1 1/8W 5% 5K1 1/8W 5% CONN...
-
Page 27: Key Board
HUDSON 9 6.3 Key Board 715G3111 1 CN402 CN403 NC/CONN POWER KEY1 KEY2 LED_LF CONN C101 C102 C103 C104 1UF10V 1UF10V NC/1UF10V 1UF10V CN402 CN403 C101 KEY1 KEY2 POWER C102 C103 C104 LED101 C2 R101 R102 R103 R107 R108 SW101 R108 R107 R103... -
Page 28: Pcb Layout
HUDSON 9 7. PCB Layout 7.1 Main Board C101 C448 R114 R425 C102 C701 R115 R429 715G3108 1 C103 C702 R116 R431 C104 C703 R117 R436 C105 C704 R118 R437 C106 C705 R119 R438 C107 C706 R120 R439 C108 C707 R121 R440 C109... - Page 29 HUDSON 9...
-
Page 30: Power Board
HUDSON 9 7.2 Power Board 715G2986 I 2 BD901 C4 IC904 B3 C604 J601 C615 J602 C616 J603 C804 J603 C819 J604 C820 J605 C821 J606 C822 J607 C900 J801 C901 J802 C902 J803 C903 J804 C905 J805 C906 J806 C908 J807 C913... - Page 31 HUDSON 9 C601 D804 R819 C602 D805 R820 C603 D806 R821 C606 D807 R822 C608 D902 R901 C609 D903 R902 C610 FB902 B4 R904 C611 IC801 A2 R905 C612 IC901 C4 R906 C613 Q608 R909 C801 Q802 R910 C802 Q805 R912 C803 Q806...
-
Page 32: Key Board
HUDSON 9 7.3 Key Board 715G3111 1... -
Page 33: Wiring Diagram
HUDSON 9 8. Wiring Diagram Panel FFC Cable 30 Pin CN301 CN902 CN802 CN801 Power Board Main Board CN701 NT68667FG U401 CN803 CN402 AC IN CN804 CN102 CN101 24Pin CN901 D-SUB 4 Pin 4 Pin Key Board Key Board CN112 CN111... -
Page 34: Scalar Board Overview
HUDSON 9 9. Scalar Board Overview DC-DC Converters EEPROM Flash ROM NOVATEK chip D-SUB D-SUB... -
Page 35: Mechanical Instructions
HUDSON 9 10. Mechanical Instructions 1. Back View as Fig1 Place the monitor face down on a smooth surface as Fig 1. Be careful to avoid scratch and injury during the uninstallation. Fig1 2. Remove the hinge as Fig2. Remove the four screws remarked in red to remove the stand-base ass'y as Fig2. Fig2... - Page 36 HUDSON 9 3. Remove bezel and rear cover as Fig3~ Fig4. Fig3 Fig4...
- Page 37 HUDSON 9 4. Remove main frame cover as Fig5~Fig7. a. Remove the two screws marked in red as Fig5. b. Disconnect the four connector marked in blue as Fig5. c. Remove the four screws marked in red as Fig6. Fig5 Fig6...
- Page 38 HUDSON 9 5. Remove power board and main board as Fig7. a. Remove the three screws marked in red as Fig7. b. Disconnect the connector marked in blue as Fig7. Fig7...
-
Page 39: Trouble Shooting
HUDSON 9 11. Trouble Shooting This page deals with problems that can be corrected by a user. If the problem still persists after you have tried these solutions, contact Philips customer service representative. - Page 40 HUDSON 9...
-
Page 41: Repair Flow Chart
HUDSON 9 12. Repair Flow Chart 12.1 Main Board (1). No Power No power Press power key and look if the picture is normal Please reinsert and make sure the AC of 100-240 is normal Reinsert or check the Adapter/Inverter section Measure U703 PIN2=3.3V Check U703, C706 and C707 X401 oscillate waveforms... - Page 42 HUDSON 9 (2). No Picture No picture The button if X401 oscillate Replace X401 under control waveform is normal Check reset circuit of Check Correspondent component U401 is normal Measure U703 PIN2=3.3V Replace U401 Check U703, C706 and C707 X401 oscillate waveform is normal Replace X401 Check HS VS from...
- Page 43 HUDSON 9 (3). White screen White screen Measure Q302 base X401 oscillate waveform is normal is low level? Replace X401 Check Q302, Q301 is broken or CN301 solder? Check reset circuit of U401 is normal Check Correspondent Check Correspondent component. component.
- Page 44 HUDSON 9 11.2. Power/Inverter Board (1) No power Check CN902 Pin7 = 12V Check AC line volt 110V or 220V Check AC input Check the voltage of C905 (+) Check bridge rectified circuit and F901 circuit Check start voltage for the pin8 of IC901 Check R904, R905 and Change IC901 Check the auxiliary voltage is bigger than 11V and smaller than 25V...
- Page 45 HUDSON 9 (2) W / LED, No Backlight Check CN902 Pin7 = 12V Check adapter or MB Check ON/OFF signal Check Main Board Check IC801 PIN11=5V Check R802 Check IC801 PIN8, 9 or PIN6, 10 have the output of square Change IC801 Check Q805 and Q806 PIN5, 6, 7, 8 have the output of square wave at short time.
- Page 46 HUDSON 9 12.3 Key Board OSD is unstable or not working Is Key Pad Board connecting normally? Connect Key Pad Board Replace Button Switch Is Button Switch normally? Replace Key Pad Board Is Key Pad Board normally? Check Main Board...
-
Page 47: Isp Instruction
HUDSON 9 13. ISP Instruction 1. When do the part, need the tools as follow: a. An i486 (or above) personal computer or compatible. b. Microsoft operation system Windows 95/98/2000/XP. c. “EasyUSB WriterV4.1” program d. Software ISP SN Alignment kits The kit contents: a. - Page 48 HUDSON 9...
- Page 49 HUDSON 9 3. Connect the ISP board as follow: Connect to Connect to the the PC LPT Philips 190SW9...
- Page 50 HUDSON 9 4. The process of ISP write is as follows. a. Double-click ，running the program as follows:...
- Page 51 HUDSON 9 b. Click and the program runs as follows: c. Select sure, the picture as below:...
- Page 52 HUDSON 9 d. Click icon and the program runs as follows: e. Click icon, search the program” Philips_190SW9_NT68667_CMO_M190A1-L0A_V1.00.hex”, and click open:...
- Page 53 HUDSON 9 f. Click icon. If it burns successfully, it will show as the follow picture:...
-
Page 54: Ddc Instruction
HUDSON 9 14. DDC Instruction General DDC Data Re-programming In case the main EEPROM with Software DDC which store all factory settings were replaced because a defect repaired monitor’ the serial numbers have to be re-programmed. It is advised to re- soldered the main EEPROM with Software DDC from the old board onto the new board if circuit board have been replaced, in this case the DDC data does not need to be re-programmed. - Page 55 HUDSON 9...
- Page 56 HUDSON 9...
- Page 57 HUDSON 9 Click to complete the installation. 3. Connect the DDC board as follow: Connect to the PC LPT When you write analog EDID, Connect this port to the Philips 190SW9’s VGA port 12V Input...
- Page 58 HUDSON 9 4. Take analog DDC write for example, as follow a. Double-click ，appear as follow Figs：...
- Page 59 HUDSON 9 b. Click c. Key 14 numbers in the Serial Number blank, then click “OK”. Now analog DDC Write completes, as follow. Note: The way of digital DDC write is the same as analog DDC write.
- Page 60 HUDSON 9 190SW9 EDID Analog 128 bytes EDID Data (Hex): 00 01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 00 FF FF FF FF FF FF 00 41 0C 6D 08 B8 B6 01 00 16: 17 0C 01 03 0E 28 19 78 2A A1 50 A3 57 4C 9D 25 32: 11 50 54 BF EE 80 71 4F 95 00 95 0F 01 01 01 01 48: 01 01 01 01 01 01 9A 29 A0 D0 51 84 22 30 50 98...
- Page 61 Detailed Timing: 1440x900 @ 60Hz. <-x-Detailed Timing Descriptions-x-> <---Detailed Timing Descriptions---> Detailed Timing: FF (Monitor SN) '132122311231' Detailed Timing: FC (Monitor Name) 'Philips 190SW' Detailed Timing: FD (Monitor limits) Min. V. rate: 55Hz Max. V. rate: 76Hz Min. H. rate: 30KHz Max.
- Page 62 HUDSON 9 Digital 128 bytes EDID Data (Hex): 00 01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 00 FF FF FF FF FF FF 00 41 0C 6D 08 CC 0D 05 00 16: 0C 0D 01 03 80 28 19 78 2A A1 50 A3 57 4C 9D 25 32: 11 50 54 BF EE 80 71 4F 95 00 95 0F 01 01 01 01 48: 01 01 01 01 01 01 9A 29 A0 D0 51 84 22 30 50 98...
- Page 63 Detailed Timing: 1440x900 @ 60Hz. <-x-Detailed Timing Descriptions-x-> <---Detailed Timing Descriptions---> Detailed Timing: FF (Monitor SN) '213231233121' Detailed Timing: FC (Monitor Name) 'Philips 190SW' Detailed Timing: FD (Monitor limits) Min. V. rate: 55Hz Max. V. rate: 76Hz Min. H. rate: 30KHz Max.
-
Page 64: White Balance, Luminance Adjustment
HUDSON 9 15. White Balance, Luminance Adjustment 1. Apparatuses and program: analyzer CA-210, PC, tool, FGA adjustment program (PHILIPS 190SW9.DDCI), Pattern generator. 2. Equipment installation: a. Connect analyzer CA-210 to PC by USB connector, install drive program CA-SDK Ver4.00 for CA-210 and restart PC after finish installing. - Page 65 HUDSON 9 4. Color Temp confirmation Connect the signal to the monitor, the monitor display white-picture, use CA-210 to measure the Color Temp of the screen center and select the OSD to make sure whether the Color Temps accord with the SPEC.
-
Page 66: Monitor Exploded View
HUDSON 9 16. Monitor Exploded View... -
Page 67: Recommended & Spare Parts List
STAND-BASE ASS'Y FQ304 996510018146 089G179E30NA08 FFC CABLE FQ205 996510018152 705GQ8CS023 CUSHION ASSY FQ202 996510018153 Q44G9129813 1A 19 LCD PHILIPS CTN E08902 996510018154 089G 728HAA DB D-SUB CABLE E08901 996500037340 089G410A18N IS POWER CORD 32E1818020 IC903 996500036055 056G 139 3A IC PC123Y22FZ0F... - Page 68 996510018162 705GQ856004 MCU ASS'Y U402 996510018313 705GQ856013 MCU ASS'Y Service Kit Description Part No. Philips 12NC Remark DDC KIT 715L2005C2 9965 000 43197 FOR ALL MODEL OSD SN KIT 715GT033 C 9965 000 43252 FOR ALL MODEL FOR ALL HUDSON 7...
-
Page 69: Different Part List
PCM Codes Description E08901 089G402A18N IS POWER CORD/32-D022438 996500037340 089G410A18N IS POWER CORD 32E1818020 FQ202 Q44G9129813 2A 19 LCD PHILIPS CARTON 996510018153 Q44G9129813 1A 19 LCD PHILIPS CTN Diversity of 190SW9FB/75 compared with 190SWFB/69 190SW9FB/75 190SWFB/69 Location Philips 12NC PCM Codes... - Page 70 A34G0815ADTA1B0100 BEZEL L19W-8PHA1 FQ105 A34G0816ADT 3B0100 REAR COVER 19W 996510018151 A34G0816ADT 1B0100 REAR COVER 19W FQ202 Q44G9129813 3A 19 LCD PHILIPS CARTON 996510018153 Q44G9129813 1A 19 LCD PHILIPS CTN FQ002 CBPC8MNDP1QP SCALER BOARD ASSY 996510018160 CBPC8MNDPHQP SCALER BOARD ASSY FQ002...
-
Page 71: General Product Specification
PROE FILES REQUIRED 5.3 LOCATION OF PHILIPS LOGO PER PHILIPS MAKE-UP SHEET 5.4 GAP BETWEEN PANEL AND FRONT BEZEL <1.0MM 5.5 LOCATION OF CONTROL ICONS- PER PHILIPS GRAPHIC SHEET 5.6 COLOR FOR RESIN/PAINT PER PHILIPS MAKE-UP SHEET 5.7 RESINS 5.8 IF RAINT IS USED 5.9 PLASITIC MOLD TOOLING... - Page 72 6.4 DISPLAY DISTURBANCES TO EXTERNAL ENVIRONMENT 7. RELIABILITY 7.1 MEAN TIME BETWEEN FAILURES 8. QUALITY ASSURANCE REQUIREMENTS 8.1 ACCEPTANCE TEST 9. PHILIPS’ FLAT PANEL MONITORS PIXEL DEFECT POLICY 10. REGULATORY COMPLIANCE 10.1 WORLDWIDE REGULATORY 10.2 EMC REQUIREMENTS 10.3 ROHS 10.4 WEEE...
-
Page 73: Foreword
30 minutes that brightness stability is optimal, and follow strictly after panel specification. 2. PRODUCT PROFILE This display monitor unit is a color display monitor enclosed in PHILIPS styling cabinet which has an integrated tilt base. 2.1 LCD Type NR. -
Page 74: Interface
HUDSON 9 3.2 Interface 3.2.1 D-Sub Cable Length : 1.5 M +/- 50 mm Fix with monitor when packing, with transplant pin protective cover. Connector type : D-Sub male with DDC2B pin assignments. Blue connector thumb-operated jack screws Pin assignments: Pin No. - Page 75 HUDSON 9 3.2.2 DVI Cable The input signals are applied to the display through DVI-D cable. Length : 1.5 M +/- 50 mm Connector type : DVI-D male with DDC-2B pin assignments White connector thumb-operated jackscrews Pin Assignment: Pin No. Description T.M.D.S.
-
Page 76: Timing Requirement
HUDSON 9 3.2.3 Software control functions via OSD /control adjustable functions: Please refer to following Hudson8 OSD definitions Reset - No: Exit Yes: Auto adjustment for displaying timing mode and recall factory preset OSD Tree Level 1 Level 2 Level 3 Default Picture Brightness... - Page 77 HUDSON 9 3.3.2 Factory preset modes Factory modes and preset modes are defined in the enclosed timing table file. H.Freq. (KHz) Mode Resolution V.Freq. (Hz) BW(MHz) 31.469 IBM VGA 10H 640x350 70.086 31.469 IBM VGA 3H 720x400 70.087 31.469 IBM VGA 12H 640x480 59.94 MACINTOSH...
-
Page 78: Horizontal Scanning
Use DDC-2B, DDC/CI, and EDID V1.3 3.10 DDC/CI SUPPORT In accordance with VESA DDC/CI and MCCS ver.2.0, the monitor should be workable with Philips Smart Manage, Smart Control V6.1, and Protrait Display Tune at least. 3.11 Data for EDID & INF file 3.12 Hot-key definition... -
Page 79: Smart Contrast (Dynamic Contrast Ratio)
HUDSON 9 3.13 Smart contrast (Dynamic contrast ratio) Smart Contrast is a kind of dynamic backlight control. This function changes the panel backlight dynamically according to the frame brightness histogram. At least the minimum contrast ratio has to be 3000:1.Suppliers to input 3.14 Smart response (over drive) Not required for 190SW9 3.15 Smart image 3.15.1 Smart Image OSD outlook... - Page 80 HUDSON 9 3.15.1.6 Linkage between Smart Image OSD and main OSD A. Settings within main OSD have linkage with Smart Image OSD. Brightness Contrast iii. Color Temperature B. Because each preset profiles will define default setting of these 3 parameters. Users can understand what is the value of that in preset profile by open the main OSD.
-
Page 81: Visual Characteristics
HUDSON 9 D. Economy Purpose: Adjust brightness level for reducing power consumptions No optimization by Smart Image. iii. Design: 1. Brightness level set to 70%, a little higher brightness level than laptop PC, fine tune brightness level before DVT exit. 2. -
Page 82: Brightness
HUDSON 9 4.2 Brightness To follow Panel specification.. 4.3 Image size Actual display size: Refer to 2.1 LCD PANEL spec. 4.4 Brightness uniformity Set contrast at 100% and turn the brightness to get average above 300 nits at centre of the screen. Apply the Fig 1;... -
Page 83: Mechanical Characteristics
5.1 Cosmetic - Philips ID 5.2 Mechanical data files - ProE files required 5.3 Location of Philips logo - Per Philips make-up sheet 5.4 Gap between panel and front bezel < 0.8 mm (typ) 5.5 Location of Control icons - Per Philips Graphic sheet 5.6 Color for resin/paint -... -
Page 84: Texture/Glossing Of Housing
HUDSON 9 5.11 Texture/Glossing of housing The texture area and texture no should follow Philips make-up sheet. The exterior surfaces shall have a uniform texture. Philips must approve the mold texturing. Detail document for texture refer to “UN-D249”, “UN-D 600”. -
Page 85: Pallet / Container Loading
HUDSON 9 • Un-packed test 1. Sine vibration (operating) 2. Half sine shock test (non operation) 5.17 Pallet / Container loading (Refer to Philips approved SHT 560) Transportation standards refer to TYE-M0002 and UAW-0309. • Air shipment - • Sea container 20'(pallet/slip sheet) •... -
Page 86: Quality Assurance Requirements
Control II level AQL: 0.4 (major) 1.5 (minor) (Please also refer to annual quality agreement) Customer acceptance criteria: UAW0377/00 9. Philips’ Flat Panel Monitors Pixel Defect Policy Philips’ Flat Panel Monitors Pixel Defect Policy BRIGHT DOT DEFECTS ACCEPTABLE LEVEL MODEL... - Page 87 HUDSON 9 Fig 1: Measurement locations of Brightness Uniformity Fig 2: Cross talk pattern Gray level 46 (64 Gray level) Fig 3: Cross talk Pattern Center at Gray level 0 (Black)
-
Page 88: Regulatory Compliance
HUDSON 9 10. REGULATORY COMPLIANCE 10.1 Worldwide Regulatory International Regulatory Specification COUNTRY DOMAIN SAFETY / EMC / ERGONOMICS / STANDARDS DOCUMENTS IEC60950-1:2001. Group -and national differences of all countries Report INTERNATIONAL listed in CB Bulletin No. 107A and CB certificate European Low Voltage Directives 73/23/EEC and 93/68/EEC Declaration of Conformity European... -
Page 89: Emc Requirements
10.2 EMC Requirements Supplier DVT EMI test result must be submitted prior to DVT samples delivery, and PVT EMI test result must be submitted again prior to PVT samples delivery, which also has to meet Philips' immunity testing specification. 10.3 RoHS Restriction on the use of certain hazardous substances. - Page 90 4. When the HV circuitry is operating properly there is no possibility of an x- tube must be the same type as the original, including suffix letter, or a Philips radiation problem. High voltage should always be kept at the manufacturer's approved type.
